Mounting
The Axis Video Server is supplied with a mounting kit for wall or rack mounting. The
mounting brackets can be positioned for mounting the video server on a vertical surface or in
a rack (4U). Follow the instructions below to attach the brackets to the video server:
Slide the grey frame off the front panel
1
of the video server (no tools needed).
Insert the metal plates in the slots on
2
each side of the video server.
Position and attach the brackets on each
3
side, using the screws provided.
Alternative A
Axis Video Server Installation Guide
Alternative B
