SERVICE MANUAL
Compact Disc Player
Laser
Laser output
Frequency response 2 Hz to 20 kHz ± 0.5 dB
Signal-to-noise ratio More than 100 dB
Dynamic range
Harmonic distortion Less than 0.005%
Channel separation
Output
LINE OUT
DIGITAL OUT
(OPTICAL)
MICROFILM
http://cxema.ru
Semiconductor laser (λ = 780 nm)
Emission duration: continuous
Max 44.6 µW*
* This output is the value measured at a distance of
200 mm from the objective lens surface on the
Optical Pick-up block with 7 mm aperture.
More than 92 dB
More than 95 dB
Jack
Maximum
type
output
level
Phono
2 V
jacks
(at 50 kΩ)
Optical
–18 dBm
output
connector
CDP-XE330
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Pick-up Name
SPECIFICATIONS
General
Power requirements
Power consumption
Dimensions (approx.) 430 × 110 × 290 mm
(w/h/d)
Mass (approx.)
Supplied accessories
Audio cord (2 phono plugs–2 phono plugs) (1)
Remote commander (remote) (1)
R6 (size AA) batteries (2)
Design and specifications are subject to change without notice.
Load
impedance
Over 10 kΩ
Wave length:
660 nm
AEP Model
UK Model
CDP-XE220/XE320
CDM14FL-5BD29C
BU-5BD29C
KSS-213BA/F-NP
220 V – 230 V AC, 50/60 Hz
10W
(17 × 4
× 11
3
/
1
/
in.) incl. projecting parts
8
2
3.1 kg (6 lbs 14 oz)
COMPACT DISC PLAYER

Advertisement

Table of Contents
loading

Summary of Contents for Sony CDP-XE330

  • Page 1 CDP-XE330 SERVICE MANUAL AEP Model UK Model Model Name Using Similar Mechanism CDP-XE220/XE320 CD Mechanism Type CDM14FL-5BD29C Base Unit Name BU-5BD29C Optical Pick-up Name KSS-213BA/F-NP SPECIFICATIONS Compact Disc Player General Laser Semiconductor laser (λ = 780 nm) Power requirements 220 V – 230 V AC, 50/60 Hz...
  • Page 2: Section 4 Test Mode

    SECTION 4 TEST MODE 4-2. ADJ MODE 4-1. AF MODE The following operations are performed in the ADJ mode, which The following checks can be performed in the AF mode, which is is set by connecting the TP3 (JW41 : ADJ) terminal to the Ground set by connecting the TP2 (JW40 : AFADJ) terminal on MAIN board and turning on the power.
  • Page 3 http://cxema.ru...
  • Page 4 http://cxema.ru...
  • Page 5 http://cxema.ru...
  • Page 6 http://cxema.ru...
  • Page 7 • IC103 DIGITAL SIGNAL PROCESSOR (CXD2529Q)(BD board) Pin No. Pin Name Function – +5V power supply – Ground LMUT Lch “L” detection flog RMUT Rch “L” detection flog ACDT Test output (Not used) CKOUT Master clock divider output (Not used) SQCK Clock input for SQSO read out SQSO...
  • Page 8 Pin No. Pin Name Function AVSS – Analog ground CLTV Control voltage input for VCO AVDD – Analog power supply EFM signal input BIAS Asymmetry circuit constant current input ASYI Asymmetry comparate voltage input ASYO EFM full swing output (“L” =VSS, “H” =VDD) ASYE Asymmetry circuit ON/OFF (“L”=OFF, “H”=ON) WDCK...
  • Page 9 Pin Name Pin No. Function — – Not used AVSS – Analog ground AVDD – Analog power supply AOUT1 Lch analog output AIN1 Lch opamp input LOUT1 Lch line output AVSS – Analog ground XVDD – Master clock power supply XTAI X’tal oscillator circuit input XTAO...
  • Page 10 • IC501 SYSTEM CONTROL ( CXP82616-034Q)(DISPLAY board) Pin No. Pin Name Function – Ground RMIN Remote control signal input – Ground 4 to 7 — – Not used Serial clock output SENSE Sense signal input from IC103 (CXD2529Q) DATA Serial data output SQCK Sub Q clock output SQSO...
  • Page 11: Ic Block Diagrams

    6-9. IC BLOCK DIAGRAMS • CD section IC101 CXA1992AR – RF SUMMING PD2 IV PD1 IV FE_BIAS SENS2 ↓ SENS1 – LASER POWER CONTROL F IV AMP FE AMP – C. OUT E IV AMP – DFCT XRST – LEVEL S DATA FO.
  • Page 12 IC102 BA5941FP – + – + – LEVEL SHIFT LEVEL SHIFT LEVEL SHIFT – LEVEL SHIFT – + – + – – – MUTE IC103 CXD2529Q 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51 LRCK WDCK AVSS...
  • Page 13 • MAIN section IC401 LB1641 DRIVER INPUT LOGIC BLOCK OUT1 OUT2 IC701 LA5601 V REF VOMUTE RESET ON/OFF — 31 — http://cxema.ru...
  • Page 14: Section 7 Exploded Views

    4-214-165-01 PANEL, LOADING 4-210-291-01 SCREW (CASE 3 TP2) 4-996-687-51 KNOB(AMS) * 14 4-980-777-01 CASE (409526) ! 15 4-996-698-01 EMBLEM, SONY 1-575-651-21 CORD, POWER 3-354-981-11 SPRING (SUS), RING X-4947-207-1 FOOT ASSY (F50150S) 4-977-593-11 RING(DIA. 50), ORNAMENTAL * 17 4-954-051-51 HOLDER, PC BOARD...
  • Page 15: Cd Mechanism Section (Cdm14Fl-5Bd29C)

    7-2. CD MECHANISM SECTION (CDM14FL-5BD29C) NOTE: There are two types of MAGNET ASSY. Confirm the shape before replacing the parts. BU-5BD29C not supplied M151 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-452-925-21 MAGNET ASSY 1-645-721-11 LOADING BOARD 4-933-134-01 SCREW (+PTPWH M2.6 ×...
  • Page 16: Base Unit Section (Bu-5Bd29C)

    7-3. BASE UNIT SECTION (BU-5BD29C) M102 M101 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks ! 151 8-848-379-31 OPTICAL PICK-UP KSS-213BA/F-NP 4-917-564-01 GEAR (P), FLATNESS 1-769-069-11 WIRE (FLAT TYPE) (16 CORE) * 157 A-4724-297-A BD BOARD, COMPLETE 3-713-786-51 SCREW +P 2 ×...
  • Page 17: Section 8 Electrical Parts List

    SECTION 8 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • CAPACITORS: • SEMICONDUCTORS parts list may be different from the parts uF: µF In each case, u: µ, for example: specified in the diagrams or the components •...
  • Page 18 DISPLAY Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R122 1-216-097-91 RES,CHIP 100K 1/10W A-4724-499-A DISPLAY BOARD, COMPLETE R123 1-216-099-00 METAL CHIP 120K 1/10W *********************** R124 1-216-091-00 METAL CHIP 1/10W R125 1-216-069-00 METAL CHIP 6.8K 1/10W 4-929-709-31 GUIDE(FL TUBE) R126 1-216-063-91 RES,CHIP...
  • Page 19: Key Loading

    LOADING MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-672-314-11 KEY BOARD C713 1-164-159-11 CERAMIC 0.1uF C714 1-164-159-11 CERAMIC 0.1uF ********* C715 1-126-933-11 ELECT 100uF < RESISTOR > C716 1-162-290-31 CERAMIC 470PF C717 1-162-290-31 CERAMIC 470PF R504 1-249-415-11 CARBON...
  • Page 20 CDP-XE330 MAIN POWER SW Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks Q354 8-729-029-56 TRANSISTOR DTA144ESA 1-672-315-11 POWER SW BOARD Q401 8-729-041-38 TRANSISTOR 2SB1241TV2Q *************** Q402 8-729-119-76 TRANSISTOR 2SA1175-HFE Q701 8-729-029-56 TRANSISTOR DTA144ESA < CAPACITOR >...
