Installing the power connector

1
Insert the power connector into the slot on the computer.
2
Secure the power connector to the computer by using 1 (M2x3) screw.
3
Install the:
a
System board
b
Coin cell battery
c
System fan
d
WLAN Card
e
Memory module
f
Heat sink
g
Hard drive assembly
h
Base cover
i
Keyboard
j
Optical drive
k
Battery
4
Follow the procedure in

Display assembly

Removing the display assembly

1
Follow the procedure in
2
Remove the:
a
Battery
b
Optical drive
c
Keyboard
d
Base cover
e
Hard drive assembly
f
WLAN card
3
To remove the display assembly:
a
Unroute the WLAN cable [1].
b Peel white adhesive tape [2].
c
Lift the locking tab [3].
d Disconnect the eDP cable [4].
38
Removing and installing components
After working inside your
computer.
Before working inside your
computer.
