Product Overview; Front View; Control Panel - Currys Essentials CFSEWH17 Instruction Manual

Product Overview

Front View

1
2
3
6
4
5
6

Control Panel

3
1. Thermostat lamp
2. Oven/hob active lamp
3. Front left hot plate control
4. Rear left hot plate control
* All images are for indication only; please refer to your individual unit for actual item.
8
1
4 5
2
6 7
5. Temperature control
6. Oven function selector
7. Rear right hot plate control
8. Front right hot plate control
1. Hot plates
2. Control panel
3. Oven shelf
4. Front flap
5. Oven door
6. Levelling feet
8
