Adjusting The Feet; Moving The Cooker; Stability Bracket - Currys Essentials CFSEWH17 Instruction Manual

Adjusting the Feet

Your oven has 2 adjustable feet at the front and 2 at the back. When the oven is placed where it will be used,
check if the oven is level. If it is not level, you can adjust the feet by turning the feet if required. It is possible to raise
the appliance a maximum of 10 mm using the feet. DO NOT move the appliance by dragging; lift it into place.
Using the fitted adjustable feet is MANDATORY. For safety reasons
and to ensure adequate ventilation, the cooker chassis MUST NOT
sit directly on the floor, a plinth, or other support surface.
1. Open the front flap to access the adjustable feet.
2. Your cooker has 4 adjustable feet, 2 at the front and
2 at the rear of the cooker.
3. Use a flat blade screwdriver to adjust the feet. Turn clockwise
to raise the cooker. Turn anti-clockwise to lower the cooker.
4. Close the flap once level.

Moving the Cooker

• Two people must always raise the cooker, as shown, to prevent
damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the floor.

Stability Bracket

The supplied stability device or a recognized cooker stability device must be fitted to the back of the cooker as
shown.
1. Adjust the feet to make sure
the appliance is level before
fitting the stability device.
2. Screw the chain to the back of
the cooker as shown above.
3. Screw the eyelet into the wall at a height of 750mm from
the floor level.
4. Clip the chain onto the eyelet.
* All images are for indication only; please refer to your individual unit for actual item.
