- Page 1 | sales@scintex.com.au Model: SPS240VADEF & SPS240VADEFA 240V AdBlue Transfer Pump Stations User’s Manual 1 OF 6...
- Page 2 MOTOR: Asynchronous motor, single-phase, 2 pole, closed type (protection class IP55 in conformance with EN 60034-5-86 regulations) self-ventilated. B. TECHNICAL DATA B1. Configuration Item No. Pump model Voltage Suction Hose Delivery Hose Nozzle Flow Meter SPS240VADEF SAP240V25L 240V 1.5M Manual SPS240VADEFA SAP240V25L 240V 1.5M Auto C. OPERATING CONDITIONS C1.
- Page 3 C4. FLUIDS PERMITTED PERMITTED • Chemical products: Urea, weak acid & weak alkaline fluid etc. • Water D. MOVING AND TRANSPORT Given the limited weight and size of the pumps (see overall dimensions), moving the pumps does not require the use of lifting devices. E.
- Page 4 Check all the connections after the initial installation and on a daily basis after that. Tighten the connections, if necessary. F. DAILY USE a. If using flexible tubing, attach the ends of the tubing to the tanks. In the absence of an appropriate slot, solidly grasp the delivery tube before beginning dispensing.
- Page 5 Leakage from the pump body Diaphragm damaged Check and replace the diaphragm H. MAINTENANCE All models are designed and constructed to require a minimum of maintenance. In any case always bear in mind the following basic recommendations for a good functioning of the pump: On a weekly basis, check that the tubing joints have not loosened, to avoid any leakage.
- Page 6 Description Description Crash gasket Clip Bracket Bolt Hose clamp Nozzle Suction hose 1.5m Nozzle holder Elbow Electric pump O-ring O-ring Flow meter Hose tail Hose tail Delivery hose 6.5m Lock nut L.DIMENSIONAL DATA 6 OF 6...
