Dynojet Power Commander V Installation Instructions Manual page 5

FIG.G
FIG.H
FIG.I
I16-017 www.powercommander.com
14 Plug the set of RED, 2-pin connectors of the PCV wiring harness in-line with
15 Locate the front ignition coil on the left hand side of the bike above the front
BLU/YEL
16 Unplug the BLUE/YELLOW wire from the coil.
17 Plug the set of GREEN colored wires of the PCV in-line with the BLUE/
the bike's Crank Position Sensor connectors (Fig. G).
cylinder head (Fig. H).
YELLOW wire and the coil.
2009-2013 Honda VT750 PCV-F/I - 5
