Tool Setup Initial Setup Basic Tool Operation • • Regulator Lubricator Air Filter Air Inlet Coupler (Socket) Air Hose Air Fitting Note: Air Hose and fittings not included with tool Figure 3: Note: WARNING!
Page 13
Mandrel Installation (with POP NUT™ Mandrel Release, DPN277-179) 1. Disconnect the Air Supply Figure 4: Mandrel Installation (without POP NUT™ Mandrel Release, DPN277-179) 1. Disconnect the Air Supply Note: Figure 5: Nosepiece Installation 1. Disconnect the Air Supply Mandrel &...
Basic Tool Operation Before setting POP NUTs™ with this tool, refer to the Safety Instructions and Tool Setup sections of this manual to ensure safe and reliable tool operation. Mandrel and Nosepiece Requirements Figure 6: Open End POP NUTs™ Closed End POP NUTs™...
Page 16
Loading the POP NUT™ onto the tool Not OK Figure 9: Installing the POP NUT™ into the work piece Figure 10: Note: • •...
Page 17
Not OK Not OK Figure 11: *Disengaging the tool from the insert WARNING! DO NOT To disengage the tool from the insert and application: To disengage the tool from the insert and work piece if the Mandrel is stuck: Figure 12:...
Setting Force Adjustment • Setting Force Valve Spring Selection • • • SPH, SFH, APH, AFH, SPS, SFS, APS, AFS & SRH Series Table 8: Thread Size Stroke (S ) Formula SPH625 Workpiece thickness value last digits number − − −...
Page 19
Figure 13: IF… THEN… Adjustment of Setting Force • • Adjustment of Setting Force DESIRED EFFECT ACTION Figure 14:...
Page 20
Note: • • Multiple work piece thicknesses WARNING!
Page 28
