- Page 1 User's Manual ETHERNET PAGING MICROPHONE Model: LDAMCA1NS01/LDAMCA1TN...
-
Page 3: Table Of Contents
Index 1. TECHNICAL DESCRIPTION......................1 1.1 Features............................1 2. CONTROLS.............................2 3. CONNECTIONS..........................3 4. TECHNICAL SPECIFICATIONS....................4 Illustration Index Illustration 1: Controls..........................2 Illustration 2: Connections........................3 Chart Index Chart 1: Connections..........................3 Chart 2: Local power connector piout....................4 Chart 3: Technical Specifications......................4... -
Page 4: Technical Description
The MCA-1N includes as well a high quality microphone capsule. It can be controlled and supervised through an Ethernet network with the LDA Software SIME. It features functions such as “call-all” button, busy line signal, permission to speak granted and a display to show the state of the microphone and the system. -
Page 5: Controls
Busy Line: It will turn red if the areas are busy by another MCA with higher priority. Talk Button: Push to talk. If the conceded word indicator turn green, you can talk. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805... -
Page 6: Connections
• MAN: Contact relay for emergency system (0V). • GND: Ground Reference (0V). • A +: positive balanced audio output. • A-: negative balanced audio output. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805... -
Page 7: Technical Specifications
Dynamic with moving coil. Dimensions without flexible lamo 131 x 60 x 173 mm (WxHxL) Flexible lamp long 250 mm Consumption 2,5W Chart 3: Technical Specifications LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805... - Page 8 LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
