User's Manual
Multizone Paging Station
Model: LDA MPS-8Z S02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPS-8Z S02 and is the answer not in the manual?

Questions and answers

Related Manuals for LDA MPS-8Z S02

Summary of Contents for LDA MPS-8Z S02

  • Page 1 User's Manual Multizone Paging Station Model: LDA MPS-8Z S02...

  • Page 3: Table Of Contents

    Index 1 SAFETY INSTRUCTIONS......................1 2 INTRODUCTION..........................1 3 DESCRIPTION..........................1 3.1 INDICATORS..........................1 3.1.1 SYSTEM CONDITION INDICATORS..................... 2 3.1.2 CALL CHANNEL CONDITION INDICATORS................. 2 3.1.3 SELECTION INDICATORS......................2 3.2 CONTROLS........................... 2 3.2.1 ZONE MEMORY CONTROLS......................3 3.2.2 TALK..............................3 3.2.3 MEMORY............................3 3.2.4 EVENTS............................
  • Page 5 Illustrations Illustration 1: Front indicators....................1 Illustration 2: Controls......................2 Illustration 3: External microphone input................4 Illustración 4: ACSI Bus Input....................5 Illustration 5: USB Port......................5 Illustration 6: Devices connection in a Public Address System..........8 Tables Table 1: External microphone input..................5 Table 2: ACSI Bus Connection....................5 Table 3: Peripheral power supply...................5 Table 4: Expansion Ports.......................
  • Page 6 User's manual: MPS 8Z LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 7: Safety Instructions

    Manual . e) The equipment dropped and it is damaged. f) The equipment has obvious sign of breakage 15. Disconnect the audio inputs and outputs while making connections. Make sure to use the proper cables to make the connections. www.lda-audiotech.com...
  • Page 8 User's manual: MPS 8Z LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 9: Introduction

    8. System fault indicator 9. Link system indicator 10. Zone memory selection indicator 11. Conceded word indicator 12. Busy bus indicator 13. 8 zone memory indicators 14. Keyboard lock 15. Zone memories shortlist memory 16. DSA ( Dynamic Sound Adjust) www.lda-audiotech.com...

  • Page 10: Indicators

    Red color. 3.1.3 SELECTION INDICATORS Selection indicators show those selection memories that have been pressed. Green color. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 11: Controls

    3.2.6 RECALL The "RECALL" button is located in the second position from the right, in the upper part of the keyboard. It allows to repeat the last voice warning through the zone memories selected. www.lda-audiotech.com...

  • Page 12: All/Clear

    ACSI bus. If the selector is in the 24V position, the MPS 8Z will be supplied exclusively from the ACSI bus. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 13: Inputs And Outputs

    Both connections are identical and interconnected. The ACSI bus supplies remote power to the equipment, see 3.2.10. The connection is made by UTP network cable, T568B standard. The maximum connection distance for the entire bus is 1000m (3280ft). Illustración 5: ACSI Bus Input www.lda-audiotech.com...

  • Page 14: Peripheral Supply Input

    The equipment has two ports for connecting additional keyboards, one on each side of the unit. Only one of the ports can be used simultaneously. Mark Description Typo Signals Activation Expansion port Table 4: Expansion Ports LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 15: Operation Description

    The equipment allows to record zone memory shortlists for user's comfort. To select a group, push the "MEM" control and then one of the set groups assigned to one of the selection zone controls. The group of zone memories will remain selected and their selection indicators will light up. www.lda-audiotech.com...

  • Page 16: Recording Zone Memory Group

    ACSI, through its connection to the bus. If this is the case keep the power supply for later use. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 17: Mps 8Z Configuration

    The microphone desk MPS 8Z allows to configurate various operating parameters. To access the configuration of the equipment, proceed as follows: • Ensure that the equipment has not got conceded word. The "CW" indicator will be off. • Hold the "CANCEL" key and the "EVENT" button for 3 seconds. www.lda-audiotech.com...

  • Page 18: Configuration. Talk

    To confirm the new configuration press "TALK"; to cancel press "CANCEL" LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 19: Configuration. Output Volume

    This may take a few minutes depending on the device and the system. During this time the device will not be operational. NOTE: The firmware update is only allowed for devices version 1.0.1 or later. The version can be checked from the system configuration application. www.lda-audiotech.com...

  • Page 20: Fault Resolution

    (NEO) is connected. In case it is a MPS 8Z in particular, check the volume configured according to section 5.3.6. LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...

  • Page 21: The Voice Warning Does Not Sound

    MPS 8Z. If necessary, reconfigure the address according to 3.2.9 and content of the zones through the application of system configuration and contact the support/repair service. 8 MAINTENANCE INSTRUCTIONS The equipment requires a reduced periodic maintenance. www.lda-audiotech.com...

  • Page 22: Technical Features

    3 special function buttons: Memory, Events and Cancel Automatic recall, all zone memories selection/deselection button 8 zone memory buttons botones de memoria de zona 1 TALK button LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
  • Page 23 1 x Ethernet cable 2m / 6,56ft. 1 x Pop filter Expansion keyboard accesories 1 x expansion port adaptor 2 x 5 contacts male-male 1 x connecting piece to MPS 8Z 4 x countersunk screw (3 x 5 mm) www.lda-audiotech.com...
  • Page 24 User's manual: MPS 8Z Ver. 0.1 LDA Audio Tech - Severo Ochoa Nº 31- 29590 MÁLAGA, ESPAÑA. Tlf: +34 952028805...
