Related Manuals for LDA MPS-8Z
Summary of Contents for LDA MPS-8Z
- Page 1 MPS-8Z connection to an audio system with ZES-22 Installation of a network MPS-8Z microphone to audio systems with SIME software Review: 1 Support Handbook...
- Page 2 (supplied with the equipment). When the selector is in the ON position, the MPS-8Z will be powered from the ACSI bus. In this case, if the local charger is also connected, it will automatically switch to the local charger if the power supply from the ACSI bus is interrupted.
- Page 3 MPS-8Z connection to an audio system with ZES-22 Picture 2: Colour chart for RJ45 type B connections This will be the input connection to the MPS-8Z microphone (ACSI bus). From there, the cable configuration for the connection to the ZES22 is done with the following pinout:...
- Page 4 This functionality is supplemented by the LDA ZES-22 ACSI S01 adapter. As shown in Picture 4: LDA ZES-2 ACSI S01 Adapter, the RJ-45 connector allows direct connection to the MPS-8Z microphone input, as well as powering it; via the local power supply of the adapter itself.
- Page 5 The ACSI bus does not provide remote power to the microphones if the adapter does not have it, so each MPS-8Z microphone must have its own local source. For the different functionalities and microphone configurations, please refer to the user...
