Getting to know your Sensor

Power Switch

Power Switch Power Switch Power Switch

Display Screen

Display Screen
Display Screen Display Screen

Menu Button

Menu Button
Menu Button Menu Button

Navigation Buttons

Navigatio Navigatio Navigatio n Buttons n Buttons n Buttons
This switch turns the Sensor on and off. It is recessed to prevent accidental
switching during travel or use.
Driving screen
Menu screen
Pressing this button toggles Sensor between the driving screen and the
top level function menu, or returns to the previous level from a sub-menu.
Button In the driving screen
Displays previous reading.
This is the screen you'll be seeing 95% of the time
while using the Sensor. It displays radio and battery
status, telemetry data that you select, and your
servo information.
This screen is the gateway to the Sensor's menu
system, which is described in detail later. You can
always go back to the driving screen by just
pressing the menu key.
Moves to next higher menu item.
Moves to next lower menu item.
Decreases selected value.
3
In the function menu
