Nomadio Sensor User Manual page 71

Setting Failsafe Positions
Use the navigation controls to set the failsafe positions as follows:
1. Access the top function menu from the
driving screen.
2. Navigate to the Advanced menu.
3. Navigate to the Failsafe menu.
4. Navigate to Set Failsafes.
5. At the confirmation screen:
Select Yes to capture the servo
•
failsafe settings.
Select No to abandon the
•
operation.
6. Confirm your selection.
7. A 3-second countdown begins on the display screen.
Before the countdown ends, use the Sensor controls to set the servo failsafe positions. (For example, on a nitro
car set steering to centered and throttle to full brake.)
At the end of the countdown, a confirmation message indicates that the servo failsafe positions were stored.
8. To test the failsafe positions, turn off the Sensor and observe the reactions of the connected servos. The
servos should go to the failsafe positions you just set.
menu
or : then
or : then
or
or
OK
65
