Nomadio Sensor User Manual page 4

Driving Screen Quick Reference
Signal Strength
Statistics: Highest
value seen of
current stat.
Statistics: Lowest
value seen of
current stat.
Key Drive Screen Controls
Currently
Displayed Stat
Vehicle Battery
Indicator
(Blinks when low)
Pressing this button toggles Sensor between the driving screen and the top level
function menu, or returns to the previous level from a sub-menu.
Displays the previous statistic.
Displays the next statistic.
Transmitter Battery
Indicator
(Blinks when low)
Current Model
Number
Current Stat
Current Stat
Bar Graph
Graph of Servo
Positions
Value
