WARNING
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or
loss of life.
This appliance MUST NOT be installed in any location where
gasoline or flammable vapors are likely to be present.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your
building.
• Immediately call your gas supplier from a near by phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
CFX-CHX-USER_100161847_2000001379_Rev C
User's Information Manual
402 - 2072
Models:
Save this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COPPER-FIN II 402 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lochinvar COPPER-FIN II 402

Summary of Contents for Lochinvar COPPER-FIN II 402

  • Page 1 CFX-CHX-USER_100161847_2000001379_Rev C User’s Information Manual 402 - 2072 Models: WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. This appliance MUST NOT be installed in any location where gasoline or flammable vapors are likely to be present.

  • Page 2: Table Of Contents

    Contents HAZARD DEFINITIONS ............ 2 3. OPERATING INSTRUCTIONS ........8 PLEASE READ BEFORE PROCEEDING ......3 4. SMART SYSTEM CONTROL MODULE 1. PREVENT COMBUSTION AIR CONTAMINATION..4 Copper-fin II Control Module ..........9 2. MAINTENANCE SCHEDULE ........5 Access Modes ..............10 Maintenance Procedures ...........

  • Page 3: Please Read Before Proceeding

    User’s Information Manual Please read before proceeding This is a gas appliance and should be Improper installation, adjustment, NOTICE WARNING installed by a licensed electrician and/or alteration, service or maintenance can certified gas supplier. Service must be cause injury or property damage. Refer performed by a qualified service installer, to this manual for assistance or additional...

  • Page 4: Prevent Combustion Air Contamination

    User’s Information Manual Prevent combustion air contamination If the boiler combustion air inlet is located WARNING Table 1A Corrosive Contaminants and Sources in any area likely to cause contamination, or if products which would contaminate Products to avoid: the air cannot be removed, you must have the combustion air and vent re-piped Spray cans containing chloro/fluorocarbons and terminated to another location.

  • Page 5: Maintenance Schedule

    User’s Information Manual Maintenance schedule Owner maintenance Service technician (see pages 6 - 7 for detailed instructions) • Check boiler area General: • Address reported problems • Check pressure/temperature • Inspect interior; clean and vacuum if gauge Daily necessary; • Check for leaks (water, gas, flue, condensate) •...

  • Page 6: Maintenance Procedures

    User’s Information Manual Maintenance schedule Maintenance procedures Check vent piping Appliance must be serviced and maintained Visually inspect the flue gas vent piping for any signs of blockage, leakage, or deterioration of the piping. Notify your qualified service technician at once if you find any The appliance must be inspected and started WARNING problems.

  • Page 7: Test Low Water Cutoff (If Installed)

    User’s Information Manual Maintenance schedule (continued) Test low water cutoff (if installed) Read the boiler pressure/temperature gauge to make sure the system is pressurized. Lift the relief valve If the system is equipped with a low water cutoff, test the top lever slightly, allowing water to relieve through low water cutoff periodically during the heating season, the valve and discharge piping.

  • Page 8: Operating Instructions

    User’s Information Manual Operating instructions FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition If you cannot reach your gas supplier, device which automatically lights the burner.

  • Page 9: Smart System Control Module

    User’s Information Manual SMART SYSTEM control module Copper-fin II control module Use the control panel (FIG. 4-1) to set temperatures, operating conditions, and monitor appliance operation. Figure 4-1_Control Panel - Operator Interface • Hold 5 seconds to enter code • 2-Line / 16 character LCD display •...

  • Page 10: Access Modes

    User’s Information Manual SMART SYSTEM control module Access modes Viewable and changeable control parameters User The user can adjust the space heating target temperature Before changing parameters, note the CAUTION and the tank target temperature (if a tank sensor is used) settings so that the unit can be returned to by using the UP and DOWN buttons (FIG.
  • Page 11 User’s Information Manual SMART SYSTEM control module (continued) B: Temperature settings (boiler only) A6: SH Night setback times If parameter A5 is set to anything other than 0°F, the night B6: Manual reset high limit setback feature becomes active. This will require start and The SMART SYSTEM control includes an integrated manual stop times to be programmed for the days that reduced reset high limit (MRHL) feature, based on the outlet temperature.
  • Page 12 User’s Information Manual SMART SYSTEM control module F: Outdoor air reset (boiler only) G: Anti-cycling G3: Ramp delay enable F5: Outdoor air shutdown When the ramp delay on/off parameter is active, the ramp When the outdoor temperature rises above this point, the delay limits the boiler firing rate when a SH cycle has started.

  • Page 13: Status Display Screens

    User’s Information Manual SMART SYSTEM control module (continued) Status display screens Status Display Screens By using the Previous/Next (, ) arrow keys on the SMART SYSTEM display panel, you can navigate through the 11 display screens. Each screen will contain two (2) viewable items. The following is a description of the individual items and what they can display: Screen # Display Shows...
  • Page 14 User’s Information Manual SMART SYSTEM control module Status Display Screens (cont’d) By using the Previous/Next (, ) arrow keys on the SMART SYSTEM display panel, you can navigate through the 11 display screens. Each screen will contain two (2) viewable items. The following is a description of the individual items and what they can display: Screen # Display shows:...
  • Page 15 User’s Information Manual SMART SYSTEM control module (continued) Status Display Screens (cont’d) By using the Previous/Next (, ) arrow keys on the SMART SYSTEM display panel, you can navigate through the 11 display screens. Each screen will contain two (2) viewable items. The following is a description of the individual items and what they can display: Screen Display shows:...

  • Page 16: Revision Notes

    Revision Notes: Revision A (ECO C08226) initial release. Revision B (ECO C11124) reflects the update of ignition timing information on page 13. Revision C (PCP #3000021634 / CN #500011858) reflects an update to the maintenance information on page 5. CFX-CHX-USER_MM #100161847_DIR #2000001379_Rev C 01/18...
