2.1.5 Exchange the green nozzle with a metal nozzle and prepare to install the syringe in the
printer. (See Figure 2.1.5 below) (See Figure 2.1.5.2 below for syringe details)
Important: You should regularly examine your nozzles. If you should damage your nozzles (or you are
unsure of their strength, shape and integrity) do not use them – Replace them.
① Nozzle
Plunger
Additional: The top part of the
Figure 2.1.4
Figure 2.1.5
Figure 2.1.5.2
30ML Mark 15ML Mark
Syringe (with the finger grip) is referred to as the Flange .
Piston O-shape Ring Syringe
