Choc Edge Choc Creator V2.0 Plus User Manual page 14

Choc Edge
Press
ENTER VALUE
specific value using the numerical pad
3.2.12 On the next screen, press the ↑ or ↓ keys until the gap between nozzle and printing
platform is approximately 2mm, which is a suitable starting height when using a 0.8mm
nozzle. If 2mm appears to be too high for your design, try 1.5mm
disc from the tool box can be used as a height guide - The disc is 0.5mm thick, so your nozzle should
be positioned approximately 1.5mm above this disc. If your nozzle touches the disc or is close to it,
your nozzle is too low; Raise the nozzle up by 1mm or more. ]
Once the desired height is set, press Save .
3.2.13 After setting the height, the screen will jump back to the home page automatically.
From here, choose Pre-stored design files , select one of the 12 printing files and press
Print to start the machine printing. (See Figure 3.2.13 below)
to manually key in a
Figure 3.2.11
4 0
Figure 3.2.11.2
. [ Hint: A food-safe metallic
14
