3.2.10 After p essi g Confirm , the screen will jump back to the home page from which you can
choose Adjust Height "ee Figure 3.2.10 below):
3.2.11 On the Adjust Height (of Z-Axis screen, you have two options for lowering the Z-axis.
(See Figure 3.2.11 below)
Option 1:
Option 2:
Note: For Option 2, a value of no more than 40 can be entered at this time.
This is to prevent novice users from lowering the nozzle too close to the
printing platform. Fine tuning to (e.g.) 42 can still be done after the Z-axis
has moved down into the position of 40.
Figure 3.2.10
Continuously press the ↓ key until the Z-axis reaches the value of 40.
From there, you can gently tap the ↓ key to fine tune to (e.g.) 42.
This option may be more suitable for first time users.
P ess the E te Value
(See Figure 3.2.11.2 below)
Enter the value of 40 into the numerical window.
utto o e to e te the u e i al pad s ee .
Adjust the height
of the E-Axis
