SMART FORCE AND TORQUE SENSORS
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7i and is the answer not in the manual?

Questions and answers

Summary of Contents for Mark-10 7i

  • Page 1 SMART FORCE AND TORQUE SENSORS User’s Guide...
  • Page 2: Table Of Contents

    Our technical support and engineering teams are eager to assist you. Before use, each person who is to use Mark-10 sensors and indicators should be fully trained in appropriate operation and safety procedures.
  • Page 3: Overview

    Indicator accuracy must be combined with sensor accuracy to determine the total accuracy of the system. Since sensors may be used with the 7i, 5i or 3i indicators, the accuracy of the indicator being used must be identified and taken into account, as follows:...
  • Page 4: Safety / Proper Usage

    If using an accessory from a supplier other than Mark-10, ensure that it is constructed of suitably rugged materials and components. Similar precautions should be taken when mounting the sensor to a test stand, work bench, or...
  • Page 5: Setup

    User’s Guide Plug & Test Smart Force & Torque Sensors 3 SETUP The Plug & Test connector must be inserted into the receptacle of the indicator with the side marked “Plug & Test Technology” facing up (see Fig. 3.1). When fully inserted, the connector will lock into place with a “click”.
  • Page 6: Series R01 Force Sensors

    [29.2] MR01-5000 3.90 3.00 3/4-16 [99.1] [76.2] MR01-10000 4.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model MR01-50 50 x 0.02 800 x 0.5 25000 x 10 25 x 0.01 250 x 0.1 50 x 0.05 25 x 0.02...
  • Page 7: Series R02 Force Sensors

    MR02-10000 [38.1] [10.9] [1.8] [15.8] [31.8] [6.4] [27.4] 5.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model MR02-100 100 x 0.05 1600 x 1 50000 x 20 50 x 0.02 500 x 0.2 100 x 0.1 50 x 0.05...
  • Page 8: Series R03 Force Sensors

    Model No. MR03-XXX 20 ft [6 m], coiled, retracted MR03-XXX-1 10 in [254 mm], straight 6.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model MR03-025 0.25 x 0.0001 4 x 0.002 100 x 0.05 1 x 0.0005...
  • Page 9: Series R04 Force Sensors

    96% max. (non-condensing) Weight: 0.015 lb [0.007 kg] NOT OK 7.4 Dimensions (in[mm]) 7.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model MR04-025 0.25 x 0.0001 4 x 0.002 100 x 0.05 1 x 0.0005 1000 x 0.5...
  • Page 10: Series R05 Force Sensors

    Operating humidity: 96% max. (non-condensing) Weight: 2 lb [0.9 kg] 8.4 Dimensions (in[mm]) 8.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model MR05-500 500 x 0.2 8000 x 5 250 x 0.1 2500 x 1 2.5 x 0.001...
  • Page 11: Series R06 Force Sensors

    Operating humidity: 96% max. (non-condensing) Weight: 2.5 lb [1.2 kg] 9.4 Dimensions (in[mm]) 9.5 Capacity x Resolution With Model 7i / 5i Indicator With Model 3i Indicator Model No. MR06-200 200 x 0.1 3200 x 2 100 x 0.05 1000 x 0.5 1 x 0.0005...
  • Page 12: Series R50 Torque Sensors

    User’s Guide Plug & Test Smart Force & Torque Sensors 10 SERIES R50 TORQUE SENSORS 10.1 Unpacking and Assembly Carefully remove the sensor from the box. For models MR50-10Z, MR50- 20Z, and MR50-50Z, remove the protective tubing inserted around the chuck.
  • Page 13 Smart Force & Torque Sensors 10.5 Dimensions (in[mm]) Model No. MR50-10Z - MR50-50Z 4.82 [122.4] MR50-12 - MR50-100 5.19 [131.8] 10.6 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model ozFin lbFin lbFft gFcm kgFmm ozFin...
  • Page 14: Series R51 Torque Sensors

    User’s Guide Plug & Test Smart Force & Torque Sensors 11 SERIES R51 TORQUE SENSORS 11.1 Unpacking and Assembly Carefully remove the sensor from the box. Series R51 sensors are available with three interchangeable chuck attachments and bit holder. To attach the chuck or bit holder, align the pin located on the end of the sensor body with the hole located on the attachment (see Fig.
  • Page 15 Plug & Test Smart Force & Torque Sensors For further calibration instructions, refer to the indicator’s user’s guide. 11.5 Dimensions (in[mm]) 11.6 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model ozFin lbFin lbFft gFcm...
  • Page 16: Series R52 Torque Sensors

    Operating temperature: 40ºF – 100ºF [5ºC – 38ºC] Operating humidity: 96% max. (non-condensing) Weight: 1.2 lb [0.5 kg] 12.4 Dimensions (in[mm]) 12.5 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model ozFin lbFin lbFft gFcm kgFmm...
  • Page 17: Series R53 Torque Sensors

    MR53-10Z - MR53-50Z: 2.2 lb [1.0 kg] / MR53-12 - MR53-100: 5.4 lb [2.5 kg] 13.4 Dimensions (in[mm]) MR53-10Z - MR53-50Z: MR53-12 - MR53-100: 13.5 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model ozFin lbFin lbFft...
  • Page 18: Series R54 Torque Sensors

    [24.9] [31.8] 5.00 1.48 2.00 MR54-5000 3/4" [127.0] [37.6] [50.8] 14.5 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model lbFin lbFft kgFmm lbFin kgFmm MR54-20 20 x 0.02 1.5 x 0.002 230 x 0.2 220 x 0.2...
  • Page 19: Series R55 Torque Sensors

    2.01 2.56 MR55-5000 3/4" [22.5] [53.5] [24.0] [19.5] [51.0] [65.0] 15.5 Capacity x Resolution With Model 7i / 5i indicator With Model 3i indicator Model lbFin lbFft kgFmm lbFin kgFmm MR55-20 20 x 0.02 1.5 x 0.002 230 x 0.2 220 x 0.2...
  • Page 20 Plug & Test Smart Force & Torque Sensors Mark-10 Corporation has been an innovator in the force and torque measurement fields since 1979. We strive to achieve 100% customer satisfaction through excellence in product design, manufacturing and customer support. In addition to our standard line of products we can provide modifications and custom designs for OEM applications.
