REGIS EXTENDING CONSOLE DESK ASSEMBLY INSTRUCTIONS
Fittings(to scale)
Ref Dlmenslons
A
CAM BOLT
B
CAM LOCK ( 15x12mm)
C
SCREW (4x40mm)
D
DOWEL (6x30mm)
E
SCREW (3x12mm)
H
SCREW (4x16mm)
M
STICKER- 20mm
N STICKER- 15mm
(Not to scale)
F
REINFORCE SUPPORT
G
FLAT WHEEL
I
NAIL
J
HANDLE
K
RAIL
L
RAIL
CAUTION:There are many small components used in the construction of this product.
Please keep these components away from young children whilst assembling this product.
If you keep the fittings in a bowl during assembly you will be less likely to lose them!
Care instruction: After assembled the rail (K) and rail (L) onto the product, please wipe off
the oil that stain on the product.
10
Qty
22
22
19
23
44
4
4
4
2
2
4
J2
2
2
K1
4
L1
Batch No.: WMI 141143
Page 5 of 12
20 30 40 50 60
J1
K2
L2
70 80 90 100
