Summary of Contents for MasterCraft X23 2017

  • Page 1 2017 BOAT OWNER’S MANUAL 1 0 0 C H E R O K E E C O V E D R . V O N O R E , T N 3 7 8 8 5 4 2 3 . 8 8 4 . 2 2 2 1 M A S T E R C R A F T .

  • Page 2: Table Of Contents

    Preparation Consistent Attention Required Ilmor Marine Engines On your boating choice! MasterCraft is the recognized world leader for inboard boats today and has been for over forty-five Events Requiring Safety knowledge Safety Checks and Services years. The quality, innovation, selection and value of MasterCraft boats are unmatched in the industry.
  • Page 3 SAFETY KNOWLEDGE 2017 OWNERS MANUAL...
  • Page 4 The precautions listed in this Owner’s Manual and on the boat are not all-inclusive. If a pro- cedure, method, tool or part is not specifically recommended by MasterCraft, using it may DANGER indicates an imminently WARNING indicates a potentially Prior to operation, be certain that all passengers are aware of where the safety equipment is stowed, the place you and others in an unsafe situation;...

  • Page 5: Safety Afloat

    (A seating label is affixed in each available. MasterCraft urges you to pursue additional training prior model.) Never stand or allow passengers to stand in the boat or BOAT OWNERS ASSOCIATION OF THE UNITED STATES to the independent operation of your boat.
  • Page 6 These include weather conditions and attempting to loosen or remove them may result in the to keep boating enjoyable for many years to come. A MasterCraft (addressed later in this chapter), operating in shallow water where •...
  • Page 7 CARBON MONOXIDE (C0) or other activities in or near the stern area of the boat, including, without limitation, the swim platform, the rear sun deck, and aft facing lounge seats when the engine is in operation. Under no circumstances should the owner and/or operator allow persons When anchoring the boat, you MUST turn OFF the engine.
  • Page 8 The victim may be in an area of CO concentration, which means you • Know where and how CO may accumulate in and around your affect CO production. Check with an authorized MasterCraft deal- • Blocked exhaust outlets. or others could be in danger from exposure to CO: boat.

  • Page 9: Line Of Sight

    Caution should always PERSONAL FLOTATION DEVICES • The U.S. Coast Guard, as well as MasterCraft, recommends the wearing of PFDs at all times when the vessel is underway, even be exhibited when putting the boat into motion or though it is not a requirement.
  • Page 10 While your MasterCraft boat is equipped with a fire suppression system and fire extinguishers (except models imported into Japan), Every boat MasterCraft builds is required by law to have on board it is important to make a quick and calculated decision regarding one (1) 2.5-pound, dry chemical fire extinguisher rated for Type A, B...
  • Page 11 MasterCraft boats have also been specified to carry a hand-held 2.5 and/or dock for service by an authorized MasterCraft dealer prior lb. monoammonium phosphate expellant (dry chemical) unit, which to operating again.
  • Page 12 Being on the ski platform at Remember that the majority of in-water injuries are the result of the boat checked out by your authorized MasterCraft dealer to be any time the boat is running can potentially expose individuals to impacts with other objects, so always look where you are going, and certain that the hull has not been weakened.
  • Page 13 Do not add any attachments that are not approved for use on your also can alert the driver when the skier falls. MasterCraft boat. Do not climb on, sit on, stand on, jump off of or dive off of the tower. Never allow passengers to sit behind the tow •...

  • Page 14: Safety Equipment

    • Manual bailing device for removing water • Combination oar/boat hook Your MasterCraft boat was equipped at the factory with most of • Day-and-night visual distress signal the federally required safety equipment for inland waters (Class II, • First aid kit and manual 26-foot-to-40-foot watercraft).
  • Page 15 2 miles • They are marked with an expiration date. Expired signals may sound signals during periods of reduced visibility. Your MasterCraft a distress signal. Such devices do NOT count toward meeting boat is equipped with a horn, but you may also purchase after- be carried as extra equipment, but cannot be counted toward the visual distress signal requirement, however.
  • Page 16 NAVIGATIONAL LIGHTS WARNING PLATES AND LABELS Your MasterCraft boat is equipped with navigational lights. See the Read and note ALL warning plates and labels from bow to stern, Guide to Individual Models section to determine the location of the including those that are installed inside the engine compartment, navigational lights on your boat or verify with your dealer.
  • Page 17 LAW ENFORCEMENT BOATING UNDER THE INFLUENCE Boating under the influence of alcohol or drugs can be as deadly A vessel underway, when hailed by a Coast Guard vessel, is required as driving a car while under the influence! to heave to, or maneuver in such a manner that permits a boarding officer to come aboard.
  • Page 18 REGISTRATION, NUMBERING As a result of alcohol’s effects, a boat operator with a blood alcohol The owner of a vessel must notify the agency which issued the • A Person is injured and requires medical treatment beyond first aid concentration of approximately .10 percent is estimated to be more certificate of number within fifteen (15) days if the vessel is •...

  • Page 19: Refuse And Pollution

    This Owner’s Manual was developed to help ensure an enjoyable There are stringent requirements regarding pollution, discharge of boating experience with a fabulous MasterCraft boat. As stated oil, discharge of garbage and the operation and discharge from san- earlier, this information is not all-inclusive. There are many factors itation devices.
  • Page 20 COMMUNICATIONS distress alert with registration information to the responsible U.S. Coast Guard (or International) Rescue Coordination Center (RCC). 406MHz EPIRBs with GPS (internal or attached) also provide an The following applies to the Great Lakes and salt water boating: immediate GPS position in the information passed to the RCC. OTHER When boating off-shore, carry communications gear such as a ma- rine VHF-FM and/or HF transceiver(s), appropriate to the operating...
  • Page 21 INSURANCE NAUTICAL CHARTS FLOAT PLAN • On-board barometers, where placed on-board by the boat owner, should be checked every two-to-three hours. A rising barometer indicates fair weather and a rise in wind velocity; a falling barometer indicates stormy or rainy weather. Even if someone else is operating the boat, the owner is generally Nautical charts are especially important to boaters planning trips, A “float plan”...

  • Page 22: Cold Water Survival

    ANCHORING • Keep your PFD on. To reduce the effects of hypothermia, get in or on the boat. Try to • Keep your knees bent. get as much of your body out of the water as possible. If you can’t •...

  • Page 23: Rules Of The Open Water

    RULES OF THE STEERING AND SAILING RULES/ GENERAL PRUDENTIAL RULE SOUND SIGNALS This rule is called Rule 2 in the International Rules and says, “In obeying and construing these rules due regard shall be had Any time two (2) vessels on the water meet one another, one vessel to all dangers of navigation and collision, and to any special OPEN WATER has the right-of-way.
  • Page 24 MEETING CROSSING OVERTAKING If you are meeting another vessel head-on, and you are close When two (2) power-driven vessels are crossing each other’s path If you are passing another vessel, you are the give-way vessel. This enough to run the risk of collision, neither of you has the right- close enough to run the risk of collision, the vessel that views the means that the other vessel is expected to maintain its course and of-way.
  • Page 25 SAILING VESSEL RIGHT-OF-WAY OTHER SPECIAL SITUATIONS READING BUOYS AND OTHER Uniform State Waterway Marker System MARKERS Green or Black Channel Marker Buoy: Traveling upstream, you should pass to the right of the buoy as it marks the left side of the Sailing vessels should normally be given the right-of-way.
  • Page 26 Channel Crossing Daymark (Red): A sign mounted on poles in the NOTE: Markings may vary by geographic location. For example, water or on the bank which means the channel is crossing from the the Western Rivers System markers are slightly different, as well right bank to the left bank as you travel upstream.
  • Page 27 2017 MODEL FEATURES AND SPECS 2017 OWNERS MANUAL / 48...
  • Page 28 FEATURES SPECIFICATIONS 02 03 05 06 08 09 10 22 23 24 25 26 28 29 30 Length of Boat 20’ 0” 01. Anchor storage 29. Underwater lights (two, where equipped, under swim platform) 02. Bow cleat Width Amidship 98” 03.
  • Page 29 FEATURES SPECIFICATIONS 08 09 22 23 24 25 26 27 28 29 30 Length of Boat 22’ 9” 01. Anchor storage 28. Engine exhaust (under swim platform) 29. Underwater lights 02. Bow cleat Width Amidship 102” 03. Horn (two, where equipped, under swim platform) 04.
  • Page 30 FEATURES SPECIFICATIONS 01 02 03 06 07 08 10 11 12 13 14 15 19 20 21 26 27 Length of Boat 24’6” 01. Ladder (where equipped) 28. Transom drain plug (center beneath swim platform) 02. Anchor Storage Width Amidship 102” 03.
  • Page 31 FEATURES SPECIFICATIONS 01 02 06 07 08 11 12 13 14 15 22 23 24 25 26 27 28 29 Length of Boat 26’ 0” 01. Bow Ladder Lid 28. Freshwater flush port (where equipped) 29. Transom drain plug (center beneath swim 02.
  • Page 32 FEATURES SPECIFICATIONS 05 06 07 11 12 13 14 15 16 17 18 22 23 26 27 Length of Boat 24’0” 01. Bow cleat swim platform) 30. Bow cleat 02. Anchor storage Width Amidship 102” 03. Ladder (where equipped) 31. Adjustable mirror 04.
  • Page 33 FEATURES SPECIFICATIONS 03 04 05 06 07 08 09 10 11 12 Length of Boat 20’0” 01. Bow hatch (where equipped) 28. MTS Ballast System (where equipped, beneath observer seat) 02. Drop-in walk-thru door Width Amidship 96” 03. Circuit breaker panel, including battery ON- 29.
  • Page 34 FEATURES SPECIFICATIONS 02 03 08 09 10 19 20 21 22 24 25 Length of Boat 20’0” 29. Bow filler cushion (where equipped) 30. Mirror Navigation light Width Amidship 98” 2. Horn 31. Walk-thru door and windshield 3. Ballast tank below floor board 32.
  • Page 35 FEATURES SPECIFICATIONS 02 03 08 09 10 19 20 21 22 24 25 Length of Boat 21’ 4” 26. Underwater lights (two, where equipped) Horn 27. Bow Cleat Width Amidship 98” 2. Navigation light 28. Navigation light 3. Ballast tank below floor board 29.
  • Page 36 FEATURES SPECIFICATIONS 02 03 08 09 10 11 20 21 23 24 25 26 27 28 29 Length of Boat 23”4’ 01. Bow cleat 29. Wake adjustment plate (where equipped) 30. Navigation light 02. Horn Width Amidship 102” 03. Anchor storage 31.
  • Page 37 FEATURES SPECIFICATIONS 02 03 04 06 07 08 09 10 11 12 13 14 20 21 22 23 24 25 29 30 Length of Boat 20’0” 01. Anchor storage compartment beneath swim platform) 30. Transom drain plug 02. Navigational light Width Amidship 91”...
  • Page 38 FEATURES SPECIFICATIONS 02 03 04 06 07 08 09 10 11 12 13 14 20 21 23 24 25 29 30 Length of Boat 22’ 0” 01. Anchor storage compartment 29. Attitude adjustment plate (where equipped, beneath swim platform) 02. Navigational light Width Amidship 98”...
  • Page 39 FEATURES SPECIFICATIONS Length of Boat 20’0” [6.1 m] Anchor storage compartment Ski locker + access to center ballast tanks Width Amidship 91” [231.1 cm] 06 07 08 09 10 11 12 13 14 21 22 23 Navigation light Glove box Bilge thru-hull Hand-held fire extinguisher (under observer seat) Boat Weight 3,550 lb [2,517.4 kg]...
  • Page 40 DASHES AND VIDEO SCREENS 2017 OWNERS MANUAL / 74...
  • Page 41 Manual is found on every model. Some equipment is optional, and the video screen(s). All functionality on the XStar and NXT appears not every option is available on all models of MasterCraft boats. only in the video screens. Also, MasterCraft utilizes a variety of gauge and switch styles...
  • Page 42 X AND XT SERIES INSTRUMENT PANEL: 4.3” VIDEO SCREEN XSTAR INSTRUMENT PANEL 2017 OWNERS MANUAL / 78...
  • Page 43 PROSTAR INSTRUMENT PANEL NXT SERIES INSTRUMENT PANEL 2017 OWNERS MANUAL / 80...
  • Page 44 MasterCraft strongly encourages you to review ALL instrumentation with your authorized MasterCraft Although it may be possible to see fuel in the bottom of the fuel dealer prior to operating the boat for the first time, and at any time during ownership you are uncertain as to tank, you still may not be able to operate the boat.
  • Page 45 3-IN-1 WATER TEMPERATURE Further, it is not recommended to allow the fuel to fall below one- If you experience low oil pressure, stop your engine immediately and quarter of a tank full at any time as it may result in damage to the check your oil level before operating again.
  • Page 46 X AND XT SERIES VIDEO SCREEN OPERATIONS HV700 The X-Series is designed for instrumentation and control on electronically controlled engines communicating via SAE J1939 and NMEA 2000. The multimedia displays provide cruise control and rider profiles, and enable boat operators to view many different engine, ballast, transmission parameters and service codes.

  • Page 47: Care And Maintenance

    QUICK ACCESS KEYS In addition, there are areas where sliding your finger up or down can adjust the settings. For example, on the Ballast and Trim screen, sliding your finger up on the inside of the tank area adjusts the The following screens can be accessed quickly by pressing a Quick ballast setting.
  • Page 48 Source - Touch this to select a connected The Ballast and Trim screen can be accessed by pressing the ning of available channels. source. MasterCraft supports the following Power - Turns stereo system on/off. Ballast/Trim Quick Access Key on the HV700. Press any Quick...
  • Page 49 GAUGES Ballast and Trim Ballast and Trim Descriptions Descriptions Touch Command Touch Command Gauge Touch Description/Action Touch to save these settings to a new rider The Gauge screen can be accessed by pressing the Gauges Commands profile. A keyboard is displayed to name Quick Access Key on the HV700.
  • Page 50 PROFILES Video Touch Video Touch GPS Touch Description/Action Description/Action Description/Action Commands Commands Commands North Up / Displays the map as having either north or The Profiles screen can be accessed by pressing the Profile Touch to view the Aux Video source. Course Up the current direction headed at the top.
  • Page 51 New User Profile Delete Current Profile New User Profile Display Instructions New User Profile Display Instructions Touch the [Up] or the [Down] A new rider profile can be set-up using the HV700 Touch. To create A rider profile can be deleted using the HV700 Touch. To delete a arrow to Set the speed for The new rider’s name is listed a new profile, press the Profile...
  • Page 52 Edit Current User Cruise SETTINGS MENU Settings Menu Description Touch Commands A rider profile can be edited using the HV700 Touch. To edit a new User Settings — allows you to customize profile, press the Profile Quick Access Key. Access the Settings Menu screen by pressing the Menu the display options for ambient light and Quick Access Key on the HV700.

  • Page 53: Service Information

    User Settings Ballast Settings (Tank Fill/Drain Times) Service Information User Settings Description of Options Touch Commands On the Settings Menu screen, touch the Touch In the User Settings screen, touch the Touch On the Settings Menu, touch the Touch Com- Night Brightness Sets the screen brightness for Command to access the first of two user settings screens.
  • Page 54 Use a positive value if more fuel read fuel levels directly from the fuel sensor on the fuel tank. Should The fuel management software in MasterCraft boats directly tank has been filled completely. Fuel levels will be displayed next to...
  • Page 55 The EPDM is a solid state engine fuse block designed for all 2017 translated into text by the display, see the engine MasterCraft boats to make engine diagnostic checks easier and manufacturer’s literature for the definition of the SPN number.
  • Page 56 24-hour time formats. You can also enable DST (Daylight Saving to an authorized MasterCraft dealer for diagnosis and servicing. • A red indicator denotes that there is a problem with the digital Time) by touching that box.
  • Page 57 GPS map and depth display. Touch DONE when finished. Display has no back light. Contact your MasterCraft service center. Display has no keypad back light. Contact your MasterCraft service center. 2017 OWNERS MANUAL / 108...
  • Page 58 X AND XT SERIES VIDEO SCREEN OPERATIONS HV450 2017 OWNERS MANUAL / 110...
  • Page 59 Soft Key commands. Soft Key commands override + PDM Diagnostics Quick Access key functions and are executed by pressing the keys The MasterCraft X and XT Series HV450 screens are designed for All product features are easily accessed through Quick Access + Factory Settings Keys, Soft Key commands and Menus.
  • Page 60 Battery Voltage, Water Depth and Engine Hours Gauges. Soft Key Commands Stereo display and functionality controls reside on the MasterCraft The Ballast and Trim screen can be accessed by pressing the NOTE: This screen is display only. There are no soft keys with it.
  • Page 61 MAIN SETTINGS MENU Engine Diagnostics If you select Yes (by pressing the second button on the right side), Step Action the following screen will appear. First screen that appears when you Utilize the up arrow once again (third button) until the Displays a list of engine fault codes and descriptions;...
  • Page 62 User Settings Soft Key Commands USER SETTINGS DESCRIPTIONS Function Description Function Control Day Brightness Sets the screen brightness for daylight. Ballast Settings Control the ballast fill and drain times. NEXT PAGE – advances to the next or previous page of settings Options: Page Function...
  • Page 63 Software Version and down arrow soft keys, then press the Next soft key. Press the description stored in the display. If there is no text, then this OK soft key when finished. SPN and FMI must be defined by referring to the engine manu- Purely informational Software Version screens provide the following: facturer or the SAE J1939 standard.
  • Page 64 The EPDM is a solid state engine fuse block designed for all 2017 tem inputs and outputs of the engine. MasterCraft boats to make engine diagnostic checks easier and Reported conditions include no faults, short circuits, open circuits more convenient for quick, on the water fixes.
  • Page 65 FULL to indicate that the tank has been filled completely. Fuel levels will be displayed next to “Amount” This screen allows the dealer to indicate or display the following: The fuel management software in MasterCraft boats directly at the top of the screen. • Boat Model connects the boat operator to the management of their fuel.
  • Page 66 button to adjust to the correct amount of fuel. Use a positive value Disabling the fuel management software will allow the fuel gauge to if more fuel needs to be entered, or use a negative value if too much read fuel levels directly from the fuel sensor on the fuel tank. Should fuel was entered.
  • Page 67 XSTAR INSTRUMENT PANEL XSTAR VIDEO SCREEN OPERATIONS 2017 OWNERS MANUAL / 128...
  • Page 68 PRODUCT INFORMATION FOR SCREENS a selection of soft keys. Soft key commands provide additional features and navigation shortcuts. Depending on the current screen THE XSTAR VIDEO TOUCH AND displayed, the soft keys may appear as icons or as a vertical control 4.5”...
  • Page 69 QUICK ACCESS/KEY FEATURES stereo control, cruise control, profiles, ballasts, and attitude adjust- tabs. Up to 16 rider/user profiles can be defined. Rider profiles can ment and surf tabs. also be uploaded via a USB connection. This section describes the features accessed through the Quick Access Keys located to the left and right of the display.
  • Page 70 MODIFY—select and edit existing user name information. Type a name for the new profile using the keypad and touch [DONE]. DELETE—deletes selected user name after confirmation warning. NEW RIDER PROFILE A new rider profile can be set up using the 4.5” touch screen. Function and Description Touch [MINUS] button to decrease the percentage, or the [PLUS] Touch [UP ARROW] or [DOWN ARROW] to change the Set Speed...
  • Page 71 Touch [SAVE] to save the new rider and settings created. The com- MODIFY RIDER PROFILE posite profile is now displayed on the 7” touch screen. SELECT—Touch [SELECT] to see the rider profile. A rider profile can be modified using the 4.5” touch The 4.5”...
  • Page 72 NOTE: To access GPS navigation, press [SELECT] as shown. Section D: MENU—Use this menu to go to the current position on The following utilities are provided directly from this menu on PREV TRACK—returns to and plays the previous track of the map, create waypoints and create, clear and save tracks.
  • Page 73 Chart and Time Set-up Depth and Position Set-up GPS Status The advantage to using the Chart and Time Set-up on the 4.5” Use the Depth and Position Set-up on the 4.5” touch screen and The GPS Status screen on the 4.5” touch screen is identical to the touchscreen is that the results can be immediately seen on the the results can be immediately seen on the map displayed on the 7”...

  • Page 74: Gps Utilities

    MAIN MENU OPTIONS CURRENT POSITION—The position of the boat. A track begins re- • System • Ballast cording from the current position and continues to record until the • Auto Launch/Exit Setpoint Speed track is cleared or saved. Menu Options CREATE WAYPOINT—Touch this button to create a waypoint at GPS UTILITIES the current position of the cursor on the map.
  • Page 75 ENGINE DIAGNOSTICS Track Enable—Shows or hides the selected Track. depth display. into text by the display, see an authorized MasterCraft dealer. FMI—“Failure Mode Indicator’’—fault code. The FMI is defined When choosing this selection, the display will query the engine’s Chart and Time Set-up by SAW J1939.
  • Page 76 Selects the previous setting. Scrolling Through Multiple Messages to an authorized MasterCraft dealer for diagnosis and servicing. • A red indicator denotes that there is a problem with the digital The title bar of the fault code pup-up may indicate multiple switch and it has tripped.
  • Page 77 [RESTORE in five percent (5%) increments until the desired brightness is DEFAULTS] for the factory settings. Contact your MasterCraft service center. achieved. NIGHT TIME BRIGHTNESS—The night time brightness control Display has no keypad back light.
  • Page 78 A “low fuel” notice will come up on the video screen as a warning to GAUGE return to shore and refuel. MasterCraft recommends that operators do not run the boat below a quarter of a tank, except as necessary GAUGES...
  • Page 79 3-IN-1 WATER TEMPERATURE If you experience low oil pressure, stop your engine immediately and check your oil level before operating again. GAUGE Continuing to operate the boat while the temperature is above normal operating parameters may cause serious damage to your Lower Left Side engine.
  • Page 80 PROSTAR VIDEO SCREEN OPERATIONS 2017 OWNERS MANUAL / 154...

  • Page 81: Basic Navigation Features

    VOLUME — Touch this button to lower the volume. Quick Access Keys allow easy and convenient access to the most used screen functions on MasterCraft boats. Only basic cleaning should be required to maintain the 7” video VOLUME — Touch this button to raiser the volume.
  • Page 82 iPod MENU — Touch this button to display the BALLAST & TRIM SCAN/STOP — Enables and stops the scanning Touch and slide your finger to change screens. iPod menu, as shown below: of available channels. Touch to stop all activity on this screen. The Ballast and Tabs screen can be accessed by pressing the Bal- REWIND —...
  • Page 83 Gauge Screen Gage Display VIDEO Touch to empty all ballasts. Touch to view the Aux Video source. • Speedometer (MPH) Press the Video Quick Access Key to go back. Touch and slide your finger to the desired Bal- • Water Depth (FT) The Video screen can be accessed by pressing the Quick Access last Tank level, or touch the UP DOWN Arrows •...
  • Page 84 Touch Commands PROFILES Type a name for the new profile using the touch keypad and touch Touch to delete the selected rider after Description [DONE]. confirmation warning. The Profiles screen can be accessed by pressing the Quick Access Key. Touch to activate the user displayed in that Touch to turn cruise control ON or OFF.
  • Page 85 Touch the [UP] or the [DOWN] arrow to Set the speed for this profile. Touch to highlight the Pull Type; touch the arrows to change the Touch to highlight the Wait Time; touch the arrows to change the Final Save profile or edit screen. Review the Profile settings. Touch Touch [Change] to set 3 Event Type.
  • Page 86 EDIT CURRENT USER TOURNAMENT EVENTS On the 3 Event Screen, everything is activated. The 3 Event screen can be accessed by pressing the Quick Access Key. This feature provides a way to keep a boat within the strict guidelines of the event it is tracking and provide a visual display of the track and the progress of the skier.
  • Page 87 Touch Commands Description Course Manager – Allows you to map a course. See Course Manager. Cruise - Touch to turn cruise control ON Pull Type –Touch to select a pull type from or OFF. (or press the Quick Access Key a list.
  • Page 88 SLALOM SETTINGS– COURSE MANAGER– ALL SLALOM Touch [Settings]. Touch [Buzzer Volume]. On the Pop-up, touch the NOTE: Additional Details on Course List: The blue lettering above arrows to turn Buzzer Volume UP or DOWN. the course list displays the mapped information for the course se- AND JUMPING EVENTS Touch [Exit] to return to close the pop-up.
  • Page 89 Press the [Start Gate] to begin Mapping. • Map Course – Touch to map another course. Settings – Select to set the Buzzer Volume, Prop • Exit – touch to return to the 3 Event screen. Type, Timing Recap, and Jump Switch Timeout. NOTE: For Slalom, press the [Start Gate] button when the GPS •...
  • Page 90 TRICK SCREEN setting. When available, touch the arrows to change the setting. Touch [Exit] to close the pop-up.\ The screen illustrates the display available when the event is Trick Tournament; the three-event features are in tournament mode and ready for settings. Use the Touch Commands in setting up, con- trolling and tracking the Trick event.
  • Page 91 TRICK SETTINGS– SETTINGS MENU Touch [Settings]. Touch [Prop Type]. On the Pop-up, touch to set at 3 blade or 4 blade. TOURNAMENT OR TRAINING The Settings Menu screen can be accessed by pressing the Quick Access Key. The following settings are available: On the 3 Event Screen, touch the Settings touch command to access the pop-up list.

  • Page 92: User Settings

    Description of Options TAB SETTINGS BALLAST SETTINGS Diagnostics – Displays Engine, PDM, and 3 Event Diagnostics including a list of fault Touch Commands Description codes and descriptions; on some screens, (SPEED, AUTO, POSITION) (TANK FILL/DRAIN TIMES) corrective action will be shown. Units US Standard (US Std) or Metric 3-Event Charts –...
  • Page 93 Dealer Service Reset – The dealer sets the SERVICE INFORMATION Time Setup Parameters – This is used to select correct time zone number of engine running hours between and clock mode for either 12-hour or 24-hour time formats. You can servicing intervals at which time an alert will also enable DST (Daylight Savings Time) by using the PLUS/MINUS On the Settings Menu, touch the Service Information touch command...
  • Page 94 DIAGNOSTICS PDM Diagnostics – Displays short Active Faults/Stored Faults Corrective Action (Suggested action for correction): circuits, open circuit, over current, in/out of range, and faults within the Shows the number of active faults and which fault number is Get Faults On the Settings Menu, touch the Diagnostics touch command to system outputs, switch inputs, ana- currently being displayed.
  • Page 95 The EPDM is a solid state engine fuse block designed for all 2017 IMPORTANT: Use the 3-Event Charts for reference only. The charts MasterCraft boats to make engine diagnostic checks easier and will not reflect any changes, should a change occur in the rule book.
  • Page 96 1. Check display supply wires are connected properly to battery. 2. Verify battery is charged properly. 3. Check battery for efficient starter current. Display has no back light. Contact your MasterCraft service center. Display has no keypad back light. Contact your MasterCraft service center. 2017 OWNERS MANUAL / 186...
  • Page 97 OPERATIONS 2017 OWNERS MANUAL / 188...
  • Page 98 Depending on the D = Blower switch. A two-position switch activates the engine box MasterCraft boats are designed for activities that should be con- item, long term use without the boat engine turned ON could result in the switch to the automatic position when finished emptying the ducted during daylight with good visibility.
  • Page 99 STARBOARD SIDE OF DASH It is possible for operators to be aware when tanks are full as over- starting an outing, and removed at the conclusion. This is intended a dead battery could cause boaters to become stranded. flow will exit the tanks through the overflow vents. When emptying, to prevent theft or unapproved use of the boat.
  • Page 100 switch. Continued practice will help you become familiar with how To raise one side, press the opposite side, i.e., to raise the right the plates perform. (starboard) side, press the left (port) side of the wake shaping device switch. NXT Wake Shaping Device switches: Press the LEFT side of the While operating attitude adjustment plates use caution.
  • Page 101 NXT20/22 VIDEO SCREEN OPERATIONS 2017 OWNERS MANUAL / 196...

  • Page 102: Product Information

    PRODUCT INFORMATION Display Keys Features And Actions Actions • Gauges • (Arrow) Scrolls to other screens. • Fuel • (Down) Highlights the next setting down. Decreases set speed only on cruise screen. • MPH The NXT20 integrates instrumentation and control. The video Avoid contact between sharp or hard objects and the video touch •...
  • Page 103 An engine fault code is present. See Engine Diagnostics for details. selected as NO, it is not displayed. A Dealer Code is required to Action: See your authorized MasterCraft dealer for assistance. access the Factory Setting screen. 2017 OWNERS MANUAL / 200...
  • Page 104 Trim User Settings Settings screen, the trim display positions will reflect that. A Dealer Fire Extinguisher Code is required to access the Factory Setting Screen. The choices are Enable (pop-up notification) or Disable (pop-up notification). Main Menu Factory Reset This choice restores all factory settings to their original values. Choices are: YES or NO.
  • Page 105 Service Information Oil Change Reset Diagnostics screen. Get Faults Select YES after an engine oil change to reset the internal clock for Selecting GET FAULTS queries the Engine Control Unit (ECU) for The Engine Diagnostics screen displays active and stored faults. oil change alerts.
  • Page 106 The EPDM is a solid state engine fuse block designed for all 2017 2. Check for loose connections at battery and display unit. MasterCraft boats to make engine diagnostic checks easier and 3. Check for reversed polarity on the power connections.
  • Page 107 BOAT OPERATIONS 2017 OWNERS MANUAL / 208...
  • Page 108 CIRCUIT BREAKERS In a water setting, such as those in which boats operate, it is espe- cially important to avoid electrical shocks. As a result, MasterCraft utilizes GFI, or Ground Fault Interruption, circuit breaker boards, Models except in the XStar. These are solid-state devices that sense when...
  • Page 109 ProStar (it is located on the starboard side of minute. Then fully push the appropriate breaker button and switch to an authorized MasterCraft dealer for service prior to returning the walk-thru to the bow area). In some models, there is an addi- ON the circuit.
  • Page 110 10.5 volts or below, the system will shut off the Make frequent checks of battery charge and bilge pump function cal components on the boat, MasterCraft does not place a specific when boats are moored and exposed to the elements.
  • Page 111 Troubleshooting possible and seek assistance from your authorized MasterCraft These are three-stage electronic chargers, completely automat- dealer’s service department to diagnose and, if necessary, repair ic, lightweight, and silent. Unlike most automotive chargers, this If the battery charger ever appears to be malfunctioning, see your the problem.
  • Page 112 Models DO NOT attempt to jump start the battery from a vehicle or another still did not recharge, take the boat to your authorized MasterCraft The key will be in one of two (2) positions: boat as this can cause an overload of the boat’s electrical system, All.
  • Page 113 • Insert the key and turn. (This turns ON the electrical system and require recharging. Use only a MasterCraft battery charger. DO NOT 2017 OWNERS MANUAL / 220...
  • Page 114 If the lever still will not move, contact your authorized MasterCraft dealer. Never attempt to shift without the engine running! The neutral Never attempt to shove or force the lever. If it does not move...
  • Page 115 FIRE SUPPRESSION AND MasterCraft. Failure to follow directions as outlined in this section can result in serious injury or death. EXTINGUISHING Purpose ADDITIONAL MasterCraft has developed an extensive fire suppression and ex- tinguishing system for its boats. All MasterCraft boats are equipped with an automatic fire suppression system.
  • Page 116 Use marine-grade lines to loop over the cleat and tie up to the dock, units on the boat. Your authorized MasterCraft dealer can assist you. allowing some slack in the rope. If there is any motion in the body of...
  • Page 117 If the horn does not sound, check the main circuit breaker panel MasterCraft was selected to maximize the range of vision for the Purpose to see whether the circuit has tripped and needs to be reset. If the driver of MasterCraft boats.
  • Page 118 SKI/WAKEBOARD/SURF ROPE Models Ski/wakeboard tow ropes may snap back into occupied portions of the boat causing serious injury. Occupants must be vigilant when May be purchased from an authorized MasterCraft dealer or towing skiers or wakeboarders. aftermarket retailer. Location Purpose Attachment locations vary by model.
  • Page 119 Purpose BILGE SYSTEM, CENTER DRAIN, Water inevitably intrudes into any boat. MasterCraft boats are de- TRANSOM DRAIN PLUGS, SEA signed to expel the water via the bilge system. When on the water, bilge pumps will expel water. Bilge pump sensors allow the system STRAINERS AND SCUPPERS to pump water overboard either automatically or manually.
  • Page 120 the lowest point of the deck, under the rear seats. Bilge pump-out ual ON position. Return the switch to the automatic position when automatically and does not require a switch or gauge to monitor. locations are on the side of the boat. Depending on the model, the finished emptying the bilge.
  • Page 121 Carbon monoxide is discussed in the Safety section of this • If the boat does not automatically pump water out of the system an authorized MasterCraft dealer as soon as possible for repairs Owner’s Manual. The engine will also create flammable, ignitable when the ignition key is ON, verify that the bilge switch is turned and do not use the boat again until it has been properly repaired.

  • Page 122: Steering System

    MasterCraft dealer for repair. needs and comfort of the operator. The system was designed to be The steering of a boat is very similar to that of a car or truck, but necessary during cruising speed.
  • Page 123 Additional steering components are At any time, if the steering is sluggish, difficult, or shows any signs taken to an authorized MasterCraft dealer for attention. The Dock- mounted under the helm and under the engine in the engine com-...
  • Page 124 There is no operation required. Boat owners should periodically tions are in areas of the boat not accessible to the consumer. examine the anode to determine how much erosion has occurred and consult an authorized MasterCraft dealer to determine the appropriate time to replace it. ZINC ANODE Models All except ProStar, as part of the Salt Water Package option.
  • Page 125 The middle position is OFF, and the MasterCraft boats should not be operated at night or in limited left position is for anchor-only lighting.

  • Page 126: Docking Lights

    Press up on the switch to turn the lights ON (a green LED A rocker switch mounted to the throttle control panel. Take the boat to an authorized MasterCraft dealer to have the bulb light will appear on the switch when the docking lights are on). Press Operation replaced.

  • Page 127: Underwater Lights

    If the circuit breaker has not tripped, the bulb may have burned out. illumination for the interior deck and compartments. Although some lights are LED, which rarely burn out, it is possible. Take the boat to an authorized MasterCraft dealer to have the bulb Location replaced.
  • Page 128 If the circuit breaker has not tripped, the bulb may have burned out. Although the lights are LED, which rarely burn out, it is possible. Take the boat to an authorized MasterCraft dealer to have the bulb replaced. 2017 OWNERS MANUAL / 250...
  • Page 129 ATTITUDE ADJUSTMENT PLATE Models Standard on the X20, X23, X26, X46 and XStar. All others X Series and NXT models, as an option. SPORT Purpose When used properly, the plate improves the ride, reduces drag, increases speed and improves the fuel efficiency of the boat. Operation Location The operation of the attitude adjustment plate is basic.
  • Page 130 Special Attention Because our models have different weights, lengths, speed decreasing lift in the stern and allowing the bow to rise. If the and performance, it will take some practice for the operator to plate(s) is/are deployed, the bow may dig. On the X10, XT23, X46, and XSTAR models, attitude adjustment understand how the boat reacts with the attitude adjustment plate plates are limited to seventy-five percent (75%) maximum exten-...
  • Page 131 To build and shape a surf wake with more push and a larger optimal optimized by MasterCraft engineers at the factory and come preset access this screen, press the Menu hot key, select user settings, surfing area.
  • Page 132 Special Attention BALLAST SYSTEMS Location The ballast system in X Series, XStar and ProStar models operates on an automated system that shuts down automatically when the On the X10, XT23, X46, and XStar models, GEN2 WSDs are limited Ballast tanks are located under the deck, in the hull, hidden from emptying process has been completed.
  • Page 133 RPM to the required level may result in malfunction potential issue that arises with the system should ever be ignored. MasterCraft dealers can help to locate any and all pumps and See the Ski/Wakeboard Rope information under Additional Safety or permanent damage to the ballast pumps that force the water impellers.
  • Page 134 Folding Down the Platform MasterCraft dealer for service. Securing the Platform Remove the safety hinge pins in each swim platform bracket. Begin by lifting the platform about four (4) inches upward while...
  • Page 135 Oiling The Garapa Gold Platform Carbon monoxide from exhaust pipes of inboard or outboard take the boat to an authorized MasterCraft dealer for repair. The Garapa Gold platform will need more frequent maintenance engines may build up inside and outside the boat in areas near if it is regularly exposed to direct sun or water.
  • Page 136 Otherwise, skis may become dis- and removing the second. The angled threaded can put the tow- of any tower that is not specified and installed by MasterCraft may lodged and strike passengers in the aft section of the boat or the er/threads in a bind.
  • Page 137 Lowering and Raising the ZFT4 Tower forward. • Feed all of the excess wires and connectors below the deck through the access hole. • It should easily slide about 1/2” before catching on a small, raised feature intended to keep the tower from sliding out too easily and •...
  • Page 138 In over-the-road transit, the adjustable towers should only be in trolled by a switch located below the shift/throttle control on the the tower. Mastercraft towers should only be used for approved a fully upright or fully lowered position to avoid potential damage driver’s armrest.
  • Page 139 Take the boat to an authorized of the board needs to be centered in the fingers to keep the MasterCraft dealer to have the ring lights replaced when necessary. board from rotating when hitting waves. If you have issues with Speakers: Tower speakers operate through the audio system.
  • Page 140 The ZFT7 tower has dedicated port and starboard surf rack pad rest against the front tower leg) Surf tows are intended for surfing only. MasterCraft highly discour- installation kits. Be sure that the correct kit is being used before ages towing any other sport from these mounts. Do not tow from all attempting to install it on the boat.
  • Page 141 STEREO COMPONENTS Optional remote controls are available on the bow for all X Series models and the XStar The iPod/USB plug-in is located on the glove box for all radios; the MP3 player jacks are below the throttle control on the driver’s side of the helm.

  • Page 142: Storage And Winterization

    The heater’s three-position switch rotary control is turned left for MasterCraft dealer for repair. While the air coming out of the vents ON (LOW), or turned right for ON (HIGH). The heater can only be may be cool at first, if it does not warm up within a reasonable operated with the engine ON.
  • Page 143 MasterCraft when it is not in use. In some instances, ladders may also be stowed practice.

  • Page 144: Canvas Covers

    Troubleshooting If the anchor line has been improperly rewound, have an authorized MasterCraft dealer assist in deploying and rewinding the line to its appropriate berth. dealers perform the installation of snap-on canvas such as cockpit Whenever the anchor line is deployed, individuals in the water and tonneau covers.
  • Page 145 Location Purpose keep occupants cool and protected from the sun’s rays. Bimini tops are designed and built to match each of MasterCraft’s The ProStar bimini casts shade on the cockpit of the boat to keep Location tower options. The bimini is integrated into its respective tower occupants cool and protected from the sun’s rays.
  • Page 146 Insert the ball joint into the bracket and insert the pin to lock the With some upward pressure on the main bimini leg, slide or deployed position, MasterCraft recommends that the bimini be the tower mounting bracket. bimini legs to the mounting bracket. To ensure proper orientation the secondary mounting ball joints down into the top of the taken to an authorized MasterCraft dealer for repair.
  • Page 147 Attached to the mooring cover and over the swim platform Should the bimini ever bind or become locked in either the stowed located on the transom. or deployed position, MasterCraft recommends that the bimini be Operation taken to an authorized MasterCraft dealer for repair.
  • Page 148 HEAD AND TOILET SYSTEM cutting wheel and ejects it into the waste tank on the starboard side of the boat via a short run of premium sanitation hose.  Do not flush waste with “Dry Bowl” Switch! To maintain proper Do not flush foreign objects! Flush only water, bodily wastes and cleanliness and operation of the toilet and macerator pump, water rapid-dissolving toilet tissue.
  • Page 149 To empty the waste holding tank 3. Insert key into pump switch panel located under this seat. 2. Open and close all plumbing valves, including seacocks. 4. Turn the key clockwise and hold to operate the discharge pump. 3. Check in-line water filters and vented loops for blockage. Dockside pump out The switch is spring loaded and must be held to run the pump.
  • Page 150 If the toilet still exhibits issues, seat base. then present the boat to and authorized MasterCraft dealer for repair. 2017 OWNERS MANUAL / 294...

  • Page 151: Wet Bar

    (See Shower and Wash Down information elsewhere in this section X26, as an option. not work or continues to trip, see an authorized MasterCraft dealer. of the Owner’s Manual.) Flip over the lid that tops the sink to allow Purpose access to the sink area.
  • Page 152 Location MasterCraft dealer to verify the exact locations on your model. is evident, take the boat to an authorized MasterCraft dealer for Use only designated storage compartments for storage. Using any The ladder is mounted to the bow of the boat.
  • Page 153 Boats equipped with the bow lid have storage space beneath it, ac- from the boat, or being run over by the boat. This could result in cessible from the walkway between the helm and observer dash- the boat to an authorized MasterCraft dealer for repair. Operation serious injury or death! es.
  • Page 154 AWAY from these exhaust vent areas, which are located at the rest of the upholstery material. That means that they will require the Comfortable seating is a hallmark of MasterCraft. Not only does the is securely engaged before using the seat back in these types stern of the boat when the boat engine is running.
  • Page 155 Models position. The seat cushion will then lift and rotate. Continue pulling GAS ASSISTED SEAT LIFT CONVERTIBLE CENTER REAR SEAT forward until the seat cushion rotates past vertical. Then lower the ProStar, as an option handle and press the seat back down toward the cockpit floor as the Models Purpose seat cushion comes to rest 180 degrees from its previous position.
  • Page 156 (aft) could lead to loss of control of the playing on the 7” dash a live stream of what the camera is actively the boat when stopped. As with all MasterCraft helm seats, the boat, injury or property damage.
  • Page 157 Plug the USB end of the Lightning to HDMI Adapter into the USB port on the HDMI/USB panel that is mounted in the glovebox Connecting a GoPro camera to the MasterCraft 7” video screen for the first time requires a few initial steps that make it simple to Step 3: 7”...
  • Page 158 PREPARATION 2017 OWNERS MANUAL / 310...
  • Page 159 This system is designed to provide years of trouble-free are required to use these; some marinas may not. Therefore, we service. The MasterCraft fuel delivery system is based on the latest recommend that you never leave the fuel fill unattended when fueling.
  • Page 160 Starting the engine with fuel levels below the acceptable standard will likely cause damage to the fuel pump. MasterCraft, working in conjunction with the fuel pump’s manufacturer, has determined that on initial (first-time) use, the boat should have a minimum of fifteen Gasoline is extremely flammable and highly explosive under (15) gallons of gas.
  • Page 161 Remedy 1 Additional, critical information regarding the proper use of gasoline Take the boat to an authorized MasterCraft dealer. Only the dealer in relation to the ILMOR Marine Engine is contained in the engine has the specialized, required tools to correct the problem.
  • Page 162 The system may have inadequate fuel pressure or clogged fuel filter and/or lines. Remedy Take the boat to an authorized MasterCraft dealer. There are a vari- ety of potential causes that can negatively impact fuel pressure. All repairs require specialized tools available only to dealers.
  • Page 163 SAFETY CHECKS should receive attention immediately. See your authorized bilge compartment. MasterCraft dealer’s service department for assistance. • Check all hoses and connections for leakage or damage. • Check that everything is secure, tower and mirror knobs are tightened, all latches and brackets are secure, and anything that...
  • Page 164 operations, there will be some vibration, and this may loosen hard- ware over time. • Check that all required Scheduled Maintenance Checks and Ser- vices (see following sections) were performed. After Operation • Check for fluid leaks. • In boats equipped with a ballast system, drain water from the ballast system before placing the boat on the trailer.
  • Page 165 Failure to follow the break-in procedure exactly as stated will void the engine warranty! Leaks can pose a serious safety threat. While all new MasterCraft NOTE: Before operating the boat for the first time, you must read boats are lake tested at the factory to check for leaks, it is still pos- BREAK-IN the engine manufacturer’s manual completely in addition to this...
  • Page 166 MasterCraft dealer to determine the cause. Always remem- ber that during normal operation you should allow the engine to warm up gradually.
  • Page 167 Before Starting Familiarize yourself with the controls and indicators used on this MasterCraft boat. Perform all Safety Checks and Services as de- Before starting the engine, open the engine compartment and scribed in that part of this section of the Owner’s Manual. Also per-...

  • Page 168: Shifting Gears

    Shifting is accomplished by moving the lever forward or backward. ately stop the boat as outlined below and check the oil level. If the the boat inspected by an authorized MasterCraft dealer. Request Center (straight up) is neutral. Moving the lever forward engages temperature gauge indicates overheating, stop the boat when it is any necessary repairs before resuming operation of the boat.
  • Page 169 Owner’s Manual regarding weight. Courtesy MasterCraft urges all who will be operating the boat to seek certified instruction from the local boating authorities. Always respect the rights of others on the water. Keep wide when This section is designed to present the most basic operational principles. It is NOT intended to cover all conditions passing, slow down in crowded areas, be alert and be aware of your encountered during operation.
  • Page 170 With the rudder in the straight-ahead position, well as damage to your MasterCraft boat that will not be covered open-throttle and note the maximum RPM. EFI engines are a counterclockwise rotation propeller tends to cause the boat to under warranty.

  • Page 171: Unusual Operating Conditions

    MasterCraft’s engine manufacturer suggests that consumers con- easier on the starboard side. On MasterCraft models equipped with sult with the dealer from whom the boat was purchased regarding...
  • Page 172 CARE AND MAINTENANCE 2017 OWNERS MANUAL / 338...
  • Page 173 Each cable should be rated above the full weight of the model to MasterCraft models. Though stern eyes are designed to lift a boat from the water, care must be taken to be lifted. When lifting, keep the bow slightly higher than the stern ensure you do not damage your boat.

  • Page 174: Storage Cradle

    STORAGE CRADLE If a storage cradle is used, the hull must be properly supported to prevent load damage. This can occur with as little as fifteen (15) pounds per square inch of pressure. DO NOT support the boat by resting the hull on the keel (the central fore-and-aft structural member in the bottom of the boat’s hull, extending from the bow to the stern).
  • Page 175 GALVANIC CORROSION to other metal parts may result. MasterCraft boats optioned with a saltwater package come equipped with a zinc anode. For fresh water boats that may be tem- porarily operated in polluted or brackish water, an authorized Mas- terCraft dealer can assist in installing proper corrosion protection systems including sacrificial anodes and fresh water flush kits.
  • Page 176 Salt Water Package. If operating a • Tower components corrosion of hardware and will void your warranty. Most fasteners used on MasterCraft boats are stainless steel or fresh-water model temporarily in salt, polluted or brackish water, Engine •...
  • Page 177 Under extreme conditions, special cleaners may be used to remove regular and routine cleaning maintenance to ensure that the boat marine growth from the hull. (See an authorized MasterCraft service exterior, interior and components retain both their appearance and department for further instructions.) strength.
  • Page 178 CARPET Spills permanent marks that are not covered under warranty. Regular Many products such as boiled linseed oil, tongue oil, wood oil and cleaning and oiling of wood will maintain its original appearance. other outdoor wood preservatives can be found at marinas, paint Scoop or scrape up as much of the spill as possible, followed by a Unprotected wood will turn gray and could split or separate.
  • Page 179 Fiberglass Swim Platform CANVAS COVERS the growth of mildew. Mold and mildew need something on which • Water should be cold to lukewarm, but never more than 100 degrees. to grow and polyester fabric is not a desirable substance for such The fiberglass swim platform requires the same kind of regular—...
  • Page 180 While the vinyl is treated to resist the growth of micro-organisms when it is covered to take advantage of air circulation. MasterCraft (meaning the vinyl is not a food source), the stain results from fail- vinyl is made to withstand the effects of sun, heat, acid rain and ure to properly clean and maintain the vinyl.
  • Page 181 • Murphy’s Oil Soap and could damage the surface of your interior. Do not use kerosene, Spray paint and lifespan of the vinyl. The vinyl manufacturer and MasterCraft gasoline or acetone, because they will remove the protective ma- • Son-of-a-Gun...
  • Page 182 Determine the operational readiness by examination, i.e., by sight, Proper care, maintenance and adjustment will contribute to the sound or feel. peak performance of the MasterCraft boat, while also extending the MAINTENANCE overall service life and the resale value. Change...

  • Page 183: Inspect Seacock Strainer

    Manual. There are important functions that must be followed before, cians at an authorized MasterCraft dealer for many of these tasks! during and after every outing: Boats equipped with an optional flushing system for use in salt water or brackish water should operate the flushing system.
  • Page 184 MasterCraft recommends doing this before MasterCraft recommends the use of a spiral-cell type battery, such to avoid allowing the solution to enter the battery vents. Rinse the Before adding electrical equipment, consult an authorized starting the boat.
  • Page 185 Because the lines on late model MasterCraft boats are pressurized, possible to smell a “rotten-egg” odor that signifies a probable issue they can be disconnected and/or removed ONLY by using special- that must be addressed.
  • Page 186 (Some MasterCraft models offer an optional Note that fuel systems vary by model. The pump-in-tank location on In instances of boats being left moored in water, it may be neces- apparent.
  • Page 187 HUNDRED [100] HOURS MasterCraft recommends that your annual—or one hundred (100) hour—maintenance requirements be performed by an authorized MasterCraft dealer. The staff there has the proper equipment and technical training to best meet your service needs 2017 OWNERS MANUAL / 368...
  • Page 188 Inspect the rubber exhaust flap for signs of deterioration. Take cable is seen (see photo to the right, notice that the engine has been removed, this is not necessary for lubrication). the boat to an authorized MasterCraft dealer to replace the flap if necessary. Step 4...
  • Page 189 Because this process should be completed while all movable com- bottom (hull) of the boat. IMPELLER ponents of the drive train are NOT in motion, MasterCraft recom- The enclosed engine compartment limits the ventilation of gasoline mends this be done while the boat is out of the water.

  • Page 190: Other Maintenance

    Run the bilge blower for at least four (4) minutes to ventilate the bilge area each time before starting the engine. All MasterCraft models are equipped with a fuel fill cap. These caps are hinged, and they snap open or closed to seal with an audible click.

  • Page 191: General Preparation

    GENERAL PREPARATION presents an excellent opportunity to perform annual maintenance. WINTERIZATION Check with an authorized MasterCraft dealer’s service department Before starting you will need the following supplies: regarding your boat’s needs to determine if this is an appropriate time for annual service.
  • Page 192 Step 3 Run the engine for at least fifteen (15) minutes while in a body of Apply a coat of wax to the entire surface of the boat. MasterCraft water. This allows for the circulation of the additives throughout the Premium Marine Wax provides excellent coverage and is fuel system.

  • Page 193: Ballast System

    If you do not have a MasterCraft mooring cover, Step 4 • Attach a garden hose to the flush valve adapter mounted on...
  • Page 194 Remove all ballast bags (if applicable) and re-attach the bridge system. Failure to do so will result in any water in the ballast MasterCraft uses a -50 F RV type, nontoxic, propylene glycol based Bridge Connector connector (pictured to the left) to the ballast thru hull vent hose and system evacuating into the storage compartment, potentially antifreeze to winterize every boat built at the factory.
  • Page 195 Only an authorized battery charger should be used to OFF two (2) or three (3) times, allowing ten (10) seconds between Step 1 charge the battery(ies) in MasterCraft boats. Use only a three-stage Step 7 key cycles, before cranking the engine. This allows the fuel pump to Ensure the engine is OFF and the emergency safety stop switch is or more battery charger.

  • Page 196: Changing Propellers

    CHANGING PROPELLERS Step 7 Install the propeller nut and tighten it into place to 50-ft-lbs with a torque wrench. Step 1 Step 8 Ensure the engine is OFF and the engine safety starting switch is disconnected. Install a new cotter pin and bend the ends around the shaft to lock the propeller on the shaft.
  • Page 197 key should be inserted prior to starting an outing, and removed at the conclusion. This is intended to prevent theft or unapproved use of the boat. This is also an engine start and stop switch. DO NOT ATTEMPT TO SURF BEHIND THE NXT20 GLOBAL EDITION. Location DOING SO CAN CAUSE SERIOUS INJJURY OR DEATH.
  • Page 198 ENGINE EMERGENCY SAFETY Operation If the slide is pulled off the switch or if the slide is loose, the engine OPERATIONAL CONTROL Location STOP SWITCH will crank but will not start. To reattach the slide to the switch, move The shift/throttle control lever is located on the starboard side the slide into place as pictured.
  • Page 199 Purpose section or the “FEATURES AND CONTROLS” chapter of the Mercury immediately taken to an authorized MasterCraft dealer for attention. Outboard Owner’s Manual included with the NXT20 Global Edition. Purpose The steering system controls the direction in which the boat moves.

  • Page 200: Other Alarms

    LOW VOLTAGE BATTERY ALARM Operation FUEL FILTER Location Generally, the appropriate action is to leave the stereo OFF, as well The Vessel Mounted Water Separating Fuel Filter is located under as disengaging any other peripheral electrical components, and the rear bilge access hatch and is mounted on the transom. keying ON the engine.
  • Page 201 FIRE SUPPRESSION Location SKI CAGE Operation The Fire Extinguisher is located under the observer’s seat, mounted To lower the ski cage unscrew the bolts that go through the rear to the inside of the storage compartment as pictured. support legs and tilt the cage forward. To raise the cage to its normal operating position, tilt the cage upright, insert the bolts Operation and tighten them into place.

  • Page 202: Swim Platform

    ROPE DEFLECTOR Location SWIM PLATFORM The rope deflector is mounted on the transom of the NXT20 Global Edition and wraps around the motor. CONTACT WITH A SPINNING PROPELLER WILL CAUSE SERIOUS INJURY OR DEATH. SHUT OFF ENGINES WHEN PEOPLE ARE IN THE Operation WATER NEAR THE BOAT OR ON THE SWIM PLATFORM.
  • Page 203 Push knob visible from the starboard side, the kickstand is only visible with engine unit trimmed up. The kickstand is mounted on and take the boat to an authorized MasterCraft dealer for repair. the engine unit between the engine and the mounting bracket, between the hydraulic cylinders.
  • Page 204 TRAILERS 2017 OWNERS MANUAL / 402...
  • Page 205 Such damage is Please take a few minutes to read this section of the Owner’s Manual completely before using your MasterCraft trailer not covered by the Limited Warranty for the trailer. To avoid chipping for the first time.
  • Page 206 The correct method for determining the load limit is to: • Emergency brake cable authorized MasterCraft dealer for a check and possible repair. • Wiring connector Parking •...
  • Page 207 If this appears to be the problem, immediately Towing with water-filled bladder(s)/ballast tank(s) may not only contact your authorized MasterCraft dealer for assistance. Ignoring Load-Carrying Capacity exceed the total weight limits for the trailer, but may also result this symptom could result in brake failure.
  • Page 208 A weight-carrying hitch is rec- pressure adjustable shock absorbers may be installed on the tow ommended for use with a MasterCraft boat and trailer. However, vehicle, or you can switch from a weight-carrying to a weight-distrib- weight-distributing (equalizing) hitches may be used.
  • Page 209 The MasterCraft trailer was designed and built to be attached from the hitch ball doing so will slow the process of the dropping of Failure to properly attach the safety cables and brake actuator ator.
  • Page 210 NOTE: Because all pins, fasteners and other components are crank the boat onto the trailer. or lost, contact an authorized MasterCraft dealer to purchase a specially designed, high-strength components, any component re- The winch is intended solely as an aid to loading the boat on the replacement pin.
  • Page 211 Trailer Runway Lights By XKGlow An audible “click” will be heard. The latch should close with finger NOTE: See an authorized MasterCraft dealer if the tow vehicle does To Open The Coupler pressure. If the latch will not close freely, the ball is not fully inserted not have the correct trailer harness.
  • Page 212 If the bearings need to be adjusted or replaced, the work should be Maintain the proper torque on the lug nuts attached to the wheel done only by an authorized MasterCraft dealer. Failure to contact bolts. Failure to do so may result in serious injury or death and/or...
  • Page 213 Ensuring that lug nuts on trailer wheels are tight and properly sistance in assessing the trailer and its gear, and retain but do not Ensure that all lug nuts are secure prior towing a MasterCraft torqued is an important responsibility for maintaining your trailer in submersion in salt water at any time, requires immediate cleaning.
  • Page 214 If this is occurring, have the toe-in adjusted to The tires that come equipped on the MasterCraft trailer were safety and convenience, inflate tires to the air pressure indicated consistently too high. The tire is riding on the a proper setting.
  • Page 215 Braking System One side wear Worn components should be adjusted The trailer is equipped with a hydraulic brake actuator. Trailer brakes In instances where an inner or outer rib or replaced with new ones. The worn tire will automatically apply whenever the tow vehicle’s brakes are applied. Disc brakes offer several advantages over drum brakes.
  • Page 216 This causes worn parts replaced by an authorized MasterCraft dealer. DO NOT USE DOT 5 brake fluid in any component of MasterCraft the brakes to drag and overheat during subsequent outings. Wet brakes usually do not hold especially well. If the wheels have Consumers must use only DOT 3—preferred—or DOT 4 brake fluid.
  • Page 217 Let the fluid in the reservoir stand until it is completely on the front axle of tandem axle trailers, or the center then finally sition/angle of the trailer. All MasterCraft trailers have an electrical free of air bubbles. the front on triple axle trailers. If installation is on a tandem-axle The reverse lockout option must only be used when moving in solenoid control to allow the trailer to back up.
  • Page 218 Ensuring that a MasterCraft boat will be held securely in place on Also, it is very important to be sure that the transom of the Mas- the trailer’s hull support (bunks), especially when towing, is ex- terCraft boat is resting fully and securely on the supports provided tremely important.
  • Page 219 If Avoid sudden steering maneuvers Before making the first major trip or lake cruise with a MasterCraft the trailer coupler comes loose from the hitch ball, unlock and go trailer, make at least one short trial run to become familiar with its These may create sway or undue side force on the trailer.
  • Page 220 Well before stopping, turning, changing lanes or passing, use turn Make it as easy as possible for faster-moving vehicles to pass you. Every MasterCraft boat owner develops his or her own favorite this will vary depending on ramp angle. Set the parking brake and signals to let other vehicles know what you intend to do.
  • Page 221 Standard 18” 18” 18” • Breakaway cable is properly attached to the tow vehicle MasterCraft dealer can help in this regard. Otherwise, contact the 16” 16” 16” • Coupler and safety chains are safely secured to the hitch of the nearest state motor vehicle department.
  • Page 222 Brake pad replacement should be performed by an authorized Aluminum wheels also require attention to routine maintenance, MasterCraft dealer. Improper pad replacement may decrease • Ensure that all vehicle and trailer maintenance has been per- particularly in keeping them clean. Failure to do so may result in braking effectiveness, potentially resulting in a collision as a result formed as set out in this Owner’s Manual and the various other...
  • Page 223 1/8” at all, the bearings may need to be readjusted. • Have the wheel bearings checked by an authorized MasterCraft • Verify and/or correct tire pressure on both the tow vehicle and • Check the safety chains and attachment points for damage or dealer prior to reuse.
  • Page 224 Extended Storage (In Excess Of One Year) Coupler Latch Handle Not Opening Or Closing Easily When Braking, Brakes Repeatedly Come On And Re- lease. Braking Is Not Smooth, Called “Chucking” Follow the recommendations listed above for storage of several months duration. Additionally: Possible Cause Remedy If the latch handle does not close freely, DO NOT tow the trailer...
  • Page 225 If frozen in place, caused the brakes to rized MasterCraft dealer. • Check that the reservoir is properly filled. drums/rotors for wear or damage. brake pads to release.
  • Page 226 Boat sections of the MasterCraft Owner’s Manual, the gel warranties of merchantability and fitness for a particular purpose, coat, which is applied to all MasterCraft boats at the factory, will be other than those warranties which are implied by, and are incapable...
  • Page 227 • Anodes (on transom, shaft, attitude adjustment plate and WSD’s); tured by MasterCraft in model years which run from July 1 of a given show signs of discoloration and/or blisters if the boat is left in the age resulting from alteration, modification, repair or replacement year through June 30 of the immediately following year (a “Model...
  • Page 228 Limited Warranty Limited Warranty is for the benefit of the owner and MasterCraft, tesy, dash and tower lights (excluding light bulbs); pired Limited Warranty coverage shall be transferred to the second shall immediately be terminated and the Limited Warranty shall and shall not create or evidence any right in any third party.
  • Page 229 (a) the sale of the boat by the original retail purchaser occurs within tors or suppliers shall create a warranty or in any manner increase At the time of delivery to the first retail owner of a MasterCraft boat, Attention: Warranty/Customer Service five (5) years of the date of the original retail purchase of the boat;...
  • Page 230 MASTERCRAFT LIMITED WARRANTY TRANSFER FORM Upon verification of the submitted documentation, any remaining warranty coverage under the Limited Warranty will be transferred to the second owner, with all warranty coverage periods running from the applicable date described in Section 2.5 of the Limited Warranty...

  • Page 231: Service Log

    SERVICE LOG - BOAT Every 100 hours Date Date Date Date Date Change transmission fluid As Needed Date Date Date Date Date Check engine mounts Replace raw water impeller Check prop shaft coupling alignments Replace ballast impeller(s) Inspect exhaust flaps Add/change oil filter Lubricate steering system Every 50 Hours...
  • Page 232 SERVICE LOG - TRAILER 3-6 Months/250 miles Date Date Date Date Date Annually/Every 2,000 miles Date Date Date Date Date Grease trailer jack Check brake fluid and for leaks Oil trailer jack handle Check breakaway cable Check pain for chips and nicks Examine entire trailer for damage or wear Check trailer bunks for abnormal wear Lubricate Rollers...
  • Page 233 BOW – The forward portion of the boat. BULKHEAD – Vertical partition (wall) in a boat. BUNKS – Carpeted trailer hull supports. MasterCraft boats rest ABYC – American Boat and Yacht Council, Inc. directly on carpeted trailer bunks when loaded onto their trailers.
  • Page 234 NAVIGATION AID – Recognizable objects on land or sea such as MasterCraft boats that calculates fuel burn and fuel tank volume to buoys, towers or lights, used to identify safe and unsafe waters.

  • Page 235: Boat Operations

    INDEX 3-in-1 Gauge: Engine Oil Pressure ..............81 3-in-1 Gauge: Fuel Gauge ................80 Ballast System Preparations ..............255 3-in-1 Gauge: Temperature ................82 Ballast System Winterization ..............378 12-Volt Receptacle ....................215 Ballast Systems ....................255 Bar, Wet ........................294 INDEX Basic Electrical Components ..............207 Basic Maneuvering ...................331 Basic Navigation Features ................
  • Page 236 Corrosion Prevention ..................341 Corrosion, Salt Water ..................343 Cable, Breakaway ....................410 Features, Basic Navigation ................43 Hazardous Operations ..................06 Coupling Alignment, Check the Propeller Shaft ......367 Cables, Safety ...................... 409 Fire Extinguishers ....................14 Head and Toilet System ................351 Courtesy/Storage Compartment Lights ..........245 Canvas Covers ....................
  • Page 237 Marine Growth ..................... 344 Reactivating The Boat After Storage ..........380 Meeting ........................41 Reading Buoys and Other Markers ............44 Jack, Trailer ......................427 Personal Flotation Devices (PFD) and Accessibility ..... 12 Mirrors ........................225 Receptacle, 12-Volt ...................215 Plan, Float ........................36 Mounts - Check the Engine ................367 Recommended Equipment ................

  • Page 238: Sport Enhancement

    Single Battery .......................210 Telephones, Radio ....................31 Ski/Wakeboard/Surf Rope ................. 227 Temperature Gauge: 3-in-1 ................82 Sleeves, Surf ....................... 303 The MasterCraft Trailer ..................401 Slot, Ignition Key ....................215 The Trailer Hitch ....................407 Zinc Anode ......................239 Sound Production Devices ................23 Throttle System, Lubricate ................

This manual is also suitable for:

X20 2017Prostar 2017Xstar 2017Xt20 2017Xt21 2017X46 2017 ... Show all

Table of Contents

Save PDF
