Dvico FusionHDTV Before Getting Started

Hide thumbs Also See for FusionHDTV:
Table of Contents

Advertisement

Quick Links

See also: User Manual
usio
1. Before Getting Started
2. Software Installation
3. Hardware Installation
4. Using DigiREC-HD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionHDTV and is the answer not in the manual?

Questions and answers

Related Manuals for Dvico FusionHDTV

Summary of Contents for Dvico FusionHDTV

  • Page 1 usio 1. Before Getting Started 2. Software Installation 3. Hardware Installation 4. Using DigiREC-HD...
  • Page 2 Agreement or the use of or inability to use the Products, even if DViCO has been advised of the possibility of such damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability for consequential or incidental damages, the above limitation applies only to the extent permitted by applicable law.
  • Page 3 (including attorneys’ fees and costs) arising out of or relating to any claims that Licensee’s use of the Products in conjunction with any Licensee Application infringes the patent, copyright, trademark, trade secret, or other proprietary rights of any third party, or resulting from any breach of this Agreement by Licensee.

  • Page 4: Table Of Contents

    Before Getting Started ..................5 FusionHDTV Specification..................5 FusionHDTV System Requirements............... 7 Package contents ....................8 Software Installation ................... 11 Installing FusionHDTV Applications..............11 Driver installation under Windows ME..............21 Driver installation under Windows 2000 Professional .......... 32 Driver installation under Windows XP ..............55 Hardware Installation..................68...

  • Page 5: Before Getting Started

    You can record live HDTV broadcasting streams to a PC and play them back anytime you want. Using most recent VSB tuner – Best DTV reception rate FusionHDTV uses the most recent VSB tuner to get the best reception rate, so you can get the un- interrupted and stable HDTV screen.
  • Page 6 Embeds the TitanTV EPG on the FusionHDTV application. Time Shifting FusionHDTV provides the various file playback functions just like live TV mode. That is, pause/ instant replay/ time-shifting by scroll bar/ fast-forward/ fast-rewind. Being interrupted while watching live TV programs (such as pick up phone calls & answer the door), all you need to do is simply press the Pause button and freeze the picture for a period of time, and then pick up right where you left off.

  • Page 7: Fusionhdtv System Requirements

    FusionHDTV System Requirements System requirements for FusionHDTV are as follows <Input/Output> One TV antenna One CABLE antenna One inside stereo connection jack to sound card for analog TV S-Video IN, Composite IN External Sound card Connection cable < DVB-T USB>...

  • Page 8: Package Contents

    Package contents The FusionHDTV package contains the following items: [FusionHDTV I] ① FusionHDTV card ② Setup CD ③ Manual ④ Internal cable to sound card for Analog TV Audio [FusionHDTV II] ① FusionHDTV card ② Setup CD ③ Manual ④ Internal cable to sound card for Analog TV Audio ⑤...
  • Page 9 ⑤ External source audio connection cable [FusionHDTV DVB-T ] ① FusionHDTV card ② Setup CD ③ Manual ④ Internal cable to sound card for External output Audio ⑤ External source audio connection cable [ DVB-T PLUS] ① FusionHDTV card ② Setup CD ③...
  • Page 10 * Optional FusionHDTV remote transceiver ① FusionHDTV transceiver Receiver ② <Important Notice> First install the software before you plug the FusionHDTV card in your system. It will ease the installation process. If you plugged the card in already, you can still proceed anyway.

  • Page 11: Software Installation

    ) before you install the software included in the CD. Installing FusionHDTV Applications Insert FusionHDTV Installation CD into the CD-ROM drive. The setup window will automatically pop up. if you downloaded the recent version on DATOptic’s website, please run install.exe or setup.exe.
  • Page 12 2.1.2 Installing FusionHDTV Software Important: Installation on Windows 2000 Professional or Windows XP Before you install FusionHDTV software, be sure that you logged on as an account with Administrator privileges. Select “Install FusionHDTV”. At the FusionHDTV Installation dialog opens, click on the “Next>” button.
  • Page 13 4) The “Choose Destination Location” window will appear. Click on “Next” if you want to install the FusionHDTV in the default directory. Otherwise, you can choose a different directory by clicking on “Browse”. 5) Press “Next” on the Destination Folder selection window.
  • Page 14 7) Choose your country, then click “OK”. 8) PC specification selection windows will appear. Please select the appropriate system. You can change the mode after installation with configuration menu of the application program. You do not need to reinstall the program with different options.
  • Page 15 9) Select your FusionHDTV card, and Press ‘Next’ to install latest drivers. 10) You will see the progress window.
  • Page 16 14) When you reboot, the system will ask for the 5~6 drivers. Please click “Yes” when the digital signature window appears. <Notes> In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVico\FusionHDTV\driver folder.
  • Page 17 Installing Microsoft DirectX 9 Important! Installing on Windows 2000 Professional or Windows XP Before you install FusionHDTV software, be sure that you logged on as an account with Administrator privileges. You can check the version of DirectX by typing “dxdiag” on the command line which appears with menu selection “start->run”...
  • Page 18 If there is a DirectX already installed in the system, a different window will show up instead of the one above. 4) Click on “Finish” to restart system and complete installation of the DirectX.
  • Page 19 Installing the FusionHDTV remote transceiver Installation Caution • Remote transceiver is optional and can be purchased separately through FusionHDTV dealers. • First, install the FusionHDTV application then install the FusionHDTV remote transceiver program. Important: Installation on Windows 2000 Professional or Windows XP Before you install FusionRemote software, be sure that you logged on as an account with Administrator privileges.
  • Page 20 4) Click on the “OK” to restart and finish installation.

  • Page 21: Driver Installation Under Windows Me

    Installing the Windows ME driver [ FusionHDTV I ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically. 2) Found New Hardware window will pop and FusionHDTV, WDM Video Capture driver will be installed automatically.
  • Page 22 [ FusionHDTV II ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically. 2) The Found New Hardware window will pop and FusionHDTV, WDM Video Capture driver will be installed automatically.
  • Page 23 (Tuner/SVHS/Video)” driver installation will be done automatically. [ FusionHDTV III ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically. 2) The Found New Hardware window will pop and FusionHDTV 88x, WDM Video Capture driver will be installed automatically.
  • Page 24 6) The Add New Hardware Wizard will pop up automatically and “FusionHDTV 88x, TEMIC+LG3302 WDM TV Tuner” driver installation will be done automatically. 7) The Add New Hardware Wizard will pop up automatically and “FusionHDTV 88x, Crossbar” driver installation will be done automatically.
  • Page 25 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically. 2) The Found New Hardware window will pop and FusionHDTV 88x, WDM Video Capture driver will be installed automatically.
  • Page 26 Tuner/Demod (T7579+MT352)” driver installation will be done automatically. [ DVB-T Lite ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically. 2) The Found New Hardware window will pop and FusionHDTV, WDM Video Capture driver will be installed automatically.
  • Page 27 In certain cases , Windows will ask for the Kstvtune.ax files. You can locate the ax files in the C:\Windows\System folder. 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows ME starts, the Add New Hardware Wizard will pop up automatically.
  • Page 28 4) The Add New Hardware Wizard will pop up automatically and “FusionHDTV USB, BDA DVB-T Tuner/Demod (T7579+MT352)” driver installation will be done automatically. 2.2.3 Checking Windows ME driver If all four drivers are found in the device manager, the Windows ME driver is installed properly. Otherwise, you must reinstall the driver.
  • Page 29 [ FusionHDTV III ] [ FusionHDTV DVB-T ]...
  • Page 30 ** In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder. Or Windows will ask for the Kstvtune.ax files. You can locate the ax files in the C:\Windows \System folder.
  • Page 31 [ DVB-T Lite ] [ DVB-T USB ]...

  • Page 32: Driver Installation Under Windows 2000 Professional

    Installing Windows 2000 driver [FusionHDTV I] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically. 2) When the Digital Signature Not Found window appears, Click on “Yes”.
  • Page 33 4) When the Digital Signature Not Found window appears, Click on “Yes”. 5) ‘New Hardware Wizard window’ will pop up automatically. 6) When the Digital Signature Not Found window appears, Click on “Yes”. 7) ‘New Hardware Wizard window’ will pop up automatically.
  • Page 34 8) When the Digital Signature Not Found window appears, Click on “Yes”.
  • Page 35 [ FusionHDTV II ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically. 2) When the Digital Signature Not Found window appears, Click on “Yes”.
  • Page 36 5) The “New Hardware Wizard” window will pop up automatically. 6) When the “Digital Signature Not Found” window appears, Click on “Yes”. 7) The “New Hardware Wizard” window will pop up automatically.
  • Page 37 8) When the “Digital Signature Not Found” window appears, Click on “Yes”. [ FusionHDTV III ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically.
  • Page 38 3) The “Found New Hardware” Wizard window will pop up automatically. 4) When the Digital Signature appears, Click on “Yes”. 5) When the “Completing…” window appears, Click on “Finish”.
  • Page 39 6) The “New Hardware Wizard” window will pop up automatically. 7) When the “Digital Signature Not Found” window appears, Click on “Yes”. 8) The “New Hardware Wizard” window will pop up automatically.
  • Page 40 9) When the “Digital Signature Not Found” window appears, Click on “Yes”. 10) The “New Hardware Wizard” window will pop up automatically. 11) When the “Digital Signature Not Found” window appears, Click on “Yes”.
  • Page 41 (ex : C:\Program Files\Dvico\FusionHDTV\driver) or Driver folder of installation CD. [ FusionHDTV DVB-T ] 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically. 2) When the Digital Signature Not Found window appears, Click on “Yes”.
  • Page 42 5) The “New Hardware Wizard” window will pop up automatically. 6) When the “Digital Signature Not Found” window appears, Click on “Yes”. 7) The “New Hardware Wizard” window will pop up automatically.
  • Page 43 In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder. 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically.
  • Page 44 3) The “New Hardware Wizard” window will pop up automatically. 4) When the “Digital Signature Not Found” window appears, Click on “Yes”. 5) The “New Hardware Wizard” window will pop up automatically.
  • Page 45 6) When the “Digital Signature Not Found” window appears, Click on “Yes”. 7) The “New Hardware Wizard” window will pop up automatically. 8) When the “Digital Signature Not Found” window appears, Click on “Yes”.
  • Page 46 In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder. 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically.
  • Page 47 3) The “New Hardware Wizard” window will pop up automatically. 4) When the “Digital Signature Not Found” window appears, Click on “Yes”. 5) The “New Hardware Wizard” window will pop up automatically.
  • Page 48 6) When the “Digital Signature Not Found” window appears, Click on “Yes”. 7) The “New Hardware Wizard” window will pop up automatically. 8) When the “Digital Signature Not Found” window appears, Click on “Yes”. 9) The “New Hardware Wizard” window will pop up automatically.
  • Page 49 In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV USB \driver or C:\Windows\System32\Drivers folder. 1) Insert the FusionHDTV board into the PCI local bus slot. When Windows 2000 starts, the Add New Hardware Wizard will pop up automatically.
  • Page 50 3) After files are copied, Click “Finish” if the “FusionHDTV USB, BDA Receiver Component (DVB-T2)” driver is properly installed. Using this way, you may install “FusionHDTV USB, WDM TvTuner DVB-T (Thomson7579)“, “FusionHDTV USB, HID IR Remote“, “HID Compliant device, FusionHDTV USB, BDA DVB-T Tuner/Demod (T7579+MT352) “drivers.
  • Page 51 Right click the “My Computer” icon and select “properties” from the popup menu. Select Hardware-> Device Manger You must see four devices properly installed under “Sound video and game controllers”. If you do not see all four drivers installed correctly, please re-install the drivers. [FusionHDTV I]...
  • Page 52 [FusionHDTV II] [ FusionHDTV III ]...
  • Page 53 [ FusionHDTV DVB-T] [ DVB-T PLUS ]...
  • Page 54 [ DVB-T Lite ] [ DVB-T USB ]...

  • Page 55: Driver Installation Under Windows Xp

    4) Check Windows XP Device Manager (with reference to 2.4.3 Checking Windows XP Driver ) 2.4.2 Installing Windows XP drivers If you already installed the FusionHDTV software, insert the FusionHDTV board into the PCI local bus slot. [ FusionHDTV III ] 1) When the “Add New Hardware Wizard window”...
  • Page 56 3) After files are copied, Click “Finish” if the FusionHDTV 88x, TEMIC+LG3302 WDM TvTuner driver is properly installed. Using this way, you may install “FusionHDTV 881, Audio Capture “, “FusionHDTV 88x, Transport Stream Capture(ATSC-A)“, “FusionHDTV 88x, Video Capture “, “FusionHDTV 88x, Crossbar “drivers.
  • Page 57 1) When the “Add New Hardware Wizard window” appears, select “Install the software automatically (Recommended)” and then click “next”. 2) When the ”FusionHDTV 88x, LGZ201 DVB-T WDM TvTuner” window appears, Click “Continue Anyway”. 3) After files are copied, Click “Finish” if the FusionHDTV 88x, LGZ201 DVB-T WDM TvTuner driver is properly installed.
  • Page 58 Using this way, you may install “FusionHDTV 88x, Transport Stream Capture(DVB-T)“, “FusionHDTV 88x, Video Capture “, “FusionHDTV 88x, Crossbar “drivers. [ DVB-T PLUS ] In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder.
  • Page 59 5) When the ”FusionHDTV 88x, Thomson7579 DVB-T WDM TvTuner” window appears, Click “Continue Anyway”. 6) After files are copied, Click “Finish” if the “FusionHDTV 88x, Thomson7579 DVB-T WDM TvTuner” driver is properly installed.
  • Page 60 Using this way, you may install “FusionHDTV 88x, Transport Stream Capture(DVB-T)“, “FusionHDTV 88x, Video Capture “, “FusionHDTV 88x, Crossbar, FusionHDTV 88x, BDA DVB-T Tuner/Demod (T7579+MT352) “drivers. [ DVB-T Lite ] 1) When the “Add New Hardware Wizard window” appears, select “Install the software automatically...
  • Page 61 2) When the ”FusionHDTV, Thomson7579+MT352 WDM TvTuner” window appears, Click “Continue Anyway”. 3) After files are copied, Click “Finish” if the FusionHDTV, Thomson7579+MT352 WDM TvTuner driver is properly installed. Using this way, you may install “FusionHDTV, Transport Stream Capture(DVB-T)“, “FusionHDTV, Video Capture “, “FusionHDTV, Crossbar(Tuner only), FusionHDTV, BDA DVB-T Tuner/Demod (T7579+MT352)
  • Page 62 1) When the “Add New Hardware Wizard window” appears, select “Install the software automatically (Recommended)” and then click “next”. 2) When the ”FusionHDTV USB, BDA Receiver Component (DVB-T2)” window appears, Click “Continue Anyway”. 3) After files are copied, Click “Finish” if the “FusionHDTV USB, BDA Receiver Component (DVB-T2)” driver is properly installed.
  • Page 63 Using this way, you may install “FusionHDTV USB, WDM TvTuner DVB-T (Thomson7579)“, “FusionHDTV USB, HID IR Remote“, “HID Compliant device, FusionHDTV USB, BDA DVB-T Tuner/Demod (T7579+MT352) “drivers.
  • Page 64 Right click the “My Computer” icon and select “properties” from the popup menu. Select Hardware-> Device Manger. You must see four devices properly installed under the “Sound video and game controllers”. If you do not see all four drivers installed correctly, please re-install drivers. [FusionHDTV I]...
  • Page 65 [ FusionHDTV II ] [ FusionHDTV III ]...
  • Page 66 [ FusionHDTV DVB-T] [ DVB-T PLUS ] [ DVB-T Lite ]...
  • Page 67 [ DVB-T USB ]...

  • Page 68: Hardware Installation

    Hardware Installation About the Board [ FusionHDTV I ] Analog Audio output port Antenna input port Antenna input port: Connects to the antenna Analog audio output port: Connects to the LINE_IN or equivalent (CD-IN, TV-IN). terminal of the sound card. This for analog TV receiving.
  • Page 69 [ FusionHDTV II ] Analog Audio Output Port AUDIO-OUT Air Antenna Cable Antenna Composite-IN SVideo-IN AUDIO-IN AUDIO-OUT: Can be connected to the Line-in port of the Sound card. Air Antenna: Connects to the terrestrial signal Cable Antenna: Connects to the Cable signal (This is used when the cable company sends the HDTV signal using the 8VSB method) Composite-IN: For external video sources.
  • Page 70 [ FusionHDTV III ] Analog Audio Output Port Air Antenna Cable Antenna Composite-IN AUDIO-IN AUDIO-OUT: Can be connected to the Line-in port of the Sound card. Air Antenna: Connects to the terrestrial signal Cable Antenna: Connects to the Cable signal (This is used when the cable company sends the HDTV signal using the 8VSB method) Composite-IN: For external video sources.
  • Page 71 [ FusionHDTV DVB-T] Analog Audio Output Port Air Antenna Composite-IN SVideo-IN AUDIO-IN Air Antenna: Connects to the terrestrial signal Composite-IN: For external video sources. SVideo-IN: For external video sources. AUDIO-IN: For the audio of external video sources.
  • Page 72 [ DVB-T PLUS ] Analog Audio Output Port Air Antenna Thru Pass Port Video -IN Air Antenna: Connects to the terrestrial signal. Thru Pass Port : The Thru Pass mean that you can plug your antenna into the card and then another cable into the card to act as a repeater signal for another TV.
  • Page 73 [ DVB-T USB ] Remote Receiver USB Port Air Antenna Thru Pass Port USB Port : Connects USB Port. Air Antenna: Connects to the terrestrial signal. Thru Pass Port : The Thru Pass mean that you can plug your antenna into the card and then another cable into the card to act as a repeater signal for another TV.

  • Page 74: Before Installation

    Insert the board by holding the top part of the board and push it until it completely locks into the slot. Fasten the screw on the bracket using a screw driver. Connect the Antenna input port to an antenna cable. [FusionHDTV I]...
  • Page 75 [ FusionHDTV II ] [ FusionHDTV III ] [ FusionHDTV DVB-T ] [ DVB-T PLUS ]...
  • Page 76 [ DVB-T Lite ] Air Antenna Thru Pass Port [ DVB-T USB ] After the board installation, when the power is on, the driver search message will appear. Please refer to chapter 2 for driver Installation.

  • Page 77: Remote Installation

    Connect the IR receiver module to the PC’s serial port(COM1, COM2…) or USB port.There are two types receivers serial or USB After IR receiver and FusionHDTV remote software is installed, please reboot and start the configuration by right cliking the FusionRemote icon at the low right bottom of the screen. If you do not see the FusionRemote icon in the tray, please start the program by Start->Program->DViCO-...
  • Page 78 FusonRemote program will start automatically when the PC is booted. You can check the FusionRemote program availability at the Task Bar of Windows like the picture below.

  • Page 79: Using Fusionhdtv

    Starting and Quitting Click Start, point to Program->DVICO->FusionHDTV, or double click on the FusionHDTV icon in the program folder to execute FusionHDTV. When you first execute the program, it will ask for a channel scan. Please say “Yes” for the channel scan.
  • Page 80 CUT mode file playback: Change cut edit playback mode. Always On Top: Shows FusionHDTV application always on top. Second language : Second language can be heard with checking "Audio > Second Language" option when it is available in digital broadcasting.
  • Page 81 4.2.2 Controller This indicates Control Buttons. 1 2 3 4 5 1) Exit button 2) Minimize 3) Maximize button 4) Configuration button 5) Help button 6) Reserve REC button: is used to Reservation record. 7) LiveTV button: Changes to live TV mode. 8) Input button: is used to select input signal.
  • Page 82 You can press stop when recording if you want to record the content without viewing. 25) Instant Replay button: goes 10 sec backward by default. You can configure the instant replay time in the configuration menu. 26) Record button 27) Cut Edit button: Is used to edit a recorded file. 28) Mark in button: Mark in the start point where the cut starts.

  • Page 83: Configuration

    Configuration Configuration: ( ), you can Configure many parameters. 4.3.1 Video Video settings tab. Input Source : Selects between multiple external video sources. You can select antenna input between Tuner (OTA) or Cable Cropping : flickering lines near the top or bottom of the picture can be removed with cropping function Video tap is possible with adjust Brightness/contrast/Hue/Saturation/Sharpness.
  • Page 84 CUT mode file playback : when you move to the position with scroll bar on the controller of the FusionHDTV, it automatically pause when this option turned on. FullScreen Refresh : it automatically sets the refresh rate of Screen to 60Hz to optimum display.
  • Page 85 - Intel Pentium 4 : CPU 2.4GHz, FSB 800, AGP 8X - AMD Athlon XP : CPU 2400+, AGP 8X < Dvico HDTV (DxVA) Video Decoder> For DxVA compatible graphics cards. ATI Radeon,Geforce4 MX,Ti series cards. Audio Decoder: Is used to select the audio decoder.
  • Page 86 4.3.3 Record This section indicates Record settings. Capture Native Record : You can record Tp stream to mpeg format with maintaining Video, Resolution, Audio information. (only with the sub-channels). Recording Folder: Sets the folder of files being recorded. Limitless Recording: If the record drive is formatted with NTSF, you are able to record a file continuously on a hard drive.
  • Page 87 4.3.4 Channel This section indicates Channel settings: terrestrial digital analog channels and cable digital /analog channels. TV : Select Cable or Air depending on your antenna connection. Type : Scan wanted type. You can scan both. Manual Tune : Check/uncheck wanted/unwanted channels. You can change the station name by clicking on names.
  • Page 88 4.3.5 Add To Favorite Channel List Add your favorite programs into favorite list before watching them. Hit the STAR( ) button above the Channel number. Click Insert button and add programs from Channel list to Favorite list. Click Delete button and delete the programs from Favorite list Click Insert All button and add all of the programs from Channel list to Favorite list Click Delete All button and delete all of the programs from Favorite list Click OK and set up current favorite list.
  • Page 89 4.3.6 Audio This section indicates Audio settings. TV Multi-Sound : is used to select the analog mono ,stereo or Multi-Language. TV Audio Input: When you watch outer input(S-VHS,Video), you can set the input of sound card. Analog Audio Attenuation : Analog audio level can be adjustable. Digital Audio Output: is used to select the audio output: 2 CH SPEAKER, 5.1CH SPEAKERS or S/PDIF.
  • Page 90 4.3.7 Analog This section indicates Analog settings. Size(NTSC) : Initialize to VCD : 352*240 , S-VCD : 480*480 ,MPEG-1 : 320*240 MPEG2 : 640*480 ,DVD : 720*480 Size(PAL) : Initialize to VCD : 352*288 , S-VCD : 480*576 ,MPEG-1 : 320*288 MPEG2 : 720*576 ,DVD : 720*576 Quality : When MPEG-1,MPEG-2,DVD ,You can select Lowest,Low,Normal,High,Highest.
  • Page 91 4.3.8 OSD This section indicates OSD settings. Show OSD: Is used to show channel and volume; on screen display. Show Signal Strength : Is used to show Signal Check.( % or db) Use BIG OSD : Is used to FusionRemote. Advanced OSD : If you click (MENU button) on remote controller, you can use advancedOSD Setting.

  • Page 92: Time Shifting

    (Instant replay button), and it’s adjustable from 2 to 60 seconds. Time-shifting buffer size means that temporary buffer size of FusionHDTV for the time-shifting functionality (like pause/ FF/ REW/ instant replay/ time-shift slider bar), and it’s adjustable from 1 to 120 minutes.

  • Page 93: Record

    Manual Record When you want record On-Air right away, click (Record button) on FusionHDTV‘s controller. If you want to terminate recording, click on the “Finish” button. The files recorded within that time will be saved.If you want to cancel recording, click on the “Cancel” button.
  • Page 94 4.4.2 Recording Scheduler This mode is enabled by pressing popup menu(Recording Scheduler). You can easily set the Channel/Date/ start time / Duration/Cycle of the TV program you want to record. Click Insert( ) button and add Recording Schedule list. Click Delete( ) button and delete Recording Schedule list.

  • Page 95: Playing Files

    Playing Files If you click on the “open file” button on the controller, you can play a file. You can also select multiple files for playback. Difference between a *.tp and *.tpl file: *.tp files are recorded files that are formatted for HDTV *.tpl file is a file that represents multiple files when one program is recorded to multiple files.

  • Page 96: Snapshot Capturing

    SnapShot Capturing FusionHDTV provides high resolution still screen capture capability in live playback as well as in file playback mode. Click the snapshot button for capturing a snapshot of LiveTV while in playback or file playback mode. In the Record Tab, you can set the file name and file format.

  • Page 97: Using Epg

    Using EPG 4.7.1 Reserved program List Reserved program list shows the program that you reserved. If you need to cancel reservation, select the program and click Button( Recording Scheduler list shows the program that you reserved.If you need to cancel reservation, select the program and click button(...
  • Page 98 4.7.2 DVB-T EPG DVB-T EPG(Electronic Program Guide) tells present/following Program for DVB-T. Click EPG Button( ), or EPG( ) on the FusionRemote. You can arrow Key with FusionRemote or keyboard. If you want to exit , Click You can easily record the present/following Program you want to record.
  • Page 99 4.7.3 TitanEPG EPG(Electronic Program Guide) tells you exactly what you can see at your location. You can use EPG to see quickly what's on for digital and analog broadcasts and data casting services When you first visit TitanTV, Click TitanTV icon( ) and you must sign up( ) to become a member before viewing your channel guides.
  • Page 100 1) TitanTV logo in top left hand corner 2) Watch Now icon( ) must be present 3) PVR icon( ) must be present. Red “HD” must be present in one or more program cells 4) All channels must have program listings data 5) Variety of networks in channel lineup 6) Variety of genres (color codes) in program grid 7) My Favorites tab present...
  • Page 101 This mode is enabled Shutdown the program or Turn the system off after the recording is finished. 1) Execute the FusionHDTV program and right click the “Tray” icon. If you do not see the FusionTray icon in the tray, uncheck ‘Fusion Tray Auto Run’. Start the program by Start->Program->DViCO- >FusionHDTV Agent.

  • Page 102: Cut Editing

    Cut Editing You can cut the live recording/broadcast files as well as recorded .tp file with the cut-editing feature of the FusionHDTV. 1) The cut-editing window will appear if you hit the ‘Cut’ button. (Mark-in/out button also brings the cut- editing window) 2) You can set the prefix name on the ‘Prefix’...
  • Page 103 5) To change the file name, just click the file name area. The edit-box will appear and you can type the filename. To change the IN/OUT position, just click the spot you want to change. The edit-box and up/down buttons will appear for you to change the position. To change the hour / minute/ second, click each area you want.

  • Page 104: Using Fusionremote

    Using FusionRemote * Optional FusionHDTV remote transceiver. This indicates Remote Buttons. 4.9.1 Using For FusionHDTV 1) HDTV button: Start or Exit FusionHDTV program. 2) PC OFF button 3) ~ 12) number button 13) Snapshot button: is used for still image capture.
  • Page 105 28) Fullscreen button: Show Fullscreen. 29) EPG button: Show Reservation/Recorded List. 30) Mute button 31) Windows button: Change Windows. 32) FOCUS button: move to FusionHDTV Controller. 33) Minimize button 34) Input button: repeat S-VHS – VIDEO – CABLE – Tuner 35) Back Channel button 36) Profile button: You can have different profile for each application programs you want to use with the remote controller.
  • Page 106 [ DVB-T USB Remote ] 1) HDTV button: Start or Exit FusionHDTV program. 2) ~ 11) numberic button 12) Back Channel button. 13) Mute button 14) Snapshot button: is used for still image capture. 15) Volume UP button 16) Record button.
  • Page 107 4.9.2 Using other Windows 1) UP button 2) LEFT button 3) Enter button 4) RIGHT button 5) DOWN button 6) TAB button 7) Shift + TAB button 8) ESC button...
  • Page 108 4.9.3 Using Remote profile program You can use Fusion Remote as the simple replacement of the keyboard. press the blue button on the remote transceiver for customizing the remote transceiver keys for the program you selected. 1. WinAMP 1) Excute WinAMP 2) PC OFF 3) ~ 12) : Numeric key 13) Pause...
  • Page 109 2. PowerDVD 1) Excute PowerDVD 2) PC OFF 3) ~ 12) Numeric key 13) Pause 14) Exit PowerDVD 15) Returns to previous chapter 16) Volume DOWN 17) Plays media 18) Volume UP 19) Jumps to next chapter 20) Step Backward 21) STOP 22) Step forward 23) Ejects Disk...
  • Page 110 3. Window Media Player 9 1) Excute WMPlayer 2) PC OFF 3) ~ 12) : Numeric key 13) Snapshot 14) Exit WMPlayer) 15) Previous File 16) Volume DOWN 17) Toggle Play/Pause 18) Volume UP 19) Next File 20) Step Backward 21) STOP 22) Step forward 23) Open File...
  • Page 111 4. Window MCE 2005 1) Excute Window MCE2005 2) PC OFF 3) ~ 12) : Numeric key 13) Pause 14) Record 15) UP arrow key 16) LEFT arrow key 17) Select (Enter key) 18) RIGHT arrow key 19) DOWN arrow key 20) Rewind 21) PLAY 22) Fast Forward...
  • Page 112 4.9.4 Using Customize mode When you are not using the FusionHDTV, you can use Fusion Remote as the simple replacement of the keyboard. You can define the key-button mapping of any program you want to use with the FusionRemote. Please refere to the instruction below.
  • Page 113 4) Please press the blue button on the remote transceiver for customizing the remote transceiver keys for the program you selected. 5) If you press the Customize… button on the picture above you will see the remote transceiver pop up.
  • Page 114 6) Please press button on the remote transceiver and input the keys or short cut keys you want to map to the button. Press SaveAll button when you are done...
  • Page 115 7) Clear button clears the button defined. 8) You can set the OSD setting in accordance to each profile like the picture below.

  • Page 116: Using Signal Checker

    Please do not execute Fusion Program and signal checker at the same time. They only work one at a time. 1) Start – Program– Dvico – FusionHDTV – Signal Checker 2) Press Scan CHs (Scan Channels) button to search the channel.

  • Page 117: Using Fusionconverter

    4.11 Using FusionConverter You can Convert Tp files to MPEG2,DVD or DivX Files. FusionConverter works in 1080i, 576p, 576i Start->Program->DVICO->FusionConverter 2. Use file open button to select Tp file to convert. Use file save button to locate the converted file to be saved.
  • Page 118 Use “MP2” Audio format option if you burn the DVD authoring tool.(Ex. Ulead Videostudio 7 SE DVD)

  • Page 119: Fusionhdtv Shortkey

    4.12 FusionHDTV ShortKey Short Key Explanation HELP A+Numeric Analog Channel D+Numeric Digital Channel ALT+F4 Exit. ALT+T Time-Shifting On/Off ALT+W Show WallPaper Page Up Fast Foward (FF) Page Down Rewind (REW) Backspace Instant Replay. ALT+Enter Fullscreen CTRL+Space Mute. Repeat all Aspect ratio...
