Dvico FusionHDTV User Manual

Dvico fusionhdtv pci card: user guide
Hide thumbs Also See for FusionHDTV:
Table of Contents

Advertisement

Quick Links

1
Before Getting Started ............................................................................... 2
1.1
FusionHDTV Specification .......................................................................................................... 2
1.2
FusionHDTV System Requirements ........................................................................................... 4
1.3
Package contents ....................................................................................................................... 5
2
Software Installation ................................................................................... 6
2.1
Installing FusionHDTV Applications ............................................................................................ 6
2.2
Driver installation ....................................................................................................................... 11
3
Hardware Installation ............................................................................... 14
3.1
About the Board ........................................................................................................................ 14
3.2
Before Installation PCI card ...................................................................................................... 16
3.3
Connecting Power UP cable ..................................................................................................... 17
3.4
PCI Board Installation ............................................................................................................... 18
3.5
Remote Installation ................................................................................................................... 19
4
Using FusionHDTV ................................................................................... 20
4.1
Starting and Quitting ................................................................................................................. 20
4.2
Display setup ............................................................................................................................ 20
4.3
Using FusionRemote ................................................................................................................ 24
4.4
FusionHDTV Shortcut Key ....................................................................................................... 25
5
Technical Support .................................................................................... 26
FusionHDTV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionHDTV and is the answer not in the manual?

Questions and answers

Related Manuals for Dvico FusionHDTV

Summary of Contents for Dvico FusionHDTV

  • Page 1: Table Of Contents

    Before Getting Started ... 2 FusionHDTV Specification ... 2 FusionHDTV System Requirements ... 4 Package contents ... 5 Software Installation ... 6 Installing FusionHDTV Applications ... 6 Driver installation ... 11 Hardware Installation ... 14 About the Board ... 14 Before Installation PCI card ...

  • Page 2: Before Getting Started

    Using the most recent tuner FusionHDTV uses the most recent tuner to get the best reception rate, so you can get the un-interrupted and stable HDTV screen...
  • Page 3 The FF/REW Function is available Windows XP Service Pack 2 or above Supports PIP (Picture in Picture) The FusionHDTV is like having two TVs in one! With the Picture in Picture (PIP) function you can now watch two of your favorite programs all on a single screen.

  • Page 4: Fusionhdtv System Requirements

    Pentium M 1.4GHz or faster for notebook PC All ATI Radeon series VGAs Windows 2000/XP/MCE 2005/Vista 32bit/Vista 64bit : FusionHDTV DVB-T Dual Digital4 is not supported under windows 2000 Ultra-DMA66 enabled main board and HDD for recording <nonDxVA VGAs> Pentium4 1.6GHz or faster with 128M memory...

  • Page 5: Package Contents

    Package contents The FusionHDTV package contains the following items. Some packages may change depending on other conditions. ① FusionHDTV card ② Setup CD ③ Manual ④ Internal cable to sound card for External output Audio (7 RT GOLD/DVB-T pro only) [ Fusion Remote ] * FusionHDTV remote transceiver is basic option.

  • Page 6: Software Installation

    Please check the site (http://www.FusionHDTV.co.kr/Eng) before you install the software included in the CD. Installing FusionHDTV Applications Insert FusionHDTV Installation CD into the CD-ROM drive. The setup window will automatically pop up. if you downloaded the recent version on DVICO’s website, please run install.exe or setup.exe.
  • Page 7 2.1.2 Installing FusionHDTV Software Important: Installation on Windows 2000 Professional or Windows XP Before you install FusionHDTV software, be sure that you logged on as an account with Administrator privileges. Select “Install FusionHDTV”. At the FusionHDTV Installation dialog opens, click on the “Next>” button.
  • Page 8 You do not need to reinstall the program with different options. Vista OS skips this step. 8) Select your FusionHDTV card, and Press ‘Install Driver’ to install latest drivers. This selector may differ to country selection. All specifications and information are subject to changes without further notices 6) Choose your country, then click “OK”.
  • Page 9 “Yes” when the digital signature window appears. <Notes> In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder. All specifications and information are subject to changes without further notices...
  • Page 10 2.1.3 Installing Microsoft DirectX 9 Important! Installing on Windows 2000 Professional or Windows XP You can check the version of DirectX by typing “dxdiag” on the command line which appears with menu selection “start->run” If you have DirectX 9 or later already, you do not need to install DirectX 9 again.

  • Page 11: Driver Installation

    2.2.1 Installing Windows drivers If you already installed the FusionHDTV software, insert the FusionHDTV board into the PCI local bus slot. In certain cases, Windows will ask for the .sys files. You can locate the sys files in the C:\Program Files\DVICO\FusionHDTV\driver or C:\Windows\System32\Drivers folder.
  • Page 12 FusionHDTV USB, AVStream Capture(DVB-T DUAL)” drivers. [ FusionHDTV DVB-T DUAL Express ] Using this way, you may install “FusionHDTV Express, Unified Capture (DVB-T Dual Express)” drivers. [ FusionHDTV7 Dual Express ] Using this way, you may install “FusionHDTV Express, Unified Capture (HDTV7Dual)” drivers.
  • Page 13 FusionHDTV7 RT, Unified AVStream ** If a driver file look for, click the browse button. Select the driver directory under the installation directory (ex : C:\Program Files\Dvico\FusionHDTV\driver) or Driver folder of installation CD. If you want to remove the driver, program, Select your FusionHDTV board type.

  • Page 14: Hardware Installation

    Hardware Installation About the Board [ FusionHDTV DVB-T Dual Digital 4 ] Air Antenna IR Remote receiver Air Antenna: Connects to the terrestrial Digital signal. Remote receiver : Connect IR Remote receiver. PME Jumper : For the PME# option of power up.(Refer to chapter 3.3) Power Up connector : For the power up cable when PME is not available.
  • Page 15 PME Jumper : For the PME# option of power up.(Refer to chapter 3.3). [ FusionHDTV DVB-T Pro ] Air Antenna Video –IN/Remote Receiver Air Antenna: Connects to the terrestrial signal (Digital & Analog). Video –IN/Remote receiver : For external video sources, Line-In and remote receiver.

  • Page 16: Before Installation Pci Card

    Power Up connector : For the power up cable when PME is not available. PME Jumper : For the PME# option of power up.(Refer to chapter 3.3). Before Installation PCI card Warning: Before installing, first touch the grounded part of the PC to protect the components on the board from static electricity.

  • Page 17: Connecting Power Up Cable

    4) Unplug the ATX power switch cable from the mainboard and connect it to the connector named “Case Power Pin” on the FusionHDTV TV PCI Tuner Card, as shown in the picture below. And you need to change the PME jumper to SW The ATX power switch cable is not polarized.

  • Page 18: Pci Board Installation

    < Note > Please double check if everything has been done properly. If you plug the cables into an incorrect pin, your PC may not start or may function improperly. The location of PME jumper may differ to the TV card model. PME/SW Selector - PME jumper used to PME# option in Bios.

  • Page 19: Remote Installation

    IR port. After IR receiver and FusionHDTV remote software is installed, please reboot and start the configuration by right clicking the FusionRemote icon at the low right bottom of the screen. If you do see the FusionRemote icon in the tray, please start the program by Start->Program->DViCO- >FusionRemote.

  • Page 20: Using Fusionhdtv

    Http://www.FusionHDTV.co.kr Starting and Quitting Click Start, point to Program->DVICO->FusionHDTV, or double click on the FusionHDTV icon in the program folder to execute FusionHDTV. When you first execute the program, it will ask for a channel scan. Please say “Yes” for the channel scan.
  • Page 21 Aspect Ratio: Adjust display ratio. TV Analog De-interlacing: removes interlace to progressive conversion artifact. Analog Color inverse Analog TV multi Audio Always On Top: Shows FusionHDTV application always on top. Second language : Second language can be heard with checking...
  • Page 22 4.2.2 Controller This indicates Control Buttons. 1) Exit button 2) Maximize button 3) Minimize 4) Channel UP/DOWN button 5) Show Input source. 6) Channel/Input button: This mode shows the channel number. If you click on the small channel sub number(2), it will show the channel list and sub channel name. 7) Video/Audio status 8) Show program name.
  • Page 23 24) Teletext button: You can show the real time teletext browser. ( DVB-T model only) 25) PIP button : is used to show the PIP screen. This button is available with dual digital or multi card. PIP controller : Dual digital model or multi-card If you click the PIP button, you can see PIP controller.

  • Page 24: Using Fusionremote

    Using FusionRemote This indicates Remote Buttons. 4.3.1 Using For FusionHDTV ** FusionHDTV series is available the Power Up function. Profile APP start FusionHDTV Start WinAMP Start Configuration Instant Replay Volume Up/Down File Open Mute DTV/ATV or LiveTV Change Input Source...

  • Page 25: Fusionhdtv Shortcut Key

    FusionHDTV Shortcut Key Shortcut Key A+Numeric D+Numeric ALT+F4 ALT+E ALT+I ALT+K ALT+P(P) ALT+Q ALT+S ALT+T (T) ALT+W (W) ALT+X Page Up Page Down Backspace Shift+ Backspace ALT+Enter CTRL+Space CTRL+B (B) CTRL+C (C) CTRL+D CTRL+E (E) CTRL+F (F) CTRL+H CTRL+I (I)

  • Page 26: Technical Support

    Technical Support Contact Us If you have attempted to resolve any problems with your FusionHDTV and still require assistance, contact us by My Q/A at Please visit our WEB (http://www.fusionhdtv.co.kr/Eng) and check the enriched FAQs and much more. And please sign-up and let Dvico support you better.
