- Page 1 LH-K001A LED 150W profile light User Manual This manual contains important information. Please read before operating fixture. Add：NO.6 Industrial Zhugang load Hongxing bridge ,ShiJing Town, BaiYun district,Guangzhou China Tel：+86 020-61162042 Fax：+86 020-61167566...
- Page 2 1 SECURITY TIPS CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! For your own safety, please read this user manual carefully before you initial start-up.
-
Page 3: Description Of The Fixture
2 TECHNOLOGY REFERENCE AC 100-240V 50/60Hz Power consumption:200W Equipped with COB LED WHITE 150W, 50,000 hours 0-100% linear dimming, separate strobe DMX 512 protocol, master/slave, auto 2/3/4 DMX channel modes Running temperature self controlling Displaying off 5 seconds automatically after finishing sets of the fixture Environmental temperature: -20℃... -
Page 4: Dmx Channel Sheet
LED DISPLAY CONTROL: Main menu Sub menu 1.A001 001-512 DMX ADDRESS SETTING 2/3/4CH CHANNEL MODES 2.CH11 01-03 PRESET SHOWS 3.SH01 MENU 01-10 RUNNING SPEED 4.SP ON/OFF SLAVE 5.SLoF 6.rdoF ON/OFF DISPLAYING REVERSEDLY 7.u255 000-255 WHITE DIMMER 4 DMX CHANNEL SHEET 2 Channel Channel Value... - Page 5 3 Channel Channel Value Description 0-255 Color White dimmer , from dark to bright Dimmer durations 0-50 0 second 51-101 1 second 102-152 2 second 153-203 3 second 204-255 5 second Not occupied 3-125 Strobe from slow to fast 126-255 Random strobe 4 Channel Channel...
- Page 6 5 Lux chart: If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating. Before replacing the fuse, unplug mains lead. Procedure: Open the fuse holder on the rear panel with a fitting screwdriver. Step 1: Remove the old fuse from the fuse holder.
- Page 7 6 Maintenance Problems Check list Trouble Shooting The fixture do 1. If your power as same as the input 1. Make sure the voltage. not work of the machine. 2. Replace the same fuse. 2. If the fuse was broken. LED dimmed If your power us same as the input Make sure the voltage...
- Page 8 Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add: Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the warranty will not work (warranty period and terms, see the following) warranty period：one year since purchase warranty terms：1、If fail when using the product in normal state, you can made under the provisions of the warranty, show the warranty card and purchase bills(copy), and enjoy free maintenance service in a specific service center or...
