- Page 1 200W Warm + Cool white LED COB Par light User Manual This manual contains important information. Please read before operating fixture.
-
Page 2: Security Tips
1. SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions: non-professionals, not to disassemble the light arbitrarily and lighting accessories inside. rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected). - Page 3 2 TECHNOLOGY REFERENCE Voltage: AC 110-220V 50-60HZ Power: 250W Light source: warm white 100w+cool white 100w 2in1 Color temperature: 2000k~6500k LED Life Time: over 50000hours IP Grade: IP20 Environment Temperature: -30° ~45° Housing Color: Black Light body: Die-casting Aluminum With barndoor Specification: Dimmer: 0~100% linearly adjustable Control Mode: DMX512/Master-slave/Sound activated/Auto mode...
- Page 4 3 Board Instruction MENU UP DOWN ENTER 1~Press MENU Can circulate 9 different functions. The front 2Digits mean the function it has. (Please see the function form as follow.) And the last 2Digits mean the function’s address, speed or parameter. Press UP or DOWN can change the value.
-
Page 5: Dmx Channel Sheet
4 DMX CHANNEL SHEET A6ch Function Introduction Total dimmer Linear dimmer, from dark to bright Total strobe Strobe from slow to fast 0—50：DMX Channel control； Function select 51－－100：Jump change; 101—150：Gradual change; 151—200:Pulse change； 201—255：Sound Function speed Function speed from slow to fast Warm white Linear dimmer, from dark to bright Cool white... - Page 6 A4ch Function Introduction Total dimmer Linear dimmer, from dark to bright Warm white Linear dimmer, from dark to bright Cool white Linear dimmer, from dark to bright Total strobe Strobe from slow to fast b4ch Function Introduction Total dimmer Linear dimmer, from dark to bright Total strobe Strobe from slow to fast 0—50：DMX Channel control；...
- Page 7 b2ch Function Introduction Warm white Linear dimmer, from dark to bright Cool white Linear dimmer, from dark to bright 5 FIXED EQUIPMENT Please fasten the fixture clamp before hanging. The clamp can be fasten by the little hole in the middle of the bracket, then tie with a safety belt.
-
Page 8: Maintenance
7 Maintenance Problems Check list Trouble Shooting The fixture do 1. If your power as same as the input 1. Make sure the voltage. not work of the machine. 2. Replace the same fuse. 2. If the fuse was broken. LED dimmed If your power us same as the input Make sure the voltage... - Page 9 we have to improve the product. 3. In addition to the lamp, also matching accessories are as follows： accessories： Power line 1 piece Optional parts： (customers） Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add:...
- Page 10 containing data may have changed, and will not notice the change any more. Company retains its right to change specifications related when product is improved. Thanks for your understanding.
