leahua LH-C019 User Manual

18pcs 3w mini moving head wash
Hide thumbs

Advertisement

Table of Contents

LH-C019 18pcs 3W Mini Moving Head Wash
User Manual
This manual contains important information.
Please read before operating fixture.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LH-C019 and is the answer not in the manual?

Questions and answers

Related Manuals for leahua LH-C019

Summary of Contents for leahua LH-C019

  • Page 1 LH-C019 18pcs 3W Mini Moving Head Wash User Manual This manual contains important information. Please read before operating fixture.
  • Page 2 1 SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions:  non-professionals, not to disassemble the light arbitrarily and lighting accessories inside.  rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected).

  • Page 3: Product Introduction

    2. Product introduction  Power supply: AC110/20V，50/60HZ  Power consumption: 80W  LED: 18*3W RGB LED （R:6 , G:6 , B:6）  DMX Channels: 8CH / 13CH optional  Dimmer: 0~100% mechanic dimmer  Maximum PAN-movement: 630 , can be adjusted ...
  • Page 4 LCD Display normally LCD Display inversion rdiS 14 Channel mode 14CH 14CH 9 Channel mode X motor 540 turn PA54 PA54 X motor 360 turn PA36 X motor 180 turn PA18 Y motor 270 turn Ti27 Ti27 Y motor 180 turn Ti18 Y motor 90...
  • Page 5 4. Channel 8 Channel Mode : Channel Function 0-255 0-255 Tilt No effect 8-134 Dimming 135-239 Strobe from low to fast 240-255 No strobe 0-255 Red Dimming 0-255 Green Dimming 0-255 Blue Dimming 0-255 Motor speed 150-200 Reset 13 Channel Mode : Channel Function 0-255...
  • Page 6 0-255 Blue Dimming Color selection 8-231 Color combination 1 232-255 Color jump 0-255 Color change speed 0-142 Auto 143-255 Sound 150-200 Reset 5.Maintenance 1. Please keep the light in dryness and avoiding use in wet place. 2. Using intermittently can be extended the life. 3.
  • Page 7  Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add: Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the warranty will not work (warranty period and terms, see the following) warranty period：one year since purchase warranty terms：1、If fail when using the product in normal state, you can made under the provisions of the warranty, show the warranty card and purchase bills(copy), and enjoy free maintenance service in a specific service center or...
