Optical Disk; Hard Disk; Usb Ports - Acer Aspire R3700 Service Manual

On-Board Graphic solution
NV GT218-ION with 512MB VRAM
•
1 D-Sub port on rear
•
1 HDMI port on rear
•
Dual view support
•

Hard disk

Support up to one SATA ports
•
2.5"
•
Capacity and models are listed on FRU
•

Optical disk

None
•
Serial ATA controller
Slot Type: SATA connector
•
Slot Quantity: 1
•
Storage Type support: HDD
•
Audio
Chip: vendor propose (Realtek 662)
•
Connectors support:
•
Audio jacks color coding: should meet Microsoft Windows Logo Program Device Requirements:
•
Audio-0002
Front 2 jack follow HD audio definition
•
Add HD de-pop CKT
•
LAN
Controller: Proposed by vender
•
Port: 1 x RJ45 rear port for Gigabit Ethernet
•
Design Criteria:
•
Should be worked under 10/100/1000Mbs environment
•
Reserved disable function on both hardware & BIOS side. Default is enabled
•
Support network PXE boot
•

USB ports

Controller: Intel NM10
•
Ports Quantity: 6 for aPluto
•
4 back panel ports
•
2 ports for front (Daughter board)
•
Connector Pin: standard Intel FPIO pin definition
•
USB 2.0/1.1Data transfer rate support
•
Extension slot
Support one Mini PCIe slot
•
2 Chapter 1
