System Tour

Features

Below is a brief summary of the computer's many feature:
NOTE: The features listed in this section is for your reference only. The exact configuration of the system
depends on the model purchased.

Operating System

Microsoft Windows 7 Home Premium X86/ X64
•
Microsoft Windows 7 Home Basic X86/ X64
•
Microsoft Windows 7 Starter x86
•
Linux x-Window mode
•
Free DOS
•
Processor
Socket Type: None
•
Processor Type:
•
Intel Atom D400/D500 series CPU
•
Atom D525+GT218
•
Chipset
Intel NM10
•
Design Criteria:
•
Should meet Intel Pine Trial-D platform design guide
•
Super I/O: ITE/8721
•
Should support SST signal output
•
PCB
170mm*170mm (Proprietary)
•

Memory subsystem

Socket Type: DDR III SO-DIMM connector
•
Socket Quantity: 2
•
Only support single channel
•
Capacity support:
•
1GB / 2 GB DDRIII 800 SO-DIMM support (follow Intel Spec.)
•
1GB to 4GB Max memory support(follow Intel Spec.)
•
Design Criteria:
•
Should follow Pine Trail-D platform design guide
•
Should meet Pine Trail-D BIOS Specification
•
