Jumper/Header Name
Function
Definition
XD-18:XD_D7
XD-19:CARD_3V3
COM1 PORT
1:JDCD1J
2:JSIN1
3:JSOUT1
4:JDTR1J
5:GND
6:JDSR1J
7:JRTS1J
8:JCTS1J
9:JRI1J
10:GND
11:GND
