1. OVERVIEW
ELIPSOLED 3100 MAX
Ellipsoidal LED luminaire - 3100K color temperature
ELIPSOLED 3100 MAX is an ellipsoidal LED luminaire
powered by 1 250W COB LED that works at 3100K
and has a performance 50% greater than the MKII
version, which has an output similar to the classic
750W halogen fixtures, with a 90Ra color reproduc-
tion. Thanks to its COB LED, Elipsoled 3100 MAX en-
ables a great energy saving and a very low heat gen-
eration, important attributes for both theater and
broadcasting. On the other hand, the luminaire has
a 16-bit dimmer with four dimming curves, strobe
effect and adjustable PWM, essential for a flicker
free operation in any given circumstances. Last but
not least, Elipsoled 3100 MAX has a wide variety of
lenses, including two zoom barrels, and is compati-
ble with the most popular lenses in the industry.
Source & Optics
• Light Source: 1 250W COB LED
• Color temperature: 3200K
• LEDs life: 50,000 hours
• Lens tubes: 5º,10º,19º,26º,36º,50º, 15-30º & 25-
50º
• Selectable refresh rate: 600Hz, 1200Hz, 2000Hz,
4000Hz & 25000Hz
Photometric data
• Luminous Flux:
• 19º: 10166 lm
• 26º: 11616 lm
• 36º: 9363 lm
• Color rendering: >90Ra
• Flux:
• 5º: 10581 Lux @ 32 ft. (10M)
• 10º: 4965 Lux @ 32 ft. (10M)
P. 2
Neo Elipsoled MAX -
English version
• 19º: 1724 Lux @ 32 ft. (10M)
• 26º: 1250 Lux @ 32 ft. (10M)
Effects & Functions
• Dimmer: Full range 0-100% (16-bit)
• 4 dimming curves
• Strobe effect: 0-20 flashes per second
• Standard beam shutters
• Manual focus
• Flat and even light field
• Compatible with industry standard lens tubes
• Adjustable PWM (Pulse Width Modulation) to
work flicker free in any given situation
Control
• DMX channels: 1/2/3
• Operational modes: DMX, Static, Master/Slave
& On-board control
• RDM Function
Electrical
• Input voltage range: AC100–240V, 50-60Hz
• Power consumption: 250W
Physical
• LED display
• DMX connectors: 4 XLR connectors (XLR-3 In
and Out; XLR-5 In and Out)
• Power supply connectors: PowerCON® In/Out
• Cooling: Forced convection
• Dimensions: 720x380x340 mm. /
28.3x14.9x13.3 in.
• Weight: 9.6 Kg. / 21.1 Lbs.
