Maestro Fixed Angle Stand Installation
Guide
February 29, 2016
The following guide will provide the necessary step-by-step procedure for installing the Maestro Fixed
Angle Stand on a Maestro Control Console for the FLEX-6000 Signature Series SDR.
Table of Contents
........................................................................................................................................... 2
Packaging and Fixed Angle Stand Contents............................................................................................ 2
Required Tools ........................................................................................................................................ 2
Using the Top Foam Packing Material as an Work Surface Offset ......................................................... 3
Place the Maestro on the Work Surface Offset ...................................................................................... 4
Locating the Fixed Angle Stand Mounting Screw Holes .......................................................................... 4
Orientating the Fixed Angle Stand on the Maestro ................................................................................ 5
Install Fixed Angle Stand Attachment Screws ......................................................................................... 6
Tighten Attachment Screws to Secure the Angle Stand on the Maestro ................................................ 7
Page 1
............................................................................................................... 2
............................................................................................................... 3
........................................................................ 3
................................................................................... 4
© 2016 FlexRadio Systems, v1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maestro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FlexRadio Systems Maestro

Summary of Contents for FlexRadio Systems Maestro

  • Page 1 Maestro Fixed Angle Stand Installation Guide February 29, 2016 The following guide will provide the necessary step-by-step procedure for installing the Maestro Fixed Angle Stand on a Maestro Control Console for the FLEX-6000 Signature Series SDR. Table of Contents ....................... 2...

  • Page 2: O Btaining T Echnica L S Upport

    Getting Started Packaging and Fixed Angle Stand Contents Remove the Maestro Fixed Angle Stand contents from the packaging and verify that the following items are included before proceeding. Refer to the image below. ...

  • Page 3: P Reparing For The M Aestro F Ixed A Ngle S Tand I Nstallation

    Using the Top Foam Packing Material as an Work S urface Offset The knobs on the front of the Maestro does not allow for the unit to lie flat on its front to facilitate easy installation of the Fixed Angle Stand. Therefore the part of the Maestro packing material will be used as an offset to create a flat work surface for installing the Fixed Angle Stand.

  • Page 4: Place The Maestro On The Work Surface Offset

    Place the Maestro on the Work Surface Offset As shown in the picture below, place the Maestro touch screen display face down on the top of the foam packing material allow the knobs to rest on the covered work surface. This will allow of the Maestro to lie flat for the installation of the Fixed Angle Stand.

  • Page 5: Orientating The Fixed Angle Stand On The Maestro

    Orientating the Fixed Angle Stand on the Maestro Carefully orientate the Maestro Fixed Angle Stand on the back of the Maestro as shown below. The three (3) small holes on the Fixed Angle Stand mounting plate should align with the three (3) metal insert mounting screw holes on the back of the Maestro.

  • Page 6: Install Fixed Angle Stand Attachment Screws

    Fixed Angle Stand. Place the screwdriver through the access hole. Then place a M4 attachment screw on the tip of the screwdriver and carefully thread it into the mounting screw hole on the back of the Maestro. Refer to the image below for installing the center M4 attachment screw.

  • Page 7: Tighten Attachment Screws To Secure The Angle Stand On The Maestro

    The Fixed Angle Stand M4 attachment screws should easily screw into the mounting screw holes on the back of the Maestro with little to no effort. If this is not the case, the screw may be cross threaded. Do not force the M4 attachment screw into the mounting screw hole to prevent striping of the M4 attachment screw or the metal screw hole insert.
