Philips HI555 Service Manual
Philips HI555 Service Manual

Philips HI555 Service Manual

Advertisement

Quick Links

Service
Service
Service
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
Features
HI555
Pilot light
Integrated cord winder
Spray
Variable steam
Turbo steam
Shot of steam
Vertical steam
Self clean
Enght cord set 2.5 m
Anti-drip function
Automatic shut-off
Anodised soleplate
Carry case
Voltage / Frequency
: 100V, 110-127V, 220-240V
50-60Hz
Power consumption
: 100V,
110-127V,
220-240V,
Soleplate temperature : 215°±25°C
Steam output : Varible steam output max. 12gr/min when :
- slide is set to position 6
- temperature dial is set to position MAX.
Turbo steam output :
Always to be used in combination with
the variable steam slide, increase the
steam output with max. 18gr/min to a total
of 30gr/min.
Shot of steam : 60gr/min.
This product meets the requirement regarding
interference suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care
4322 277 00258
02/00
Ver.2
HI556
HI565 HI566
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
-
-
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
-
-
x
x
x
x
x
x
-
x
-
x
1200W at 100V
1300W at 120V
1450W at 220V
Service manual 4822 729 22167 is herewith cancelled
Turbo steam function :
The steam output of the variable steam function depends upon
the position of the slide knob.
When set to position 6 the steam output is 12 gr/min.
This might be not sufficient. In that case the turbo button has to
be pushed down for max 10 sec. Due to this operation the steam
output will increase to 30 gr/imn.
Vertical steam :
When the iron is kept in a vertical position, the s.o.s. button can
be used to iron hanging fabrics as curtains.
Self-clean function :
When the self-clean button is pushed down, a sudden flow of
water is released from the tank into the heated sole plate.
This thermal shock will cause scale particles come loose from
the steam chamber. These particles are then flushed out through
the steam vents by the water.
Anti-drip :
Water is only released through the tank valve into the steam
chamber if the sole plate temperature is high enough to evaporate
all water. If the temperature is not hot enough the tank valve is
closed by means of the bi-metal disc.
Auto shut-off :
A relay in the electronic module interrupts the power to the heating
element when the iron has been motionless :
- for 30 seconds in horizontal position.
- for 8 minutes in vertical position.
The red " Auto-off " pilot light starts blinking, a sound signal is
heard too.
When the iron is moved again, it's automatically switched on
again. When the iron is moved again, it's automatically switches
on again.
N.B. When the iron is plugged in in a horizontal position, it will
not be switched off during the first 2 minutes to ensure that
it heats up properly.
Real-off function :
The movement of the thermostat's bi-metal is limited in downward
direction thus will prevent the thermostat contacts from closing
at room temperature at MIN setting.
©
Printed in Hong Kong
Copyright reserved
Steam Iron
HI555
HI556
HI565
HI566
Subject to modification

Advertisement

loading
Need help?

Need help?

Do you have a question about the HI555 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philips HI555

  • Page 1 TV. at room temperature at MIN setting. © Published by Philips Domestic Appliances and Personal Care Printed in Hong Kong Copyright reserved Subject to modification 4322 277 00258 02/00 Ver.2...
  • Page 2 DISASSEMBLY ADVICE PART LIST POWER PACK + STAND AND CARRY CASE POWER PACK: Description Service code CORDSET 30.1 30.0 Power pack complete, with UK cordset 4239 020 97120 SWIVEL 30.2 Power pack complete, with EU cordset 4239 020 95570 Power pack complete, with flat pin cordset 4239 020 98570 CONTACT 30.1...
  • Page 3 EXPLODED VIEW POWER PACK AND STAND Screws :...
  • Page 4 DISASSEMBLY ADVICE Replacement Thermostat see fig. 1-4 DIAL 1 SLIDE UNIT 13 RATTLE SPRING 2 NEEDLE 14 remove SCREW C 1x remove BACK PLATE 4 remove INLAY 6 remove SCREW A 2x HANDLE 15 SPRAY PUMP 16 S.O.S.PUMP 17 BACK PLATE 4 TANK 18 remove SCREW C1x SELF CLEAN...
  • Page 5: Parts List

    In case the item 131 or item 132 need to be replaced, both item have to be replaced together under code number 4239 022 52850 ( item 25). Screws : A, A1 M2.6 x M3.5 x M3.5 x HI555 ~ HI556 HI565 ~ HI566...
  • Page 6 EXPLODED VIEW Part modified since week 0005 M2.6 x M3.5 x M3.5 x Part modified since week 0005...
  • Page 7 IMPORTANT + ADJUSTMENT AND CONTROLS IMPORTANT Due to the high wattage of the iron, only the specified cordsets must be used. NOTES : 1) For standardisation reasons : Dial : With English / Spanish text only. Rattle spring : 5 pieces will be supplied when ordered Type plate : No info about the type number and voltage have been stamped onto the typeplate.
