Philips DST7510/80 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Steam Iron
DST7510/80
DST7012/76
V2
DST7030/21
V2
V2
DST7040/86
DST7051/30
V2
DST7061/30
V2
Published by Philips Domestic Appliances
Document No. : CSW-07-081-22188
DST7511/80 DST7011/20
V2
DST7020/20 DST7020/21
V2
V2
DST7030/26 DST7031/70
V2
V2
DST7041/20 DST7041/21
V2
V2
DST7051/36 DST7060/20
V2
V2
DST7011/26
V2
DST7022/40
V2
DST7040/80
V2
DST7041/23
V2
DST7060/21
V2
Page 1 of 26
DST7012/70
V2
DST7030/20
V2
DST7040/81
V2
DST7050/70
V2
DST7060/26
V2
For internal use only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DST7510/80 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips DST7510/80

Summary of Contents for Philips DST7510/80

  • Page 1 DST7011/26 DST7012/70 DST7012/76 DST7020/20 DST7020/21 DST7022/40 DST7030/20 DST7030/21 DST7030/26 DST7031/70 DST7040/80 DST7040/81 DST7040/86 DST7041/20 DST7041/21 DST7041/23 DST7050/70 DST7051/30 DST7051/36 DST7060/20 DST7060/21 DST7060/26 DST7061/30 Published by Philips Domestic Appliances Page 1 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 2: Table Of Contents

    4.Instructions ................................10 4.1 Disassembly Instruction ..........................10 4.2 Reassembly Instruction ...........................14 5.Service Lists ..............................19 5.1 Part list ................................19 5.2 Exploded view ..............................25 6.Revision History ...............................26 Published by Philips Domestic Appliances Page 2 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 3: Important Repair Instructions

    Loose part Check that there are no loose parts such as extra screws in the product that can cause short circuit or product malfunction. Published by Philips Domestic Appliances Page 3 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 4: Product Information

    • Robust heel rest water and 50% demineralized water. • Extra large filling hole Soleplate • Soleplate is the best Philips Soleplate for Steam Fast crease removal • Soleplate: SteamGlide, SteamGlide Plus, Iron. It has great scratch resistance, glides SteamGlide Advance & SteamGlide Elite excellent and it is easy to clean.

  • Page 5: Product Matrix

    Auto Shut-off QuickCalc QuickCalc QuickCalc QuickCalc Calc Solution Release Release Release Release Cord length (m) Water Tank capacity (ml) Dimension 320x130x154 320x130x154 320x130x154 320x130x154 Published by Philips Domestic Appliances Page 5 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 6 Auto Shut-off Calc Solution QuickCalc Release QuickCalc Release QuickCalc Release QuickCalc Release Cord length (m) Water Tank capacity (ml) Dimension 320x130x154 320x130x154 320x130x154 320x130x154 Published by Philips Domestic Appliances Page 6 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 7 Auto Shut-off Calc Solution QuickCalc Release QuickCalc Release QuickCalc Release QuickCalc Release Cord length (m) Water Tank capacity (ml) Dimension 320x130x154 320x130x154 320x130x154 320x130x154 Published by Philips Domestic Appliances Page 7 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 8 SteamGlide Elite Drip stop ECO mode Auto Shut-off Calc Solution QuickCalc Release QuickCalc Release Cord length (m) Water Tank capacity (ml) Dimension 320x130x154 320x130x154 Published by Philips Domestic Appliances Page 8 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 9: Troubleshooting Guide

    Change Thermostat Dial Bullet Change Bullet Deco Plate Change Deco Plate Rubber Seal torn/ degraded Tank Top Seal Change Tank Top Seal Descaling Instruction: Published by Philips Domestic Appliances Page 9 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 10: Instructions

    2x Screw B (Refer to step 13 to 20 for detail instruction) Remove CLAMPING PLATE (Refer to step 1 to 12 for detail instruction) Published by Philips Domestic Appliances Page 10 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 11 2. Remove DECO14 PLATE & BACKPLATE 2 3. Remove DECO PLATE 14 4. Open FILLING DOOR 5. Remove Inlay Sticker 6. Remove TANK TOP SEAL 15 Published by Philips Domestic Appliances Page 11 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 12 9. Remove INLAY ASSY 5 10. Remove THERMOSTAT DIAL 11 11. Remove BULLET MOLDED 12 & BULLET 12. Remove 2x Screw B & Clamping Plate SPRING 13 Published by Philips Domestic Appliances Page 12 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 13 18. Remove BALL SWIVEL 10, BACKPLATE 2 connectors with clean cloth. Press the tab of & MAINSCORD 6 Quick Connector on MAINSCORD and pull it out from Frame Connector. Published by Philips Domestic Appliances Page 13 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 14: Reassembly Instruction

    1. Connect the LAMP ASSY 9 (with resistor side) 2. Connect blue wire of MAINSCORD 6 to 'N' to Frame Connector at the most left Frame Connector (second from the right) Published by Philips Domestic Appliances Page 14 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 15 7. Apply Heat Sink Paste onto pink terminal of 8. Assemble Thermostat Bush to Shaft ASO 1 and blue terminal of MAINSCORD 6 to Frame Connector Published by Philips Domestic Appliances Page 15 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 16 12. Open the Filling Door 13. Assemble and fasten Screw T1 14. Assemble and fasten 2x Screw A3 at rear of WATER TANK ASSY 7 to Cover Published by Philips Domestic Appliances Page 16 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 17 20. Dress brown wire onto slot on the right side brown wire of ASO 1 of half-ring plate, and also dress the connection into slot on Tank Top Published by Philips Domestic Appliances Page 17 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 18 24. Assemble DECO PLATE 14 onto Tank Top half-ring plate 25. Assemble BALL SWIVEL 10 to Tank Top 26. Place BACKPLATE 2 onto rear of Iron Rear Published by Philips Domestic Appliances Page 18 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 19: Service Lists

    423902283261 423902283261 423902283261 423902283261 BULLET SPRING 423902283271 423902283271 423902283271 423902283271 DECO PLATE 423902292181 423902292811 423902293981 423902293981 TANK TOP SEAL 423902292191 423902288481 423902282501 423902282501 Published by Philips Domestic Appliances Page 19 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 20 423902283261 423902283261 423902283261 423902283261 BULLET SPRING 423902283271 423902283271 423902283271 423902283271 DECO PLATE 423902293961 423902293991 423902293991 423902293961 TANK TOP SEAL 423902282501 423902288481 423902288481 423902282501 Published by Philips Domestic Appliances Page 20 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 21 423902283261 423902283261 423902283261 423902283261 BULLET SPRING 423902283271 423902283271 423902283271 423902283271 DECO PLATE 423902293991 423902293991 423902293991 423902293941 TANK TOP SEAL 423902288481 423902288481 423902288481 423902292191 Published by Philips Domestic Appliances Page 21 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 22 423902283261 423902283261 423902283261 423902283261 BULLET SPRING 423902283271 423902283271 423902283271 423902283271 DECO PLATE 423902293931 423902293941 423902293941 423902293941 TANK TOP SEAL 423902288431 423902292191 423902292191 423902292191 Published by Philips Domestic Appliances Page 22 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 23 423902283261 423902283261 BULLET 423902283261 423902283271 423902283271 423902283271 BULLET SPRING 423902283271 423902293961 423902293971 423902293961 DECO PLATE 423902293941 TANK TOP SEAL 423902282501 423902282501 423902282501 423902292191 Published by Philips Domestic Appliances Page 23 of 26 For internal use only Document No. : CSW-07-081-22188...
  • Page 24 The above mentioned CRP is applicable for following country only:- Germany, Austria, Netherlands, Belgium, France, Italy, Spain, UK, Denmark, Sweden, Poland, Czech Republic, Hungary & Romania Published by Philips Domestic Appliances Page 24 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 25: Exploded View

    Service Lists 5.2 Exploded view Notes: Scale: Not to scale Published by Philips Domestic Appliances Page 25 of 26 For internal use only Document No. : CSW-07-081-22188...

  • Page 26: Revision History

    Update Pos 7 – 12NC in all the versions, Palani Pandurangan 04-09-2023 Add new version 688001000278,688001000101. Add new version: 688001001545 Palani Pandurangan 08-02-2024 Add 12nc for alternate Mainscord Palani Pandurangan 09-02-2024 Published by Philips Domestic Appliances Page 26 of 26 For internal use only Document No. : CSW-07-081-22188...
