General Toolsmart Instruction Manual page 7

Multimeter Picture Gallery
1
From the
dashboard, tap the
gallery button in the
lower left corner of
the screen
2
Tap the photo you Tap somewhere on the
would like to add picture to place a box
your for values to be
measurements to. entered. The box can be
moved by tapping it and
dragging it. Custom
values may be entered
by double tapping the
box. To input previously
saved measurements,
see next step.
3
Tap the button on the bottom center
to display your previously logged
measurements. Then swipe the bar
with the values to scroll through, tap
and drag that value to the desired box
(value is entered when the box turns
orange). To change the direction of the
arrow on the box, click the box so it
turns orange and tap the direction you
would like the arrow to point (tap
outside but close to the box).
4
When all measurements
are finalized, save your
new picture to the gallery
by tapping the save
button in the bottom
right corner of the page.
Boxed values can be
deleted by tapping them
so they turn orange and
hitting the "X".
5
