Socket Series 9 Quick Start Manual

Cordless ring scanner with bluetooth wireless technology
Hide thumbs Also See for Series 9:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version

Quick Start Guide

Cordless Ring Scanner Series 9
®
with Bluetooth
Wireless Technology
Instructions for Windows Mobile
System Requirements
Your Windows Mobile-based device should satisfy these minimum requirements:
• Windows Mobile 2003, 2003SE or 5.0
• Any of the following Bluetooth stacks*:
− Socket Mobile Drakar v1.4 (from Socket Mobile SD/CF Connection Kits)
− Broadcom (Widcomm) v1.5 or greater for Windows Mobile 2003/2003SE
− Broadcom (Widcomm) v1.7 or greater for Windows Mobile 5.0
− Microsoft Bluetooth stack
• Software installation requires a host computer running ActiveSync 4.0 or greater
or Windows Vista. If needed you can download ActiveSync free from:
www.socketmobile.com/activesync.
*Other stacks may be compatible but have not been tested by Socket.
Package Contents
• Ring scanner (C)
• Wrist unit (A) with attached cable (B)
• Wrist unit case (D)
• Wrist strap (E)
• Finger strap (F)
• 2 adhesive Velcro strips (G)
• Rechargeable 3.7V lithium-ion battery
• Battery charger
• CD with software and user documentation
Product Registration
We highly recommend that all customers register their Socket products. Registered
users receive the following benefits:
• Priority for technical support
• Special offers for future products and upgrades
• The latest new product information
Register online at:
www.socketmobile.com/support/support/new/
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Series 9 and is the answer not in the manual?

Questions and answers

Related Manuals for Socket Series 9

Summary of Contents for Socket Series 9

  • Page 1: Quick Start Guide

    Windows Vista. If needed you can download ActiveSync free from: www.socketmobile.com/activesync. ® with Bluetooth Wireless Technology *Other stacks may be compatible but have not been tested by Socket. Package Contents • Ring scanner (C) • Wrist unit (A) with attached cable (B) • Wrist unit case (D) •...

  • Page 2: Additional Documentation

    Technical Support unit, then close and lock the battery door. If you have trouble installing or using the CRS, contact Socket technical support by first registering your product at www.socketmobile.com/support/support/new/. After product registration, log in, click on the Technical Support tab, and click Create New Ticket to submit an online request for technical support.

  • Page 3: Assembling And Putting On The Crs

    Assembling and Putting on the CRS Putting on the Wrist Strap You can put on the CRS either with or without the case. If you choose not to use the case, the plastic parts of the wrist unit will be more susceptible to abuse. Attaching the Finger Strap to the Ring Scanner Note: To remove the finger strap, grasp the clips with your thumb and index finger.
  • Page 4 Putting on the Wrist Strap Using the CRS with the Wrist Case Note: During insertion, you may hear a beep and see the LED flicker because the power button was pressed, however, the wrist unit will not turn on unless the button was pressed for more than 2 seconds, and the LED continues to blink.

  • Page 5: Setup Instructions

    Using the CRS without the Wrist Case ETUP NSTRUCTIONS Note: Using the CRS without the wrist case makes it more susceptible to damage. STEP 1: Install the Software Note: If you are using the SoMo™, software installation is not required. SocketScan and Connect!Agent software come pre-loaded on your device.

  • Page 6: Step 2: Configure Scanner Settings

    STEP 2: Configure Scanner Settings STEP 3: Connect CRS to Host Device with Bluetooth 1. Tap Start | Settings | System tab | Socket Scanner Settings. SocketScan supports a generic Bluetooth COM port and may be able to connect to Bluetooth stacks on host mobile computers other than those listed.

  • Page 7: Step 4: Assemble And Put On The Crs

    STEP 4: Assemble and Put on the CRS SocketScan Auto-Reconnect Please refer to the instructions earlier in this guide. If the Pocket PC suspends or the CRS moves out of range, the connection will end. After the Pocket PC turns on again or returns in range, SocketScan will try to re- connect for approximately 3 minutes.

  • Page 8: Hardware And Software Indicators

    Socket Communications, Inc. dba Socket Mobile, Inc. The Bluetooth word mark and logo are owned Battery Charger LEDs by the Bluetooth SIG, Inc. USA, and any use by Socket Mobile, Inc. is under license. Any other product names are trademarks of their respective owners.
