- Page 1 Ditec VALOR R IP2089 EN Technical manual Sliding door installed in escape routes (Original intructions) www.entrematic.com...
-
Page 2: Table Of Contents
INDEX Subject Page 1. General safety precautions 2. Declaration of incorporation of partly completed machinery 2.1 Machinery directive Technical data 4. Standard installation Electrical connections with Electrical connections with Electrical connections Signals maintenance program 10. User instructions All rights reserved purposes. -
Page 3: General Safety Precautions
GENERAL SAFETY PRECAUTIONS This installation manual is intended for professionally competent personnel only. DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY 10-11-2010 (Managing Director) 2.1 Machinery directive Directive. -
Page 4: Technical Data
TECHNICAL DATA VALOR LR VALOR NR VALOR TR Power supply Intermittence Service life * (reinforced wheels) (reinforced wheels) Temperature Degree of protection IP20 IP20 IP20 * 3.1 Applications Service life: 6 Applications: CONTINUOUS data. each single installation. -
Page 5: Standard Installation
STANDARD INSTALLATION 3x1,5 mm² REF. CODE DESCRIPTION Drive unit Power supply unit Release handle MD1** Display module (included) Power supply NOTE: The given operating and performance features can only be guaranteed with the use of DITEC accessories and safety devices. - Page 6 INSTALLATION OF THE AUTOMATION 5.1 Box VALOR LR-NR fastening +/- 8 +/- 6 70 max 0KP515AB to the measurements in the related manuals. WARNING: The fastening of the box to the wall must be suitable in order to sustain the weight of the door wings.
- Page 7 5.2 Box VALOR TR fastening +/- 8 +/- 6 +/- 6 70 max 70 max KPAM45 KPAM45 to the measurements in the related manuals. WARNING: The fastening of the box to the wall must be suitable in order to sustain the weight of the door wings.
- Page 8 5.3 VALOR LR-NR wings installation and adjustment VALOR LR-NR 2 OPEN OPEN VALOR LR-NR 1 DX OPEN VALOR LR-NR SX OPEN on the guide. WARNING: Leave a gap of at least 10 mm between the glass door wings when closed to avoid contact of the glass.
- Page 9 5.4 VALOR TR wings installation and adjustment 3 mm on the guide. Place the door in the closed position.
- Page 10 VALORTR 2+2 OPEN OPEN OPEN OPEN VALORTR 1+1 DX OPEN OPEN VALORTR 1+1 SX OPEN OPEN...
- Page 11 3.5 Floor guide installation enter the doorway. min 21 max 40 10-12...
- Page 12 5.6 Belt adjustment WARNING: incorrect adjustment impairs the correct functioning of the automation. LT<2600 = 22 mm LT≥2600 = 20 mm 5.7 Lock device installation Place the door wing in the closure position. VALOR LR VALOR TR VALOR NR...
-
Page 13: Electrical Connections With
ELECTRICAL CONNECTION WITH COMER SELECTOR... -
Page 14: Electrical Connections With
ELECTRICAL CONNECTION WITH COMKR SELECTOR... -
Page 15: Electrical Connections
ELECTRICAL CONNECTION Installation, electrical connections and adjustments must be performed in accordance with Good Working Methods and in compliance with applicable regulations. The safety devices must protect any areas where the risk exists of being crushed, cut or gragged, or where there are any other risks generated by the motorised door or gate. - Page 16 The closing of the contact activates the opening manoeuvre. MD1 display module). NOTE: this command can be associated with a key to allow to go out in the evening or to come back in the morning from the shop door set to “NIGHT” mode. The closing of the contact activates the closing manoeuvre.
- Page 17 6.2 Outputs and accessories Output Value - Accessory Description Accessories power supply. output. NOTE: the maximum absorption of 0.5 A corresponds to the sum of all terminals 1. 0 1 21 22 NOTE: use a data transmission type screened cable. NOTE: connect terminals 21-22- (REMOTE) to jack DMCS socket present in COMKR selector, using a data transmission type...
-
Page 18: Signals
6.5 Signals Flashing POWER ALARM 24 V= power supply. Safety test failure. BUZZER Event Effect Escape route test 1 acoustic signal every second 6.6 ESCAPE ROUTE SENSORS WARNING: on sliding doors used in escape routes, the opening on the exit direction shall be controlled by an autocontrolled safety sensor model PASAM24T (or equivalent). - Page 19 STARTING ATTENTION: the control panel performs an automatic POWER RESET on each start and the first opening or closing manoeuvre is performed at low speed allowing the automatic self-learning of the stop positions (acquisition); WARNING: pass the accessory cable through the ferrite (1 turn), as shown on page 13 or 14. NOTE: in case of alarms, follow the instructions given in section 9.
-
Page 20: Maintenance Program
ORDINARY MAINTENANCE SCHEDULE Power off 230 V~ and batteries: carriages run). NOTE1: Use original spare parts only for repairing or replacing products. If control panel EL21 is replaced, the last used con guration can be restored using the SF RL function of MD1 display module, or a con guration from the BIXMR2 storage module can be recalled using SF RC function of MD1 display module, if previously saved. -
Page 21: Troubleshooting
TROUBLESHOOTING The MD1 display module displays the following alarms that have the priority on all the other displayed messages. The following alarms cause door immediate opening. NOTE: where indicated, perform an ALARM CLEAR to restore door operation. If it does not work, perform a POWER RESET as speci ed in the INSTRUCTIONS FOR USE on page 26. - Page 22 ALARM POWER DISPLAY INTERVENTION DESCRIPTION RESET tion plete IG - Motor drive fault IH - Motor currents fault electronic failure M4 - Motor short circuit MB - No motor P0 - No mains voltage. error tor. Mechanical selector Replace selector. ror or failure connection failure...
- Page 23 ALARM POWER DISPLAY INTERVENTION DESCRIPTION RESET permanently closed T0 - Motor test failure T1 - Motor 2 test failure ALARM POWER DISPLAY INTERVENTION DESCRIPTION RESET detection tions onto door wings. sion failure – Door is too long. M9 - Door dimension error - Door too short.
-
Page 24: User Instructions
10. USER INSTRUCTIONS 10.1 General safety precautions Do not lean against or hang on to the door when it is moving. personnel. - Page 25 10.2 Manual release instructions open position. WARNING: carry out the door wing blocking and release with the motor switched off. WARNING: carry out the door wing blocking and release with the motor switched off. 10.3 Escape route test starting from the last test carried out. NOTE: escape route test is carried out on the following occasions: upon every start (see section 7), with the POWER RESET, and when you quit the NIGHT-TIME CLOSURE mode after at least 4 hours.
- Page 26 11. FUNCTION SELECTOR USER INSTRUCTION FUNCTION SELECTOR COMER COMKR The door opens and remains open. WARNING: MD1 display module displays S3 alarm. Door closes after a 10 s operation to allow authorised door management autho- NOTE: with the COMER selector, operation can be extended to 60 s, while with COMKR selector operation can be set from MD1 display module.
- Page 27 SYMBOL MEANING DESCRIPTION The door opens and remains open. ENABLING DOOR OPERATION DISABLING DOOR OPERATION ALARM RESET...
- Page 28 Entrematic Group AB Lodjursgatan 10 SE-261 44, Landskrona Sweden www.entrematic.com...
