  • Page 1 NavStar Operation Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS NAVSTAR 10/12 Series Welcome NAVSTAR 10/12 Series Introduction Display Unit Installation HOW GPS WORKS #Sonar - How it works Installation of GPS ANTENA The installation of the GPS ANTENNA. Installation of The Transducer Display Unit Location Display Unit Installation Power Connection Transducer Connection Installing the Transducer Cable...
  • Page 3 5.2. Moving 5.3. Removing the cursor 5.4. Cursor information window 5.5 .Cursor information window shown/hidden 6. Page 6.1. Page mode 6.2. Modify 7. Active 8. Navigation Data 8.1. Type 8.2. Edit 9. MOB 9.1. Inputing 9.2. Exiting the alarm 9.3. Removing 10.
  • Page 4 3.2. Route detail 3.3. Creating 3.4. Edit 3.5. Detail edit 3.6. Navigating 3.7. Erasing 4. Track 4.1. Track on/off 4.2. Choosing the track 4.3. Setting the thickness 4.4. Track Color 4.5. Track type 5. Measuring the distance and bearing 6. User Line 7.
  • Page 5 AIS operation 1. AIS on/off 2. List 2.1. List 2.2. Detail 2.3. Goto 2.4. Sort 3. Display Radius 4. AIS target size 5. Display vessels by Color 6. Display vessels by Type 7. Filter AIS types 8. Alarm 8.1. CPA Alarm 8.2.
  • Page 6 #Sonar operation 1. Menu 1.1. Userdata 1.2. Deep Depth Range 1.3. Shift 1.4. Mode 1.5. Bottom Zoom Range 1.6. Fish symbol 1.7. Fish size 1.8. Interference Rejection 1.9. Noise Rejection 2. Advanced Menu 2.1. Display 2.2. Color 2.3. Pulse 2.4. Output Power 2.5.
  • Page 7 3.6. Remote control setting 3.7. Initialization 3.8. Wire LAN 4. Calendar 5. Others 5.1. Screen capture 5.2. Capture List 5.3. Save User Setting Data layout 1. Display 2. EDIT 2.1. Move 2.2. GPS 2.3. Time&Date 2.4. Userdata Display 2.5. Fishfinder 2.6.
  • Page 8 Pictorials This manual uses the following symbols for easy understanding safety instructions. Always follow these instructions carefully. Always follow this safety instruction to prevent death or WARNING injury. Follow this safety instruction to avoid possible injury or damage to your property. CAUTION Symbol “△”...
  • Page 9 WARNING <For System Operators> Always follow this instruction to prevent death or personal injury. Turn power If smoke or a small of burning occurs, a fire or an electrical short circuit may result. Turn the power switch OFF and shut down the power supply immediately. Never During try to repair the system yourself.
  • Page 10 Installation Cautions <For service Personnel> Follow installation instructions to avoid personal injury and system malfunction. Mount your NAVSTAR 10/12 on a rigid frame or base to prevent your Installation in rigid location. unit from working loose. Use the installation materials provided in the standard accessory pack Use correct Installation only.
  • Page 11 Maintenance Cautions<For Maintenance Personnel> Use the following safety precaution internal inspection. Discharge High voltage may be retained in the capacitors if the high-tension circuit several minutes after you have turned the power switch off. capacitors. To prevent an electrical injury due to erroneous power switching, Check that make sure that the main power supply and the system power switch are both in the off position.
  • Page 12 Operation Notes <For operators> Observe the following operation notes, otherwise the system failure or deterioration can result. And periodical inspection and maintenance are required for keeping the system in an optimum condition. The waypoint and other registered data may become Backup important unreadable by unexpected failure.

  • Page 13: Navstar 10/12 Series

    NAVSTAR 10/12 Series Welcome The NAVSTAR 10/12 Series Color LCD Chartplotter & Fishfider Systems employs the latest in proven technology to provide accurate fish & bottom information. The Plotter functions of NAVSTAR 10/12 series are totally dependent upon the capability of the navigation source to provide accurate position information.
  • Page 14 INDICATION NOTICE *: It is important or warning notice on front of article [ ]: Keyboard. - 13 -...

  • Page 15: Navstar 10/12 Series Introduction

    NAVSTAR 10/12 series Introduction Fix Text Below, so that Words Do Not Separated Strangely at End of each Line. For centuries, sailors have been searching for a reliable and precise method of travelling the world’s waterways. From celestial navigating to the modern navigation techniques as Loran, Decca navigator, Omega or Transit Satnav, each system has had its problems with weather, range and reliability.
  • Page 16 bolts through the mounting surface. Place large flat washers on the opposite side of the mounting surface from the bracket and then install lock washers and nuts. Tighten securely. Install the display unit into the mounting bracket. Check alignment and operation of the pivots and security of the mounting.
  • Page 17 [Flush Mounting] - 16 -...

  • Page 18: How Gps Works

    NAVSTAR 10/12 series Introduction HOW GPS WORKS Currently, the GPS constellation consists of 26 orbiting satellites (including 3 spares), but this number will increase in the future. The GPS receiver computes an accurate position by calculating the distance to the GPS satellites that orbit the earth.
  • Page 19 NAVSTAR 10/12 series Introduction [The GPS position calculation] As illustrated in the previous figure, the position is calculated as the meeting point of three spheres, which are drawn around the three satellites with diameters d1, d2 and d3. Position Fixing Accuracy: HDOP The GPS fix accuracy is due to the locations of 3 satellites in the sky.

  • Page 20: Sonar - How It Works

    NAVSTAR 10/12 series Introduction #Sonar - How it works- The NAVSTAR 10/12CF sonar consists of a transceiver display unit and a dual frequency transducer. An electronic signal pulse is generated in the transmitter section of the display unit. When coupled to the transducer, this signal is converted into an ultrasonic signal and is transmitted toward the bottom.

  • Page 21: Installation Of Gps Antena

    Installation of GPS ANTENA The installation of the GPS ANTENNA. The GPS ANT must be installed at the highest area of the boat and the easiest place to receive the signal from the satellites. If there are obstacles around the GPS ANT, it isn't able to receive all signals. The receiving time could be longer or the receiving power would be weaker.

  • Page 22: Installation Of The Transducer

    Installation of the Transducer A careful installation will assure maximum performance from your new NAVSTAR 10/12 series. Display Unit Location Select a location for your Display unit that provides easy viewing from all likely operator’s positions. The display unit is designed to be mounted on either a console or from an overhead surface. The Display unit is also designed for flush mounting using six threaded holes on the rear panel.

  • Page 23: Power Connection

    Installation of the Transducer Drill a 1/4 in. diameter hole at each marked location. Mount the Display unit bracket using bolts through the mounting surface. Place large flat washers on the opposite side of the mounting surface from the bracket and then install lock washers and nuts. Tighten securely. Install the display unit into the mounting bracket.
  • Page 24 NAVSTAR 10/12 Transducer Options Model # Beam Angles Type Hole Size 45º @ 50kHz Plastic transom mount w/ 250/50/200ST-CX 11º @ 200kHz depth, spd, temp. 45º @ 50kHz Bronze thru hull depth & 1700/50/200T-CX 7/8" 11º @ 200kHz temp. 45º @ 50kHz Bronze thru hull depth, 500/50/200ST-CX 2"...

  • Page 25: Installing The Transducer Cable

    Secure the cable in place using Nylon Wire Ties. Coil the extra cable and tie it out of the way. 4th) If transducer cable is not long enough, 15 & 30 foot extension cables are available from SI-TEX When you attach the extension cable, be sure that the connections are tight and watertight. Use Dow Corning DC-4 or an equivalent sealing compound to protect the connector assemblies.

  • Page 26: Installing The Power Cable

    Installation of the Transducer Installing the Power Cable- ) The 6-foot power cable supplied with the display unit should reach the source of DC power. Connect the power leads directly to the main battery isolation switch or breaker, or route the power leads to the DC power distribution panel.

  • Page 27: Installing A Thru-Hull Transducer

    Installation of the Transducer Installing a Thru-Hull Transducer Follow these instructions if you are installing the thru-hull transducer. ) Once you have decided where to install the transducer, drill the hole for the part. Begin by drilling a small pilot hole (1/8" or 3mm) from the inside of the hull. (This small hole can be filled easily if the mounting location is not suitable.) Before you drill the hole, be sure you will be able to reach the large nut on the top of the transducer, once it has been mounted.
  • Page 28 Installation of the Transducer ) Go to the inside of the hull and slide the hex nut over the end of the cable. Fit the hex nut over the end of the transducer and tighten it. (On a vessel with a wooden hull, do not tighten the nut completely right away.

  • Page 29: Positioning The Transom-Mount Transducer

    Installation of the Transducer Positioning the Transom-Mount Transducer Follow these instruction if you are installing the transom-mount transducer. Begin by finding the best location for the mounting bracket. Here are the rules: If your boat has one propeller (outboard or inboard-outboard), mount the transducer about 18"(455mm) to the side of the centerline of the boat.

  • Page 30: Mounting The Transom-Mount Transducer

    Installation of the Transducer Mounting the Transom-Mount Transducer Follow these instructions if you are installing the transom-mount transducer. ). On a boat with a fiberglass hull, the leading edge of the transducer should extend 1/8""(3.2mm) to 1/4""(6mm) below the bottom edge of the hull. See picture 1-3. On an aluminum hull, the transducer should extend a bit more - 1/4"(6mm) to 3/8"(9mm).
  • Page 31 Installation of the Transducer ) Tilt the transducer in the brackets until it is positioned as illustrated in Picture 1-3 ) Once the bracket is in the correct position, you can tighten the screws. - 30 -...

  • Page 32: Getting Started

    Getting Started 1. The Keyboard Description use this to select menu items, move the on-screen cursor and Choosing the frequency Rotary: use this to select menu items and Adjustment of gain & STC level with turning. Button: push the end of the everything to confirm a selection or entry Change the chart of scale and Setting up the depth range Open the menu Select the Goto function...
  • Page 33 (Fig.1.1) 1.1.1. Turn on Switch on. 1.1.2 Turn off Choose “Power off” on (Fig. 1.1). 1.1.3 Restart Choose Restart on (Fig. 1.1). 1.1.4. Adjust brightness Choose “Brightness” on (Fig.1.1). Control the brightness on (Fig.1.2). (Fig.1.2) 1.1.5. Use day/night mode Choose “night mode” on (Fig.1.1). 1.1.6.

  • Page 34: Specification Of The Connectors

    1.1.7. WiFi Choose “WiFi” on (Fig.1.1). 1.1.8. Bluetooth Choose “Bluetooth” on (Fig.1.1). 1.1.9. Data Layout Choose “Data Layout” on (Fig.1.1). (*For detailed information, PLS refer how to use data layout) 1.1.10. Sky Mate Choose “Sky Mate” on (Fig.1.1). 1.1.11. Web Browser Choose “WWW”...

  • Page 35: Screen Overview

    3. Screen Overview 3.1. Chartplotter page ② ① ③ ⑤ ⑥ ④ ① Vessel icon The present position. ② Cursor Showing the cursor icon. ③ AIS target Showing the received AIS target. ④ Databar Showing various data on the top or bottom. ⑤...

  • Page 36: Sonar Page

    3.2. Sonar page ③ ④ ② ① ⑤ ⑥ ⑤ ⑥ ⑦ ① Palette Showing the chosen colors. ② Depth bar The current depth. ③ Low Frequency Showing 50KHz. ④ High Frequency Showing 200KHz. ⑤ LF INFO The information of Low Frequency, 50KHz. ⑥...

  • Page 37: Navigation Data Page

    3.3. Navigation Data page 3.3.1. Navigation Data Type1 3.3.2. Navigation Data Type2 - 36 -...

  • Page 38: Highway Page

    3.4. Highway page ② ① ③ ④ ⑥ ⑤ ① WPT name The current WPT name. ② Direction of steer The best direction of the steering. ③ WPT icon The remaining distance of the WPT. ④ Vessel The out of the range from the best. ⑤...

  • Page 39: Steering Page

    3.5. Steering page ② ① ③ ④ ① WPT name Name of the WPT. ② Direction of steer The best direction of the steering. ③ WPT icon Showing the WPT and the bearing ④ Navigation Data Information of the various data. - 38 -...

  • Page 40: Gps Status Page

    3.6. GPS Status page ① ② ③ ④ ① Receiver status The current GPS status. ② Position of SAT. Position of the satellites. ③ SNB Graph Showing the WPT and the bearing. ④ Navigation Data Information of the various data. * Colors of the GPS status Black: Tracked, but no signal...

  • Page 41: Databar

    4. Databar Showing various data on the top or bottom. 4.1. Mode ▶[MENU]->Advance->Setup->Customizing->Databar->Mode Databar has three meanings as below. 4.1.1. GPS Showing the largest LAT/LOT. 4.1.2. HY Showing the LAT/LOT, SOG, COG and userdata. 4.1.3. HY2 Showing LON/LAT, mark, track and time/date. 4.1.4.Customizing Showing various data as what the user wants.
  • Page 42 (Fig.1.3.1) The databar is coming as (Fig.1.3.1), and choose the frame with [◀][▶]. Four frames are available as (Fig 1.3.2). (Fig.1.3.2) When choosing the frame, setting up in each box as (Fig.1.3.3). - 41 -...

  • Page 43: Display

    (Fig.1.3.3) When finishing the set up, press [CANCEL] to exit or touch “EXIT” on the screen.. (*Please, refer “Customizing” for further question.) 4.2. Display ▶[MENU]->Advance->Setup->Customizing->Databar->Display Setting the databar, “Shown/Hidden”. 4.3. Position ▶[MENU]->Advance->Setup->Customizing->Databar->Position Setting the databar position on the top or bottom. 5.
  • Page 44 Press [◀][▼] together, the cursor is moving to “↙”. Press [▶][▼] together, the cursor is moving to “↘”. Press [◀][▲] together, the cursor is moving to “↖”. Press [▶][▲] together, the cursor is moving to “↗”. 5.3. Removing the cursor Press to remove the cursor.
  • Page 45 6. Page [PAGE] Choosing the various pages that set up pages or customized. Move the red box to choose the page. Rotate the knob or press [◀][▶][▼][▲] to move the red box on your page and Enter to finish. Selected (red color) (Fig.1.4) 6.1.
  • Page 46 (Fig.1.4.1) Choose your frame on (Fig.1.4.1). Using key: use [▼][▲] and move the red box to choose the pages and press [▶]. When you finish, press Enter. 2. Press [▶], choose with [▼][▲] 1. Choose the pages with [▼][▲] - 45 -...
  • Page 47 4. Keep choosing and Enter to finish 3. Enter (Fig.1.4.2) Long press: Choose the page and long press for drag the page into the frame.. (Fig.1.4.3) When complete, press Enter to finish. - 46 -...
  • Page 48 7. Active ▶[ACTIVE] When pressing [FUNC], the red box moves to to chartplotter or sonar. (*All key functions change to chartplotter or sonar) Selected (red color) - 47 -...

  • Page 49: Navigation Data

    8. Navigation Data Navigation data is available in Navigation data page, Steering page, Highway page as (Fig.1.5). (Fig.1.5) 8.1. Type ▶[MENU]->Advance->Setup->Customizing->Navigation data->Type Two types of Navigation data page. 8.1.1.Type1 Large LAT/LOT as (Fig.1.5.1). (*Editing the LAT/LOT is unavailable) 8.1.2. Type2 Various data as (Fig.1.5.2).
  • Page 50 8.2. Edit (*If there is no navigation data on the page, editing the navigation data is unavailable) ▶[MENU]->Advance->Setup->Customizing->Navigation data->Edit After finishing as (Fig.1.5.3), press [CANCEL] to exit. (*Please, refer “Customizing” for further question) (Fig.1.5.3) - 49 -...
  • Page 51 9.MOB If a person or missing an object overboard and you need to get present position, use the MOB function. 9.1. Inputing Keep pressing [WPT] until the window comes out as [Fig.1.6] and then “MOB” comes out with alarm. 9.2. Exiting the alarm When alarming, press [CANCEL] and you may exit the alarm.

  • Page 52: Memory Card

    10. Memory Card Inserting the SD, micro SD & USB OTG as (Fig.1.7.1). (Fig.1.7.1) - 51 -...
  • Page 53 11. Save Userdata ▶[MENU]->Userdata->Save Userdata Userdata is stored in the external Micro SD. So if you want to save the userdata, a micro SD must be inserted in the slot. (*Userdata is in “..\HY\UserData\”) 11.1. WPT WPT can be stored in a SD/Micro SD/USB. When storing, give it a name and you will be able to store many WPT’...
  • Page 54 Track can be stored in a SD/Micro SD/USB. When storing, give it a name and you will be able to store many tracks in the SD/Micro SD/USB. 11.3.2. Type2 Track can be stored in a SD/Micro SD/USB. Index will be a standard in Type2. After choosing the index, stored it. 11.4.
  • Page 55 12. Load Userdata ▶[MENU]->Userdata->Load Userdata Userdata loads from the stored SD/MicroSD/USB. If you need to load the userdata, the stored SD/MicroSD/USB must be inserted in the slot. (*Userdata is in “..\HY\UserData\”) 12.1. WPT WPT loads from the stored SD/MicroSD/USB. All of WPT in the SD/MicroSD/USB show on the list. Choose one of them and it will show. There are two ways to load WPT.
  • Page 56 12.3.Track 12.3.1. Type1 Track loads from the stored SD/MicroSD/USB. All of track in the SD/MicroSD/USB show on the list. Choose one of them and it will show. 12.3.2. Type2 Track loads from the stored SD/MicroSD/USB. Index will be a standard in Type2. After choosing the index, stored it. 12.4.
  • Page 57 - 56 -...
  • Page 58 Chartplotter getting started 1. GOTO 1.1. Goto type1 1.1.1. Setting ▶[MENU]->Navigation->Goto type->type1 Setting GOTO with creating a route at the same time. Move the cursor to the position where you want to go and press [ENTER]. (*While navigating, WPT can be added in the route) 1.1.1.2.
  • Page 59 2. WPT 2.1. List ▶[MENU]->Userdata->WPT->List Editing, creating, erasing and navigating are available on the WPT list. ② Selected ③ ④ ① ⑤ ⑥ ⑧ ⑦ ⑨ ① List Showing all of the stored WPT. ② Latitude/Longitude LAT/LOT of the WPT. ③...
  • Page 60 2.2. Setting the WPT symbol ▶[MENU]->WPT Symbol Selected(red color) Choose the symbol and press [ENTER]. The chosen symbol will show when inputting WPT. 2.3. Setting WPT Color ▶[MENU]->WPT Color Selected(red color) - 59 -...
  • Page 61 Choose the color and press [ENTER]. The chosen color will show when inputting WPT. 2.4. Creating 2.4.1. Creating on the list ▶[MENU]->Userdata->WPT->List->[2.Add] Adding WPT with pressing [2.Add]. (*When adding, LAT/LOT show the present position and current symbol/color show for the WPT) 2.4.1.
  • Page 62 2.6 Erasing all of WPT ▶[MENU]->Userdata->WPT->List->[5.All Erase] On the WPT list, press [5.All Erase]. 1. Erase all: Choose “ALL” of symbol and color and “Erase” and Enter. 2. Erase by color and symbol: Choose the color and the symbol and “Erase” and Enter. Selected (Fig.1.8.) 2.7.
  • Page 63 3. Move the WPT to the position where you want to move, and press [ENTER]. 2.8. Navigating 2.8.1. Navigating on the list ▶[MENU]->Userdata->WPT->List->[6.Goto] Choose the WPT on the list and press [6.Goto]. 2.8.2. Navigating on the chart Call the cursor and move it on the WPT, and press [ENTER]. Choose “GOTO” to start. 2.8.2.
  • Page 64 2.9. Move to vessel Call the cursor and move the WPT and Enter. Choose “Move to vessel”. 2.10. Sorting ▶[MENU]->Userdata->WPT->List->[4.Sort] Sorting the order of WPT on the list. - 63 -...
  • Page 65 - 64 -...
  • Page 66 2.11. Editing ▶[MENU]->Userdata->WPT->List Editing the WPT on the list. Edit Selected WPT Selected 1. Choose the WPT as the blue and press [ENTER]. 2. Choose the item as the green and you may begin to edit. 3. After finishing, press [CANCEL] to exit. - 65 -...
  • Page 67 3. Route 3.1. List ▶[MENU]->Userdata->Route->List ③ ② ④ ⑤ ⑥ ① ⑦ ⑧ ① List Showing the stored WPT ② Name Name of the route ③ Number of WPT Number of WPT in the route ④ Total distance Total distance of the route ⑤...
  • Page 68 3.2. Route detail ▶[MENU]->Userdata->Route->List->[4.Detail] ② ③ ④ ① ⑤ ⑥ ⑦ ⑧ ⑨ ① List Showing the stored WPT ② Latitude/Longitude LAT/LOT of the WPT ③ Name Name of the WPT ④ Date & Time Date and time of the WPT when stored ⑤...
  • Page 69 3.3. Creating Two ways to create route The first uses “GOTO type1” and the second is “Creating new route” on the list. 3.3.1. Using “GOTO” Use “GOTO type1” and create a route. Press [ENTER] to start. Press [GOTO] to exit and choose “Store” if needed. 3.3.2.
  • Page 70 3.4. Edit ▶MENU->Userdata->Route->List Choose the route on the list to edit. 3.5. Detail edit ▶[MENU]->Userdata->Route->List->[4.Detail] Choose the route on the list and press [4.Detail]. The window of Route detail shows. 3.5.1. Adding WPT Two ways to add WPT 3.5.1.1. Adding the stored WPT ▶[MENU]->Userdata->Route->List->[PAGE]->[2.Saved WPT] (Fig.2.1) - 69 -...
  • Page 71 Press [2.Saved WPT] on the Route detail and you may add the stored WPT as (Fig.2.1). 3.5.2.1. Adding new WPT Press [3.New WPT] on Rout detail and you may add new WPT. 3.5.3. Erasing WPT Choose the WPT and press [4.Erase]. 3.6.
  • Page 72 4.2.4. Setting the distance interval ▶[MENU]->Userdata->Track->Track Setup->DIST Interval Setting the distance interval. 4.3. Setting the thickness ▶[MENU]->Userdata->Track->Track Setup->Thickness Setting the track thickness. 4.4. Track Color ▶[MENU]->Track Color Selected(red color) Choose the color and press [ENTER]. (* The number next the color shows the number point of the track color) 4.5.
  • Page 73 4.5. 2. Erasing all of track ▶[MENU]->Userdata->Track->Erase Press [1.All Erase]. 4.5. 3. Erase with cursor ▶[MENU]->Userdata->Track->Erase->Partial Erase Choose [2.Partial Erase]. Long press where you want to start erasing the track. (*1 should show on the left top.) - 72 -...
  • Page 74 Choose the end of the track to erase. - 73 -...
  • Page 75 5. Measuring the distance and bearing 1. Measuring two points, “A” and “B”. 2. Call the cursor and move it on the point, “A”. 3. After Enter, calculating the distance/BRG. 4. Move the cursor on the point, “B”. 5. The cursor windows provides the distance and bearing between A and B. 6.
  • Page 76 6. User Line Adding lines directly on the chart. 1. Call the cursor. 2. Press [ENTER] and “User Line” shows. 3. Move the cursor to the beginning point and press [ENTER]. 4. Keep moving the cursor and press [ENTER] each time. 5.

  • Page 77: User Name

    7. User Name Adding a place name directly on the chart. 1. Call the cursor and move it to the point. 2. Press [ENTER] and choose “User Name”. 4. Inputting letters with [◀][▶][▼][▲]. 5. Press [CANCEL] to exit. - 76 -...

  • Page 78: Map Orientation

    Chartplotter operation 1. Map Orientation ▶[MENU]->Advance->Map Setup->Map Orientation 1.1. True Motion ▶[MENU]->Advance->Map Setup->Map Orientation->True motion The True Motion is in the way the vessel position is presented. In True Motion mode, the vessel icon moves over the map while the map remains stationary. (* It is not available to operate on Course up and Head up.) 1.2.

  • Page 79: Map Setup

    2. Map setup ▶[MENU]->Advance->Map Setup 2.1. Map orientation 2.1.1. True motion You can select “True motion” (☞ The default setting is OFF.) 2.1.2. Up mode You can select “Map Orientation” (☞ The default setting is North Up.) 2.2. UserData Display You can set up shown/hide the user data on the display.
  • Page 80 - Multimedia: turns On or Off Multimedia which allows assigning one or more image to any chart object, such as high definition pictures of ports, piers, bridges diagram... 2.4.1.2. Marine Setting The Marine Settings menu controls the display on the chart of the marine features. - Tides &...
  • Page 81 This feature has preprogrammed settings which allow to customize the look of the cartographic pages. 2.4.2.1. Presentation Setting You can select and configure the chart symbology and palette. - US: draws the chart using US symbology - International: draws charts using International symbology (☞...
  • Page 82 You can set the alpha value of the overlaid image.. 2.4.4. 3D 2.4.4.1. 3D View You can turn on/off the 3D view. (☞ The default setting is off.) 2.4.4.2. Draw Mode You can set the draw mode of the 3D view.. (☞...
  • Page 83 ( The default setting is 270.) 3.3. Vessel style (Circle/Arrow/Vessel) Select the vessel symbol among Circle, Arrow and vessel. (☞ The default setting is circle.) 3.4. Orient. Resolution Sets you preferred Rolling Road Scale. ( The default setting is 0.) 4.
  • Page 84 ( The default setting is OFF.) 5.2.2. Anchor Radius: If you vessel is out of the range of the anchor, it gives you notice with alarm. ( The default setting is 0.05nm.) 5.3. Interval 5.3.1. Interval Alarm: It alarms every time you set. ( The default setting is OFF.) 5.3.2.
  • Page 85 - 84 -...

  • Page 86: What Is Ais

    AIS getting started 1. What is AIS? AIS is an Automatic Identification System. It has been introduced to improve the safety of navigation by assisting in the efficient operation of ship to ship, ship reporting and VTS applications. The system should enable operators to obtain information from the ship automatically, requiring a minimum of involvement of ship’s personnel, and should have a high level of availability.
  • Page 87 color to red color. Target Sleeping Target located outside the Activation Range. Sleeping target is represented by a small oriented triangle. Target Lost Target When the AIS info is not received from that vessel. The presentation will be marked X on the target. 3.

  • Page 88: Quick Info On Ais Target

    4. Quick INFO on AIS target Choose “AIS information window” on (Fig.3.1) and AIS data shows under the AIS target. (*Up to four kinds of data is available to choose in Quick INFO) - 87 -...

  • Page 89: Ais On/Off

    AIS operation ▶[MENU]->AIS 1. AIS On/Off Turns the display of AIS targets overlay on the screen On or Off. ( The default setting is On.) 2. List Selected(blue color) 2.1. List ④ ⑤ ⑥ ① ② ③ ⑦ (Fig.3.2) ① Name Name of the AIS target ②...

  • Page 90: 2.2. Detail

    2.2. Detail Choose the AIS target and press [ENTER]. 2.3. Goto Choose the AIS target and press [4.Find]. - 89 -...

  • Page 91: Ais Target Size

    2.4. Sort Press [3.Sort] to choose how to sort on (Fig.3.2). 3. Display radius Displays range rings centered on your current position. (☞ The default setting is OFF.) 4. AIS target size Choose the size of AIS tartget. (☞ The default setting is Large.) - 90 -...

  • Page 92: Display Vessels By Color

    5. Display vessels by Color Different types of AIS transmissions can be selected to display different colors of icons on the chart display. 6. Display vessels by Type Different types of AIS transmissions can be selected to display different types of icons on the chart display.

  • Page 93: 10.1. Labels On Vessels

    (☞ The default setting is OFF.) 8.7. Ignore Vessels if Speed Less If you want the alarms to ignore vessels that are travelling at less than a particular speed then switch 8.8. Speed less than The values allowed are from 0.1kt to 9.9kt. 9.

  • Page 94: 10.4. Test View

    ★ AIS SART Messages If an AIS SART message is received it will immediately be displayed on whatever screen you are viewing. If the “Status” shows “Test” then no further action is required as it is just a test transmission. If the “...
  • Page 95 - Highlight : Showing the registered MMSI of AIS targets with the chosen color/symbol. - Only : Showing the registered MMSI AIS targets only. 10.7.2 List Add/Erase MMSI of AIS targets for group fishing. 10.7.3. Vessel Symbol Choose the symbol of MMSI of AIS targets for group fishing. 10.7.4.

  • Page 96: Choosing The Frequency

    Sonar getting started 1. Choosing the frequency In dual frequency mode, choosing the frequency with [▲][▼]. (*The chosen frequency shows in red) Selected 2. Auto/Manual Gain Press [ENTER] to choose” AUTO/Manual” of Gain. 3. Gain/STC Choose “Gain” and “STC” with [◀][▶]. 4.

  • Page 97: Controlling Stc

    5. Controlling STC 1. Choose the frequency. 2. Choose the STC. 3. Twisting the rotary key to control the STC. 6. Mode ▶[MENU]->Mode Three kinds in Sonar. 6.1. Normal Normal mode (with Auto Range active) displays the sounder image with the surface at the top of the screen and the sea bottom in the lower part of the screen.
  • Page 98 distance. The sea bottom contour is displayed and additional contour lines are added at intervals above the sea bottom to aid in determining distances of echoes near the bottom. Use the Sounder Menu to set the magnified Bottom Range from 2.5 to 20m (10 to 60ft.). Default setting is 10m (40ft.). If the depth Range is set manually, the setting must place the sea bottom echo in the lower portion of the screen for Bottom Zoom to be effective.
  • Page 99 zoom or lock. 7. VRM ▶ [WPT] The VRM (movable marker) shown by the green line can be moved up and down. It is convenient to measure the depth by aligning with the target such as school of fish. [Fig.2.1] - 98 -...

  • Page 100: Sonar Operation

    Sonar operation 1.Menu ▶ [MENU] 1.1. Userdata It is same as Chartplotter. PLS refer the Chartplotter operation manual. 1.2. Deep Depth Range Smart4/5 selects the best condition for measuring the depth automatically in the environment of the sea. ( The default setting is Auto.) 1.3.

  • Page 101: Advanced Menu

    When there are another boats around you on sailing, your Fish finder could be disturbed to work. The step of the function is from off to level 2. The bigger number, the more rejection. ( The default setting is OFF.) 1.9.
  • Page 102 ( The default setting is Hidden.) 2.1.7.TEMP Font Select the temperature font size on the screen. ( The default setting is Large.) 2.1.8. Image Filtering This function is reduction of the noise. (☞ The default setting is On.) 2.2. Color 2.2.1.
  • Page 103 2.5.1.1. Deep Depth Alarm It alarms when the set deep depth is out of the range. ( The default setting is OFF.) 2.5.1.2. Deep Depth Range Setup the range of deep depth alarm (☞ The default setting is 0M.) 2.5.1.3. Shallow alarm It alarms when the set shallow depth is out of the range.
  • Page 104 display is shown) (☞ The default setting is 50m.) 2.5.3.4. Alarm Interval If the the alram is on, It is available to setup the alarm interval. (☞ The default setting is middle) 2.5.3.5. Color Level If the the alram is on, It is available to setup the color level. It is available to setup the color level 2.6.
  • Page 105 - 104 -...

  • Page 106: General Operation

    General operation 1.GPS It is available to control and confirm information in GPS receiver. 1.1. Coordinate System It sets coordinate system of GPS or Loran. (☞The default setting is GPS.) 1.2. Datum It shows GPS Datum. WGS-84, which is the worldwide standard is only available. (☞...
  • Page 107 (☞ The default setting is incorrect every the country.) 1.8. LAT/LON Unit It is to select the number of the unit for Lat/Lon. (☞ The default setting is 4 unit.) 1.9. Receiving Port It is to select Inter receiver Internal, External and AIS. (☞...
  • Page 108 2.2.2. Variation There could be a difference between the magnetic compass and the GPS compass. An error depends upon your area. 2.3. Time & Date 2.3.1. Reference Available to adjust the collect local time by the UTC time from the GPS. ( The default setting is incorrect every the country.) 2.3.2.
  • Page 109 DESCRIPTIONS CONTENTS OF DATA FIELD DEFAULT $GPGGA Global Positioning System Fix Data $GPVTG Course and Ground Speed $GPZDA Time and Date $GPRMB Recommended minimum navigation information $GPRMC Recommended Minimum Specific GPS/TRANSIT DATA $GPAPB Heading/track controller (Autopilot) sentence B $GPXTE Cross-track error, measured $GPBOD Bearing, origin to destination $GPBWC...
  • Page 110 2.7.1.2. Position Setting up up/down the position of databar on the display. (☞ The default setting is Down.) 2.7.1.3. Edit It customizes the data bar information. 2.7.1.4 Mode It is available to set up the data bar. - Customizing : It is selectable and modifiable the data bar by user. - GPS/HY/NAV: It is fixed data bar by default.
  • Page 111 (☞ Standard is Large) 2.7.5. Userdata 2.7.5.1. WPT 16 kinds of symbol and color. Choose the symbols and the colors. 2.7.5.1.1. Symbol Setup In 16 kinds of the symbols, you can choose as many as you want, and those will show on the WPT symbol window.
  • Page 112 3. Maintenance It is necessary to check the system or the version for maintenance and demonstrate Stella series with the simulators 3.1. Program Version It contains ID and the program version, and it has important information for maintenance and upgrade. 3.2.
  • Page 113 (*All user data will be deleted) 3.8. Wire LAN Setting the wire LAN IP. 4. Calendar It is available to check the solar/moon calendar and tide. 5. Others 5.1. Screen capture This is the function of save the current screen Note: The capture file is stored in external SD card.
  • Page 114 Data layout 1. Display Setting the data layout on the screen. Only available in “Shown”. (☞ Standard is Hidden) 2. EDIT 2.1. Move Available to move the layout data with drag and drop. Touch “EXIT” to finish. (*Available when more than one data layout on the screen) - 113 -...
  • Page 115 2.2. GPS Showing the layout, Position, SOG and COG. 2.3. Time&Date Showing the layout, Time and Date. 2.4. Userdata Display Showing the layout, WPT and Track.. 2.5. Fishfinder Showing the layout, Depth and Temp. 2.6. Unspecified Showing the layout, Voltage. - 114 -...
  • Page 116 NS-12 series General specification 1. Display Screen: 12.1inch Color LCD with LED backlight 2. Resolution: XGA (1024 X 7680 pixels) 3. Power Supply: DC 12V~36V(+-10%) 19W 4. Operating Temperature: -15°C~+50°C 5. Performance Standard: IMO Resolution MSC.112(73) 6. Option: SD/MicroSD/USB OTG, External GPS Antenna, Transducer, Remote control GPS Receiving specification 1.
  • Page 117 2. Frequency: 50 and 200 KHz (single or dual) 3. Output Power: 600W 4. Range speed: 600W : 2.5m ~ 600m 5. Image speed: Fixed 8 speeds (4/1, 2/1, 1/1, 1/2, 1/4, 1/8, 1/16, 1/32) and stop 6. Rejection: Interferences rejection:3 levels, Noise rejection:4 levels 7.
  • Page 118 NS-10 series General specification 1. Display Screen: 10.4inch Color LCD with LED backlight 2. Resolution: XGA(1024 X 768 pixels) 3. Power Supply: DC 12V~36V(±10%) 14W 4. Operating Temperature: -15°C~+50°C 5. Performance Standard: IMO Resolution MSC.112(73) 6. Option: MicroSD, External GPS Antenna, Transducer, Remote control GPS Receiver specification 1.
  • Page 119 2. Frequency: 50 and 200 KHz (single or dual) 3. Output Power: 600W 4. Range speed: 600W : 2.5m ~ 600m 5. Image speed: Fixed 8 speeds (4/1, 2/1, 1/1, 1/2, 1/4, 1/8, 1/16, 1/32) and stop 6. Rejection: Interferences rejection:3 levels, Noise rejection:4 levels 7.
  • Page 120 Customizing items LAT/LOT of the present position. (Red: out of GPS service/Black: GPS on service/Blue: SBAS or DGPS on service) (Speed Of Ground) Boat speed. (Course Of Ground) Boat direction. DATE Date of today. TIME Present time. HDOP Horizontal Dilution Of Precision. PDOP Position Dilution Of Precision.
  • Page 121 - 120 -...
  • Page 122 - 121 -...
  • Page 123 - 122 -...
  • Page 124 Defects will be corrected during normal working hours by an authorized SI-TEX Marine Electronics Inc. dealer, service center, or at the SI-TEX office in Riverhead, NY. There will be no charge for labor for a period of one year from the date of purchase, except as provided below under Limited Warranty Exceptions.
  • Page 125 VHF radio are items excluded from the two-year warranty and are covered by warranty for a period of one year for both parts and labor. SI-TEX Marine Electronics Inc. will not, at any time, assume any costs or labor charges for checkout or external line fuse replacement or problems not found to be at fault in equipment itself.
  • Page 126 If you encounter problems during the installation or operation of this product, or cannot find the information you need, please contact SI-TEX Customer Service. The contact numbers and e-mail address for SI-TEX Customer Service are: SI-TEX Main Office…….………..+1-631-996-2690 SI-TEX Fax..………………….…..+1-631-996-2693 SI-TEX Service E-mail address: service@si-tex.com...
