Page 1 TABLE OF CONTENTS General Information ModLock™ Connector Disassembly Outlaw / Rogue Components Waistband Extender ModLock™ Connectors Double Cylinder Setup Waistband / Shoulder Strap Assembly Anchorline Retainer Aircell Assembly BC Specifications Weight Pocket Assembly Outlaw / Rogue © 2017 Aqua Lung International...
Page 2: Copyright Notice
Aqua Lung International ® GENERAL INFORMATION General information can be found in the Buoyancy Compensator User’s Guide that has been provided with this product. The Buoyancy Compensator User’s Guide is also available on the Aqua Lung website ® at www.aqualung.com...
Page 3 Table of Contents OUTLAW / ROGUE COMPONENTS Dump Valve (Rogue Only) Anchorline Retainer Shoulder Straps Aircell Harness Waistband Waistband GripLock ™ Tank Band Waistband Trim Weight SureLock ™ Extender Pocket Weight Pocket © 2017 Aqua Lung International...
Page 4 (Rogue Only) Waistband Connector Waistband Connector (Female) (Female) Waistband Connector Waistband Connector SureLock or Trim Weight (Male) (Male) Pocket Connector (Dual Female) Trim Weight SureLock Weight ™ Pocket Connector Pocket Connector (Dual Male) (Dual Male) © 2017 Aqua Lung International...
Page 5 Place the male connector on the waistband over the female connector on the harness and slide it into place. An audible “click” will confirm the connectors are locked, securing the waistband in place. © 2017 Aqua Lung International...
Page 6 An audible “click” will confirm the connectors are locked, securing the shoulder strap in place. AIRCELL ASSEMBLY 1. Unclip the upper tank strap and separate the hook and loop tabs on the retainer. Unbuckle the tank band and lay it out across the harness. © 2017 Aqua Lung International...
Page 7 3. Insert each side of the tank band through the lower slots in the aircell. Attach the lever to the bail securing it in place. © 2017 Aqua Lung International...
Page 8 To attach the pull dump cord, insert the male end into the female end of the T-Lock connector and twist to secure the cord in place. To test the connection, pull down on the knob to make sure the dump valve activates. © 2017 Aqua Lung International...
Page 9 ™ When attaching the SureLock weight pockets ensure the release handle is pointed downward. Trim ™ weight pockets can face either direction. SureLock Weight Pocket Trim Weight Pocket ™ © 2017 Aqua Lung International...
Page 10 The SureLock weight pocket must be attached with the handle facing downward in ™ order to release properly. 3. To release the SureLock weight pouches ™ simply pull on the handle. Trim weight pockets are non-releasable. © 2017 Aqua Lung International...
Page 11 ModLock connector may disengage. This circumstance will not ™ occur on the SureLock or trim pocket weight system because of the dual ModLock connection. ™ ™ Alignment Hole © 2017 Aqua Lung International...
Page 12 WAISTBAND EXTENDER An optional waistband extender with pocket is available that will provide an extra 8 inches (20 cm) of length to the waistband of the BC. © 2017 Aqua Lung International...
Page 13 Such an event while diving may separate you from your primary air source, and could lead to serious injury or death. ANCHORLINE RETAINER This BC comes equipped with an anchorline retainer for attaching an alternate air source. © 2017 Aqua Lung International...
Page 14 10 lb / 4.5 kg X 2 NOTE: The Outlaw BC uses a 12 lb or 25 lb aircell and the Rogue a 35 lb aircell. A right shoulder dump valve with detachable cord is used on the 35 lb aircell and is therefore not interchangeable with the Outlaw BC.
