ContourU™/ Silhouette™Seating Systems
Installation Instructions
SAVE THESE INSTRUCTIONS
NOTE: Check all parts for shipping damage. In case of shipping damage, DO NOT use. Contact carrier/dealer for further
instruction.
Safety Summary
To ensure the safe installation, operation and use of the seat, these instructions MUST be followed:
WARNING
DO NOT use this product or any available optional equipment without first completely reading and
understanding these instructions and any additional instructional material such as owner's manuals,
service manuals or instruction sheets supplied with this product or optional equipment. if you are
unable to understand the warnings, cautions or instructions, contact a healthcare professional, dealer
or technical personnel before attempting to use this equipment - otherwise, injury or damage may
.
occur
After any adjustments, repair or service and before use, make sure all attaching hardware is
tightened securely. Otherwise, injury or damage may occur.
If the seat and/or back does not fit the user properly, DO NOT use. Contact Invacare for proper
instruction, otherwise injury to the user may occur.
The best way to avoid problems related to pressure sores is to understand their causes and your role
in a skin management program.
Your therapist and physician should be consulted if you have any questions regarding weight relief,
self-examination of skin, or individual limitations and needs.
All cushions used for the prevention or treatment of decubitus ulcers (pressure sores) should be
selected carefully. Working with your therapist, physician and cushion supplier is the best way to
assure that a cushion choice matches your individual needs.
As the needs of the client become more complex, the cushion evaluation becomes more important.
Skin condition should be checked very frequently after the provision of any new seating system.
With regard to seat/chest positioning straps – it is the obligation of the DME dealer, therapists and
other healthcare professionals to determine if a seat/chest positioning strap is required to ensure the
safe operation of this equipment by the user. Serious injury can occur in the event of a fall from a
wheelchair.
Stabilize from the ground up. A stable base, pelvis and footrests are requirements for any torso
positioning system.
The position of back angle, rear wheels, seat depth and wheel locks are directly related to wheelchair
stability. Any change to one or any combination of the four may cause the wheelchair to decrease in
stability. Use extreme caution when using a new seating position.
ALWAYS make sure wheelchair is stable before reclining the back system. Refer to the Owner's
Manual provided with the wheelchair.
To maintain the stability of the wheelchair when moving the rear wheels to ANY forward position,
the amount of recline MUST be limited to prevent the wheelchair from tipping onto the anti-tippers.
The necessary back angle MUST be selected before repositioning rear wheels forward.
ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested by
Invacare and are not recommended for use with Invacare products.
1
Part No 1154276
ContourU™/ Silhouette™Seating Systems

Advertisement

loading
Need help?

Need help?

Do you have a question about the ContourU and is the answer not in the manual?

Questions and answers

Summary of Contents for Invacare ContourU

  • Page 1 After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely. Otherwise, injury or damage may occur. If the seat and/or back does not fit the user properly, DO NOT use. Contact Invacare for proper instruction, otherwise injury to the user may occur.
  • Page 2: Product Description

    The cover is designed to protect the foam against a user’s incontinence and to provide fire retardation, so the cushion must not be used without its cover. If the cover is torn, it must be replaced. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 3 DO NOT overtighten the set screws. Otherwise damage may occur. 3/4-inch diameter cane 6. Slide the assembly to the desired position and  tighten the set screws. 7. Repeat STEPS 3‐6 to attach the other three  FIGURE 1 Installing Back Cane Hardware Kwik Fit assemblies to the back canes. Assemblies - Kwik Fit Assemblies 8. Make sure that the assemblies at the top and  bottom of the of the back canes are lined up  horizontally. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 4 CAUTION DO NOT overtighten the set screws. Otherwise damage may occur. 3/4-inch diameter cane 8. Slide the assembly to the desired position and  tighten the set screws. 9. Repeat STEPS 5‐8 to attach the other three  HWBAK assemblies to the back canes. FIGURE 2 Installing Back Cane Hardware Assemblies - HWBAK Assemblies 10. Make sure that the assemblies at the top and  bottom of the of the back canes are lined up  horizontally. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 5 1. Follow the procedures in the Shape Sensor Owner’s Manual to determine where the Kwik Fit back will  attach to the wheelchair back canes. CAUTION DO NOT overtighten the set screws. Otherwise damage may occur. 2. If necessary, adjust the position of the Kwik Fit assemblies on the back canes. Tighten the set screws  when adjustments are complete. 3. Position the Kwik Fit back on the wheelchair in the position determined in STEP 1. 4. Determine the mounting positions of the four adjustable mounting brackets. Make note of which holes  to use to best fit the user. NOTE: Refer to Detail ʺBʺ of FIGURE 3 for position options.  5. Attach the adjustable mounting bracket guide to the adjustable mounting bracket with two socket cap  screws. DO NOT tighten the socket cap screws. 6. Insert the adjustable mounting bracket guide into the slot on the side of the Kwik Fit back and slide the  bracket into the position determined in STEP 3. Tighten socket cap screws. 7. Repeat STEPS 5 and 6 to install the other three adjustable mounting brackets. NOTE: When installed properly, there will be two adjustable mounting brackets on each side of the wheelchair. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 6 DETAIL “A” - ADJUSTABLE MOUNTING BRACKET OPTIONS NOTE: The dashed lines represent the back cane relative to the adjustable mounting bracket position. Front of wheelchair DETAIL “B” - INSTALLING THE KWIK FIT BACK ONTO THE WHEELCHAIR Quick-Lock Bracket TO OPEN ‐ Flip UP  TO CLOSE ‐ Flip DOWN Kwik Fit Back Back Cane Mounting Bracket FIGURE 3 Installing the Kwik Fit Back Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 7 Installing the Back Cushion Pan Base NOTE: For this procedure, refer to FIGURE 5. 1. Put the back cushion pan onto the wheelchair.  Put the top of the back cushion pan in place in  the clamp bases at the top of the back canes. Stainless Steel 2. Push the bottom of the back cushion pan toward  Back Pins the Snap‐lock clamps on the bottom of the back  Cane canes. Lift the back cushion pan up about  1/2‐inch and push down to “snap” the stainless  steel pins in place in the Snap‐lock clamps. NOTE: To remove the back cushion pan from the  Snap-Lock wheelchair, reverse STEPS 1 and 2. Clamp BOTTOM FIGURE 5 Installing the Back Cushion Pan Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 8 Button Head up the L‐brackets with the clamp bases on the  Cap Screws back canes. FIGURE 6 Wood-mounted 6. Adjust/recline the back cushion until the desired  Back Cushion Hardware back angle is reached. Make note of the holes in  the L‐brackets that line up with the clamp bases  at the desired angle. Remove the back cushion  from the wheelchair. 7. Thread one stainless steel pin into each  L‐bracket in the holes determined in STEP 6  using the 9/64 hex key wrench supplied in the  kit. Installing the Wood-mounted Back Cushion 1. Put the stainless steel pins in the Short L‐brackets onto the clamp bases. 2. Push the bottom of the back cushion toward the Snap‐lock clamps on the bottom of the back canes. Lift  the back cushion pan up about 1/2‐inch and push down to “snap” the stainless steel pins in place in the  Snap‐lock clamps. NOTE: To remove the wood‐mounted back cushion from the wheelchair, reverse STEPS 1 and 2. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 9 Damage to the cushion may result. Socket Head Cap Screws 5. For each mounting bracket, place the lanyard  and detent assembly on one of the socket head  cap screws.  6. At each location, attach the mounting bracket to  Lanyard and Detent Pin Assembly the board with two socket head cap screws. FIGURE 7 Attaching a Wood Mount Board to the Wheelchair Seat Rails Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 10 Detent Pin holes of the seat pan and through the mounting  (insert in the direction show) hole of the bracket. Put a hex nut onto the cap  FIGURE 8 Attaching a Seat Pan to the Wheelchair screw. DO NOT tighten the hex nut. Seat Rails 7. From underneath the seat pan, insert the detent  pin through the holes in the bracket. NOTE: Use the innermost holes to attach the lanyard  to the seat pan. Make sure to attach the lanyard close to  the mounting bracket. 8. Attach the lanyard to the seat pan with a cap  screw and hex nut. 9. Tighten the hex nuts. 10. Repeat STEPS 6 and 9 at each bracket location. Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 11: Installing The Seat Cushion

    Exercise caution when transferring in and out of the wheelchair, especially if the wheelchair is not equipped with hook and loop fasteners. 4. Secure cushion to the seating surface, making sure that the hook and loop fasteners are securely  attached to the seating surface and the cushion.  NOTE: If the wheelchair seating surface has neither hook or loop attachment strips, remove the double sided hook  from the bottom of the cover. Seat Cushion Seating Surface FIGURE 9 Installing the Seat Cushion Part No 1154276 ContourU™/ Silhouette™Seating Systems...
  • Page 12: This Warranty Shall Be Extended To Comply With State/Provincial Laws And Requirements

    Invacare warrants its product to be free from defects in materials and workmanship for the period of two years of use by original purchaser except for the cover, which is warranted for a period of 90 days of use by the original purchaser.
