Damit Sie Ihren Rollstuhl optimal nutzen können, lesen Sie die
D
Gebrauchsanleitung vor dem Rollstuhleinsatz genau durch.
Inhalt
- Uebersicht
- Sicherheit
- Bedienung
- Bremsen
- Einstellmöglichkeiten
- Zubehör
- Wartung & Pflege
- Technische Daten
- Gewährleistungspflichten
To ensure that you can make the best use of your wheelchair,
GB
please read the instructions thoroughly.
Contents
3
4
5
7
9
13
17
18
21
25
26
27
29
31
35
39
40
43
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Invacare Ultra-Light Neo
Summary of Contents for Invacare Ultra-Light Neo
-
Page 1: Table Of Contents
Damit Sie Ihren Rollstuhl optimal nutzen können, lesen Sie die Gebrauchsanleitung vor dem Rollstuhleinsatz genau durch. Inhalt - Uebersicht - Sicherheit - Bedienung - Bremsen - Einstellmöglichkeiten - Zubehör - Wartung & Pflege - Technische Daten - Gewährleistungspflichten To ensure that you can make the best use of your wheelchair, please read the instructions thoroughly. -
Page 2: Summary
Compact Plus Backrest upholstery Tipper aid Wheelhub with floating axle Ultra-Light Neo Küschall Compact Contact Hemi Küschall Kid Quality policy Our primary mission is, through modern technology, to accelerate the rehabilitation process of customers with individual profiles and to enhance their mobility and independance. -
Page 3: Safety
Safety Please adhere closely to the following safety instructions: Weight limitations Maximum load: 120 kg (60 Kg for Kid Neo). Pneumatic air pressure / Brakes characteristics Sufficient air pressure should be kept in the tyres in order to maintain a good performance of the brakes Observe a weekly check of the tyre pressure! Types of tyres... -
Page 4: Using The Wheelchair
Always tighten all screws and nuts firmly after each adjustment. Screws may come slightly loose with time, especially when the wheelchair is in constant use; we therefore advise you (or your Küschall/Invacare dealer) to control the tightness of the screws monthly. - Page 5 Unfolding the wheelchair Tip the wheelchair slightly to one side so that the load is taken from one driving wheel. Then with your other hand push one of the seat tubes downwards - the wheelchair unfolds. Let the wheelchair go again so that it rests on all four wheels.
-
Page 6: Brakes
CAUTION: Make sure that the axles are well engaged and that the axle knob is not pressed down. Check by pulling the wheels outwards. Removal Release the brakes. Hold the wheel around the hub, through the spokes with one hand. Press the axle knob with your thumb and slide the wheel out of the axle plate socket. - Page 7 Standard brakes Actioning the brakes: push the brake handle down as far as the stop. Releasing the brakes: pull the brake handle back into vertical position. Pull brakes The models with removable leg supports are, for safety reasons, only fitted with the pull brake so that if the leg supports swing back the brake cannot be released.
-
Page 8: Settings And Adjustments
Settings and adjustments We advise you to call upon your Küschall / Invacare dealer for any change or adjustment made on your wheelchair. Every Küschall wheelchair is made-to-measure, according to the detail given on the prescription form. A comfortable and energy sparing drive can however depend on small adjustments which can only be carried out once the wheelchair user has tried out his wheelchair. - Page 9 Bottom tube adjustment with the Clamping System In order to adjust the height of the footrest slacken the hexagon head socket screw with the 5mm Allen key. Adjust the bottom tube length by smoothly sliding it along the frame tube and re- tighten the screw.
- Page 10 Slacken the front wheel axle (13mm open-ended spanner, steadying with 13mm open-ended spanner) and place the castor to the desired height. ULTRA-LIGHT NEO Tête de fourche Tête de fourche orientée vers le haut orientée vers le ba...
- Page 11 Octogonal Excentrique à 8 pans ULTRA-LIGHT NEO with titanium or Carbon front frame Since the bearing blocks are fixed, no adjustment is possible. Therefore, ensure that the seat angle of the wheelchair is always 4.2 +/- 1.5cm (seat angle = seat height at front - seat height at back).
-
Page 12: Accessories
Accessories Backrest angle adjustment Slide the bottom of the backrest upwards on the Hinge Fulcrum Point backrest tube - 2 hexagon socket screws will d'articulation appear. Unscrew the bottom one completely (5mm Angle position Allen key). The backrest angle can be set in one of Position de for 3°... - Page 13 Height-adjustable push handles, mounted back Thanks to its height adjustability, this option enables your companion to push the wheelchair comfortably. Because the push handles are set backwards, the user's shoulders will benefit from more freedom of movement. This is important for the mobility and independance of the user. Height adjustment Loosen the locking handle, adjust the push handles to the desired height and tighten the locking handle firmly.
- Page 14 Clothes guard / Fixed mudguard clothes Kleider- guard schutz The clothes guard is fixed to a supporter plate. You can adjust it as follows: loosen the 2 screws (spanner 8mm or 10mm and Allen key 3mm). Level the clothes guard with the backwheel and position it in front of the next available hole.
- Page 15 With the design frame and on the Ultra-Light Neo, you can adjust the position of the tipper aid. Make sure not to adjust this position above the outer diamter of the rear wheel (can be dangerous when driving over a step) Swing-away anti-tip device This option stops the wheelchair from tiping backwards.
-
Page 16: Care And Maintenance
Care and maintenance In order to guarantee a good performance of your equipment, we advise you to carry out a carefull and regular check to your wheelchair. Do not use abrasive or heigh pressure cleaners on the wheelchair. Best is to wash it using a damp cloth or a bicycle spray. Dry your wheelchair thoroughly after a shower or a drive under the rain. -
Page 17: Technical Data
Technical data Ultra-Light Neo Legend: Standard (cm) Options(cm) Seat width 33/36/39/42/45/48 SH v Seat height front 50 39.7-55 SH h Seat height back 45 34-50.5 Seat angle variable Seat depth 30-50 Back height 37.5 31.5-48 (every 1.5) Total width SB+20... - Page 18 Compact Plus Legend: Standard (cm) Options (cm) Seat width 33/36/39/42/45/48 SH v Seat height front 50 43-55 SH h Seat height back 46 34-50.5 Seat angle variable Seat depth 30-50 Back height 37.5 31.5-48 (every 1,5) Total width SB+20 Total length approx.
- Page 19 Kid Neo Legend: Standard (cm) Options(cm) Seat width 27/30/33/36 SH v Seat height front 50 43-53.8 SH h Seat height back 46 38-50.5 Seat angle variable Seat depth 30-38 Back height 37.5 31.5-48 (every 1.5) Total width SB+20 Total length approx.
-
Page 20: Warranty Conditions
Standard terms This is to certify that your küschall design wheelchair is warranted by Invacare, for an unlimited period of time for the frame and crossbars and 12 months for all other parts. This warranty is subject to the following conditions: Only Küschall design wheelchairs purchased at full price are...
