Instance Attributes (Instance #20, QuickConnect)
This instance enables or disables the QuickConnect functionality from the application. Changes are valid
after reset or power cycle. The value of the QuickConnect attribute (#12) in the TCP/IP Interface ob-
ject (F5h), will change immediately.
QuickConnect has to be enabled in the Ethernet Host object (F9h) for this instance to be available.
See also ...
• "TCP/IP Interface Object (F5h)" on page 87
• "Ethernet Host Object (F9h)" on page 171
Extended
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Multilingual Strings
The instance names and enumeration strings in this object are multi-lingual, and are translated based on
the current language settings as follows:
Instance English
3 IP address
4 Subnet mask
5 Gateway
6 DHCP
Enable
Disable
7 Comm 1
Auto
10 HDX
10 FDX
100 HDX
100 FDX
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Access Type
Get Array of CHAR 'QuickConnect'
Get UINT8
Get UINT8
Get UINT8
Get/Set ENUM
Get ENUM
German
IP-Adresse
Subnetzmaske
Gateway
DHCP
Einschalten
Ausschalten
Komm 1
Auto
10 HDX
10 FDX
100 HDX
100FDX
Description
08h (= ENUM)
01h
07h (read/write/shared access)
Value Meaning:
00h Disable (default)
01h Enable
Holds the configured value, which will be written to attribute
#5.
Value Meaning:
00h Disable (default)
01h Enable
Spanish Italian
Dirección IP Indirizzo IP
Masac. subred Sottorete
Pasarela Gateway
DHCP DHCP
Activado Abilitato
Desactivado Disabilitato
Comu 1 Connessione 1
Auto Auto
10 HDX 10 HDX
10 FDX 10 FDX
100 HDX 100 HDX
100 FDX 100 FDX
107
French
Adresse IP
Sous-réseau
Passerelle
DHCP
Activé
Désactivé
Comm 1
Auto
10 HDX
10 FDX
100 HDX
100 FDX
