Page 1 User’s Manual AQ6373 Optical Spectrum Analyzer IM AQ6373-01EN 2nd Edition...
Page 2: Product Registration
Product Registration Thank you for purchasing YOKOGAWA products. YOKOGAWA provides registered users with a variety of information and services. Please allow us to serve you best by completing the product registration form accessible from our homepage. http://tmi.yokogawa.com/ PIM 103-03E...
Page 3 For correct operation, please read this manual thoroughly before use. After reading this manual, keep it in a convenient location for quick reference in the event a question arises during operation. There are two manuals for the AQ6373 including this one. Read them along with this manual.
Page 4 Checking the Contents of the Package After opening the package, check the following items before beginning use. If any of the contents are incorrect, missing, or appear to be abnormal, please contact your Yokogawa dealer or representative. AQ6373 Main Unit Check that the model and suffix code on the name plate on the rear of the instrument match those of your order.
Page 5: Safety Precautions
If the instrument is used in a manner not specified in this manual, the protection provided by the instrument may be impaired. Yokogawa Electric Corporation assumes no liability for the customer’s failure to comply with these requirements.
Page 6 • Do not Operate in an Explosive Atmosphere Do not operate the instrument in the presence of flammable liquids or vapors. Operation in such environments constitutes a safety hazard. • Do Not Remove the Covers or Disassemble or Alter the Instrument Only qualified YOKOGAWA personnel may remove the covers and disassemble or alter the instrument. Opening the cover is dangerous, because some areas inside the instrument have high voltages. • Installation Location • This instrument is designed to be used indoors. Do not install or use it outdoors. • Install the instrument so that you can immediately remove the power cord if an abnormal or dangerous condition occurs. IM AQ6373-01EN...
Page 7 0.275 CAUTION Operating Environment Limitations This product is a Class A (for industrial environment) product. Operation of this product in a residential area may cause radio interference in which case the user is required to correct the interference. IM AQ6373-01EN...
Page 8 Waste Electrical and Electronic Equipment Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC (This directive is only valid in the EU.) This product complies with the WEEE Directive (2002/96/EC) marking requirement. This marking indicates that you must not discard this electrical/ electronic product in domestic household waste. Product Category With reference to the equipment types in the WEEE directive Annex 1, this product is classified as a “Monitoring and Control instrumentation” product. Do not dispose in domestic household waste. When disposing products in the EU, contact your local Yokogawa Europe B. V. office. IM AQ6373-01EN...
Page 9 Bold characters used in the procedural explanations indicate characters that are marked on the panel keys or the characters of the soft keys displayed on the screen menu. Unit k: Denotes “1000.” Example: 100kS/s K: Denotes “1024.” Example: 459KB (file data size) IM AQ6373-01EN...
Page 10 Section 6.8 Searching Section 6.12 Waveform Analysis Waveform Analysis Section 7.1 to 7.9 GO/NO-GO Judgment Section 7.11 Saving Display Data and Printing Out Storage Media Section 8.1 Saving Data Section 8.2 to 8.8 Internal Printer(Optional) Section 4.6 viii IM AQ6373-01EN...
Page 11 Setting the Reference Level ................... 5-12 Center Wavelength (Center Frequency) Setting ............5-16 Index Sweep Width Settings ....................5-21 Wavelength (Frequency) Resolution Settings ..............5-25 Sampling Point/Interval Settings ..................5-28 Sensitivity Settings ......................5-30 5.10 Averaging Times Setting....................5-32 IM AQ6373-01EN...
Page 12 8.1 USB Storage Media ......................8-1 8.2 Temporarily Saving and Redisplaying Traces to and from Internal Memory ....8-2 8.3 Saving/Loading Displayed Data ..................8-6 8.4 Saving/Loading Displayed Data(All Trace) ..............8-22 8.5 Saving/Loading Setting Data ..................8-28 8.6 Saving/Loading Analysis Results Data ................8-33 8.7 Saving/Loading Program Data ..................8-41 8.8 Saving Screen Image Data .................... 8-47 8.9 Saving/Loading Template Data..................8-51 8.10 Creating Files ......................... 8-57 IM AQ6373-01EN...
Page 13 10.10 Warning Display Function ....................10-11 Chapter 11 Specifications 11.1 Specifications ........................11-1 11.2 External Dimensions .......................11-4 Appendix Appendix 1 Data Calculation Algorithms for Spectrum Widths ..........App-1 Appendix 2 Details of Each Analytical Functions ..............App-10 Appendix 3 Detailed Explanations of OSNR (WDM) Analysis Function ......App-17 Appendix 4 Details of Optical Filter Analysis Function ............App-26 Appendix 5 Soft Key Tree Diagram ..................App-31 Appendix 6 END USER LICENSE AGREEMENT ............... App-49 Index Index IM AQ6373-01EN...
Page 14 COPY Used to make hard copies of the screen through the internal printer (optional) FEED Used to feed recording paper OPTICAL INPUT Optical input connector CALIBRATION OUTPUT Reference light source optical output connector used for alignment adjustments Index IM AQ6373-01EN...
Page 15: Rear Panel
Power cord connector Connect the power cord to this connector VIDEO OUT (SVGA) Analog RGB video signal (SVGA-compliant) interface ETHERNET Ethernet Interface (10/100BASE-TX) USB interface Used to connect USB storage media or USB mouse External keyboard interface (PS/2) Exhaust holes IM AQ6373-01EN...
Page 16: Function Section
MARKER Index The MARKER key contains functions related to markers. PEAK SEARCH The PEAK SEARCH key contains functions for searching for peaks and bottoms in measured waveforms. ANALYSIS The ANALYSIS key contains functions related to measured waveform analysis. IM AQ6373-01EN...
Page 17: Data Entry Section
When you press the HELP key, a soft key menu of the currently displayed screen is displayed explanations. Soft keys for selecting the “MORE INFO” which indicate additional information are displayed by some soft keys in HELP screen. IM AQ6373-01EN...
Page 18 (right-most) character is removed, allowing entry of the correct character. Index By holding the BACK SPACE key down, you can erase the entire entry in the numeric keypad input area and make the numeric keypad input area disappear, returning it to the condition preceding numeric keypad input. IM AQ6373-01EN...
Page 19: Lcd Screen
Displays the statuses of main settings (When a setting is ON, its display is depressed, or is displayed with white on black background if the display colors are black and white.) Displays wavelength axis scale per DIV Displays sweep status (RPT=Repeat; SGL=Single; STP=Stop) Displays soft key menu (Displays markers and data analysis results.) IM AQ6373-01EN...
Page 20 1.4 LCD Screen Parameter display area Parameter input area OVERVIEW display screen (Only displayed when ZOOM function is used.) Displays sub-scale Index IM AQ6373-01EN...
Page 21: Power
FILE BACK SPASE PROGRAM ADVANCE SYSTEM ENTER OREMOTE UNDO/ HELP COPY FEED ENTER LOCAL OPTICAL INPUT CALIBRATION OUTPUT POWER GP-IB1 interface RS-232 interface Ethernet interface Control target Control target USB storage USB mouse USB 101 keyboard medium Index IM AQ6373-01EN...
Page 22: Measurement
Smoothing <<See section 5.17 for the operating procedure>> This function attenuates the noise in the measured waveform. By using the Smoothing function, areas on the waveform with a large amount of noise can be “smoothed out” when measured. IM AQ6373-01EN...
Page 23 The function is used in cases such as: when the light source’s level is fluctuating; when Index measuring a modulated signal of several kHz or less; when the waveform is disrupted and difficult to measure; when it is necessary to obtain even higher measurement sensitivity. IM AQ6373-01EN...
Page 24 The power per 1 nm is called the power density. The level axis of the AQ6373 indicates the absolute power per wavelength resolution. For example, if the resolution is set to 0.1 nm, the power per 0.1 nm will be displayed.
Page 25 Thus, the time after a sweep trigger signal is input until the sweep starts will fluctuate in the range of 5 ms. Trigger Output <<See section 5.16 for the operating procedure>> This function outputs trigger signals from the trigger output terminal on the rear panel of the instrument (only during sweeping). Index IM AQ6373-01EN...
Page 26 The Resolution Correction function is available when the resolution is set between 0.1nm and 10.0 nm. The Resolution Correction function is only available when the horizontal axis is in wavelength mode. It cannot be used in Frequency mode. IM AQ6373-01EN...
Page 27: Waveform Display
Therefore, the waveform on the screen is not overwritten. If you want to fix the waveform data of a trace, set the trace to FIX mode. The trace display at the side of the data area changes to “FIX.” Index IM AQ6373-01EN...
Page 28 Calculations are applied to mode peaks at or above the threshold value. The threshold value is set in the range of 0 to 99 dB (steps of 1). The trace display at the side of the data area changes to “PKCVFIT @”. IM AQ6373-01EN...
Page 29 If you select UP, it is assigned to the top. (Default) If you select LOW, it is assigned to the bottom. You can set trace B to G in the same manner as when setting trace A. IM AQ6373-01EN...
Page 30 You can also search for the next peak or bottom. There is also an auto search function that automatically performs peak/bottom searches each time sweeping is performed. It is very useful for purposes such as observing peak/ bottom level changes during repeat sweeping. 2-10 IM AQ6373-01EN...
Page 31 Chromaticity coordinate analysis (COLOR analysis) <<See section 7.8 for the operating procedure>> The COLOR analysis function performs a color analysis the active trace waveform using a color matching function, determines the chromaticity coordinates, and displays a chromaticity diagram. 2-11 IM AQ6373-01EN...
Page 32 Analysis in the Zoom Area <<See section 7.12 for the operating procedure>> You can specify the zoomed area as the analysis range. For example, there is a zoom area power measurement function. This function calculates totalized power between display scales. 2-12 IM AQ6373-01EN...
Page 33 For details, see the separate user’s manual, “Remote/Program Function.” Program (Separate Document) The program function allows you to control an external instrument without using a PC. The function uses Ethernet, RS-232, or GP-IB. For details, see the separate user’s manual, “Remote/Program Function.” Index 2-13 IM AQ6373-01EN...
Page 34: Installing The Instrument
• Do Not Apply Shock to the Instrument non-horizontal orientation, and do not drop the instrument from a height of 2 cm or more. This can adversely affect the accuracy of the internal monochromator and inhibit performance. Take great care when transporting the instrument, and use packaging with a shock absorbing capacity that is greater than or equal to the packaging used upon shipment from the factory. Never use inferior packaging materials that are unable to sufficiently absorb vibrations and shocks occurring during transport. This can adversely affect the accuracy of the internal monochromator and inhibit performance. • When unpacking When the instrument is packaged in a box and moved, prevent condensation by allowing sufficient time for the instrument to acclimatize before removing it from the box. Installation Conditions Install the instrument so that the following conditions are met. Flat Horizontal Location Place the instrument in a stable location that is flat in all directions. If the instrument is used in an unstable or angled surface, the accuracy of the internal monochromator can be compromised. Location without Vibration Do not install the instrument in a location subject to vibration. Use in a location that experiences large vibrations can lead to instability of operation, measurement stopping Index before completion, or notable decreases in accuracy of the wavelength and level axes. Well Ventilated Location Ventilation holes are present at the sides and rear of the instrument. To keep the internal temperature from rising, always maintain a gap of 200 mm or more between the ventilation holes and the installation surfaces. IM AQ6373-01EN...
Page 35 When removing dirt from the case or operation panel, disconnect the power to the circuits under test and the instrument, remove the instrument’s power cord from the power outlet, then wipe gently with a clean, dry cloth. Do not use volatile chemicals since this might cause discoloring and deformation. IM AQ6373-01EN...
Page 36: Usb Interface
Connect the PS/2 mouse to the PS/2 terminal on the keyboard. Note The default for the PS/2 terminal is the keyboard. To attach a PS/2 mouse directly without going through the keyboard requires a splitter cable. For instructions on using the mouse, see section 4.2. Index IM AQ6373-01EN...
Page 37 (RS-232) KBD connector VIDEO OUT ETHERNET (SVGA) 10/100BASE-TX GP-IB1 (IEEE488.1/488.2) GP-IB2 (IEEE488.1) (FOR TLS,ETC.) WARNING Do not operate without reading the safety precautions in the user’ s manual. For information on operations using the keyboard, see section 4.2. IM AQ6373-01EN...
Page 38 Connecting with Other Devices You can use the GP-IB, RS-232C, or Ethernet interface to connect other external instruments to the AQ6373. For details, see the user’s manual of the relevant instrument. Note When connecting a GP-IB instrument such as an external computer, or a CRT or other display to the instrument, always turn OFF the power to the instrument and the instruments to be connected first.
Page 39 Preparing to Turn ON the Power The AQ6373 has a MAIN POWER switch for turning the main power ON/OFF, and a POWER switch for starting and shutting down the instrument. The POWER switch is a push-button switch;...
Page 40 1/9 through STEP 9/9 are displayed in the lower right part of the screen to indicate the progress of initialization. Index CAUTION Do not press the POWER or MAIN POWER switches while initialization is in progress. Doing so can cause malfunction. IM AQ6373-01EN...
Page 41 • The instrument is installed properly. See section 3.1, "installing the instrument." • The power cord is connected properly. See the previous page. If the instrument still does not work properly, contact your nearest YOKOGAWA dealer for repairs. If an error occurs in the memory or some other part of the instrument during initialization, the AQ6370C will stop running with "STEP @ / 9"...
Page 42 YES and NO soft keys. Press the YES soft key. The message, “AQ6373 is shutting down. Please wait...” appears, and shut-down begins. If you do not wish to shut down, press the NO soft key.
Page 43 Note that the operating system configuration file will not be backed up, possibly resulting in malfunctions upon start up the next time the instrument is turned on. 3-10 IM AQ6373-01EN...
Page 44 • Before connecting the input light, make sure that it does not exceed the AQ6373’s maximum rated level. If input light exceeding the maximum rated level is introduced, the optical section may be damaged.
Page 45 Clean the top of the optical connector on the other end of the optical fiber with a fiber cleaner. Connect the optical connector on the other end of the optical fiber to the optical connector on the DUT. Measuring System AQ6373 Light source Optical fiber 3-12 IM AQ6373-01EN...
Page 46: Alignment Adjustment
Press the EXECUTE soft key. Alignment adjustment is automatically executed. Adjustment finishes a few minutes thereafter, and you are returned to the original screen. Press the CANCEL soft key to cancel alignment adjustment partway through the process. Index 3-13 IM AQ6373-01EN...
Page 47 The alignment adjustment has no effect if the process is stopped. The instrument remains in the state prior to execution of the alignment adjustment. • Correct alignment adjustment may not be obtained with optical fibers other than 50/125 µm 3-14 IM AQ6373-01EN...
Page 48: Wavelength Calibration
• If the set wavelength is not the same as that of the calibration light source. • If the wavelength error of the instrument is outside of ±0.5 nm. (Readjustment required. Please contact your nearest Yokogawa representative.) • If the level of the light source used for calibration is -40 dBm or less.
Page 49 Press nm/ENTER. The wavelength value is set. Press the EXECUTE soft key. Wavelength calibration is executed. The previous screen is displayed again after the calibration process ends. Press the CANCEL soft key during wavelength calibration to cancel the wavelength calibration process. 3-16 IM AQ6373-01EN...
Page 50 For wavelengths in the air, change the setting. For the procedure, see section 5.2. Initializing the wavelength calibration value If you fail to set the calibration wavelength value, the data is cleared. For the procedure, see section 9.2, “Data Initialization” Index 3-17 IM AQ6373-01EN...
Page 51 The wavelength value displayed in the soft key menu is for in the air or in a vacuum depending on the measurement wavelength setting on the instrument. Measurement Wavelength Setting List Wavelength in the air Wavelength in a vacuum 441.565nm 441.690nm 487.986nm 488.123nm 632.816nm 632.991nm 1152.274nm 1152.589nm 3-18 IM AQ6373-01EN...
Page 52 µ Type Core Diameter (in Resolution (in nm) Accuracy Setting 0.02 SMALL 0.02 SMALL 0.05 SMALL 62.5 0.05 SMALL 0.05 SMALL 0.10 SMALL 0.20 SMALL 0.50 LARGE 1.00 LARGE 2.00 LARGE * Calibrated at 850 nm. Index 3-19 IM AQ6373-01EN...
Page 53 (with illumination of 300 to 1000 Ix). Therefore, depending on the illumination in the installation location, the instrument may receive some ambient light which can affect measurements of light with small level measurement values. In such cases, turn lights around the instrument Off to reduce inaccuracies. 3-20 IM AQ6373-01EN...
Page 54 SWITCH measurement is possible through subtraction. Stray light suppression ratio: 60 dB or more Selecting FIBER CORE SIZE When LARGE is selected, the stray light increases. Index Waveform with CORE SIZE SMALL CORE SIZE set to LARGE 3-21 IM AQ6373-01EN...
Page 55 To keep these steps as far as possible from the center of the screen, the switching point changes according to the center wavelength setting as shown in the figure above. 3-22 IM AQ6373-01EN...
Page 56 From this you can see that a ghost can appear at 800 nm in addition to the correct optical spectrum at 400 nm. Also, you can see that this ghost is suppressed down to a level of 40 dB or lower relative to the correct optical spectrum. 3-23 IM AQ6373-01EN...
Page 57 3.7 Important Points During Measurement Relationship between displayed and actual wavelength 1400 1200 1000 20dB 40dB 15dB 35dB 40dB 40dB 20dB 40dB 30dB 1000 1200 1400 Wavelength displayed on screen(nm) 3-24 IM AQ6373-01EN...
Page 58 Press to display the previous soft key menu. This is a selection soft key. Select one of the soft keys connected with the black band. When selected, the soft key is displayed in reverse video. Several soft keys can be connected. Index IM AQ6373-01EN...
Page 59 (for display only, no keys are available). to a function that closes the window. For example, when the MORE 1/2 soft key is pressed, the menu changes to the LEVEL 2/2 soft key menu, and the key display changes to MORE 2/2. IM AQ6373-01EN...
Page 60: Undo/Local
Operations the Same as the Soft Keys Index Selecting Functions from the Soft Key Menu Move the pointer to the soft key you wish to select and click. A screen corresponding to the action of the soft key appears. IM AQ6373-01EN...
Page 61: Help
Deletes one character from input value um/ENTER None Confirms entry nm/ENTER ENTER Confirms entry Rotary knob [→],[←] Changes numeric values/items DATA ENTRY Arrow keys [↑],[↓] Numeric value one-step change, item change, table ([UP][DOWN]) scrolling COARSE [ALT]+[N] Switches between fine and coarse encoder IM AQ6373-01EN...
Page 62: Entering Numerical Values And Strings
Press the COARSE key again to restore the previous digit/step. When COARSE is selected, the COARSE key lights. DATA ENTRY Rotary knob Arrow keys COARSE Index BACK SPASE Numeric keypad ENTER ENTER IM AQ6373-01EN...
Page 63: Screen Display
In addition to when pressing DISPLAY, the character input screen appears whenever a string must be entered on the instrument, such as when entering a file name for saving a file. • Numerical input can be performed directly from the numeric key pad. IM AQ6373-01EN...
Page 64 COLOR2 Sets the screen display color to “COLOR 2”. COLOR3 Sets the screen display color to “COLOR 3”. COLOR4 Sets the screen display color to “COLOR 4”. COLOR5 Sets the screen display color to “COLOR 5”. B&W Sets the screen display color to black-and-white. IM AQ6373-01EN...
Page 65: Setting The Date And Time
The date is displayed in the order Day, Month, Year. Press the YR-MO-DY soft key. The date is displayed in the order Year, Month, Day. Concluding the Settings Press the RETURN soft key. The settings are concluded, and the screen returns to the previous stage. IM AQ6373-01EN...
Page 66: Storage Precautions
The printer uses proprietary roll paper. Do not use any other kind of paper. When using the printer for the first time, use the paper included. When the roll paper runs out, order refills from you nearest Yokogawa branch, dealer, or sales office. Part Number...
Page 67 Close the cover firmly until you hear a click. Note The paper feed can be unstable immediately after the roll paper has been installed. Print out 2 or 3 screen shots before beginning normal use. 4-10 IM AQ6373-01EN...
Page 68: Copy
The following warning is displayed: (WARNING 164: “Printer Head Temperature error”). If this warning appears, wait a few minutes and try again. When the printer head cools down, the printing capability will be restored. Avoid printing continuously for long periods of time. Index 4-11 IM AQ6373-01EN...
Page 69: Auto Measurement
• Resolution (RESOLUTION) After performing one auto sweep and setting optimal measurement conditions, a repeat sweep is made for measurement. During the automatic setting, only the following keys are enabled: REPEAT, SINGLE, STOP, and UNDO/LOCAL (when under remote control). Index IM AQ6373-01EN...
Page 70 Note • This function only applies to measurements taken after the setting is selected. Previously measured waveforms are not affected. • If vacuum wavelength is set, is displayed at the very bottom of the screen in inverse video. IM AQ6373-01EN...
Page 71 Press the LIN BASE LEVEL soft key. A screen for setting the lower-end value of the level scale is displayed. Enter a value using the rotary knob, arrow keys, or numeric key pad. Press ENTER. Index IM AQ6373-01EN...
Page 72 • If the REF position value is larger than the number of divisions, it is forcibly reduced to the number of divisions. • When using linear scale, the REF position is at the top (fixed to 10 divisions). IM AQ6373-01EN...
Page 73 Under the measurement sensitivity settings NORMAL AUTO, MID, and HIGH 1–3, an automatic gain is used, permitting measurements over a wide level range through a single sweep. Select the appropriate sensitivity level based on the light reception level required for the particular measurement application. IM AQ6373-01EN...
Page 74 The power per 1 nm is called the power density. The level axis of the AQ6373 indicates the absolute power per wavelength resolution. For example, if the resolution is set to 0.1 nm, the power per 0.1 nm will be displayed.
Page 75 Since the power measurement function performs different calculations according to the level axis display, correct results will be available whichever display is employed. Note Specifications such as level accuracy, measurement level range, and level linearity of the instrument are provided for the absolute power display. Index IM AQ6373-01EN...
Page 76 If the left scale (main scale) is changed to LOG (8 DIV) or linear (10 DIV), the sub scale is displayed to correspond to the DIV count on the main scale. IM AQ6373-01EN...
Page 77 Press the MORE 1/2 soft key. Press the OFFSET LEVEL soft key. The offset value (sub scale REF value) setting screen is displayed. Enter a value using the rotary knob, arrow keys, or numeric key pad. Press ENTER. Index IM AQ6373-01EN...
Page 78 Press the MORE 1/2 soft key. Press the SCALE MIN soft key. The sub scale lower end value setting screen is displayed. Enter a value using the rotary knob, arrow keys, or numeric key pad. Press ENTER. 5-10 IM AQ6373-01EN...
Page 79 The REF position is set at DIV number **, counting from the bottom of the screen. The setting range is 0 to 12. Settings can be adjusted in steps of 1. The value changes in steps of 1-2-5 if you press the COARSE key. 5-11 IM AQ6373-01EN...
Page 80: Setting The Reference Level
Press the REF LEVEL soft key. The reference level setting screen is displayed. Enter a reference value using the rotary knob, arrow keys, or numeric key pad. Press ENTER. Note The vertical axis setting is applied in real time on the waveform display. 5-12 IM AQ6373-01EN...
Page 81 When a value is input a soft key menu for selecting the instrument appears. Press the soft key corresponding to the desired units. The reference level is set. Note When entered with the rotary knob or arrow keys, the reference level is set using the current units. Index 5-13 IM AQ6373-01EN...
Page 82 With the moving marker displayed, press the MARKER-> REF LEVEL soft key. The specified reference level is displayed, and the displayed waveform is redrawn according to the changed reference level. For details on displaying moving markers, see the explanation in section 6.8. 5-14 IM AQ6373-01EN...
Page 83 If the moving marker value exceeds the allowed range, it is set to the nearest value in the range and a warning is displayed. In the following states, the MARKER → REF LEVEL key is disabled. • When the moving marker is OFF • When both split screens are on HOLD Index 5-15 IM AQ6373-01EN...
Page 84 • When a setting is changed, appears in the measurement conditions area. • If a value outside the setting range is entered, the nearest permitted value is set. For instructions on switching the wavelength and frequency displays, see section 5.2. 5-16 IM AQ6373-01EN...
Page 85 When a setting is changed, appears in the measurement conditions area. • If a value outside the setting range is entered, the nearest permitted value is set. For instructions on switching the wavelength and frequency displays, see section 5.2. Index 5-17 IM AQ6373-01EN...
Page 86 With the moving marker displayed, press the MARKER-> CENTER soft key. The specified center wavelength or center frequency is displayed, and the displayed waveform is redrawn according to the changed center wavelength or center frequency. For details on displaying moving markers, see the explanation in section 6.8. 5-18 IM AQ6373-01EN...
Page 87 This key is used to set the currently set ZOOM scale (ZOOM CENTER, ZOOM SPAN, ZOOM START, ZOOM STOP) as the measurement scale (CENTER, START, STOP, SPAN). When you press this key, the current waveform display scale is set as the measurement scale for the next sweep. 5-19 IM AQ6373-01EN...
Page 88 This key is used to set the currently set ZOOM scale (ZOOM CENTER, ZOOM SPAN, ZOOM START, ZOOM STOP) as the measurement scale (CENTER, START, STOP, SPAN). When you press this key, the current waveform display scale is set as the measurement scale for the next sweep. 5-20 IM AQ6373-01EN...
Page 89 When a setting is changed, appears in the measurement conditions area. • If a value outside the setting range is entered, the nearest permitted value is set. For instructions on switching the wavelength and frequency displays, see section 5.2. Index 5-21 IM AQ6373-01EN...
Page 90 When a setting is changed, appears in the measurement conditions area. • If a value outside the setting range is entered, the nearest permitted value is set. For instructions on switching the wavelength and frequency displays, see section 5.2. 5-22 IM AQ6373-01EN...
Page 91 The MKR L1-L2 ->SPAN soft key cannot be used under the following conditions. • When both L1 and L2 are OFF. • When both SPLIT screens are on HOLD. • When the span of the active trace is 0 nm. 5-23 IM AQ6373-01EN...
Page 92 The setting range is 250.0000 to 999.9000 THz. The value changes in 0.1 THz steps if you press the COARSE key. If you do not press it, the value changes in 0.01 THz steps. Note that the frequency at which measurement ends is 856.5 THz or lower. 5-24 IM AQ6373-01EN...
Page 93: Wavelength (Frequency) Resolution Settings
• Increase the number of samples. • Lower the resolution (increase the value). • Select AUTO with the SAMPLING POINT soft key under SETUP. Index The “UNCAL” display disappears if the span, number of samples, and the resolution settings are appropriate. 5-25 IM AQ6373-01EN...
Page 94 The Resolution Correction function is available when the resolution is set between 0.1nm and 10.0 nm. The Resolution Correction function is only available when the horizontal axis is in wavelength mode. It cannot be used in Frequency mode. 5-26 IM AQ6373-01EN...
Page 95 10 nm in other wavelength bands, but the resolution is the same effective resolution value as when set to 5 nm. Also, the effective resolution when set to 10 nm is approximately 8 nm even at the widest. 5-27 IM AQ6373-01EN...
Page 96: Sampling Point/Interval Settings
Sets sampling points Sets sampling interval Note • The instrument displays if the settings for span, the number of sampling points, and the resolution are inappropriate. • See section 5.7 for the corrective actions when is displayed. 5-28 IM AQ6373-01EN...
Page 97 If settings are entered such that the sampling interval determined by the settings for the span and number of samples is extremely long relative to the wavelength (frequency) resolution, data may be lost. Enter settings that are appropriate for the resolution. Index 5-29 IM AQ6373-01EN...
Page 98: Sensitivity Settings
Press the CHOP MODE soft key. Press the SWITCH soft key. To turn CHOP MODE OFF, press the OFF soft key. Note If you set the CHOP MODE to SWITCH, the corresponding sensitivity soft key display will change to MID/SW or HIGH1/SW–HIGH3/SW. 5-30 IM AQ6373-01EN...
Page 99 MID or HIGH 1–3 and CHOP MODE can be set to SWITCH in order to reduce the effects of the stray light. Waveform with CHOP MODE OFF CHOP MODE set to SWITCH Index 5-31 IM AQ6373-01EN...
Page 100: Averaging Times Setting
If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 1-2-5 steps. The value changes in 1 step if you do not press the COARSE key. 5-32 IM AQ6373-01EN...
Page 101: Trace Settings
Press the VIEW B soft key and select DISP. Press the WRITE B soft key. Trace B is placed in write mode. Note Waveforms of traces for which VIEW A–VIEW G are set to BLANK cannot be displayed on screen. Index 5-33 IM AQ6373-01EN...
Page 102 The trace display changes to "FIX". When the FIX soft key is pressed during sweeping, the waveform displayed at that time is fixed. The "at" (@) symbol indicates the currently selected trace. One is included from A–G. 5-34 IM AQ6373-01EN...
Page 103: Measurement Start (Sweep)
Setting the Unit of Segments Continuing on from step 1, press the SEGMENT POINT soft key. The segment unit setting screen is displayed. Enter a numerical value using the rotary knob, arrow keys, or numeric keypad, Index then press ENTER. 5-35 IM AQ6373-01EN...
Page 104 When you press this key, the current setting time is displayed in the parameter input window. The setting range is MINIMUM or 1 to 99,999 seconds, and is set in the DATA ENTRY section. If “0” is entered through the numeric keypad, then MINIMUM is set. 5-36 IM AQ6373-01EN...
Page 105: Specifying A Sweep Range
If just L2 is set, the sweep occurs over the span from the left edge of the screen to line marker 2. • If neither L1 nor L2 is set, analysis is performed from the set start wavelength to the stop wavelength. Index 5-37 IM AQ6373-01EN...
Page 106: Pulse Light Measurement
An appropriate sensitivity is determined from the pulse width of the measured pulse light. For details, see the table, “Sensitivity Name and Corresponding Pulse Width.” • Enter a value longer than the period of the pulse light being measured for the peak hold value. 5-38 IM AQ6373-01EN...
Page 107 P-MID E-MID HIGH1 HIGH1 P-HIGH1 E-HIGH1 10ms HIGH2 HIGH2 P-HIGH2 E-HIGH2 50ms HIGH3 HIGH3 P-HIGH3 E-HIGH3 200ms MID/SW P-MID/SW E-MID/SW HIGH1 HI1/SW P-HI1/SW E-HI1/SW 10ms SWITCH HIGH2 HI2/SW P-HI2/SW E-HI2/SW 50ms HIGH3 HI3/SW P-HI3/SW E-HI3/SW 200ms Index 5-39 IM AQ6373-01EN...
Page 108: External Trigger Measurement
To set sample trigger mode or sweep trigger mode, press the SMPL TRIG or SWEEP TRIG soft key, respectively. If you set SWEEP TRIG, that concludes the settings. If you press the EXEC soft key, the instrument returns to the original screen. 5-40 IM AQ6373-01EN...
Page 109 Press the DELAY soft key. Enter a delay time and press ENTER. Note When AVERAGE TIMES is set, sweeping stops when a number of external signals equaling the Index specified sampling points times the "average times" is input. 5-41 IM AQ6373-01EN...
Page 110 E-NORMAL P-MID E-MID HIGH1 HIGH1 P-HIGH1 E-HIGH1 10ms HIGH2 HIGH2 P-HIGH2 E-HIGH2 50ms HIGH3 HIGH3 P-HIGH3 E-HIGH3 200ms MID/SW P-MID/SW E-MID/SW HIGH1 HI1/SW P-HI1/SW E-HI1/SW 10ms SWITCH HIGH2 HI2/SW P-HI2/SW E-HI2/SW 50ms HIGH3 HI3/SW P-HI3/SW E-HI3/SW 200ms 5-42 IM AQ6373-01EN...
Page 111: Trigger Output
OFF PLS LIGHT MEASURE. Explanation You can synchronize sweeping from the trigger output terminal on the rear panel of the instrument and output a positive logic signal. Signals are only output when sweeping. Output signals are of TTL levels. Index 5-43 IM AQ6373-01EN...
Page 112: Smoothing
Also, if a relatively small number of samples is set relative to the measurement span (or example, when UNCAL is displayed), the appropriate Smoothing function may not be performed. Waveform with SMOOTHING OFF SMOOTHING set to ON 5-44 IM AQ6373-01EN...
Page 113: Analog Out
Note • The analog out function is enabled only when the sensitivity is set to NORM/HOLD. • If the level of the input light is high, the output voltage level is saturated. Index 5-45 IM AQ6373-01EN...
Page 114 -17 dBm or more * At wavelength 700 to 900 nm ANALOG OUT Output Specifications Output saturation voltage +6 V or more Offset voltage (including noise) ±5 mVp-p Bandwidth 10 kHz or more Load 1 kΩ or more 5-46 IM AQ6373-01EN...
Page 115: Zooming In/Out On Waveforms
Waveform display example Setting the peak wavelength to the center wavelength of zoom display Index Display scale initialization The zoom area is displayed as a dotted line in the overview window After changing the display scale (zooming), is displayed IM AQ6373-01EN...
Page 116 After changing the display scale (zooming), is displayed Note • It is not necessary to press nm/ENTER when using the rotary knob or arrow keys. • If a value outside the setting range is entered, the nearest permitted value is set. IM AQ6373-01EN...
Page 117 Also, an overview window that shows the measurement scale is displayed in the corner of the measurement screen. Index • The display scale and measurement scale are mutually independent. • Changing the zoom function settings does not change the measurement conditions. IM AQ6373-01EN...
Page 118 Hide, Display Left, and Display Right. Setting the Window Size Press ZOOM. Press the OVERVIEW SIZE LARGE/SMALL soft key. The window switches between large and small. Waveform display example OVERVIEW DISPLAY OFF/L/R set to L and OVERVIEW SIZE LARGE/SMALL set to SMALL. IM AQ6373-01EN...
Page 119 Drag outside of the zoom area. A new zoom area is created. When doing so, the mouse pointer changes to a plus (+) sign. Note For information on power measurement inside the zoom area, see section 7.4, “Power Measurement.” Index IM AQ6373-01EN...
Page 120 When the zoom start or stop wavelength is set, one wavelength becomes fixed, and this changes the value of the wavelength display sweep width. In addition, the zoom center wavelength value is also changed at the same time. IM AQ6373-01EN...
Page 121 When the zoom start or stop frequency is set, one frequency becomes fixed, and this changes the value of the frequency display sweep width. In addition, the zoom center frequency value is also changed at the same time. IM AQ6373-01EN...
Page 122: Wavelength Updating/Fixing
Only 1 trace can be set as the active waveform. If you wish to update multiple traces, update them one at a time. • If all traces are set to FIX, a warning appears, and measurement cannot be performed. For information on the trace function, see section 2.3 IM AQ6373-01EN...
Page 123 The trace display changes to "FIX". When the FIX soft key is pressed during sweeping, the waveform displayed at that time is fixed. The "at" (@) symbol indicates the currently selected trace. One is included from A–G. Index IM AQ6373-01EN...
Page 124: Max/Min Hold Display
If you selected MIN HOLD and the measured value is smaller than the previous value, waveform data is updated. Note MAX/MIN HOLD is only enabled when the sweep mode is REPEAT. It does not function even if you perform repeated SINGLE sweeps. 6-10 IM AQ6373-01EN...
Page 125: Sweep Average
Enter a number of averaging times using the rotary knob, step keys, or numeric key pad. Perform measurement. The sweep average value is updated each time measurement is performed. Note The allowed setting for averaging times is 2-100. Index 6-11 IM AQ6373-01EN...
Page 126 The setting values of the NOISE MASK function are not affected by sweep averaging. The noise mask is executed when the results of the sweep average are displayed. • When CHOP MODE in the measurement sensitivity settings is set to SWITCH, two sweepings is one count. 6-12 IM AQ6373-01EN...
Page 127: Displaying Calculated Waveforms
If a trace targeted for calculation is remeasured and the center wavelength and measurement span of the trace being measured is changed, it is recalculated and Index redisplayed. • If the measurement condition (resolution) of the trace targeted for calculation does not match, a warning is displayed after calculation. 6-13 IM AQ6373-01EN...
Page 128 C=1-k(B/A) Given Trace A and Trace B, calculates 1-k(B/A). Calculates 1-k x (Trace B/Trace A) (linear value), and writes the results to trace C. The trace display on the side of the data area changes to “1-k(B/A)”. 6-14 IM AQ6373-01EN...
Page 129 (Each level is a linear value.) Estimating the reflected light spectrum from the transmission light spectrum k t = (Pin–Pre)/Pout Estimating the transmission light spectrum from the reflected light spectrum k r = (Pin–Pout)/Pre Index 6-15 IM AQ6373-01EN...
Page 130 Subtracts trace C from trace D in linear form. F=D+E(LIN) Adds trace D and trace E in linear form. F=D-E(LIN) Subtracts trace E from trace D in linear form. F=E-D(LIN) Subtracts trace D from trace E in linear form. 6-16 IM AQ6373-01EN...
Page 131 G=NORM B Normalizes trace B and writes the normalized data to trace G. G=NORM C Normalizes trace C and writes the normalized data to trace G. CURVE FIT For more information, see section 6.7, “Curve Fit.” Index PEAK CURVE FIT For more information, see section 6.7, “Curve Fit.” 6-17 IM AQ6373-01EN...
Page 132: Normalized Display
G=NORM B, and to normalize Trace G, press G=NORM C. Example of waveform before normalization Example of waveform after normalization Note • Normalization is not possible if the waveform level is too low. • See section 6.5 for information about NORMALIZE. 6-18 IM AQ6373-01EN...
Page 133: Curve Fitting
Press the CURVE FIT soft key. The menu for selecting the trace to curve fit is displayed. To curve fit Trace A press the G=CRV FIT A soft key, to curve fit Trace B press G=CRV FIT B, and to curve fit Trace G, press G=CRV FIT C. Index 6-19 IM AQ6373-01EN...
Page 134 Selecting the Curve Fitting Algorithm Press the FITTING ALGO soft key. The algorithm setting menu is displayed. Press the soft key corresponding to the algorithm you wish to use. Note For information about the curve fitting algorithm, see the explanation. 6-20 IM AQ6373-01EN...
Page 135 Trace B press G=PKCVFIT B, and to peak curve fit Trace G, press G=PKCVFIT C. Step 8 and thereafter are the same as for curve fitting. Example of the screen for running peak curve fitting when the curve fitting function is set to GAUSS. Index 6-21 IM AQ6373-01EN...
Page 136 Curve-fits trace C. G=MKR FIT Make the curve-fit data form markers which are set currently. MKR FIT is independent on the trace. Example of a curve-fitted waveform (data range: OUTSIDE L1-L2) Example of a marker-fitted waveform (data range: ALL) 6-22 IM AQ6373-01EN...
Page 137 The trace display at the side of the data area changes to “PKCVFIT @". Peak Curve Fit Target Trace Soft Key Display G= PKCVFIT A Peak-curve-fits trace A. G= PKCVFIT B Peak-curve-fits trace B. G= PKCVFIT C Peak-curve-fits trace C. Index 6-23 IM AQ6373-01EN...
Page 138 If G=MKR FIT is selected, fitting cannot be performed if only a small number of markers are placed. A warning displays in these cases: WARNING 111: <G=MKR FIT>failed GAUSS, LORENZ: Fewer than 3 markers 3RD POLY: Fewer than 4 markers 4TH POLY: Fewer than 5 markers 5TH POLY: Fewer than 6 markers 6-24 IM AQ6373-01EN...
Page 139: Marker Display
Press the SET soft key. The fixed marker is placed in the position of the current moving marker. Fixed markers are automatically assigned numbers in order starting from 001. Fixed markers of any number can be positioned. The value is entered in the DATA ENTRY section. Moving marker Fixed markers Index 6-25 IM AQ6373-01EN...
Page 140 Press the CLEAR soft key. Clearing All Markers Press the ALL MARKER CLEAR soft key. All markers (moving markers and fixed markers) displayed on the screen are cleared. In addition, the MARKER ACTIVE soft key turns OFF. 6-26 IM AQ6373-01EN...
Page 141 5.4, “Reference Level Setting.” You can also rewrite the currently displayed waveform according to the modified reference level. The measurement center wavelength can be set by continuing in the DATA ENTRY section. Index 6-27 IM AQ6373-01EN...
Page 142 The fixed marker’s level value is updated to track the waveform each time the displayed waveform is updated. Press MARKER. Press the MORE soft key twice. The MORE 3/3 key menu is displayed. Press the MARKER AUTO UPDATE OFF ON soft key to select ON. 6-28 IM AQ6373-01EN...
Page 143 Press the MARKER LIST PRINT soft key. The marker value is printed out from the internal printer. To cancel a print job which is in progress, press the COPY CANCEL soft key, which appears after this key is pressed. Index 6-29 IM AQ6373-01EN...
Page 144 Clearing Line Markers Press the MARKER. The soft key menu for marker settings appears. Press the MORE 1/3 soft key. Press the LINE MARKER 1 OFF/ON or LINE MARKER 2 OFF/ON soft key to turn the function OFF. 6-30 IM AQ6373-01EN...
Page 145 When both L1 and L2 are OFF. • When both SPLIT screens are on HOLD. • When the span of the active trace is 0 nm. Note For information on analysis inside the line markers, see section 7.13, “Specifying an Analysis Range.” Index 6-31 IM AQ6373-01EN...
Page 146 Turn the rotary knob to the left. Press the DOWN arrow key. Clearing All Cursors Press the LINE MARKER ALL CLEAR soft key. All markers (wavelength line markers and level line markers) displayed on the screen are cleared. 6-32 IM AQ6373-01EN...
Page 147 Wavelength and level values at moving marker Trace with moving marker Moving marker value - fixed marker value (Active trace) Wavelength and level values of fixed marker 1 Trace with fixed marker 1 Moving marker Index Number displayed on fixed marker 6-33 IM AQ6373-01EN...
Page 148 Sets the difference value display as the difference between each marker and the moving marker (OFFSET). Data area when MARKER DISPLAY is set to OFFSET SPACING Sets the difference value display as the difference between each marker and the next marker. Data area when MARKER DISPLAY is set to SPACING 6-34 IM AQ6373-01EN...
Page 149 When line markers are displayed, they are also displayed on the OVERVIEW window. When a line marker is moved on the OVERVIEW window, it also moves in the waveform area. When moving a line marker, the mouse pointer changes to a hand tool. Index Drag Line markers linked 6-35 IM AQ6373-01EN...
Page 150: Displaying A Split Screen
ON soft key again. The display scale and waveform are updated. Returning to Normal Display Press DISPLAY. The soft key menu for setting the screen display appears. Press the NORMAL DISPLAY soft key. The screen returns to normal display (1 screen). 6-36 IM AQ6373-01EN...
Page 151 • When a trace in the HOLD state (FIX state) is set to a state other than FIX, the HOLD is cleared automatically. When this happens, a warning message is displayed. Index 6-37 IM AQ6373-01EN...
Page 152: Noise Mask
Trace clearing Note The allowed setting range for the noise mask value is OFF (-999), and -100–0. Settings can be adjusted in steps of 1. The value changes in steps of 10 if you press the COARSE key. 6-38 IM AQ6373-01EN...
Page 153 VERT Displays the waveform with level values at or below the mask value as the display lower limit value (–210 dBm). Mask line Note The noise mask function is disabled when the vertical axis is linear. Index 6-39 IM AQ6373-01EN...
Page 154: Copying And Clearing Traces
Press the COPY EXECUTE soft key. The copy executes. Note • After the copy is executed, the copy destination trace status changes to FIX and DISP. • If the copy source and destination trace are the same, the COPY EXECUTE soft key is disabled. 6-40 IM AQ6373-01EN...
Page 155 Press the soft key (A through G) corresponding to the trace of the data you wish to clear. To clear the data from all traces, press the ALL TRACE soft key. Trace List Press TRACE. The soft key menu for trace settings appears. Press the TRACE LIST soft key. Index 6-41 IM AQ6373-01EN...
Page 156: Searching
With the moving marker displayed at a waveform peak or bottom, press the NEXT SEARCH LEFT soft key. The moving marker is placed on the peak (maximum level value) or bottom (minimum level value) to the left of its current position. 6-42 IM AQ6373-01EN...
Page 157 Press nm/ENTER. Auto Search Press PEAK SEARCH. The menu for searching for the peak value is displayed. Press the MORE 1/2 soft key. The 2/2 soft key screen is displayed. Press the AUTO SEARCH soft key. Index 6-43 IM AQ6373-01EN...
Page 158 CLEAR MARKER CLEAR Clears the specified fixed marker number. The marker value in the data area is also cleared. The fixed marker number to be cleared (default value) is the last set fixed marker number. 6-44 IM AQ6373-01EN...
Page 159 When set to ON, a peak/bottom search is performed automatically and a moving marker is set automatically after sweeping ends. (Initial value: OFF.) Index When this key is set to ON, is displayed at the very bottom of the screen in reverse video. 6-45 IM AQ6373-01EN...
Page 160: Spectrum Width Measurement
Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in the data area. Analysis parameter setting screen Index IM AQ6373-01EN...
Page 161 Press the RESULT PRINT soft key. The results are printed out on the built-in printer. Saving Analysis Results Continuing on from step 1, press the MORE 1/2 soft key. Press the RESULT SAVE soft key. The file list is displayed. For the subsequent steps, see section 8.5, “Saving/Loading Analysis Results Data.” IM AQ6373-01EN...
Page 162 DATA ENTRY section. This setting is held independently by each analysis algorithm. If the SPEC WIDTH soft key is OFF, this soft key is disabled. The value set by this soft key is shared by the analysis parameter setting screen under the PARAMETER SETTING soft key. Index IM AQ6373-01EN...
Page 163: Notch Width Measurement
Notch width measured waveform (BOTTOM) Data area Analyzes the waveform with the minimum level value as a referemce. Notch width measured waveform (PEAK) Data area Analyzes the waveform with the maximum level value as a referemce. IM AQ6373-01EN...
Page 164 Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in the data area. Analysis parameter setting screen Note For details about the notch width analysis algorithms and parameters, see appendix 2, “Data Calculation Algorithms for Spectrum Widths.” Index IM AQ6373-01EN...
Page 165: Smsr Measurement
Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in the data area. Analysis parameter setting screen IM AQ6373-01EN...
Page 166 Analysis results Analysis parameter setting value PK: Mode peak wavelength, level value MODE 1: Set the 2nd peak excluding the 2nd PK: Side mode wavelength, level value MASK AREA as the side mode. SMSR MASK: Mask setting range Index IM AQ6373-01EN...
Page 167: Power Measurement
Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in the data area. Analysis parameter setting screen Note For details on POWER analysis algorithms, see appendix 3, “Details of Analysis Functions.” IM AQ6373-01EN...
Page 168: Dfb-Ld, Fp-Ld, And Led Measurement
Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in the data area. Index Note For details on the analysis algorithms for the DFB-LD, FP-LD, and LED light sources, see appendix 3, “Details of Analysis Functions.” IM AQ6373-01EN...
Page 169: Pmd Measurement
MODE DIFF soft key is recognized as a mode. • See section 6.12 for how to set the mode judgment threshold value. • For an explanation on the PMD analysis algorithms, see appendix 3, “Details of Analysis Functions.” 7-10 IM AQ6373-01EN...
Page 170 (the level difference between the maximum and minimum values). After the polarization controller has been adjusted, press the SINGLE soft key to perform a single sweep. Acquisition of measured waveforms is complete. Index 7-11 IM AQ6373-01EN...
Page 171: Osnr Analysis (Wdm Analysis)
The analysis results display screen is switched with the SWITCH DISPLAY soft key. Data area Note When zooming a waveform, if you click in the list of analysis results, the waveform of the selected channel is displayed in the center of the waveform screen. 7-12 IM AQ6373-01EN...
Page 172 Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in a list. Analysis parameter setting screen Note See appendix 4, “OSNR (WDM) analysis Function” for a description of the OSNR (WDM) Index analysis algorithms and parameters. 7-13 IM AQ6373-01EN...
Page 173 • Parameters related to channel detection (CHANNEL DETECTION SETTING) • Parameters related to noise level measurement (INTERPOLATION SETTING) • Parameters related to analysis results display method (DISPLAY SETTING) These are explained below. See appendix 4, “OSNR (WDM) analysis Function” for a description of the parameters. 7-14 IM AQ6373-01EN...
Page 174 If AUTO-FIX, AUTO-CTR, or PIT is selected, the NOISE AREA and MASK AREA parameters are set automatically according to the measured waveform. FITTING ALGO is set to LINEAR. • See appendix 4, “OSNR (WDM) analysis Function” for a description of the OSNR (WDM) analysis algorithms and parameters. 7-15 IM AQ6373-01EN...
Page 175 This parameter is used to set the noise bandwidth. DUAL TRACE This parameter is used to turn the dual trace function ON/OFF. When the dual trace function is used, the signal level and noise level during SNR measurement can each be determined from different traces. 7-16 IM AQ6373-01EN...
Page 176 • To change the measurement conditions and set the initially measured a reference) waveform as the reference There are no parameter setting items since the data that was measured first becomes the reference. Index 7-17 IM AQ6373-01EN...
Page 177 Data used for fitting (blue) MASK AREA NOISE AREA (between X - X) Other parameter settings SIGNAL POWER You can set the signal power calculation method. INTEGRAL RANGE You can set the integral range for determining signal power. 7-18 IM AQ6373-01EN...
Page 178: Chromaticity Coordinate Analysis (Color Analysis)
The display screens for analysis results can be switched with the SWITCH DISPLAY soft key. Switching the display Press the SWITCH DISPLAY soft key. Displaying the chromaticity diagram Press the TABLE soft key. Index 7-19 IM AQ6373-01EN...
Page 179 7.8 Chromaticity coordinate analysis (COLOR analysis) Displaying the spectrum Press the TRACE soft key. 7-20 IM AQ6373-01EN...
Page 180 It is the wavelength that represents the color of the measured spectrum, and is sometimes called the main wavelength. Index 7-21 IM AQ6373-01EN...
Page 181: Optical Filter Characteristics Measurement
Press the CLOSE WINDOW soft key. The FILTER-PK analysis parameter setting screen closes, and the soft key menu returns to the previous stage. Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in a list. 7-22 IM AQ6373-01EN...
Page 182 Press the ANALYSIS EXECUTE soft key. Analysis is performed according to the changed parameters, and the results are displayed in a list. Note See appendix 6, “Optical Filter Analysis Function” for a description of the optical filter analysis algorithms and parameters. Index 7-23 IM AQ6373-01EN...
Page 183 The following configuration and general procedure is used to measure WDM optical filter characteristics. A pass band type WDM optical filter is used as an example. Reference spectrum AQ6373 Wideband light source ex. TRACE A Spectrum measurement after passing through the filter AQ6373 Wideband light source ex. TRACE B 7-24 IM AQ6373-01EN...
Page 184 Press the LOG MATH soft key. The math function selection menu is displayed. Press the C = A-B (LOG) soft key. The waveform which is obtained by subtracting the trace B waveform from the trace A waveform is displayed on trace C. Index 7-25 IM AQ6373-01EN...
Page 185: Measurement Of Level Fluctuations In Single-Wavelength Light (0 Nm Sweeping)
Press the 0 nm SWEEP TIME soft key. A screen for specifying the sweep time is displayed. Enter a numerical value using the rotary knob or numeric key pad, then press nm/ENTER. Press SWEEP, followed by the REPEAT soft key. Sweeping begins. 7-26 IM AQ6373-01EN...
Page 186 The sweeping time varies depending on the measurement sensitivity (SENS/MODE soft key under SETUP). If the setting for this key is less than the sweeping time for each sensitivity, the setting for the key is invalid and the MINIMUM setting is used. Index 7-27 IM AQ6373-01EN...
Page 187 (SENS/MODE soft key under SETUP). If the setting for this key is less than the sweeping time for each sensitivity, the setting for the key is invalid and the MINIMUM setting is used. The sampling points are automatically set to 1001. 7-28 IM AQ6373-01EN...
Page 188: Go/No-Go Judgment (Template)
INSERT soft key. • When the target line is turned OFF with the TEMPLATE DISPLAY soft key, if you edit the template data at the target line, the target line TEMPLATE DISPLAY turns ON. 7-29 IM AQ6373-01EN...
Page 189 • Waveform files of the instrument (.CSV or .BIN files) Note • After loading data, WL SHIFT and LVL SHIFT in the template are set to zero. • For information about data formats when creating template data on an external PC, see the Explanation subsection. 7-30 IM AQ6373-01EN...
Page 190 RELATIVE switching function. The template data themselves can be shifted by changing the ZOOM CENTER WL or REF LEVEL. The following settings are an example. • ZOOM CENTER WL: 406.282 nm • REF LEVEL: 0.00 dBm Creating a Template in ABSOLUTE Mode Index 7-31 IM AQ6373-01EN...
Page 191 Enter 1544.000 using the rotary knob or arrow keys, then press nm/ENTER. Press LEVEL, followed by the REF LEVEL soft key. Enter 10.00 using the rotary knob or arrow keys, then press nm/ENTER. The template relative value does not change after editing. 7-32 IM AQ6373-01EN...
Page 192 Press the TEMPLATE EDIT soft key. The edit menu is displayed. Press the MODE ABS/REL soft key, then select ABS. The instrument enters Absolute mode. Index The results and template are shifted 0.1 nm to the left on screen. 7-33 IM AQ6373-01EN...
Page 193 Note If the GO/NO GO soft key is set to ON, a Go/No Go test is performed according to the test type, even if the TEMPLATE DISPLAY soft key indicator is set to OFF. 7-34 IM AQ6373-01EN...
Page 194 602.5 Wavelength (nm) Lower Limit Line Judgment FAIL Judgment conditions (measured data) <= (upper limit line) -> Go (PASS) (upper limit line) < (measured data) -> No Go (FAIL) Lower Limit Line 597.5 602.5 Wavelength (nm) Index 7-35 IM AQ6373-01EN...
Page 195 Target Line Display FAIL Judgment conditions Go/No Go cannot be determined for target line only. Upper Limit Line Target Line Lower Limit Line 597.5 602.5 Wavelength (nm) 7-36 IM AQ6373-01EN...
Page 196 Upper Limit Line Lower Limit Line Wavelength (nm) Note When performing Go/No Go judgment, display the wavelength range on the screen. The Go/No Go testing process is not performed on wavelength ranges that are not displayed. Index 7-37 IM AQ6373-01EN...
Page 197 (not linked to the waveform). 597.5 602.5 598.5 Wavelength (nm) Wavelength (nm) When ZOOM CENTER WL = 600 nm When ZOOM CENTER WL is changed to 598.5 nm (template not moved) 7-38 IM AQ6373-01EN...
Page 198 • For templates set to None, the Go/No Go judgment range from the template can be narrower than the waveform display screen. Pay attention to the judgment execution ranges for the upper limit and lower limit lines. 7-39 IM AQ6373-01EN...
Page 199 50,001 template data points can be defined. Save the template data created on an external PC to a USB storage device for loading in the instrument. <- Header for the AQ6373 <- Header indicating template data <- Header indicating the template type (ABSOLUTE or RELATIVE) <- Extrapolation type (A or B or None)
Page 200: Specifying An Analysis Range
If just L2 is set, the measurement occurs over the span from the left edge of the screen to line marker 2. • If neither L1 nor L2 is set, measurement is performed from the set start wavelength to the Index stop wavelength. 7-41 IM AQ6373-01EN...
Page 201 • If the SEARCH/ANA ZOOM AREA key is OFF, analysis is performed over the entire range of the measurement scale. • For details on the POWER analysis function, see appendix 3, “Details of Analysis Functions.” 7-42 IM AQ6373-01EN...
Page 202 ANA L1-L2 and SEARCH/ANA ZOOM AREA soft keys are ON. As both of these soft keys are ON, at the bottom of the screen are displayed in inverse video. The area between line markers overlaps the zoom area Index 7-43 IM AQ6373-01EN...
Page 203: Correcting Displayed Values
Enter a level shift amount using the rotary knob, arrow keys, or numeric key pad. Press ENTER. Note After entering the wavelength or level shift amount, the setting is applied to the displayed values upon the next measurement. 7-44 IM AQ6373-01EN...
Page 204 The setting range is -60.00 to 60.00 dB. Settings can be adjusted in steps of 0.01 dB. The value changes in steps of 0.1 dB if you press the COARSE key. When setting the wavelength shift amount, is displayed at the bottom of the screen in inverse video. Index 7-45 IM AQ6373-01EN...
Page 205: Usb Storage Media
Supported USB Storage Media The instrument supports USB 1.0 or USB 2.0 compliant USB memory devices or hard disks. For details, contact your nearest Yokogawa representative. Removing USB Storage Media Always follow the procedure below when removing USB storage media.
Page 206: Temporarily Saving And Redisplaying Traces To And From Internal Memory
Select a destination memory number using the rotary knob, arrow keys, or numeric key pad. Press the soft key corresponding to the trace to be saved. The trace data is saved to the selected memory number. Change display contents IM AQ6373-01EN...
Page 207 Select the memory number of the data to be cleared using the rotary knob, arrow keys, or the UP/DOWN arrow soft keys. Press the EXECUTE soft key. The data of the selected memory number is cleared. Change display Index contents IM AQ6373-01EN...
Page 208 (data measurement condition). The displayed items of the memory list change to labels or measurement conditions. You can also change the display contents of the memory list by using the SAVE, RECALL, and CLEAR menus. LBL (Label) CONDIN (Measurement conditions) IM AQ6373-01EN...
Page 209 C-F, F-C, C+F, E+F, F-E, E+F, F-E, E+F Linear calculation display waveforms A+B LIN, A-B LIN, B-A LIN, 1-k(A/B), 1-k(B/A), C+D LIN, C-D LIN, D-C LIN, D+E LIN, D-E LIN, E-D LIN, C+F LIN, C-F LIN, F-C LIN, E+F LIN, E-F LIN, F-ELIN Index IM AQ6373-01EN...
Page 210: Saving/Loading Displayed Data
Press the ITEM SELECT soft key. The menu for selecting the type of files to be saved is displayed. Press the TRACE soft key. TRACE is selected, and the screen returns to the previous stage. Press the WRITE soft key. The TRACE LIST is displayed on screen. Trace list File list IM AQ6373-01EN...
Page 211 Selecting a Trace to Save 7. Press the TRACE @->FILE soft key (where @ is the currently selected trace number). The trace selection menu is displayed. Press the soft key corresponding to the trace to be saved. Selected trace Index IM AQ6373-01EN...
Page 212 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage. 15. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. File name IM AQ6373-01EN...
Page 213 Press the FILE SORT soft key. The file sort menu is displayed. Press the soft key corresponding to the item by which to sort. The files are sorted in ascending order by the selected item. Index IM AQ6373-01EN...
Page 214 Select a file to load from the file list using the rotary knob or the arrow keys. If the VIEW soft key is pressed, the display toggles between list and thumbnail display. To sort the files, see page 8-9. Thumbnail display File sort 8-10 IM AQ6373-01EN...
Page 215 When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. Note After loading waveform files (*.WV6) that were saved by the AQ6370 under the CHOP MODE of “CHOP,” the sensitivity setting becomes “SWITCH.” Index 8-11 IM AQ6373-01EN...
Page 216 Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Press the FILE TYPE soft key and specify a data format of BIN (binary) or CSV (ASCII format). 8-12 IM AQ6373-01EN...
Page 217 Follow the instructions in section 4.3 to enter a file name. Press the DONE soft key. The file name is confirmed, and the screen returns to the previous stage. Sets the file name Moves the cursor Index Creates a directory Sorts the file list 8-13 IM AQ6373-01EN...
Page 218 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage. 16. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. 8-14 IM AQ6373-01EN...
Page 219 Select a file to load from the file list using the rotary knob or the arrow keys. You can also press the FILE SORT soft key to sort the files. For more information, see page 8-9. File sort Index 8-15 IM AQ6373-01EN...
Page 220 Executing the Load Press the EXECUTE soft key. The file is loaded and registered into the specified memory number. When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. 8-16 IM AQ6373-01EN...
Page 221 The file size differs depending on the data saved. Be sure to check whether sufficient space is available before saving. File Sort Index You can sort the file list in ascending order by file name, file type, file date, or label. 8-17 IM AQ6373-01EN...
Page 222 8.3 Saving/Loading Displayed Data CSV Data Format CSV data is saved in the following format. 73CSV Header // AQ6373 OPTICAL SPECTRUM ANALYZER // "CTRWL",550 "SPAN", 400 "START WL",350 "STOP WL",750 "WLFREQ", 0 "REFL",-37.1 "LSCL",-10 "BASEL", 0 "RESLN",10 "AVG", 1 "SMPLAUTO", 1 Measurement condition parameters "SMPL", 201...
Page 223 “LOFST”,***.* Level offset Linear “REFL”,***.* Reference level “SSCLN”,***.* Level scale “SMIN”,****.** Base level DB/km “REFL”,***.* Reference level “SSKM”,**.* Level scale “OFSKM”,***.* Offset level “LENG”,**.*** Optical fiber length “REFL”,***.* Reference level “SSPS”,***.* Level scale Index “SMINP”,***.* Base scale 8-19 IM AQ6373-01EN...
Page 224 HIGH2 (SWITCH ON) "HI3D_SW" HIGH3 (SWITCH ON) Note If PEAK HOLD is selected in pulse light measurement mode, a P- is added to the front of the data above. Similarly, if EXTERNAL TRIGGER is selected, an E- is added. 8-20 IM AQ6373-01EN...
Page 225 Header indicating the start of the trace data ****.****,*.***E±***(CR)(LF) Wavelength value and level value (LINEAR) of first point ****.****,*.***E±***(CR)(LF) Wavelength value and level value (LINEAR) of second point ****.****,*.***E±***(CR)(LF) Wavelength value and level value (LINEAR) of final point Index 8-21 IM AQ6373-01EN...
Page 226: Saving/Loading Displayed Data(All Trace)
Press the ITEM SELECT soft key. A menu for selecting files to save appears. Press the ALL TRACE soft key. ALL TRACE becomes selected, and the screen returns to the previous menu. Press the WRITE soft key. TRACE LIST is displayed on screen. t race List File List 8-22 IM AQ6373-01EN...
Page 227 Press the FILE NAME soft key. The text input window and corresponding soft key menu appear. Enter a file name according to the instructions in section 4.3. Press the DONE soft key. The file name is entered, and you are returned to the previous screen. Index 8-23 IM AQ6373-01EN...
Page 228 Press the ITEM SELECT soft key. A menu for selecting files to save appears. Press the TRACE ALL soft key. TRACE becomes selected, and the screen returns to the previous menu. Press the READ soft key. The file list is displayed on screen. File list Trace list 8-24 IM AQ6373-01EN...
Page 229 Executing the load Press the EXECUTE soft key. The file is loaded, and the specified trace number is displayed. If you press the RETURN soft key, loading is cancelled. The screen returns to the previous menu. Index 8-25 IM AQ6373-01EN...
Page 230 The maximum file size differs depending on the data being saved. Make sure the save destination has sufficient space before saving. Sorting files The file list can be sorted in ascending order by FILE NAME, FILE DAT, or FILE LABEL. 8-26 IM AQ6373-01EN...
Page 231 (TRACE A) (TRACE B) (TRACE G) Header 73CSVG File header // AQ6373 OPTICAL SPECTRUM ANALYZER // label (57 characters) Measurement condition parameters Measurement conditions of each trace, measurement conditions when files were saved, and trace settings are saved. [MEAS SETTING] section:...
Page 232: Saving/Loading Setting Data
Press the ITEM SELECT soft key. The soft key menu switches. Press the SETTING soft key. SETTING is selected, and the screen returns to the previous stage. Press the WRITE soft key. The file list is displayed. 8-28 IM AQ6373-01EN...
Page 233 Follow the instructions in section 4.3 to enter a file name. Press the DONE soft key. The file name is confirmed, and the screen returns to the previous stage. Sets the file name Creates a directory Sorts the file list Index 8-29 IM AQ6373-01EN...
Page 234 Press the ITEM SELECT soft key. The soft key menu switches. Press the SETTING soft key. SETTING is selected, and the screen returns to the previous stage. Press the READ soft key. The file list is displayed. 8-30 IM AQ6373-01EN...
Page 235 Press the EXECUTE soft key. The file is loaded and the settings on the instrument are changed. When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. Index 8-31 IM AQ6373-01EN...
Page 236 !#$%&’()- 0123456789@ ABCDEFGHIJKLMNOPQRSTUVWXYZ^ abcdefghijklmnopqrstuvwxyz{}¯ File Size The file size is approximately 74 KB. File Sort You can sort the file list in ascending order by file name, file type, file date, or label. 8-32 IM AQ6373-01EN...
Page 237: Saving/Loading Analysis Results Data
Press the ITEM SELECT soft key. The soft key menu switches. Press the DATA soft key. DATA is selected, and the screen returns to the previous stage. Press the WRITE soft key. The file list is displayed. Index 8-33 IM AQ6373-01EN...
Page 238 Selecting Data Items to Save Press the OUTPUT ITEM SETTING soft key. The menu for selecting data items to be saved is displayed. Press the Data Item soft key and specify ON (save) or OFF (do not save). 8-34 IM AQ6373-01EN...
Page 239 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous menu. 16. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. Index 8-35 IM AQ6373-01EN...
Page 240 Select a file to load from the file list using the rotary knob or the arrow keys. You can also press the FILE SORT soft key to sort the files. For more information, see page 8-9. Sorts files 8-36 IM AQ6373-01EN...
Page 241 8.6 Saving/Loading Analysis Results Data Executing the Load Press the EXECUTE soft key. The file is loaded. When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. Index 8-37 IM AQ6373-01EN...
Page 242 If files of the same name reside in the save destination, you can select whether to overwrite them or add the data. OVER: Overwrites the file. ADD: Adds the data to be saved to the existing file data. 8-38 IM AQ6373-01EN...
Page 243 "CTRWL 1551.670000" "SPAN 20.000000" "REFL -10.0 dBm" "LSCL 10.0" Measurement condition parameter "RESLN 0.100" "AVG", 1 "SMPL 2001" "HIGH 2" "NMSK OFF" Sampling point portion of the waveform data 1541.6700, -23.200 (wavelength and level value) ... Index 8-39 IM AQ6373-01EN...
Page 244 FIT ALGO,LINEAR NO.,WAVELENGTH[nm],INPUT LVL[dBm],OUTPUT LVL[dBm], ASE LVL[dBm],RESOLN[nm],GAIN[dB],NF[dB] 1,1544.4983,-29.320,-2.260,-22.281,0.102,27.017,8.533 2,1545.3041,-29.530,-2.420,-22.184,0.101,27.064,8.619 CTRWL,1551.670000 SPAN,20.000000 Measurement condition parameter REFL[dBm],-10.0 LSCL,10.0 RESLN,0.100 AVG,1 SMPL,2001 HIGH 2 NMSK,OFF Sampling point portion of the waveform data (wavelength and level value) 1541.6700, -23.200 8-40 IM AQ6373-01EN...
Page 245: Saving/Loading Program Data
Press the ITEM SELECT soft key. The soft key menu switches. Press the PROGRAM soft key. PROGRAM is selected, and the screen returns to the previous stage. Press the WRITE soft key to display the program list and file list. Program list File list Index 8-41 IM AQ6373-01EN...
Page 246 Press the CURSOR soft key, then set the cursor selection to UP (on the program list side). Select the program number of the data to save using the rotary knob, arrow keys, or numeric key pad. Selected program number 8-42 IM AQ6373-01EN...
Page 247 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous menu. 15. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. Index 8-43 IM AQ6373-01EN...
Page 248 Select a file to load from the file list using the rotary knob or the arrow keys. You can also press the FILE SORT soft key to sort the files. For more information, see page 8-9. Sorts files 8-44 IM AQ6373-01EN...
Page 249 When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. Note After loading program files (*.PG6) that were saved by the AQ6370 when the parameter of the CHOPPER command was “CHOP,” the parameter becomes “SWITCH.” Index 8-45 IM AQ6373-01EN...
Page 250 56 characters (including the extension). The following characters can be used in file names. !#$%&’()- 0123456789@ ABCDEFGHIJKLMNOPQRSTUVWXYZ^ abcdefghijklmnopqrstuvwxyz{}¯ File Size The file size is approximately 13 KB. Data Format Saves the file in binary format. 8-46 IM AQ6373-01EN...
Page 251: Saving Screen Image Data
Press the ITEM SELECT soft key. The soft key menu switches. Press the GRAPHIC soft key. GRAPHIC is selected, and the screen returns to the previous stage. Press the WRITE soft key to display the file list. Index 8-47 IM AQ6373-01EN...
Page 252 Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Selecting the Color and File Format Press the MODE soft key and specify B&W (black and white) or COLOR. Press the FILE TYPE soft key to select BMP or TIFF. 8-48 IM AQ6373-01EN...
Page 253 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage. 16. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. Index 8-49 IM AQ6373-01EN...
Page 254 The file size differs depending on the data format and color specified. BMP (color): Differs depending on the display color. BMP (B&W): Approximately 52 KB TIFF (color): Approximately 412 KB TIFF (black & white): Approximately 52 KB 8-50 IM AQ6373-01EN...
Page 255: Saving/Loading Template Data
Press the ITEM SELECT soft key. The soft key menu switches. Press the TEMPLATE soft key. TEMPLATE is selected, and the screen returns to the previous stage. Press the WRITE soft key to display the template list and file list. Template list File list Index 8-51 IM AQ6373-01EN...
Page 256 EXT (USB storage medium). Selecting a Template to Save Press the @@@@->FILE soft key (where @@@@ is UPPER, LOWER, or TARGET). The template selection screen appears. Press the soft key corresponding to the template to be saved. Selected template 8-52 IM AQ6373-01EN...
Page 257 When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage. 15. When overwriting during a save, a confirmation message appears. Press the YES soft key. To cancel the save press NO soft key. Index 8-53 IM AQ6373-01EN...
Page 258 Select a file to load from the file list using the rotary knob or the arrow keys. You can also press the FILE SORT soft key to sort the files. For more information, see page 8-9. Sorts files 8-54 IM AQ6373-01EN...
Page 259 Press the soft key corresponding to the template to be loaded to. Executing the Load Press the EXECUTE soft key. The file is loaded as the specified template. When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. Index 8-55 IM AQ6373-01EN...
Page 260 File Size The file size differs depending on the data. Data Format You can save the file in CSV format. Data Format Header indicating the AQ6373, AQ6373 Header indicating template data TEMPLATE, Template type (ABSOLUTE or RELATIVE) TYPE,ABSOLUTE Extrapolation type (A, B, or NONE)
Page 261: Creating Files
ENTER. The instrument moves to the selected directory. Select ".." and press ENTER to move up one directory. Displays the name of the selected file/directory When setting a file name, the name is shown Index Move one directory up Directory 8-57 IM AQ6373-01EN...
Page 262 Press the DELETE soft key. A deletion confirmation message appears. Press the YES soft key. The selected file or directory is deleted. Press the NO soft key to cancel deletion of the file or directory. The screen returns to the previous state. 8-58 IM AQ6373-01EN...
Page 263 Note When pasting in the same directory as the copy source, change the name before pasting. Name of file/directory to be pasted Name of copied file/directory Paste under a separate name Execute the paste Index 8-59 IM AQ6373-01EN...
Page 264 Press the DONE soft key. The file or directory name is confirmed, and the screen returns to the previous stage. Press the EXECUTE soft key. The data is changed to the specified file or directory name. Press the CANCEL soft key to cancel changing of the file or directory name. 8-60 IM AQ6373-01EN...
Page 265 Sorting Files Press the FILE SORT soft key. The file sort menu is displayed. Press the soft key corresponding to the item by which to sort. The files are sorted in ascending order by the selected item. Index 8-61 IM AQ6373-01EN...
Page 266 The maximum file name length is 56 characters (including the extension). The following characters can be used in file names. !#$%&’()- 0123456789@ ABCDEFGHIJKLMNOPQRSTUVWXYZ^ abcdefghijklmnopqrstuvwxyz{}¯ File Sort You can sort the file list in ascending order by file name, file type, file date, or label. 8-62 IM AQ6373-01EN...
Page 267: Registering Soft Keys
Like the soft keys of other function keys, registered soft keys execute actions based on the registered contents. Explanation Any soft key can be registered as one of up to 24 user keys. Frequently used functions can be registered to a user soft key for easy access in the Index USER menu. IM AQ6373-01EN...
Page 268: Data Initialization
Parameter setting values as well as data including MEMORY and PROGRAM are initialized. • CAL DATA CLEAR Alignment adjustment values and wavelength calibration values are initialized. • ALL CLEAR Current parameter setting values and data as well as alignment adjustment values and wavelength calibration values are initialized. IM AQ6373-01EN...
Page 269 SUB SCALE**.*%/D 10.0 , OFF 125.0 Index OFFSET LEVEL**.*dB 99.9 -99.9 SCALE MIN *.** 0.00 1.25 0.00 OFFSET LEVEL**.*dB/km 99.9 -99.9 SCALE MIN **.*% 100.0 LENGTH**.***km 1.000 99.999 0.001 AUTO SUB SCALE OFF/ON SUB REF LVL POSITION **DIV IM AQ6373-01EN...
Page 270 ZOOM STOP WL ****.***nm wavelength of the trace that 1625.000 350.050 was measured or read last Measurement stop frequency ZOOM STOP FREQ ***.****THz of the trace that was 999.9000 250.0050 measured or read last OVERVIEW DISPLAY OFF/L/R OVERVIEW SIZE LARGE/SMALL LARGE IM AQ6373-01EN...
Page 271 TRACE E UP/LOW SPLIT TRACE F UP/LOW DISPLAY TRACE G UP/LOW UPPER HOLD OFF/ON HOLD LOWER HOLD OFF/ON // AQ6373 OPTICAL LABEL SPCTRUM ANALYZER // NOISE MASK ***dB OFF(-999) MASK LINE VERT / HRZN HRZN TRACE Function Initial Value Maximum Value...
Page 272 50.00 0.01 1.00 10.00 1.00 THRESH LEVEL *.**dB 20.00 50.00 0.01 2.00 10.00 1.00 THRESH LEVEL *.**dB 20.00 50.00 0.01 PEAK RMS 2.00 10.00 1.00 THRESH LEVEL *.**dB 3.00 50.00 0.01 NOTCH 1.00 10.00 1.00 TYPE PAEK/BOTTOM BOTTOM IM AQ6373-01EN...
Page 273 MODE FIT OFF/ON MODE DIFF *.**dB 3.00 50.00 0.01 ALGO Index ENVELOPE/THRESH/RMS/PK-RMS THRESH **.**dB 20.00 50.00 0.01 THRESH2 **.**dB 20.00 50.00 0.01 2.00 10.00 1.00 MODE FIT OFF/ON MODE DIFF *.**dB 3.00 50.00 0.01 OFFSET LEVEL *.**dB 0.00 10.00 -10.00 IM AQ6373-01EN...
Page 274 3RD POLY/4TH POLY/5TH POLY NOISE BW *.**nm 0.10 1.00 0.01 DUAL TRACE OFF/ON DISPLAY TYPE ABSOLUTE ABSOLUTE/DRIFT(MEAS) CH RELATION OFFSET OFFSET/SPACING REF CH HIGHEST 1024 HIGHEST/****CH OUTPUT SLOPE OFF/ON POINT DISPLAY OFF/ON SIGNAL POWER PEAK PEAK/INTEGRAL INTEGRAL RANGE ***GHz IM AQ6373-01EN...
Page 275 SW OFF/ON SW OFF/ON SW OFF/ON ALGO PEAK/BOTTOM BOTTOM THRESH LEVEL *.**dB 3.00 50.00 0.01 Index MODE DIFF *.**dB 3.00 50.00 0.01 SW OFF/ON ALGO PEAK/BOTTOM BOTTOM THRESH LEVEL *.**dB 3.00 50.00 0.01 MODE DIFF *.**dB 3.00 50.00 0.01 IM AQ6373-01EN...
Page 276 AUTO ANALYSIS OFF/ON SEARCH/ANA L1-L2 OFF/ON SEARCH/ANA ZOOM AREA OFF/ON MEMORY Function Initial Value Maximum Value Minimum Value LIST PARAMETER LBL/ SAVE CONDTN LIST PARAMETER LBL/ RECALL CONDTN LIST PARAMETER LBL/ CLEAR CONDTN LIST PARAMETER LBL/ MEMORY LIST CONDTN 9-10 IM AQ6373-01EN...
Page 277 UPPER LINE FILE SORT @@@@ FILE NAME DRIVE INT/EXT TRACE FILE → TRACE @ MEMORY CURSOR UP/DOWN DOWN FILE SORT @@@@@@@@@@ FILE NAME ITEM SELECT @@@@@ TRACE DRIVE INT/EXT COPY DRIVE INT/EXT FILE SORT @@@@@@@@@@ FILE NAME Index 9-11 IM AQ6373-01EN...
Page 278 LOWER LINE TEMPLATE DISPLAY DISPLAY OFF/ON TARGET LINE DISPLAY OFF/ON TEST TYPE @@@@ UPPER&LOWER LINE SELECT @@@@ UPPER LINE TEMPALTE EDIT MODE ABS/REL EXTRAPOL TYPE TYPE A WL SHIFT**.***nm 999.999 -999.999 TEMPLATE SHIFT LEVEL SHIFT *.**dB 99.99 -99.99 9-12 IM AQ6373-01EN...
Page 279 HARD COPY DEVICE @@@@ FILE TRIG INPUT MODE SMPL TRIG TRIG OUTPUT MODE AUTO OFFSET OFF/ON UNCAL WARNING DISPLAY OFF/ON CLICK OFF/ON WARNING OFF/ON LEVEL DISP DIGIT * WINDOW TRANSPARENT OFF/ON YR-MO-DY MO-DY-YR DY-MO-YR SELECT COLOR @@@@ COLOR1 Index 9-13 IM AQ6373-01EN...
Page 280: Help
Select the soft key of the help text to display, then press the SELECT soft key. The help information is displayed. To quit, press the QUIT HELP soft key. Menu after pressing HELP Selection of soft keys for displaying help Displays the selected help text 9-14 IM AQ6373-01EN...
Page 281 Select the registration number of the string to delete using the UP and DOWN arrow keys. Press the CLEAR soft key. The character string is registered to the specified number. Character string selection Index List of registered character strings 9-15 IM AQ6373-01EN...
Page 282: Other Settings
Press the MORE 1/4 soft key three times to display the MORE 4/4 screen. Press the TEST MODE soft key. The password entry screen is displayed. To cancel this screen press another soft key or panel key. 9-16 IM AQ6373-01EN...
Page 283 FILE soft key to specify a file. Note • The INTERNAL key is not available if no built-in printer is installed. • If you select FILE, files are saved to the current directory, which is set using the FILE key. Index 9-17 IM AQ6373-01EN...
Page 284 If the AUTO OFFSET key is OFF, the offset can fluctuate over time, and the level axis performance can degrade. Always have it turned ON. • When the AUTO OFFSET key is set to ON, is displayed at the bottom of the screen. 9-18 IM AQ6373-01EN...
Page 285 ZEROING. . . Note • During the offset process, the receiving of remote commands, execution of processes, and various processes for sending of talker commands are suspended. • For the calibration procedure, see section 3.6, “Wavelength Calibration.” Index 9-19 IM AQ6373-01EN...
Page 286: Displaying System Information
If you press the RETURN soft key, you are returned to the original menu. Display Contents MODEL Model No. SPECIAL CODE (not always Special Code displayed) SERIAL NO. Serial No. MAC ADDRESS MAC address of the Ethernet port 9-20 IM AQ6373-01EN...
Page 287 Press the CLEAR soft key , followed by the YES soft key The system log is cleared. Copying the system log to USB memory Index After connecting the USB memory, press the SAVE TO USB MEMORY soft key. The USB system log is copied to USB memory. 9-21 IM AQ6373-01EN...
Page 288: Upgrading The Firmware
10.1 Upgrading the Firmware Procedure Preparing for Upgrade Downloading the Firmware Download the updating software from the Yokogawa Web site. Save the downloaded software to a USB memory device. http://www.yokogawa.co.jp/tm/ Removing the Ethernet Cable Confirm that the instrument is not connected to a network. The upgrade cannot be performed if connected to a network.
Page 289 Continuing on from step 3, press the PATCH LIST soft key. A list of patches installed up to the present is displayed. Explanation When the version is upgraded, settings entered prior to the upgrade are initialized. If necessary, save your settings. 10-2 IM AQ6373-01EN...
Page 290 • If any of the various types of connectors do not fit snugly, the instrument may not operate normally. • If any abnormalities occur, please contact your nearest Yokogawa representative. Check the following: • That the instrument’s exterior is not damaged or deformed.
Page 291: Operational Inspection
4.6, “Printing from the Built-In Printer.” When the window shows waveforms, press the FEED switch and check that paper is being fed into the printer. Press the COPY switch and check that the indications on the window are printed properly. 10-4 IM AQ6373-01EN...
Page 292: Inspection Of Wavelength Accuracy
Note If the wavelength error of the instrument is outside of [+/-] 5 nm, you cannot perform wavelength calibration with the reference light source. In this case, readjustment is necessary. Please contact your nearest Yokogawa representative. Index 10-5 IM AQ6373-01EN...
Page 293: Inspection Of Level Accuracy
The instrument’s absolute level is calibrated using a 5/125 μm single-mode optical fiber (0.14 NA typ.). Even if a single-mode optical fiber is used, the level accuracy will be outside the specifications if the NA is not in the range shown above. 10-6 IM AQ6373-01EN...
Page 294: Replacing Fuses
If you need to replace a fuse due to an equipment failure, first determine the cause of the failure and solve the problem before replacing the fuse. The AQ6373 uses ordinary fusing-type 5-amp fuses with a 100–120 V power supply, and use time lag-type 3.15-amp fuses with a 200–240 V power supply.
Page 295 Open the optical connector cover at the front of the unit. Use the cleaner to clean the optical connector connection section. Insert the cleaner straight into the optical connector connection section and rotate it. Cleaner (stick type) Optical Connector Connection Section CAUTION Wiping with a soiled cleaner can damage the optical outputs. 10-8 IM AQ6373-01EN...
Page 296: Care During Storage
For extended storage, it is recommended that the instrument be stored within the range of the following environmental conditions while, at the same time, the above conditions are met. • Temperature 5–30[DEGC] • Humidity 40-70% • Daily fluctuations of temperature/humidity are small. Index 10-9 IM AQ6373-01EN...
Page 297: Recommended Replacement Parts
10.9 Recommended Replacement Parts Yokogawa warrants the instrument based on the period and stipulations described on the warranty sheet. As stated in the warranty, the following parts (parts with limited lifespan) are not included in the warranty. For replacement of parts, please contact your nearest Yokogawa representative.
Page 298 <G=MKR FIT> failed Trace G cannot write fitting curve because numbers of data is not sufficient during <G=MKR FIT>. USB Storage not inserted USB storage medium not inserted. USB Storage not initialized SUB storage not initialized. 10-11 IM AQ6373-01EN...
Page 299 An abnormality occurred during instrument-internal communication. Internal communication error! An abnormality occurred during instrument-internal communication. Internal Temperature Over! Internal temperature is abnormally high. Automatically shuts down after 10 seconds from occurrence. Internal Temperature warning! Warning for rising internal temperature. 10-12 IM AQ6373-01EN...
Page 300 F1>F2 when the “IF F1 ≤ @@@@@ ≤ F2” command was executed. Printer paper empty No printer paper Printer head up No print is made because the printer’s head-up lever is raised. Option does not respond No response from an external device. 10-13 IM AQ6373-01EN...
Page 301 A file cannot be saved due to an incorrect file name. Undefined program An attempt was made to run a program that is not defined. Syntax error Command incorrect (a program has been rewritten for some reason). 10-14 IM AQ6373-01EN...
Page 302: Specifications
DFB-LD analysis, FP-LD analysis, LED analysis, SMSR analysis, power analysis, PMD analysis, Pass/Fail judgment from template, auto analysis, analysis between vertical axis line markers, analysis within the zoom area Other Auto alignment function with built-in reference light source 11-1 IM AQ6373-01EN...
Page 303: External Dimensions
• Use a USB peripheral (such as a mouse) that uses a USB port and shielded cable • Use a keyboard connector and PS/2 shielded cable • Use the GP-IB1 or GP-IB2 interface connector and a GP- IB shielded cable 11-2 IM AQ6373-01EN...
Page 304 Pollution degree 1 applies to closed atmospheres (no pollution, or only dry, non-conductive pollution). Pollution degree 2 applies to normal indoor atmospheres (with only non-conductive pollution). 10: Use a cable of 3 m in length or less. 11: Use a cable of 30 m in length or less. Index 11-3 IM AQ6373-01EN...
Page 305 ( 18.06 ) ( 1.26 ) 12.3 12.3 ( 0.48 ) ( 16.77 ) ( 0.48 ) If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 11-4 IM AQ6373-01EN...
Page 306 If “MODE FIT” is set to ON in the case of a one mode peak, the spectrum width Δλ and the center wavelength λC will become as follows. Δλ = 0.0000nm λC = center wavelength of the mode peak App-1 IM AQ6373-01EN...
Page 307: Appendix 1 Data Calculation Algorithms For Spectrum Widths
)/2 (when “MODE FIT” is ON) λ λ λ C = ( )/2 (when “MODE FIT” is OFF) λ λ λ MODE displayed in the data area shall be the number of mode peaks between λ λ App-2 IM AQ6373-01EN...
Page 308 = K × ( - λ'C) + λ'C λ λ • Obtain the spectrum width from the following equation. Δλ λ λ • Obtain the center wavelength λC from the following equation. C = ( λ λ λ Index App-3 IM AQ6373-01EN...
Page 309 = K × ( 'C) + λ λ λ λ • Obtain the spectrum width from the following equation. Δ λ λ λ • Obtain the center wavelength C from the following equation λ C = ( λ λ λ App-4 IM AQ6373-01EN...
Page 310 'C) + λ λ λ λ • Obtain the spectrum width from the following equation. Δ λ λ λ • Obtain the center wavelength C from the following equation. λ C = ( λ λ λ Index App-5 IM AQ6373-01EN...
Page 311 λ ∑ Pi x λ λc = ∑ • By using the mean wavelength c, find the spectrum width by the following λ Δλ expression. ∑ Pi x (λ λ ∆λ = ∑ App-6 IM AQ6373-01EN...
Page 312 ∑ Pi x λ λc = ∑ • By using the mean wavelength c obtained in above discription, find the spectrum λ width by the following expression. Δλ ∑ Pi x (λ λ ∆λ = ∑ Index App-7 IM AQ6373-01EN...
Page 313 B = K × ( 'C) + λ λ λ λ • Obtain the NOTCH width from the following equation. Δλ λ λ • Obtain the center wavelength C from the following equation. λ C = ( B)/2 λ λ λ App-8 IM AQ6373-01EN...
Page 314 'C) + λ λ λ λ • Obtain the NOTCH width from the following equatio. Δλ λ λ • Obtain the center wavelength C from the following equation. λ C = ( B)/2 λ λ λ Index App-9 IM AQ6373-01EN...
Page 315 B. Also, set the levels (linear values) for each point of A and λ λ λ to LA and LB. • Obtain SMSR and from the following equations. Δλ SMSR = LA / LB Δ λ λ λ App-10 IM AQ6373-01EN...
Page 316 • Also, set the levels (linear values) for each point of A and B to LA and LB. λ λ • Obtain SMSR and from the following equations. Δλ SMSR = LA / LB Δλ λ λ Index App-11 IM AQ6373-01EN...
Page 317 C, is set to dBm/nm (LEVEL UNIT dBm/dBm/nm soft key in the LEVEL) display, obtain the total power from the equation below. SPAN ∑ POWER = Li x POWEROFFSET SAMPLE - 1 App-12 IM AQ6373-01EN...
Page 318 • Set the frequency of the rightmost valid mode peak to F2(THz). • Set the number of mode peaks between F1 and F2 to N. • Obtain the PMD value from the following equation. PMD = (N-1) / (F2-F1) Index App-13 IM AQ6373-01EN...
Page 319 SMSR1 / SMSR MODE SMSR1 SMSR2 SMSR SMSR MASK ±0.00 0.00 to 99.99 MODE DIFF 3.00 0.01 to 50.00 Concerning the algorithms for DFB-LD analysis, refer to data calculation algorithms for spectrum widths and SMSR analysis algorithms. App-14 IM AQ6373-01EN...
Page 320 1.00 to 10.00 MODE FIT ON / OFF Valid only when ALGO is THRESH. MODE DIFF 3.00 0.01 to 50.00 Concerning the algorithms for FP-LD analysis, refer to data calculation algorithms for Index spectrum widths and power analysis algorithms. App-15 IM AQ6373-01EN...
Page 321 ON / OFF Valid only when ALGO is THRESH. MODE DIFF 0.01 to 50.00 TOTAL OFFSET LEVEL -10.00 to 10.00 POWER Concerning the algorithms for LED analysis, refer to data calculation algorithms for spectrum widths and power analysis algorithms. App-16 IM AQ6373-01EN...
Page 322 Threshold value for channel detection. Minimum value for peak/bottom MODE DIFF 0.0 to 50.0 difference during channel detection. OFF, Levels equal to or below this level are not DISPLAY MASK -100.0 to 0.0 detected as WDM channels. Index App-17 IM AQ6373-01EN...
Page 323 NOISE BW 0.10nm 0.01 to 1.00nm nm Setting of noise bandwidth. OFF: Active trace is handled as the target for analysis. Wavelengths and levels are DUAL TRACE ON/OFF calculated from TRACE A. Noise levels are calculated from TRACE App-18 IM AQ6373-01EN...
Page 324 Setting of the integral range for determining the signal power INTEGRAL 10 to 999 Valid when the SIGNAL POWER setting is INTEGRAL. RANGE If the set value is Δ f, the integral is calculated in the range of channel center wavelength ±Δ f. Index App-19 IM AQ6373-01EN...
Page 325 Lni. λ 8. Use the peak level LSi and the noise level LNi obtained in 4 and 7 to obtain the level Li of each channel from the following equation. Li = LSi(linear) - LNi(linear) App-20 IM AQ6373-01EN...
Page 326 • Set the level of i of the data generated in the fitting to the noise level LNi. λ Note Due to being set to LINEAR, it is not possible to set the mask areas. Index App-21 IM AQ6373-01EN...
Page 327 Internally obtain the measurement resolution of SNi calculation trace and the value of the noise measurement point NOISE AREA in accordance with the resolution, and then obtain the values from the following equations. NA_Ri = i + NOISE AREA λ NA_Li = i - NOISE AREA λ App-22 IM AQ6373-01EN...
Page 328 The parameter “OUTPUT SLOPE” provides a function to obtain the least square approximation curve of channel peaks. This function makes it possible to measure gain tilts. If “OUTPUT SLOPE” is set to ON, results will be displayed in the waveform display section and in the analysis table. Index App-23 IM AQ6373-01EN...
Page 329 REF CHANNEL*** shall be the reference. The wavelength difference and level difference (LOG) against it shall be OFFSET WL and OFFSET LVL of each WDM mode peak. (If the ***th mode peak does not exist, the WDM mode peak on the longest wavelength shall be the reference.) App-24 IM AQ6373-01EN...
Page 330 Reference wavelength/level can be changed under the following conditions. • Active trace waveform data when MAX/MIN RESET is set by the parameter. • The first waveform data measured when wavelength axes (SPAN WL/START WL/ STOP WL) were changed according to the measurement conditions. Index App-25 IM AQ6373-01EN...
Page 331 AQ6317 series. Items for analysis PEAK LVL: Peak level PEAK WL: Peak wavelength CENTER WL: Center wavelength SPECTRUM WIDTH: Wavelength width at threshold value TH RIPPLE WIDTH: Ripple width CROSS TALK: Cross talk App-26 IM AQ6373-01EN...
Page 332: Appendix 4 Details Of Optical Filter Analysis Function
GRID : - Valid only when ALGO is THRESH. CH SPACE 0.4 0.00 to 50.00 Setting of channel spacing SEARCH Setting of the analysis range. 0.01 0.01 to 10.00 AREA Valid only when ALGO is GRID. App-27 IM AQ6373-01EN...
Page 333 Unless the parameter “MODE DIFF” is set to a value smaller than uneven portions of a waveform regarded as a ripple, RIPPLE = 0 will result. • RIPPLE = 0 if the parameter setting is “THRESH” < “MODE DIFF” App-28 IM AQ6373-01EN...
Page 334 00 to 50.0 Valid only when ALGO is THRESH. CH SPACE 0.0 to 50.00 Setting of channel spacing. SEARCH Setting of the range of analysis. 0.01 0.01 to 10.00 Index AREA Valid only when ALGO is GRID. App-29 IM AQ6373-01EN...
Page 335 BOTTOM WL for BOTTOM LV). Also, obtain the level value at the wavelength which is ± CH SPACE[nm] away from the reference wavelength. Then, set the λ difference in level value between the two to the cross talk. App-30 IM AQ6373-01EN...
Page 336 Setting the sweep width as six times the RMS 20 dB width of the active trace measurement waveform (2.2,5.6) 0 nm sweep screen range measurement time setting (7.10) Index Setting the current waveform display scale as the measurement scale for the next sweep (2.2, 5.5) App-31 IM AQ6373-01EN...
Page 337: Appendix 5 Soft Key Tree Diagram
Setting subscale to dB/km (5.3) Setting subscale to % (5.3) Linear subscale bottom setting or offset level settting for LOG (5.3) Optical fiber length setting (5.3) Automatic scaling of subscale (5.3) Position settings in the reference level subscale (5.3) App-32 IM AQ6373-01EN...
Page 338 Peak hold time setting (5.14) External trigger mode setting (5.15) Trigger condition settings (5.15) 10-1 Edge setting (5.15) 10-2 Delay setting (2.2, 5.15) Resolution correction function ON/OFF (5.7) Smoothing (5.17) Setting the optical fiber core size (3.4) Index App-33 IM AQ6373-01EN...
Page 339 Overview display position setting (6.1) Overview size setting (6.1) Display scale initialization (6.1) DISPLAY Normal display (6.9) Split display (6.9) Display position setting Display position fixing Label setting (4.3) Noise mask setting (2.3, 6.10) Mask method setting (6.10) Trace clearing (6.11) App-34 IM AQ6373-01EN...
Page 340 LOG based between-trace calculation (6.5, 7.9) LIN based between-trace calculation (6.5) Trace normalization (trace G only) (6.5, 6.6) Trace curve fitting (trace G only) (6.5, 6.7) Trace peak curve fitting (trace G only) (6.5, 6.7) Trace conditions list display (6.11) App-35 IM AQ6373-01EN...
Page 341 Appendix 5 Soft Key Tree Diagram TRACE(MORE 2/2) Copy trace (6.11) Copy source trace setting (6.11) Copy target trace setting (6.11) Execute copy (6.11) Trace clearing (6.11) App-36 IM AQ6373-01EN...
Page 342 (For both the PEAK SEARCH and ANALYSIS menus) Setting the peak search, bottom search, and analysis function ranges to within the zoom range (6.12, 7.13) (For both the PEAK SEARCH and ANALYSIS menus) Print out multi marker values (6.8) Index App-37 IM AQ6373-01EN...
Page 343 L1 and L2 (6.12, 7.13) (For both the MARKER and ANALYSIS menus) Setting the peak search, bottom search, and analysis function ranges to within the zoom range (6.12, 7.13) (For both the MARKER and ANALYSIS menus) App-38 IM AQ6373-01EN...
Page 344 L1 and L2 (6.12, 7.13) (For both the MARKER and PEAK SEARCH menus) Setting the peak search, bottom search, and analysis function ranges to within the zoom range (6.12, 7.13) (For both the MARKER and PEAK SEARCH menus) Index App-39 IM AQ6373-01EN...
Page 345 Appendix 5 Soft Key Tree Diagram MEMORY Temporarily saving a trace (8.2) Loading temporarily saved trace (8.2) Clearing temporarily saved traces (8.2) Displaying temporarily saved traces in a list (8.2) Changing list display contents (8.2) App-40 IM AQ6373-01EN...
Page 346 Deleting a file (8.10) Copying a file (8.10) Index 5-3-1 Setting the paste destination (8.10) 5-3-2 File name when saving to separate name (8.10) Renaming (8.10) Creating a directory (8.10) Sorting a file (8.10) File selection (8.10) App-41 IM AQ6373-01EN...
Page 347 Switching the cursor target window (8.3) (setting the source/destination memory number) Setting the data format (8.3) Switching the MEMORY list display contents (8.3) Setting the MEMORY data loading source (8.3) Switching the cursor target window (8.3) (setting the source/destination load file) App-42 IM AQ6373-01EN...
Page 348 Setting the save destination for analysis results data (8.6) Entering a file name (8.6) Setting the items to save (8.6) Data format setting (8.6) Setting overwrite or add (8.6) Setting the loading source for analysis results data (8.6) Index App-43 IM AQ6373-01EN...
Page 349 TEMPLATE Setting the save destination for template data (8.9) Entering a file name (8.9) Setting a template to save (8.9) Setting the loading source for template data (8.9) Setting the loading destination for template data (7.12, 8.9) App-44 IM AQ6373-01EN...
Page 350 2-2-6-2 Pasting (overwriting) 2-2-7 Printing program lists Copying programs 2-3-1 Overwriting 2-3-2 Copying and adding contents (merge) Deleting programs Index OUTPUT WINDOW display OUTPUT WINDOW print out Closing the OUTPUT WINDOW Executing programs registered to soft keys App-45 IM AQ6373-01EN...
Page 351 (7.13) Setting the level shift amount (value specified for the level axis display value is added) (7.13) Editing a user wavelength calibration table (3.7) Editing a user level calibration table (3.7) Registering user keys (9.1) App-46 IM AQ6373-01EN...
Page 352 Ethernet interface settings (see IM AQ6372-17EN) Setting the screen image data output destination (9.5) Setting the trigger input mode (5.15) Setting the trigger output mode (5.16) Auto offset ON/OFF (9.5) Turning automatic offset ON/OFF (9.5)) Setting the offset interval (9.5)) Index App-47 IM AQ6373-01EN...
Page 353 Displaying, clearing, and saving the system log to USB memory (9.6) Initializing settings (9.2) Displaying the software version and upgrading (10.1) 10-1 Displaying the patch list (10.1) 10-2 Upgrading the software (10.1) Service menu (9.5) System shutdown (3.4) App-48 IM AQ6373-01EN...
Page 354 • Limitations on Reverse Engineering, Decompilation, and Disassembly. You may not reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation. • SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS. You may permanently transfer rights under this EULA only as part of a permanent sale or transfer of the Device, and only if the recipient agrees to this EULA. If the SOFTWARE is an upgrade, any transfer must also include all prior versions of the SOFTWARE. • EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is of US-origin. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end- user, end-use and country destination restrictions issued by U.S. and other governments. For additional information on exporting the SOFTWARE, see http://www.microsoft.com/exporting/. Installation and Use. The SOFTWARE may not be used by more than two (2) processors at any one time on the DEVICE. You may permit a maximum of ten (10) computers or other electronic devices (each a “Client”) to connect to the DEVICE to utilize the services of the SOFTWARE solely for file and print services, internet information services, and remote access (including connection sharing and telephony services). The ten (10) connection maximum includes any indirect connections made through “multiplexing” or other software or hardware which pools or aggregates connections. Except as otherwise permitted in the NetMeeting/Remote Assistance/ Remote Desktop Features terms below, you may not use a Client to use, access, display or run the SOFTWARE, the SOFTWARE’s user Index interface or other executable software residing on the DEVICE. If you use the DEVICE to access or utilize the services or functionality of Microsoft Windows Server products (such as Microsoft Windows NT Server 4.0 (all editions) or Microsoft Windows 2000 Server (all editions)), or use the DEVICE to permit workstation or computing devices to access or utilize the services or functionality of Microsoft Windows Server products, you may be required to obtain a Client Access License for the Device and/or each such workstation or computing device. Please refer to the end user license agreement for your Microsoft Windows Server product for additional information. App-49 IM AQ6373-01EN...
Page 355 Internet Gaming/Update Features. If the SOFTWARE provides, and you choose to utilize, the Internet gaming or update features within the SOFTWARE, it is necessary to use certain computer system, hardware, and software information to implement the features. By using these features, you explicitly authorize MS, Microsoft Corporation and/or their designated agent to use this information solely to improve their products or to provide customized services or technologies to you. MS or Microsoft Corporation may disclose this information to others, but not in a form that personally identifies you. Internet-Based Services Components. The SOFTWARE may contain components that enable and facilitate the use of certain Internet- based services. You acknowledge and agree that MS, Microsoft Corporation or their affiliates may automatically check the version of the SOFTWARE and/or its components that you are utilizing and may provide upgrades or supplements to the SOFTWARE that may be automatically downloaded to your Device. Links to Third Party Sites. The SOFTWARE may provide you with the ability to link to third party sites through the use of the SOFTWARE. The third party sites are not under the control of MS, Microsoft Corporation or their affiliates. Neither MS nor Microsoft Corporation nor their affiliates are responsible for (i) the contents of any third party sites, any links contained in third party sites, or any changes or updates to third party sites, or (ii) webcasting or any other form of transmission received from any third party sites. If the SOFTWARE provides links to third party sites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an endorsement of the third party site by MS, Microsoft Corporation or their affiliates. Additional Software/Services. The SOFTWARE may permit YOKOGAWA METERS & INSTRUMENTS CORPORATION, MS, Microsoft Corporation or their affiliates to provide or make available to you SOFTWARE updates, supplements, add-on components, or Internet-based services components of the SOFTWARE after the date you obtain your initial copy of the SOFTWARE (“Supplemental Components”). If YOKOGAWA METERS & INSTRUMENTS CORPORATION provides or makes available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply. If MS, Microsoft Corporation or their affiliates make available Supplemental Components, and no other EULA terms are provided, then the terms of this EULA shall apply, except that the MS, Microsoft Corporation or affiliate entity providing the Supplemental Component(s) shall be the licensor of the Supplemental Component(s). YOKOGAWA METERS & INSTRUMENTS CORPORATION, MS, Microsoft Corporation and their affiliates reserve the right to discontinue any Internet-based services provided to you or made available to you through the use of the SOFTWARE. This EULA does not grant you any rights to use the Windows Media Format Software Development Kit (“WMFSDK”) components contained in the SOFTWARE to develop a software application that uses Windows Media technology. If you wish to use the WMFSDK to develop such an application, visit http://msdn.microsoft.com/workshop/imedia/windowsmedia/sdk/wmsdk.asp, accept a separate license for the WMFSDK, download the appropriate WMFSDK, and install it on your system. App-50 IM AQ6373-01EN...
Page 356 Interval ................5-29 CSV ................8-17, 8-40 CSV Data Format ............... 8-18 Curve Fit ................2-8 Keyboard ............... 3-4, 4-4 Curve Fit Target Range ............6-22 Curve Fit Target Trace ............6-22 Curve Fitting Algorithm ............6-24 Index-1 IM AQ6373-01EN...
Page 357 Sub Scale REF Position ............5-8 SWEEP ..............1-3, App-31 Panel Keys ................1-3 Sweep Average ..............6-11 Peak Curve Fit ..............2-8 Sweeping between Line Markers ........5-37 Peak Curve Fit Target Range ..........6-23 SWEEP INTERVAL ............5-36 Index-2 IM AQ6373-01EN...
Page 358 ZOOM ............... 1-3, 2-7, App-34 Zoom Center Frequency............6-7 Zoom Center Wavelength ............. 6-6 Zooming In/Out .............. 6-1, 6-3 Zoom Start Frequency ............6-7 Zoom Start Wavelength ............6-6 Zoom Stop Frequency ............6-7 Zoom Stop Wavelength ............6-6 Index-3 IM AQ6373-01EN...

YOKOGAWA AQ6373 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA AQ6373

Summary of Contents for YOKOGAWA AQ6373

Table of Contents
