TABLE OF CONTENTS

Before driving

1

When driving

2

Interior

3

features

Maintenance

4

and care

When trouble

5

arises

Vehicle

6

specifications

For owners

7

Index

Adjusting and operating features such as door locks,

mirrors, and steering column.

Driving, stopping, and safe-driving information.

Air conditioning and audio systems, as well as other in-

terior features for a comfortable driving experience.

Cleaning and protecting your vehicle, performing do-it-

yourself maintenance, and maintenance information.

What to do if the vehicle needs to be towed, gets a flat

tire, or is involved in an accident.

Detailed vehicle information.

Reporting safety defects for U.S. owners, and seat belt

and SRS airbag instructions for Canadian owners.

Alphabetical listing of information contained in this

manual.

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Sequoia 2011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Sequoia 2011

Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping, and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 2 TABLE OF CONTENTS Index 1-5. Refueling Before driving Opening the fuel tank cap... 100 1-6. Theft deterrent system 1-1. Key information Engine immobilizer Keys ........32 system ......105 Alarm ........107 1-2. Opening, closing and locking the doors 1-7. Safety information Wireless remote control ..
Page 3 2-3. Operating the lights and Interior features wipers Headlight switch....186 Fog light switch ....190 3-1. Using the air conditioning Windshield wipers and system and defogger washer ......191 Front air conditioning Rear window wiper and system......280 washer ......193 Rear air conditioning Headlight cleaner switch ..
Page 4 TABLE OF CONTENTS Index ® 3-3. Using the Bluetooth audio 3-6. Using the interior lights system Interior lights list....429 ® • Personal/interior light Bluetooth audio system..348 main switch....... 430 ® Using the Bluetooth audio • Personal/interior lights ..431 system......
Page 5 Luggage compartment When trouble arises features......480 Garage door opener.... 485 Compass......491 5-1. Essential information Emergency flashers.... 572 Maintenance and care If your vehicle needs to be towed....... 573 If you think something is 4-1. Maintenance and care wrong ....... 579 Cleaning and protecting Fuel pump shut off the vehicle exterior....
Page 6 TABLE OF CONTENTS Index Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ... 622 Fuel information ....635 Tire information ....639 6-2. Customization Customizable features ..650 Items to initialize....654 For owners Reporting safety defects for U.S. owners ....656 Seat belt instructions for Canadian owners (in French)......
Page 8 Pictorial index Exterior Windshield wipers P. 191 ∗ Moon roof P. 97 Hood Outside rear view P. 513 mirrors P. 86 Front side marker lights P. 186 Headlights (low beam) P. 186 ∗ Fog lights P. 190 Headlights (high beam) P.
Page 9 Stop/tail and rear side marker lights P. 186 Roof luggage Tail lights P. 186 ∗ carrier P. 90 Rear window defogger P. 292 Fuel filler door P. 100 Back window P. 95 Side doors Rear window P. 37 wiper P. 193 License plate Tires lights...
Page 10 Pictorial index Interior Seat belts P. 71 Front console box P. 436 Head restraints P. 67 Horn P. 166 Bottle holders P. 452 SRS driver airbag P. 112 Cup holders P. 448 SRS front passenger airbag P. 112 Auxiliary boxes P.
Page 11 Personal/interior Type A lights P. 431 ∗ Personal/interior lights Moon roof switches P. 431 P. 97 Rear seat entertainment Overhead console ∗ system P. 364 P. 446 SRS curtain shield Conversation mirror airbags P. 112 P. 462 Personal/interior Vanity mirrors lights P.
Page 12 Pictorial index Interior Type B Personal/interior Personal/interior lights lights P. 431 P. 431 Rear seat entertainment Overhead console ∗ system P. 364 P. 446 SRS curtain shield Conversation mirror airbags P. 112 P. 462 Personal/interior Vanity mirrors lights P. 431 P.
Page 13 Driving position memory Inside door lock Door lock switch ∗ switches P. 37 P. 64 button P. 38 Power window Auxiliary box Window lock switches switch P. 92 P. 453 P. 92 ∗ : If equipped...
Page 14 Pictorial index Interior Cup holders P. 448 Ashtray P. 460 Shift lever P. 160 Map holder P. 439 Shift lock override button P. 610...
Page 15 Vehicles without rear seat entertainment system Rear air conditioning system P. 288 Cup holders P. 448 Power outlet P. 463...
Page 16 Pictorial index Interior Vehicles with rear seat entertainment system A/V input port Rear air conditioning P. 389 system P. 288 Cup holders P. 448 Power outlet P. 463 Headphone jacks P. 367...
Page 17 Vehicles with rear console box Rear console box P. 443 Cup holders P. 448 Cup holders P. 448 Seat heater switches Auxiliary box P. 453 P. 470...
Page 18 Pictorial index Instrument panel Headlight switch P. 186 Turn signal lever P. 164 ∗ Fog light switch P. 190 Gauges and meters P. 167 Windshield wipers and washer switch P. 191 Rear window wiper and washer switch P. 193 Tire pressure warning reset switch P.
Page 19 Audio system P. 297 Rear window defogger switch/ Rear window defogger and outside rear Navigation system ∗ P. 292 view mirror defogger switch ∗ Security indicator Windshield wiper de-icer P. 294 P. 105, 107 Accessory meter P. 183 Air conditioning system P.
Page 20 Pictorial index Instrument panel Emergency flasher switch P. 572 Accessory meter ∗ control switches P. 183 Multi-information display Intuitive parking assist control switches P. 177 ∗ switch P. 209 Front wheel drive control switch P. 229 Coin holder P. 435 Center differential lock switch P.
Page 21 Power back window switch P. 95 Engine (ignition) switch VSC OFF switch P. 234, 237, 238, 239 P. 157 ∗ : If equipped : 4WD models : 2WD models : Vehicles with multi-information display...
Page 22 Pictorial index Instrument panel ∗ Audio remote control Climate remote control Talk switch ∗ ∗ switches switches P. 295 P. 345 P. 404 ∗ Distance switch Cruise control ∗ Telephone switches P. 404 P. 198 switch P. 195, 198...
Page 23 Personal/interior light Tilt and telescopic steering ∗ main switch P. 430 control switch P. 82 Outside rear view Instrument panel light mirror switches control dial P. 86 P. 171 Power back door Tilt and telescopic steering ∗ switch P. 43 ∗...
Page 24: Luggage Compartment
Pictorial index Luggage compartment Shopping Seatback folding/ bag hook Power outlet returning switches P. 482 P. 463 P. 62 Power back Back door Child restraint Shopping ∗ door switch strap anchor bracket bag hook P. 43 P. 44 P. 134 P.
Page 26: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 27 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 28: Keys
CAUTION General precautions while driving ■ Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 29 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 31 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 611)
Page 32: Wireless Remote Control
1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles with power back door Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door.
Page 33 1-2. Opening, closing and locking the doors Panic mode ■ When is pushed for longer than about one second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, push any button on the wireless remote control.
Page 34 Customization ■ That can be configured at Toyota dealer (vehicles without multi-informa- ● tion display) Settings (e.g. wireless remote control) can be changed.
Page 35 1-2. Opening, closing and locking the doors Certification for wireless remote control ■ MODEL/FCC IDs: Transmitter: GQ43VT20T Receiver: GQ4-34R IC (Canada) IDs: Transmitter: 1470A-1T Receiver: 1470A-6R MADE IN U.S.A. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Page 36: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the wireless remote control, key or door lock switch. Wireless remote control ■ →P. 33 ■ Locks all doors Closes the windows and moon roof (turn and hold) Unlocks all doors Turning the key unlocks the...
Page 37 1-2. Opening, closing and locking the doors Inside lock button ■ Locks the door Unlocks the door Pulling the door handle can open the front door even if the lock button is in the lock posi- tion. Locking the front doors from the outside without a key Move the inside door lock button to the lock position.
Page 38 1-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of P locks all door locking function doors. Shift position linked Shifting the shift lever to P unlocks all doors.
Page 39 1-2. Opening, closing and locking the doors Shift the shift lever to P or N, press and hold the driver’s door lock switch ( ) for approximately 5 seconds and then release. The shift lever and switch posi- tions corresponding desired function to be set are shown as follows.
Page 40 1-2. Opening, closing and locking the doors CAUTION To prevent an accident ■ Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Always use a seat belt.
Page 41: Back Door
1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. Locking and unlocking the back door ■ Unlocks all doors Opens the back window (turn and hold) Locks all doors Closes the back window (turn and hold) Door lock switches...
Page 42 1-2. Opening, closing and locking the doors Opening the back door from inside the vehicle (vehicles ■ with power back door) Push and hold the switch to open/close. Power back door switches (vehicles with power back door) Push and hold the switch to close.
Page 43 1-2. Opening, closing and locking the doors Rear step bumper For rear end protection and eas- ier step-up loading. To get on the rear step bumper, use the shaded area in the illus- tration. Back door strap ■ Use the strap when closing. The power back door can be opened when ■...
Page 44 While the power back door is opening automatically, applying excessive force to it will stop the opening operation to prevent the power back door from rapidly falling down. Customization that can be configured at Toyota dealer ■ Settings (e.g. power back door) can be changed.
Page 45 1-2. Opening, closing and locking the doors CAUTION Operating the back door ■ Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in seri- ous injury. Remove any heavy loads, such as snow and ice, from the back door ●...
Page 46 CAUTION Operating the back door ■ Do not attach any accessories other than genuine Toyota parts to the back ● door. Such additional weight on the back door may cause the back door to fall closed again after it is opened.
Page 47 ON position or the engine is started during auto- matic operation Do not attach any accessories other than genuine Toyota parts to the back ● door. The power back door may not operate, causing itself to malfunction, or the back door may fall closed again after it is opened.
Page 48 ● gloves or other fabric items. Do not attach any accessories other ● Damper stay rod than genuine Toyota parts to the back door. Do not place your hand on the damper ● stay or apply lateral forces to it.
Page 49: Front Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Passenger’s seat Driver’s seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever Seat cushion (front) angle adjustment knob Seat lumbar support adjustment switch...
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat Passenger’s seat Driver’s seat Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Driver’s seat leg support adjustment switch (if equipped) Seat lumbar support adjustment switch...
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Seatback table (if equipped on front passenger seat) Pull the seatback angle adjusting lever and raise the seatback to its upright position. Pull the seatback folding lever and fold the seatback down.
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment ■ Be careful that the seat does not hit passengers or luggage. ● Do not recline the seat more than necessary when the vehicle is in motion ● to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of...
Page 53: Rear Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seats ■ Separated seat Seat position adjustment lever Seatback angle adjustment lever...
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) Bench seat Seat position adjustment lever Seatback angle adjustment lever :The center second seat can be moved forward further than side seats.
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Third seats ■ Manual seat Seatback angle adjustment lever...
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat Seatback angle adjustment switch Seatback folding/returning switch Moving a second seat for third seat access Getting in the vehicle ■ Pull up the lever and fold down the seatback. The seat will slide forward.
Page 57: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Getting out of the vehicle ■ Depress the release pedal and fold down the seatback. The seat will slide forward. Move the seat to the front-most position Make sure that no passenger is seated on the second seat before depressing the release pedal.
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Folding down the second seat ■ Separated seat Pull the lever to unlock the seat- back and then fold the seatback down. Bench seat Pull the lever to unlock the seat- back and then fold the seatback down.
Page 59: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Folding down the third seat Before folding down the third seat ■ Insert the key into the hole on the center seat belt buckle to release tab (with hooked end), and allow the belt to retract. Stow the seat belt tabs in the cover set in the roof as shown.
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) Adjust the head restraint to the downmost position. Stow the third seat belt buckles. Folding down the third seat ■ Manual seat (from rear door side) Pull the lever to unlock the seat- back and then fold the seatback down.
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Manual seat (from back door side) Pull the lever to unlock the seat- back and then fold the seatback down. Power seat (from rear door side) Press and hold the seatback folding switch until the seatback folds down fully and the buzzer sounds.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When adjusting a rear seat ■ Be careful that the seat does not hit passengers or luggage. ● Do not recline the seat more than necessary when the vehicle is in motion ●...
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) ∗ Driving position memory (driver’s seat) Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. Two different driving positions can be entered into memory.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Linking driving position memory with door unlock operation Memorized driving positions can be recalled when you unlock the driver’s door using the wireless remote control and open the driver’s door. Setting the linked door unlock operation ■...
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Retained accessory power ■ Each memorized position (except for the tilt and telescopic steering column) can be activated within 30 seconds after the driver’s door is opened, even if the key is not in the engine switch. If any position memory button is pushed while the adjustments are ■...
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button. Second seats Vertical adjustment Pull the head restraints up.
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the head restraints ■ Front seats Pull the head restraint up while pushing the lock release button. Second seats Pull the head restraint up while pushing the lock release button. Third seats Pull the head restraint up while pushing the lock release button.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Second seats Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. Third seats Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Head restraint precautions ■ Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. ●...
Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts ■ ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Adjusting the height of the belt ■ Down Move the height adjuster up and down as needed until you hear a click.
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) Center third seat belt The center third seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation. Make sure that the buckle securely latched for ready use of the center seat belt.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Stow the seat belt tabs in the cover set in the roof as shown. Extracting the belt ■ Pull the belt out partially, and then remove the tabs from the cover. Seat belt comfort guide (center third seat) If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide.
Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) Slide the belt past the slot of the guide. The elastic cord must be behind the seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal...
Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) ■ The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 76 Each seat belt should be used by one person only. Do not use a seat belt ● for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always ● use a seat belt and/or an appropriate child restraint system.
Page 77 Ensure that the belt and tab are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 78 Do not attempt to install, remove, modify, disassemble or dispose of the ● seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender ■ Do not wear the seat belt extender if you can fasten the seat belt without ● the extender. Do not use the seat belt extender when installing a child restraint system ●...
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel (manually adjustable type) The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel horizontally and vertically.
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel (power-adjustable type) The steering wheel can be adjusted to a comfortable position. Down Toward the driver Away from the driver Auto tilt away When the key is removed from the engine switch, the steering wheel returns to its stowed posi- tion by moving up and away to enable easier driver entry and...
Page 82: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position...
Page 83 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode ON/ The indicator comes on when automatic mode is turned on.
Page 84 1-3. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error (vehicles with auto anti-glare inside rear view ■ mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. If a sun visor interferes with the mirror ■...
Page 85: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the engine switch is in the ACC or ON position. Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch.
Page 86 1-3. Adjustable components (seats, mirrors, steering wheel) From inside (if equipped) Press the switch. Pressing again will unfold the mir- rors. Linked mirror function when reversing (if equipped) Press the switch to turn on/off linked mirror function. The outside rear view mirrors will automatically tilt downwards...
Page 87 1-3. Adjustable components (seats, mirrors, steering wheel) When the mirrors are fogged up (vehicles with outside rear view mirror ■ defoggers) Turn on the mirror defoggers to defog the mirrors. (→P. 292) Automatic adjustment of the mirror angle (vehicles with driving posi- ■...
Page 88 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE If ice should jam the mirror ■ Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror.
Page 89: Roof Luggage Carrier
1-3. Adjustable components (seats, mirrors, steering wheel) ∗ Roof luggage carrier Roof rails Cross rails Adjustment the position of cross rails Turn the knobs counterclockwise to loosen the cross rails. Slide the cross rails to the appro- priate position for loading lug- gage.
Page 90 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Cross rail adjustment ■ Make sure the cross rails are locked securely by applying pressure forward and rearward. Failure to do so may cause an accident, death or serious injury in the event of emergency braking or a collision.
Page 91: The Windows And Moon Roof Power Windows
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (Front windows only) Opening One-touch opening (Front windows only) : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 92 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer.
Page 93 1-4. Opening and closing the windows and moon roof Customization that can be configured at Toyota dealer ■ Settings (e.g. power windows) can be changed. (Customizable features →P. 650) CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury.
Page 94: Power Back Window
1-4. Opening and closing the windows and moon roof Power back window The power back window can be opened and closed using the switch and key. From inside One-touch closing Closing One-touch opening Opening :Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 95: Moon Roof
■ If an object becomes caught between the window and the window frame, window travel is stopped and the window is opened slightly. Customization that can be configured at Toyota dealer ■ Settings (e.g. rear window) can be changed. (Customizable features →P. 650)
Page 96 1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing ■ Open Close To stop partway, press the switch lightly. Tilt up and down ■...
Page 97 Check to make sure that the moon roof is com- pletely stopped and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. To reduce wind noise ■...
Page 98 ■ An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the engine switch off. Customization that can be configured at Toyota dealer ■ Settings (e.g. moon roof) can be changed. (Customizable features →P. 650)
Page 99: Opening The Fuel Tank Cap
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle ■ Turn the engine switch off and ensure that all the doors and win- dows are closed. Opening the fuel tank cap ■...
Page 100 1-5. Refueling Hang the fuel tank cap on the back of the fuel filler door. Closing the fuel tank cap When installing the fuel tank cap, turn it until you hear a click. The cap will turn slightly to the opposite direction when released.
Page 101 1-5. Refueling Identifying flex-fuel vehicles ■ Flex-fuel vehicles can be identified by ● the fuel tank cap, which is marked “FLEXFUEL E85/GASOLINE”. Fuel tank capacity ■ Approximately 26.4 gal. (100 L, 22.0 Imp. gal.) E85 Fueling Stations (Flex-fuel vehicles) ■ E85 fueling stations and fuel pumps can be identified by the indication “E85 85% Ethanol”.
Page 102 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel cap ■ Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 103 1-5. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. To prevent damage to the fuel filler door ■...
Page 104: Engine Immobilizer System
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi-...
Page 105 1-6. Theft deterrent system FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For vehicles sold in Canada This device complied with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
Page 106: Alarm
1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. Triggering of the alarm ■ The alarm is triggered in the following situations when the alarm is set. ● A locked door is unlocked or opened in any way other than using the wireless remote control door lock function or key.
Page 107 1-6. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. ●...
Page 108 1-6. Theft deterrent system Alarm-operated door lock ■ When the alarm is operating, the doors are locked automatically to pre- ● vent intruders. Do not leave the key inside the vehicle when the alarm is operating, and ● make sure the key is not inside the vehicle when recharging or replacing the battery.
Page 109: Correct Driving Posture
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 50) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 110 1-7. Safety information CAUTION While driving ■ Do not adjust the position of the driver’s seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...
Page 111: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 112 1-7. Safety information Airbag system components Side airbags Occupant detection system (ECU and sensors) AIR BAG ON and AIR BAG OFF indicator lights Curtain shield airbag sen- sors Curtain shield airbags warning light Front passenger airbag RSCA OFF indicator light Knee airbags RSCA OFF switch Side and curtain shield air-...
Page 113: Front Passenger Occupant Classification System
1-7. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 114 1-7. Safety information Operating conditions (front airbags) ■ The SRS front airbags will deploy in the event of an impact that exceeds ● the set threshold level (the level of force corresponding to an approxi- mately 12-18 mph [20-30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 115 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other ■ than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or ●...
Page 116 1-7. Safety information Types of collisions that may not deploy the SRS airbag ■ (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 117 1-7. Safety information When to contact your Toyota dealer ■ In the following cases, contact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 118 1-7. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts ● properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 119 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 120 1-7. Safety information CAUTION SRS airbag precautions ■ Do not sit on the edge of the seat or ● lean against the dashboard. Do not allow a child to stand in front of ● the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 121 1-7. Safety information CAUTION SRS airbag precautions ■ Do not attach anything to or lean any- ● thing against areas such as the dash- board, steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
Page 122 If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. Modification and disposal of SRS airbag system components ■...
Page 123 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover (4WD models only) On/off (hold for a few seconds) The RSCA OFF indicator turns on. (only when the engine switch is in the ON position.) The switch only should be used ■...
Page 124 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 125: Child Restraint Systems
1-7. Safety information Conditions and operation of the front passenger occupant classification system Adult* ■ AIR BAG ON and AIR BAG OFF indica- AIR BAG ON tor lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder Flashing* light Front passenger airbag Front passenger knee airbag...
Page 126 1-7. Safety information Unoccupied ■ AIR BAG ON and AIR BAG OFF indica- Not illumi- tor lights nated Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Front passenger knee airbag Side airbag on the front passenger seat Devices Activated Curtain shield airbag in the front passen-...
Page 127 1-7. Safety information : When a larger child who has outgrown a child restraint system sits in the front passenger seat, the system may recognize him/her as an adult depending on his/her physique or posture. : Never install a rear-facing child restraint system on the front pas- senger seat.
Page 128 Do not kick the front passenger seat or subject it to severe impact. Other- ● wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the ●...
Page 129 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 130 1-7. Safety information Forward facing — Convertible seat Booster seat Selecting an appropriate child restraint system ■ Use a child restraint system appropriate for the child until the child ● becomes large enough to properly wear the vehicle’s seat belts. If a child is too large for a child restraint system, sit the child on a rear ●...
Page 131 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 132 1-7. Safety information CAUTION Child restraint precautions ■ Make sure you have complied with all installation instructions provided by ● the child restraint manufacturer and that the system is properly secured. If it is not secured properly, it may cause death or serious injury to the child in the event of a sudden stop, sudden swerve or accident.
Page 133: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 134 1-7. Safety information Using the seat belts ■ Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except driver’s seat belt) (→P. 71) Using the top tether strap ■ Anchor brackets (for top tether strap) Second seats (Separated seat) Anchor brackets are provided for all of the second seats.
Page 135 1-7. Safety information Second seats (Bench seat) Anchor brackets are provided for all of the second seats. Third seats Anchor bracket is provided for the center third seat. Installation with LATCH system (second seat only) Second seat (except center seat) Fold the seatback while pulling the lever.
Page 136 1-7. Safety information Center second seat (bench seat) Fold the seatback while pulling the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 8th lock position. (→P. 54) 1st lock position 8th lock position Type A...
Page 137 1-7. Safety information Type B Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. The anchors are installed in the lower seatback under a flap. Confirm the position of the anchors below the sym- bol in the seatback.
Page 138 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear seat facing the rear of the vehi- cle. Run the seat belt through the child seat and insert the plate into the buckle.
Page 139 1-7. Safety information While pushing the child seat down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 140 1-7. Safety information While pushing the child seat into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 141 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Second seat Secure the child restraint using the LATCH anchors or seat belt, and adjust the head restraint to the upmost position.
Page 142 1-7. Safety information Second seat Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. Hook Top tether strap Anchor bracket Center third seat Open the anchor bracket cover. Latch the hook onto the anchor bracket and tighten the top tether strap.
Page 143 1-7. Safety information Laws and regulations pertaining to anchorages ■ The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. CAUTION When installing a booster seat ■...
Page 144 1-7. Safety information CAUTION When installing a child restraint system ■ Only put a forward-facing or booster ● child seat on the front seat when unavoidable. When installing a forward- facing or booster child seat on the front passenger seat, move the seat as far back as possible even if the AIR BAG OFF indicator light is illuminated.
Page 145 1-7. Safety information CAUTION When installing a child restraint system (vehicles with bench type sec- ■ ond seat) Observe the following precautions. Failure to do so may cause death or serious injury to the child or other pas- sengers in the event of a sudden stop or accident. When installing the child restraint system onto the center second seat, ●...
Page 146 ® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 147 ® 3-3. Using the Bluetooth audio system ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG. Inc. Compatible models ■ ® Bluetooth specifications: ● Ver. 1.2 Following Profiles: ● • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 •...
Page 148 ® 3-3. Using the Bluetooth audio system CAUTION FCC WARNING ■ Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio frequency exposure. This device is approved for Mobile Application only and, to comply with applicable FCC radio frequency exposure regula- tions, must be used with a distance of at least 7.9 in.
Page 149 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system Audio unit ■ Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
Page 150 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following the voice guidance instructions output from the speaker, ® voice commands enable the operation of the Bluetooth audio sys- tem without the need to check the display or operate Operation procedure when using voice commands ■...
Page 151 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press until “BT AUDIO”...
Page 152: Audio System
® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system Normal operation ■ Second First menu Third menu Operation detail menu “Pair Audio Registering a portable player Player” “Select Audio Selecting a portable player to Player”...
Page 153 ® 3-3. Using the Bluetooth audio system When using a voice command ■ For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. The system may not recognize your voice in the following situations: ■...
Page 154 ® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Selecting an album Selector buttons Fast-forwarding Playback/pause and reversing/ Displaying text messages Selecting a track Selecting a track Playback Selecting an album Press “∨” or “∧” on Selecting tracks Turn or press “∧”...
Page 155 ® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time Using the steering wheel audio switches →P.
Page 156 ® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: Functions and operation procedures ■...
Page 157 ® 3-3. Using the Bluetooth audio system Selecting a portable player to be used Select “Select Audio Player” using a voice command or Select the portable player to be used by either of the following methods, and select “Confirm” by using a voice command or a.
Page 158 ® 3-3. Using the Bluetooth audio system Changing the registered name of a portable player Select “Change Name” using a voice command or Select the name of the portable player to be changed by either of the following methods, and select “Confirm” using a voice command or a.
Page 159 ® 3-3. Using the Bluetooth audio system Changing the passkey Select “Set Passkey” using a voice command or Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or When the entire number to be registered as a passkey has been input, press again.
Page 160 ® 3-3. Using the Bluetooth audio system The number of portable players that can be registered ■ Up to 2 portable players can be registered in the system.
Page 161 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup System setup items and operation procedures ■ ● Setting voice guidance volume 1. “Setup” → 2. “System Setup” → 3. “Guidance Volume” (→P. 421) ® ● Displaying the Bluetooth device address and name 1.
Page 162 3-4. Using the rear audio/video system ∗ Rear seat entertainment system The rear seat entertainment system is designed for the rear passen- gers to enjoy audio and DVD video separately from the front audio system. Front audio system DVD player Display Rear seat entertainment system remote controller A/V input port (→P.
Page 163 3-4. Using the rear audio/video system Opening and closing the display Press the lock release button to open the display. Pull the display down to an easily viewable angle (between 90° and 125°). To close the display, push the display up until a click is heard. The illumination of the screen is automatically turned off when the display is closed.
Page 164 3-4. Using the rear audio/video system Ejecting a disc Press and remove the disc. Turning the rear seat entertainment system power on/off Operating from the front audio system ■ Selecting either the front audio system or DVD player audio for the speakers Press that corresponds to “OFF”, to turn off the rear...
Page 165 3-4. Using the rear audio/video system Setting the rear seat entertainment system lock Front audio system Selecting either the front audio system or DVD player audio for the speakers Selecting “LOCK” “UNLOCK” for the rear seat entertainment system The rear seat entertainment sys- tem lock remains on, even when the engine switch is turned off.
Page 166 “REGION CODE ERROR”:Indicates that the DVD region code is not set properly. “DVD ERROR”: Indicates that there is a problem inside the player. Eject the disc. Set the disc again. If the malfunction still exists, take the vehicle to your Toyota dealer.
Page 167 The operational range is reduced. ● When replacing the AA batteries ■ Batteries can be purchased at your Toyota dealer, electric appliance shop, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer. Dispose of used batteries according to local laws.
Page 168 3-4. Using the rear audio/video system Headphones ■ With some headphones generally available in the market, sound quality may be poor. Toyota recommends the use of Toyota genuine wireless head- phones. Please contact your Toyota dealer for further details. Volume ■...
Page 169 3-4. Using the rear audio/video system NOTICE For normal operation after replacing the batteries ■ Observe the following precautions to prevent accidents. Always work with dry hands. ● Moisture may cause the battery to rust. Do not touch or move any other components inside the remote controller. ●...
Page 170 3-4. Using the rear audio/video system Using the DVD player (DVD video) Remote controller ■ Turning on the DVD mode Turning on/off the control icon screen Selecting a chapter Reversing a disc Turning on the menu screen Turning on the title selection screen Searching the title Changing the screen angle...
Page 171 3-4. Using the rear audio/video system Unit ■ Ejecting a disc Turning on the DVD mode Skipping to the desired chapter Playing/pausing a disc Turning on/off the control icon screen Selecting a control icon Inputting the selected con- trol icon...
Page 172 3-4. Using the rear audio/video system Control icon screen (Page1) ■ Turning off the control icon screen on the screen Displaying control icon screen page 2 Turning on/off title selection screen for the disc Turning on/off the menu screen for the disc Reversing a disc Stopping a disc Playing/pausing a disc...
Page 173 3-4. Using the rear audio/video system Operating from the front audio system ■ Press: Selecting a chapter Press and hold: Fast-for- warding/reversing a disc Stopping/playing a disc Selecting the DVD mode Starting a disc Displaying a elapsed time Playing/pausing a disc NOTICE Cleaning the screen ■...
Page 174 3-4. Using the rear audio/video system Turning on/off the control icon screen Press to turn on the control icon screen. Press once again or select to turn off the control icon screen. Turning on the title selection screen Press or select to turn on the title selection screen.
Page 175 3-4. Using the rear audio/video system Changing the subtitle language Press or select display the subtitle language screen. Each time is pressed or is selected, another lan- guage stored on the disc is selected. Select to return to the pre- vious screen.
Page 176 3-4. Using the rear audio/video system Changing the angle Press or select display the screen to change the angle. Each time is pressed or is selected, the angle changes. Select to return to the pre- vious screen. DVD player and DVD video discs ■...
Page 177 3-4. Using the rear audio/video system Marks shown on DVD video discs ■ Indicates NTSC format of color TV. Indicates the number of audio tracks. Indicates the number of language subtitles. Indicates the number of angles. Indicates the screen to be selected. Wide screen: 16:9 Standard: 4:3 Indicates regions in which this video disc can...
Page 178 3-4. Using the rear audio/video system Multi-angle feature: Allows you to enjoy the same scene at different ● angles. Multi-language feature: Allows you to select the language of the subtitles ● and audio. Region codes: Region codes are provided on DVD players and DVD ●...
Page 179 3-4. Using the rear audio/video system Using the DVD player (video CD) Remote controller ■ Turning on the DVD mode Turning on/off the control icon screen Selecting a chapter Reversing a disc Searching the disc menu number Inputting the selected con- trol icon Turning off the screen Selecting a control icon...
Page 180 3-4. Using the rear audio/video system Control icon screen (Page1) ■ Selecting a disc menu num- Turning off the menu screen Displaying control icon screen page 2 Turning on the disc menu Returning to the previous page screen (with the disc menu displayed) Proceeding to the next page screen (with the disc menu...
Page 181 3-4. Using the rear audio/video system Operating from the front audio system ■ Press: Selecting a chapter Press and hold: Fast-for- warding/reversing a disc Stopping/playing a disc Selecting the DVD mode Starting a disc Displaying a elapsed time Playing/pausing a disc Selecting a disc menu number Select to display the disc menu number search screen.
Page 182 3-4. Using the rear audio/video system Using the DVD player (audio CD/CD text) Control screen ■ Press to dis- play the control screen. Repeat play Random playback Search playback Operating from the front audio system ■ Press: Selecting a track Press and hold: Fast-for- warding/reversing a disc Selecting the DVD mode...
Page 183 3-4. Using the rear audio/video system Search playback Scanning tracks ■ Select The first 10 seconds of each track will be played. Select again when the desired track is reached. Canceling repeat play and random playback ■ Select once again.
Page 184 3-4. Using the rear audio/video system Using the DVD player (MP3 discs) Control screen ■ Press to dis- play the control screen. Repeat play Random playback Search playback Displaying file information Selecting a folder Operating from the front audio system ■...
Page 185 3-4. Using the rear audio/video system Random playback Playing files from a particular folder in random order ■ Select Playing all of the files on a disc in random order ■ Select , and press and hold Selecting and scanning folders Selecting folders one at a time ■...
Page 186 3-4. Using the rear audio/video system Canceling repeat play and random playback ■ Select once again.
Page 187 3-4. Using the rear audio/video system Using the video mode Press to select the video mode. Before switching to the video mode, connect audio source to the A/V input port. Using the A/V input port Open the cover. The A/V input port is composed of 3 input adapters.
Page 188 3-4. Using the rear audio/video system NOTICE When the A/V input port is not in use ■ Keep the A/V input port cover closed. Inserting anything other than an appropriate plug may cause electrical fail- ure or a short circuit.
Page 189 3-4. Using the rear audio/video system Changing the Setup Menu settings Press or select display initial setting screen. The following settings can be customized here. ● Audio language ● Subtitle language ● DVD language ● Angle mark ● Parental lock Changing the audio language Select Select the language you want to...
Page 190 3-4. Using the rear audio/video system Select if you cannot find the language you would like to hear. Enter the appropriate 4-digit lan- guage code. (→P. 396) Select a number, and press to input it. If a code that is not in the list is entered, “Incorrect Code”...
Page 191 3-4. Using the rear audio/video system Changing the DVD language Select Select the language you would like to hear and press to input it. Select if you cannot find the language you would like to hear. Enter the appropriate 4-digit lan- guage code.
Page 192 3-4. Using the rear audio/video system Setting viewer restriction levels Setting a personal code allows the viewer restriction to be used. Select Enter a personal code and press The setting cannot be changed unless personal code entered. When you forget a personal code, initialize a personal code.
Page 193 3-4. Using the rear audio/video system Setting the display mode Pressing changes the dis- play mode sequentially as fol- lows: Normal → Wide 1 → Wide 2 Returning to the previous screen Select to return to the previous screen.
Page 194 3-4. Using the rear audio/video system To initialize the password ■ Press on the remote controller or unit ten times when the Enter Personal Code screen is displayed. Language code list ■ Code Language Code Language 0514 English 0208 Bihari 0618 French 0209...
Page 195 3-4. Using the rear audio/video system Code Language Code Language 0721 Gujarati 1311 Macedonian 0801 Hausa 1312 Malayalam 0809 Hindi 1314 Mongolian 0818 Croatian 1315 Moldavian 0821 Hungarian 1318 Marathi 0825 Armenian 1319 Malay 0901 Interlingua 1320 Maltese 0905 Interlingue 1325 Burmese 0911...
Page 196 3-4. Using the rear audio/video system Code Language Code Language 1914 Shona 2014 Setswana 1915 Somali 2015 Tonga 1917 Albanian 2018 Turkish 1918 Serbian 2019 Tsonga 1919 Siswati 2020 Tatar 1920 Sesotho 2023 1921 Sundanese 2111 Ukrainian 1923 Swahili 2118 Urdu 2001 Tamil...
Page 197 3-5. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone. Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”.
Page 198 3-5. Using the hands-free phone system (for cellular phone) Title Page Using the hands-free phone system ■ Operating the system by using a voice command ■ Using the hands-free phone system for P. 403 the first time ■ Menu list of the hands-free phone sys- Making a phone call ■...
Page 199 OPP (Object Push Profile) Ver. 1.1 ● For detailed information about Hands-free Phone System ■ For assistance with pairing and operating your cell phone, go to the website www.toyota.letstalk.com. ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG. Inc.
Page 200 3-5. Using the hands-free phone system (for cellular phone) CAUTION FCC WARNING ■ Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio frequency exposure. This device is approved for Mobile Application only and, to comply with applicable FCC radio frequency exposure regula- tions, must be used with a distance of at least 7.9 in.
Page 201 3-5. Using the hands-free phone system (for cellular phone) Using the hands-free phone system Audio unit ■ Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters, such as an umlaut, cannot be dis- played. Displays information that is too long to be displayed at one time on the display (press and hold)
Page 202 3-5. Using the hands-free phone system (for cellular phone) Steering wheel ■ Type A Volume The voice guidance volume cannot be adjusted using this button. On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Off-hook switch Turns the hands-free sys- tem on/starts a call Talk switch Turns the voice command...
Page 203 3-5. Using the hands-free phone system (for cellular phone) Type B Volume The voice guidance volume cannot be adjusted using this button. On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Off-hook switch Turns the hands-free sys- tem on/starts a call Talk switch Turns the voice command...
Page 204 3-5. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following the voice guidance instructions output from the speaker, voice commands enable the operation of the hands-free phone sys- tem without the need to check the display or operate Operation procedure when using a voice command ■...
Page 205 3-5. Using the hands-free phone system (for cellular phone) Register a phone name by either of the following methods. a. Select “Record Name” by using , and say a name to be registered. b. Press the talk switch and say a name to be registered. A voice guidance instruction to confirm the input is heard.
Page 206 3-5. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Normal operation ■ Second First menu Third menu Operation detail menu Dialing a number stored in “Callback” the incoming call history memory Dialing a number stored in “Redial”...
Page 207 3-5. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Phonebook Locking the phone book “Security” Lock” “Phonebook Unlocking the phone book Unlock” Registering the cellular phone “Pair Phone”...
Page 208 3-5. Using the hands-free phone system (for cellular phone) Using a short cut key ■ First menu Second menu Operation detail Dialing a number registered “Dial XXX (name)” in the phone book “Dial XXX (number)” Dialing the input numbers “Phone book add Adding a new number entry”...
Page 209 3-5. Using the hands-free phone system (for cellular phone) Automatic volume adjustment ■ When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command ■...
Page 210 3-5. Using the hands-free phone system (for cellular phone) Making a phone call Making a phone call ■ ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 211 3-5. Using the hands-free phone system (for cellular phone) Dialing by inputting a name Press the talk switch and say “Dial by name”. Select a registered name to be input by either of the following methods: a. Press the talk switch and say a registered name. b.
Page 212 3-5. Using the hands-free phone system (for cellular phone) Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the oper- ation of the phone.
Page 213 3-5. Using the hands-free phone system (for cellular phone) The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” by using a voice command or Storing the number in the phone book: Select “Store” by using a voice command or Deleting: Select “Delete”...
Page 214 3-5. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: Functions and operation procedures ■...
Page 215 3-5. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used Select “Select Phone” by using a voice command or Pattern A Select the cellular phone to be used by either of the following methods, and select “Confirm” by using a voice command or a.
Page 216 3-5. Using the hands-free phone system (for cellular phone) Select “Confirm” by using a voice command or Listing the registered cellular phones Selecting “List Phones” by using a voice command or causes the list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”.
Page 217 3-5. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” by using a voice command or Press the talk switch, say a 4 to 8-digit number, and select “Confirm” by using a voice command or The number should be input 1 digit at a time.
Page 218 3-5. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedure ■ ● Setting or changing the PIN (Personal Identification Number) 1.
Page 219 3-5. Using the hands-free phone system (for cellular phone) Changing the PIN ■ Select “Set PIN” by using a voice command or Enter the registered PIN by using a voice command or Enter a new PIN by using a voice command or When using , input the code 1 digit at a time.
Page 220 3-5. Using the hands-free phone system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using ® Turn to display the Bluetooth device address and name. Select “Go Back” using to return to “System Setup”. Initialization Select “Initialize”...
Page 221 3-5. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1.
Page 222 3-5. Using the hands-free phone system (for cellular phone) Adding procedure ■ Select “Add Entry” by using a voice command or Use one of the following methods to input a telephone num- ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
Page 223 3-5. Using the hands-free phone system (for cellular phone) Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History” by using a voice command or STEP2-2 Select “Outgoing” or “Incoming” by using a voice command or STEP2-3 Select the data to be registered by either of the fol- lowing methods: a.
Page 224 3-5. Using the hands-free phone system (for cellular phone) Setting speed dials Select “Set Speed Dial (Speed Dial)” by using a voice com- mand or Select the data to be registered as a speed dial by either of the following methods: a.
Page 225 3-5. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” by using a voice command or Select the name to be changed by either of the following methods. a. Press the talk switch, say desired name, and select “Con- firm”...
Page 226 3-5. Using the hands-free phone system (for cellular phone) Deleting speed dials Select “Delete Speed Dial” by using a voice command or Press the preset button for which the desired speed dial is registered, and select “Confirm” by using a voice command or Listing the registered data Selecting “List names”...
Page 227 3-6. Using the interior lights Interior lights list Your Toyota is equipped with an illuminated entry system to assist in entering the vehicle. Due to the function of the system, the lights shown in the following illustration automatically turn on/off accord- ing to whether the doors are locked/unlocked, whether the doors are opened/closed, and the engine switch position.
Page 228 20 minutes. Customization ■ That can be configured at Toyota dealer (vehicles without multi-informa- ● tion display) Settings (e.g. The time elapsed before lights turn off) can be changed.
Page 229 3-6. Using the interior lights Personal/interior lights Personal/interior lights Front ■ Type A On/off Type B On/off Center ■ Type A On/off...
Page 230: Interior Light
3-6. Using the interior lights Personal/interior lights and interior light Type B On/off Rear ■ On/off Interior light DOOR position The interior light comes on when a back door is opened. It turns off when the door is closed.
Page 231 3-7. Using the storage features List of storage features Overhead console Glove boxes Auxiliary boxes Bottle holders Cup holders Rear console box (if equipped) Cup holder (if equipped) Front console box • Card holder • Map holder • Pen holder •...
Page 232: Glove Boxes
3-7. Using the storage features Glove boxes CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact ●...
Page 233 3-7. Using the storage features Glove boxes and coin holder Pull the lever up. CAUTION Caution while driving ■ Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Coin holder (if equipped) Open the lid.
Page 234 3-7. Using the storage features Front console box Front console box Pull the knob up and lift the lid. When using the front console box lid as an armrest ■ Pull the knob up and slide the lid forward. If necessary, the console box lid can slide forward.
Page 235 3-7. Using the storage features Front console box Tray in the front console box ■ The tray slides forward or backward. The tray can be removed. The box can be removed. Hanging file folders can be hung on the rails when the box is removed.
Page 236: Card Holder
3-7. Using the storage features Card holder Card holder Pull the knob up and lift the lid. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 237 3-7. Using the storage features Map holder Map holder Center console Push the tab down to release the lock. Remove the lid. Stow the lid. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 238 3-7. Using the storage features Map holder Front console box Pull the knob up and lift the lid. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 239 3-7. Using the storage features Pen holder Pen holder Pull the knob up and lift the lid. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 240 3-7. Using the storage features Tissue pocket Tissue pocket Pull the knob up and lift the lid. CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 241 3-7. Using the storage features Rear console box Rear console box (if equipped) Upper box Push the knob and lift the lid. Lower box Pull the knob up and lift the upper box.
Page 242 3-7. Using the storage features Rear console box The separator can be used at either of two positions shown in the illus- ■ tration Change the separator position. The separator can be stowed ■ Stow the separator to the lid. Back side tray ■...
Page 243 3-7. Using the storage features Rear console box The inside tray can be removed ■ Pull the tray up. When closing the rear console box lid ■ Close the rear console box by lifting the grip on the inside of the upper box.
Page 244: Overhead Console
3-7. Using the storage features Rear console box and overhead console CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking. When opening/closing the lower box ■ Be careful not to get your hands or feet caught between the lower box and the upper box.
Page 245 3-7. Using the storage features Overhead console Type B Push the knob forward to open the console. CAUTION Caution while driving ■ Do not leave the overhead console open while driving. Items stored in it may fall out and cause injury.
Page 246 3-7. Using the storage features Cup holders Cup holders Front Front console box Pull the lid down. Rear...
Page 247 3-7. Using the storage features Cup holders Rear console box (if equipped) Attach the separator when using either console box as a cup holder. Both cup holders cannot be used at the same time. Removing the cup holder (front) ■ Push the tab down to release the lock.
Page 248 3-7. Using the storage features Cup holders Pull the cup holder up. Removing the separator (rear console box) ■ Inside Pull the separator up. Outside Pull the separator up.
Page 249 3-7. Using the storage features Cup holders The position of the separator can be changed (rear console box) ■ Inside Change the separator position. Outside Change the separator position. The separator can be adjusted (rear console box) ■ Adjust the separator.
Page 250: Bottle Holders
3-7. Using the storage features Cup holders and bottle holders CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 251: Auxiliary Boxes
3-7. Using the storage features Bottle holders and auxiliary boxes Rear NOTICE Items that should not be stowed in the bottle holders ■ Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break.
Page 252 3-7. Using the storage features Auxiliary boxes Rear Pull the lid up. Rear console box (if equipped) Pull the lever up to release the lock. Pull the handle. CAUTION Caution while driving ■ Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking.
Page 253 3-8. Other interior features Sun visors Main visor ■ Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position then slide backwards. Sub visor (if equipped) ■ Flip down.
Page 254 3-8. Other interior features Vanity mirrors Vehicles without vanity light Open the cover. Vehicles with vanity light Open the cover. The light turns on when the cover is opened. Adjust the brightness of the light.
Page 255 3-8. Other interior features Clock Adjusts the hours. Adjusts the minutes. For quicker adjustment of the clock ■ Hold down the M or H button continuously. This allows faster advancement of the minutes and hours. The clock is displayed when ■...
Page 256: Multi-Information Display
3-8. Other interior features Outside temperature display Displays the outside air temperature. The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C). Switches the outside air temperature display between °C (Celsius) and °F (Fahrenheit). equipped) Vehicles without multi-informa- tion display: Push the SETUP button until the desired unit of measure-...
Page 257 3-8. Other interior features When – –°C or – –°F is displayed ■ The system may be malfunctioning. Take your vehicle to your Toyota dealer. The outside air temperature is displayed when ■ The engine switch is in the ON position.
Page 258 3-8. Other interior features Portable ashtray The ashtray can be installed in a cup holder. The ashtray can be removed ■ Pull the ashtray up. CAUTION When not in use ■ Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident.
Page 259 3-8. Other interior features Cigarette lighter Push the cigarette lighter. The cigarette lighter will pop up when it is ready for use. The cigarette lighter can be used when ■ The engine switch is in the ACC or ON position. CAUTION To avoid burns or fires ■...
Page 260 3-8. Other interior features Conversation mirror Push the lid. The mirror can be adjusted by pushing the mirror edge. CAUTION Caution while driving ■ Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
Page 261 3-8. Other interior features Power outlets The power outlet can be used for a following component. 12 V: Accessories that run on less than 10 A. 115V AC: Accessories that use less than 100 W. Instrument panel (12 V)
Page 262 3-8. Other interior features Inside the front console box (12 V) Pull the knob up to release the lock. Lift the lid. Back of the front console box (12 V) : Vehicles without rear seat entertainment system...
Page 263 3-8. Other interior features Back of the front console box (115V AC) Power outlet socket Luggage compartment (12 V) : Vehicles with rear seat entertainment system The power outlet can be used when ■ The engine switch is in the ACC or ON position. 115V AC The engine switch is in the ON position.
Page 264 Do not modify, disassemble or repair the power outlet or its inverter, in any ● way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs. To prevent injuries and accidents, securely fix all electric appliances ■...
Page 265 3-8. Other interior features NOTICE To avoid damaging the power outlet and the plug ■ Close the power outlet lid when not in use. ● Foreign objects or liquids that enter the power outlet may cause a short ● circuit. Do not use plug adaptors to connect too many plugs to the power outlet.
Page 266 If the power outlet is loose when an electrical appliance plug is con- ■ nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. If the power outlet gets dirty ■ Turn the main switch off and use a soft, clean cloth to wipe it gently.
Page 267 3-8. Other interior features ∗ Seat heaters Front seat ■ The indicator comes on. Adjusts the seat tempera- ture. The further you turn the dial upward, the warmer the seat becomes. ∗ : If equipped...
Page 268 3-8. Other interior features Rear seat (vehicles with rear console box) ■ Press the LO or HI switch to warm the seats to a low or high temperature respectively. High temperature The indicator (yellow) comes Low temperature The indicator (green) comes The seat heaters can be used when ■...
Page 269 3-8. Other interior features CAUTION Burns ■ Use caution when seating the following persons in a seat with the seat ● heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled •...
Page 270 3-8. Other interior features ∗ Seat heaters and ventilators Blows air from the seats The indicator comes on. The higher the number, the stron- ger the airflow becomes. Heats the seats The indicator comes on. The higher the number, the warmer the seats become.
Page 271 3-8. Other interior features CAUTION Burns ■ Use caution when seating the following persons in a seat with the seat ● heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled •...
Page 272 3-8. Other interior features ∗ Armrests Separated seat Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise the armrest to the desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position.
Page 273 3-8. Other interior features ∗ Rear side sunshades Rear door window Pull the tab up. Hook the sunshade onto the anchors. To lower the sunshade, pull the tab slightly to unhook the shade, and lower it slowly. ∗ : If equipped...
Page 274 3-8. Other interior features Rear quarter window Pull the tab up. Hook the sunshade onto the anchors. To lower the sunshade, pull the tab slightly to unhook the shade, and lower it slowly. NOTICE To ensure normal operation of the sunshade ■...
Page 275 3-8. Other interior features ∗ Seatback table Front passenger’s seatback can be used as a temporary table only when the vehicle is stopped. Fold down the front passen- ger’s seat to use the seatback table. (→P. 52) CAUTION Caution while driving ■...
Page 276 ■ Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver’s seat. ● Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 277 3-8. Other interior features CAUTION Before driving ■ Check that the floor mat is securely ● fixed in the right place with all the pro- vided retaining hooks (clips). Be espe- cially careful to perform this check after cleaning the floor. With the engine stopped and the shift ●...
Page 278 3-8. Other interior features Luggage compartment features Tie-down hooks ■ Tie-down hooks are provided for securing loose items.
Page 279 3-8. Other interior features Cargo net hooks ■ To hang the cargo net, use the cargo net hooks. The cargo net itself is not included as original equipment.
Page 280 3-8. Other interior features Shopping bag hooks ■ To hang shopping bags, use the shopping bag hooks.
Page 281 3-8. Other interior features Auxiliary boxes ■ Type A Pull the lever upwards to lift the deck board. Type B (if equipped) Open the cover.
Page 282 3-8. Other interior features CAUTION When the tie-down hooks are not in use ■ To avoid injury, always return the tie-down hooks to their retracted positions when they are not in use. Caution while driving ■ Keep the auxiliary box closed. Injuries may result in the event of an accident or sudden braking.
Page 283 3-8. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 284 3-8. Other interior features Press and hold down one of the ® buttons on the HomeLink the button on the transmitter. When indicator ® HomeLink changes from a slow to a rapid flash, you can release both buttons. ® If the HomeLink indicator comes on but does not flash, or flashes rapidly for 2 seconds and remains...
Page 285 3-8. Other interior features Programming a Rolling Code system (for U.S.A. owners) ■ If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 286 ® the remaining HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 287 3-8. Other interior features ® Erasing the entire HomeLink memory (all three programs) Press and hold down the 2 out- side buttons for 10 seconds until the indicator flashes. If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 288 3-8. Other interior features When support is necessary ■ Visit on the web at www.homelink.com or call 1-800-355-3515. CAUTION When programming a garage door or other remote control device ■ The garage door may operate, so ensure that people and objects are out of danger to prevent potential harm.
Page 289 3-8. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation ■ Type A To turn the compass on or off, press the switch. Type B To turn the compass on or off, press the switch.
Page 290 3-8. Other interior features Displays and directions ■ Display Direction North Northeast East Southeast South Southwest West Northwest Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle.
Page 291 3-8. Other interior features Deviation calibration ■ Stop the vehicle where it is safe to drive in a circle. Press the switch until a number (1 to 15) appears on the com- pass display. Type A Type B Press the switch, and referring to the map above, select the number of the zone where you are.
Page 292 3-8. Other interior features Circling calibration ■ When “C” appears on the dis- play, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 293 3-8. Other interior features NOTICE To avoid the compass malfunctions ■ Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass ■...
Page 294 3-8. Other interior features...
Page 295 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 296 4-1. Maintenance and care Bumpers and side moldings ■ Do not scrub with abrasive cleaners. CAUTION Caution about the exhaust pipe ■ Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns.
Page 297 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ■ Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 298 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 299 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use organic substances such as benzene or gasoline, acidic or ● alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Do not use polish wax or polish cleaner.
Page 300: Scheduled Maintenance
Repair and replacement ■ It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 301 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer ■ Toyota technicians are well-trained specialists and are kept up to date ● with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 302 “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 303: Vehicle Interior
4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 304: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
Page 305 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test: ■...
Page 306 • FMVSS No.116 DOT 3 or SAE Brake fluid level (→P. 521) J1703 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 307 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- age rating as original Light bulbs (→P. 558) • Phillips-head screwdriver • Flathead screwdriver • Automatic transmission fluid ® DEXRON II or III Power steering fluid level •...
Page 308 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment ■ Keep hands, clothing, and tools away from the moving fan and engine ●...
Page 309 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner ■ Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. If the brake fluid level is low or high ■...
Page 310 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION Pre-driving check ■...
Page 311 4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 527) Brake fluid reservoir (→P. 521) Engine oil level dipstick (→P. 515) Fuse box (→P. 547) Engine coolant reservoir Battery (→P. 524) (→P. 519) Radiator (→P. 521) Engine oil filler cap Condenser (→P.
Page 312 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After turning off the engine, wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
Page 313 4-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 314 4-3. Do-it-yourself maintenance Engine oil consumption ■ The amount of engine oil consumed depends on the oil viscosity, the ● quality of the oil and the way the vehicle is driven. More oil is consumed under driving conditions such as high speeds and ●...
Page 315 ● not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 316: Engine Coolant
■ Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. Coolant selection ■...
Page 317 4-3. Do-it-yourself maintenance CAUTION When the engine is hot ■ Do not remove the radiator cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing burns or other injuries. NOTICE When adding engine coolant ■...
Page 318 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot ■...
Page 319 4-3. Do-it-yourself maintenance CAUTION When filling the reservoir ■ Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 320 4-3. Do-it-yourself maintenance Power steering fluid Fluid level ■ The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
Page 321 4-3. Do-it-yourself maintenance CAUTION Checking the fluid level ■ Take care, as the reservoir may be hot. NOTICE When adding fluid ■ Avoid overfilling, or the power steering may be damaged. After replacing the reservoir cap ■ Check the steering box case, vane pump and hose connections for leaks or damage.
Page 322 4-3. Do-it-yourself maintenance Before recharging ■ When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: If recharging with the battery installed on the vehicle, be sure to discon- ● nect the ground cable. Make sure the power switch on the charger is off when connecting and ●...
Page 323 4-3. Do-it-yourself maintenance CAUTION Emergency measures regarding electrolyte ■ If electrolyte gets in your eyes ● Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 324 4-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations. ● Any washer does not work. ● The low washer fluid warning light comes on. ● The warning message appears on the multi-information display. (if equipped) Open the lid. Add washer fluid.
Page 325 4-3. Do-it-yourself maintenance CAUTION When refilling the washer fluid ■ Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE Do not use any fluid other than washer fluid ■...
Page 326 The tire pressure warning system ■ Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 586)
Page 327 Have tire pressure warning valve and trans- mitter ID codes registered by your Toyota dealer. (→P. 531) Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■...
Page 328 A tire goes flat repeatedly or cannot be properly repaired due to the ● size or location of a cut or other damage If you are not sure, consult with your Toyota dealer.
Page 329 4-3. Do-it-yourself maintenance Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly. After driving for about 20 minutes, the tire pressure warning light comes on after blinking for 1 minute to indicate a system malfunction.
Page 330 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- ●...
Page 331 Do not mix tires of different makes, models or tread patterns. Also, do ● not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply ●...
Page 332 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 333 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure ■ The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 639)
Page 334 4-3. Do-it-yourself maintenance Inspection and adjustment procedure ■ Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the graduations of the gauge. If the tire inflation pressure is not within the recommended levels, adjust inflate the tire.
Page 335 Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 336 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear ● Uneven wear ● Poor handling ●...
Page 337 ● Bent wheels that have been straightened Wheel precautions ■ ● Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 100 miles (160 km).
Page 338 Because tire repair or replacement may affect the tire pressure warn- ● ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 339 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method ■ Turn the engine switch off. Open the glove box. Remove the internal tray. Remove the inside cover by sliding up while pulling toward you.
Page 340 Hold the air gun 2 in. (5 cm) from the filter and blow for approximately 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm or bar). If it is not available, have the filter cleaned by your Toyota dealer.
Page 341 4-3. Do-it-yourself maintenance Replacement method ■ Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. Checking interval ■ Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule.
Page 342 4-3. Do-it-yourself maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. You will need the following items: ■ Lithium battery CR2032 Replacing the battery ■ Remove the cover using a coin protected with tape etc. Remove the discharged trans- mitter battery.
Page 343 ● The operational range is reduced. ● Use a CR2032 lithium battery ■ Batteries can be purchased at your Toyota dealer, jewelers, or camera ● stores. Replace only with the same or equivalent type recommended by your ● Toyota dealer.
Page 344 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 345 4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool.
Page 346 Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer.
Page 347 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ Fuse Ampere Circuit Multiport fuel injection system/ 15 A sequential multiport fuel injection system HORN 10 A Horn Multiport fuel injection system/ EFI NO.1 25 A sequential multiport fuel injection system IG2 MAIN 30 A...
Page 348 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 15 A Front fog lights Stop lights, high mounted stop- light, vehicle stability control sys- tem, anti-lock brake system, shift STOP 15 A lock system, multiport fuel injection system/sequential multiport fuel injection system, towing converter TOW BRK 30 A Trailer brake controller...
Page 349: Cruise Control
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Interior lights, personal lights, van- ity lights, engine switch light, foot DOME 7.5 A light, door courtesy lights, acces- sory meter, power back door, power third seat Left-hand headlight HEAD LH 15 A (high beam) Left-hand headlight HEAD LL 15 A...
Page 350 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 30 A Power back door RR HTR 40 A Air conditioning system H-LP CLN 30 A Headlight cleaner DEFOG 40 A Rear window defogger SUB BATT 40 A Trailer towing Anti-lock brake system, vehicle sta- ABS1 50 A bility control system...
Page 351 4-3. Do-it-yourself maintenance Under the instrument panel ■ Fuse Ampere Circuit INVERTER 15 A Power outlet (115 V) FR P/SEAT LH 30 A Power front driver’s seat DR/LCK 25 A Multiplex communication system POWER No.5 30 A Power back door 7.5 A On-board diagnosis system PWR OUTLET...
Page 352: Intuitive Parking Assist
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, multiplex com- munication system, intuitive parking assist system, power front driver’s seat, power tilt and power ECU-IG No.1 7.5 A telescopic, shift lock, tire pressure warning system, accessory meter, trailer towing, power outlet, electric moon roof, power back door, head light cleaner...
Page 353 (→P. 558) If the replaced fuse blows again, have the vehicle inspected by your ● Toyota dealer. If there is an overload in the circuits ■ The fuses are designed to blow, protecting the wiring harness from damage.
Page 354 Never use a fuse of a higher amperage rating than indicated, or use any ● other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. ● Never replace a fuse with a wire, even as a temporary fix.
Page 355 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 356: Replacing Light Bulbs
4-3. Do-it-yourself maintenance Rear bulb locations ■ Stop/tail and rear side marker lights Tail lights License plate lights Rear turn signal lights Back-up lights Replacing light bulbs Headlight high beam ■ Unplug connector while depressing the lock release.
Page 357 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Headlight low beam ■ Unplug connector while depressing the lock release. Turn the bulb base counterclock- wise.
Page 358 4-3. Do-it-yourself maintenance Front turn signal/parking lights and daytime running lights ■ (if equipped) Turn the bulb base counterclock- wise. Remove the light bulb.
Page 359 4-3. Do-it-yourself maintenance Front side marker lights ■ Remove the fender liner clip. Partly remove the fender liner and turn the bulb base counter- clockwise.
Page 360 4-3. Do-it-yourself maintenance Remove the light bulb. Front fog lights (if equipped) ■ Remove the bolts and partly remove the fender liner. Unplug connector while depressing the lock release. Turn the bulb counterclockwise.
Page 361 4-3. Do-it-yourself maintenance Stop/tail and rear side marker lights, rear turn signal lights ■ Right side Open the back door and remove the cover. To protect the cover, place a rag between the flathead screwdriver or equivalent and cover as shown in the illustrations.
Page 362 4-3. Do-it-yourself maintenance Left side (vehicles with speaker in the luggage) Open the back door and remove the cover. To protect the cover, place a rag between the flathead screwdriver or equivalent and cover as shown in the illustrations. Turn the bulb bases counter- clockwise.
Page 363 4-3. Do-it-yourself maintenance Tail lights, back-up lights Remove the covers. (vehicles with power back door only) To protect the cover, place a rag between the flathead screwdriver or equivalent and cover as shown in the illustrations. Remove the nuts. Remove the rear combination light assembly in the order shown in the illustration.
Page 364 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Tail light Back-up light Remove the light bulb. Tail light Back-up light License plate lights ■ Remove the screws and light unit.
Page 365 ■ The high mounted stoplight and side turn signal light consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. Installing the fender liner clips ■...
Page 366 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ Turn off the headlights. Do not attempt to replace the bulb immediately ● after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the ●...
Page 367 4-3. Do-it-yourself maintenance...
Page 368 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent battery discharge ■...
Page 369 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 370 5-1. Essential information Type B Towing eyelet Emergency towing procedure ■ The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models: Put the front wheel drive control switch in 2WD. Put the shift lever in N. Release the parking brake.
Page 371 5-1. Essential information NOTICE To prevent causing serious damage to the transmission ■ Never tow this vehicle from the rear with the four wheels on the ground. This may cause serious damage to the transmission. Emergency towing eyelet precautions ■ Before emergency towing, check that the eyelet is not broken or damaged ●...
Page 372 5-1. Essential information Towing with a wheel lift-type truck from the front Use a towing dolly under the rear wheels. NOTICE To prevent causing serious damage to the transmission ■ Never tow this vehicle wheels on the ground. Towing with a wheel lift-type truck from the rear 2WD models Turn the engine switch to the ACC position.
Page 373 5-1. Essential information 4WD models When not using a towing dolly, turn the engine switch to the ACC position, shift the shift lever to N and put the front wheel drive control switch in 2WD. NOTICE To prevent causing serious damage to the transmission (4WD models) ■...
Page 374: Electronically Modulated Air Suspension
5-1. Essential information Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in the illustration. Vehicles without electronically modulated air suspension If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 375 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 376 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 377 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 378 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained ●...
Page 379 Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging sys-...
Page 380 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 381 5-2. Steps to take in an emergency Warning light Warning light/Details Automatic transmission fluid temperature warn- ing light • When the light comes on: Indicates that the auto- matic transmission fluid temperature is too high. • When the light flashes: Indicates a malfunction in the automatic transmission fluid temperature warning system.
Page 382 • When the light comes on Have the system after blinking for 1 checked by your minute: Malfunction in Toyota dealer. the tire pressure warning system. Low fuel level warning light Refuel the vehicle. Low level of fuel.
Page 383: Four-Wheel Drive System
5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Master warning light A buzzer sounds and the warning light comes on →P. 592 and flashes to indicate that the master warning system has detected a malfunction. : Open door warning buzzer: The buzzer sounds to indicate that any door is opened (with the vehicle hav- ing reached a speed of 3 mph [5 km/h])
Page 384 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Front passenger detection sensor and passenger seat belt reminder ■...
Page 385 If there is a lot of snow or ice on the vehicle, in particular around the ● wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota ● wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 386 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, ●...
Page 387 5-2. Steps to take in an emergency CAUTION Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
Page 388 Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates that the engine coolant temperature is too high A buzzer also sounds.
Page 389 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning message Details Correction procedure Indicates that one or more of the doors is not fully closed.
Page 390 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the park- ing brake is still engaged with the vehicle having reached a speed Release the parking of more than 3 mph (5 brake. km/h). (Flashing) A buzzer also sounds intermittently.
Page 391 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the fuel level is low. Fill up the tank as soon A buzzer also sounds as possible. and the low fuel level warning light comes on. Indicates that the laser radar sensor is dirty or Clean the sensor.
Page 392 5-2. Steps to take in an emergency After changing the engine oil (U.S.A. only) ■ Make sure to reset the oil maintenance data. (→P. 517) Warning light display in vehicle-to-vehicle distance control mode ■ In the following cases, the warning light may not be displayed even if vehi- cle-to-vehicle distance closes.
Page 393 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle ■ ● Stop the vehicle on a hard, flat surface. ● Press the height control mode select switch to set the height control system to manual mode (if equipped) ●...
Page 394 5-2. Steps to take in an emergency Taking out the jack and tool bag Pull the deck board up. Remove the cover and loosen the strap. Remove the tools. Tighten Loosen...
Page 395 5-2. Steps to take in an emergency Taking out the spare tire Remove the cover. Assemble the jack handle exten- sion as shown. Insert the end of the jack handle extension into lowering screw and turn it counterclock- wise. After the tire is lowered com- pletely to the ground, remove the holding bracket.
Page 396 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left- the front...
Page 397 5-2. Steps to take in an emergency Position the jack at the correct jack point as shown. Front Rear Front Make sure the jack is positioned on a level and solid place. Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 398 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 399 5-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 154 ft·lbf (209 N·m, 21.3 kgf·m) : When used on aluminum wheel, apply 97 ft·lbf (131 N·m, 13.4 kgf·m) Stowing the flat tire, jack and all tools Remove the center wheel ornament by pushing from the...
Page 400 5-2. Steps to take in an emergency CAUTION Using the jack ■ Improper use of the jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the jack for any purpose other than replacing tires or install- ●...
Page 401 5-2. Steps to take in an emergency CAUTION Replacing a flat tire ■ Observe the following precautions to reduce the risk of death or serious injury. Never use oil or grease on the wheel bolts or wheel nuts. ● Oil and grease may cause the wheel nuts to be excessively tightened, leading to bolt or disc wheel damage.
Page 402 5-2. Steps to take in an emergency CAUTION Driving with tire chains and the temporary spare tire ■ Do not fit tire chains to the temporary spare tire. Tire chains may damage the vehicle body and adversely affect driving performance. When the spare tire is attached ■...
Page 403 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 404 5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 157) or releasing the steering lock (→P. 158), confirm the following points. The engine will not start even when the starter motor oper- ■...
Page 405 One of the following may be the cause of the problem. ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 612) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 406 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 407 5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the master keys and the key number stamped on your key number plate. (→P. 32) If you lose all your master keys.
Page 408 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connect the jumper cables.
Page 409 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Starting the engine when the battery is discharged ■...
Page 410 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it ●...
Page 411 If the fan is operating: Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer.
Page 412 Note that water draining from the air conditioning is normal if it has been used. Add engine coolant if required. Water can be used in an emer- gency if engine coolant is unavailable. (→P. 629) Have the vehicle checked at your nearest Toyota dealer as soon as possible.
Page 413 5-2. Steps to take in an emergency Overheating ■ If you observe the following, your vehicle may be overheating. The engine coolant temperature gauge enters the red zone or a loss of ● power is experienced. Steam is coming from under the hood. ●...
Page 414 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P.
Page 415 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 416 5-2. Steps to take in an emergency CAUTION If the engine has to be turned off while driving ■ Power assist for the brakes and steering wheel will be lost, making the ● brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 417 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 205.1 in. (5210 mm) Overall width 79.9 in. (2030 mm) Without roof rails 74.6 in. (1895 mm) Overall height* With roof rails 77.0 in. (1955 mm) Wheelbase 122.0 in. (3100 mm) Front tread 67.9 in.
Page 418 6-1. Specifications Weight Vehicle capacity Driving Model code Engine weight system (Trailer weight + cargo) (Occupants+luggage) 1220 lb. (550 kg) UPK60L-GKTSKA 6900 lb. (3130 kg) 4.6L V8 1250 lb. (565 kg) UPK60L-GKTLKA 6800 lb. (3084 kg) (1UR-FE) UPK65L-GKTSKA 1245 lb. (560 kg) engine 6600 lb.
Page 419 Vehicle identification number ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 420 6-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. 4.6 L V8 (1UR-FE) engine 5.7 L V8 (3UR-FE, 3UR-FBE) engine...
Page 421 6-1. Specifications Engine Model 1UR-FE, 3UR-FE, 3UR-FBE Type 8-cylinder V-type, 4-cycle, gasoline 4.6 L V8 (1UR-FE) engine 3.70 × 3.27 in. (94.0 × 83.0 mm) Bore and stroke 5.7 L V8 (3UR-FE, 3UR-FBE) engine 3.70 × 4.02 in. (94.0 × 102.0 mm) 4.6 L V8 (1UR-FE) engine 281.2 cu.in.
Page 422: Lubrication System
7.4 qt. (7.1 L, 6.2 Imp.qt.) Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toy- ota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. 4.6 L V8 (1UR-FE) engine...
Page 423 6-1. Specifications 5.7 L V8 (3UR-FE, 3UR-FBE) engine Oil grade: ILSAC multigrade engine oil Recommended viscosity: SAE 5W-20 or 0W-20 SAE 5W-20 or 0W-20 engine oil may be used. However, SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather.
Page 424: Cooling System
3UR-FBE) Vehicles with towing package engine 15.4 qt. (14.6 L, 12.8 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 425: Electrical System
Oil type and viscosity LT 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please...
Page 426: Automatic Transmission
NOTICE Automatic transmission fluid type ■ Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
Page 427 6-1. Specifications Brakes Pedal clearance 4.1 in. (104 mm) Min. 0.04 ⎯ 0.20 in. (1 ⎯ 5 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Parking brake pedal travel 6 —...
Page 428 6-1. Specifications Tires and wheels Type A P275/65R18 114T, Tire size P255/70R18 112T (spare tire) Front tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 33 psi (230 kPa, 2.3 kgf/cm or bar) inflation pressure) Spare tire: 33 psi (230 kPa, 2.3 kgf/cm...
Page 429: Light Bulbs
6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights 9005 (high beam) Headlights — (low beam) Front fog lights 9145 Front side marker lights Front turn signal/parking 4157NAK 27/8 lights Exterior Rear turn signal lights — Stop/tail and rear side 7443 21/5 marker lights...
Page 430 6-1. Specifications Fuel information Gasoline engine Your vehicle must use only unleaded gasoline. Select octane rating 87 (Research Octane Number 91) or higher. Use of unleaded gasoline with an octane rating lower than 87 may result in engine knocking. Persistent knocking can lead to engine damage. At minimum, the gasoline you use should meet the specifications of ASTM D4814 in the U.S.A.
Page 431 6-1. Specifications Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks ■ Consult your Toyota dealer.
Page 432 Toyota allows the use of oxygenate blended gasoline where the oxygen- ● ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no ● lower than 87.
Page 433 6-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. ● If improper fuels are used, the engine will be damaged. Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 434 6-1. Specifications Tire information Typical tire symbols Tire size (→P. 641) DOT and Tire Identification Number (TIN) (→P. 640) Location of treadwear indicators (→P. 529) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 435 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (→P. 532) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
Page 436 6-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 437 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 438 6-1. Specifications Treadwear ■ The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 439 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 440: Cargo And Luggage
6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 441 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 442 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall...
Page 443 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 444 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indica- designed to give a visual indication of the...
Page 445 Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
Page 446 6-2. Customization Customized Item Function Default setting setting Wireless Push twice* remote con- Power back door oper- Push and hold trol ation One short push* → P. 33) Switch operation Push and hold One short push Wireless remote control linked operation Operation signal vol- Power back Operation when door...
Page 447 6-2. Customization Customized Item Function Default setting setting Driver’s door unlocked in All doors Door lock one step, all Unlocking using a key unlocked in (→P. 37) doors one step unlocked in two steps Open only Power Door key linked opera- windows Open and close Close only...
Page 448 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Illumination Operation after the → P. 429) engine is off Operation when the doors are unlocked Seat Belt Vehicle speed linked Reminder seat belt reminder Buzzer...
Page 449 6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference • After reconnecting or changing Power back door the battery.
Page 450 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 451 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.
Page 454 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English.
Page 465 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory AI-SHIFT Artificial Intelligence shifting Automatic Locking Retractor A-TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Adaptive Variable Suspension System Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor...
Page 466 ABBREVIATIONS MEANING Resume RSCA Roll Sensing of Curtain shield Airbags Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control...
Page 467 Alphabetical index Alphabetical index A/C........280, 288 Alarm.........107 ABS ...........236 Antenna ........306 Active traction control.....236 Anti-lock brake system ... 236 Adaptive variable suspension Armrest ........474 system ........228 Ashtrays ........460 Air conditioning filter....542 A-TRAC ........236 Air conditioning system Audio input.......343 Air conditioning filter....542 Audio system Front air conditioning A/V input port ......
Page 468 Alphabetical index Back-up lights Child restraint system Replacing light bulbs .... 558 Booster seats, definition..130 Wattage ........ 634 Booster seats, installation ..141 Back door Convertible seats, Back door ....... 42 definition ......130 Wireless remote control..33 Convertible seats, Back window ......95 installation......140 Battery Front passenger occupant...
Page 469: Winter Driving Tips
Alphabetical index Cleaning Doors Exterior........498 Back door........ 42 Interior ........500 Door glasses ......92 Seat belts ......501 Door lock......33, 37 Climate control seat....472 Side doors.......37 Clock ........457 Side mirrors......86 Coin holder .......435 Driver's seat belt reminder Compass........491 light......... 585 Condenser ........521 Driving Console box .....436, 443 Break-in tips ......
Page 470 Alphabetical index If your vehicle has to FFV ........100, 635 be stopped in an Flex-fuel ......100, 635 emergency ......619 Flexible fuel vehicle ..100, 635 If your vehicle needs to be Floor mat........478 towed ......... 573 Fluid If your vehicle overheats ..615 Brake........521 Engine Washer........527...
Page 471 Alphabetical index Garage door opener....485 Interior lights Gas station information...688 Interior lights ......429 Gauges........167 Switch ........430 Glove box........434 Wattage......... 634 Instrument panel light control ........171 Hands-free system Intuitive parking assist.... 209 (for cellular phone) ....406 Hazard lights Switch........572 Jack Head restraints Positioning the jack ....
Page 472 Alphabetical index Lights Noise from under vehicle ..26 Door courtesy lights....429 Emergency flasher switch ..572 Odometer ........167 Fog light switch..... 190 Off-road precautions ....242 Hazard light switch ....572 Headlight switch ....186 Engine oil ......515 Interior light switch..431, 432 Opener Outer foot lights ....
Page 473 Alphabetical index Radar cruise control ....198 Seatback table....52, 477 Radiator ........521 Seat belts Radio .........301 Adjusting the seat belt.....71 Rear air conditioning ALR .........76 system ........288 Automatic Locking Rear console box .....443 Retractor.......76 Rear seat Child restraint system Adjustment ......54 installation......
Page 474 Alphabetical index Service reminder Stuck indicators ......172 If your vehicle becomes Shift lever stuck ........618 Automatic Sun visors.........455 transmission....... 160 Sunshade........475 If the shift lever cannot Switch be shifted ......610 Emergency flasher switch ..572 Shift lock system..... 610 Engine switch ......157 Shopping bag hooks....
Page 475: Trailer Towing
Alphabetical index Tachometer.......167 Turn signal lights Tail lights Replacing light bulbs..... 558 Replacing light bulbs .....558 Switch ........164 Switch........186 Wattage......... 634 Wattage.........634 Talk switch........404 Valet key ........32 Telephone switch.....404 Vanity lights Theft deterrent system Vanity lights......456 Alarm........107 Wattage......... 634 Engine immobilizer system ...105 Vanity mirrors ......
Page 476 Alphabetical index Weight Cargo capacity ..... 247 Load limits ......251 Towing capacity....623 Trailer Weight Rating..262, 623 TWR ......262, 623 Vehicle capacity weight ..623 Weight ........623 Wheels........540 Window glasses ....92, 95 Window lock switch ....92 Windows Power back window....
Page 477: System
What to do if... What to do if... A tire punctures If you have a flat tire P. 597 P. 608 If the engine will not start The engine does not start P. 105 Engine immobilizer system If the vehicle battery is discharged P.
Page 478: Instrument Cluster
What to do if... The warning light or indicator If a warning light turns on P. 583 light comes on Instrument cluster ■ Vehicles with multi-information display Vehicles without multi-information display Center panel ■...
Page 479: System
What to do if... ■Warning lights Master warning light Brake system warning light P. 587 VSC OFF indicator and P. 583 slip indicator* Charging system warning light P. 583 P. 584 Malfunction indicator Tire pressure warning lamp light P. 584 P.
Page 480 Memo...
Page 481: Hood
GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 513 P. 100 Hood lock release lever Tire inflation pressure P. 513 P. 633 Fuel tank capacity 26.4 gal. (100.0 L, 22.0 lmp.gal.) (Reference) Fuel type P. 626 Cold tire inflation P.
