Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Operation of Reading this manual ....14 each component How to search......15 Pictorial index ......16 3-1. Key information Keys........108 For safety and security 3-2. Opening, closing and locking the doors Side doors ......
Page 3 4-5. Using the driving Driving support systems Toyota Safety Sense P..247 4-1. Before driving (Pre-Collision System)..254 Driving the vehicle..... 176 Cargo and luggage.... 187 (Lane Departure Alert)..268 Vehicle load limits ..... 193 Dynamic radar cruise Trailer towing..... 194 control ......
Page 4 TABLE OF CONTENTS 5-4. Other interior features Interior features Other interior features..375 • Sun visors ..... 375 5-1. Using the air conditioning • Vanity mirrors ....376 system and defogger • Power outlets ....377 Front air conditioning • USB charging ports ..380 system......
Page 5 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers... 458 the vehicle exterior..398 If your vehicle has to be Cleaning and protecting stopped in an the vehicle interior... 401 emergency....... 459 If the vehicle is trapped 6-2.
Page 6 TABLE OF CONTENTS Vehicle specifications Index 8-1. Specifications What to do if... (Troubleshooting)..... 570 Maintenance data (fuel, oil level, etc.) ..518 Alphabetical index ...... 574 Fuel information ....529 Tire information ....532 8-2. Customization Customizable features ..544 8-3.
Page 7 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recording The vehicle is equipped with sophisticated computers that will record certain...
Page 10 Usage of data collected through Safety connect (U.S.mainland only) If your Toyota has Safety connect and if you have subscribed to those ser- vices, please refer to the Safety connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 574 Searching installation ■ position • Pictorial index....P. 16 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 570 Searching by title ■ • Table of contents .....P. 2...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 113 Locking/unlocking .
Page 17 Pictorial index Fuel filler door ........P. 244 Refueling method.
Page 18 Pictorial index ■ Instrument panel Engine switch........P. 214 Starting the engine/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 98 Display ..........P. 98 When the warning messages are displayed .
Page 20 Pictorial index ■ Switches Outside rear view mirror switches ....P. 161 Personal/interior light main switch ....P. 356 Automatic High Beam switch .
Page 21 Pictorial index Power outlets ........P. 377 USB charging ports .
Page 22 Pictorial index Meter control switches ......P. 99 Cruise control switch Dynamic radar cruise control .
Page 23 Pictorial index ■ Interior SRS airbags ........P. 40 Floor mat .
Page 24 Pictorial index Personal/interior lights ......P. 357 “SOS” button ........P. 76 Inside rear view mirror .
Page 25 For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......40 Front passenger occupant classification system ..51 Safety information for children ......57 Child restraint systems..58 Installing child restraints..
Page 26: For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see the rear of the vehicle clearly by adjusting the inside and outside rear view mirrors properly. (P. 158, 161) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Fastening the rear center seat belt Take out the plates, and then pull the seat belt. Push the plate into the buckle in Plate “A” Plate “B” the order of plate “A” and plate “B” until a clicking sound is heard.
Page 32 1-1. For safe use Releasing and stowing seat belt (for the third center seat) To release the hooked plate “B”, push the buckle release button. To release the hooked plate “A”, insert the plate “B” or the key into the hole on the buckle. When releasing the seat belt, retract it slowly.
Page 33 1-1. For safe use Adjusting the seat belt shoulder anchor height (front and second outer seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 34 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.
Page 35 1-1. For safe use ■ Seat belt comfort guide (third center seat) If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide. Pull the comfort guide from the pocket. Slide the belt past the slot of the guide.
Page 36 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 37 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 38 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 39 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 40: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 41 1-1. For safe use SRS airbag system components Side airbags Front passenger occupant classification system (ECU “AIR BAG ON” and “AIR and sensors) BAG OFF” indicator lights Side impact sensors (rear) Curtain shield airbags SRS warning light Front passenger airbag Driver’s seat position sen- Knee airbags Side impact sensors (front...
Page 42 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 43 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 44 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 45 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
Page 46 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 47 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 48 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 49 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 50 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 51: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag, front passenger knee airbag in the front passenger side, and front passenger’s seat belt pretensioner.
Page 52 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light flashing Front passenger airbag Devices...
Page 53 1-1. For safe use Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Front passenger knee airbag Devices Activated Front passenger’s seat belt pretensioner deactivated...
Page 54 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Devices Front passenger knee airbag Front passenger’s seat belt pretensioner...
Page 55 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 56 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 57: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 58: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 59 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/con- Forward facing  Convertible   vertible seat seat Booster seat ...
Page 60 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 61 1-1. For safe use WARNING ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 62: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH (Lower Anchors and Tethers for Children) anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH system.
Page 63 1-1. For safe use Anchor brackets (for top tether strap) An anchor bracket is provided for all of the second seats and third center seat. Second seat (separated type) Second seat (bench type)   Third center seats ...
Page 64 1-1. For safe use Installation with LATCH system (second seats only) Fold the seatback while pulling the lever. Second seat (except center seat)  Return seatback secure it at the 1st lock position (most upright position). Adjust the seatback to the 4th lock position.
Page 65 1-1. For safe use Type A  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. The anchors are installed in the lower seatback under a flap.
Page 66 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 67 1-1. For safe use Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is...
Page 68 1-1. For safe use Forward-facing Convertible seat ■ Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 69 1-1. For safe use If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. (P. 70) Booster seat ■ Place the child restraint sys- tem on the seat facing the front of the vehicle.
Page 70 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Second seat  Secure the child restraint sys- tem using the seat belt or LATCH anchors, and adjust the head restraint to the upmost...
Page 71 1-1. For safe use Third center seat  Secure the child restraint sys- tem using the seat belt, and adjust the head restraint to the upmost position. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 72 1-1. For safe use WARNING ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (P. 34) ■...
Page 73 1-1. For safe use WARNING ● When installing a child restraint system on the third center seat, adjust both seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sud- den braking, sudden swerving or an accident.
Page 74 1-1. For safe use WARNING ■ Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a sud- den braking, sudden swerving or an accident.
Page 75: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 76: Emergency Assistance Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada.
Page 77 A variety of subscription terms are available for purchase. Contact your Toyota dealer, call the following appropriate Customer Experi- ence center or push the “SOS” button in your vehicle for further subscription details.
Page 78 Safety Connect is active and in use. ● Safety Connect is available beginning Fall 2009 on select Toyota models (in the contiguous United States only). Contact with the Safety Connect response center is dependent upon the telematics device being in operative...
Page 79 Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Emergency Assistance Button (“SOS”) ■...
Page 80 For a description of the Enhanced Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 81 1-2. Emergency assistance ■ Certification for Safety Connect SEQUOIA_OM_USA_OM0C021U_20MY...
Page 82: 1-3. Theft Deterrent System
1-3. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 83 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system For vehicles sold in the U.S.A.  FCC ID: MOZRI-42BTY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 84: Alarm
1-3. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 85 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 86 1-3. Theft deterrent system ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ● When a person remaining in the vehicle locks the door and the alarm is acti- vated.
Page 87: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......88 Gauges and meters .... 94 Multi-information display ..98 Fuel consumption information ...... 104 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 88: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 89 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning ABS warning light light (P. 469) (P. 470) (U.S.A.) (U.S.A.) Brake system warning ABS warning light light (P. 469) (P.
Page 90 There may be a malfunction in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : The light illuminates on the multi-information display.
Page 91 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (P. 225) (P. 285) Headlight indicator Cruise control set indica- (P. 227) tor (P. 276) (U.S.A.) LDA indicator (P.
Page 92 If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction in the system. If this occurs, have the vehicle inspected by your Toyota dealer. : This light illuminates on the center panel.
Page 93 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 94: Gauges And Meters
2. Instrument cluster Gauges and meters The displayed content may differ depending on the type of meter. Tachometer Displays the engine speed in revolutions per minute Engine oil pressure gauge Displays the engine oil pressure Outside temperature display Displays the outside temperature within the range of -40 °F (-40 °C) to 122 °F (50 °C).
Page 95 2. Instrument cluster Odometer and trip meter display P. 95 Shift position and shift range display Displays the selected shift position or selected shift range (P. 220) Engine coolant temperature gauge Displays the engine coolant temperature Instrument panel light control button ( P.
Page 96 ● When “--” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display.
Page 97 When the oil pressure drops even though the engine oil amount has not decreased, or if the oil pressure does not increase when engine oil is added, contact your Toyota dealer, as there may be a problem with the lubri- cation system.
Page 98: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. ● Menu icons Displays the following informa- tion when an icon is selected. Some of the information may be displayed automatically depending on the situation.
Page 99 2. Instrument cluster Operating the meter control switches ■ Select an item/change pages Press: Enters/Sets Press and hold: Resets Switch menu/Displays the top screen Returns previous screen Drive information ● Average fuel economy (Total Average /Tank Average/Trip Average) Displays the average fuel consumption since the function was reset, the vehicle was refueled, or the engine was started, respec- tively Use the displayed average fuel consumption as a reference.
Page 100 2. Instrument cluster ● Average speed (Average Speed /Trip Average Speed) Displays the average since engine was started or the average since the function was reset, respectively ● Elapsed Time (Total Time /Trip Time) Displays the engine was started or the elapsed time since the func- tion was reset, respectively ●...
Page 101 2. Instrument cluster ● Vehicle Settings • Brightness (P. 548) Select to set up the BSM (Blind Spot Monitor) outside rear view mirror indicators brightness. • RCTA volume (P. 548) Select to set up the RCTA (Rear Cross Traffic Alert) sensitivity. •...
Page 102 2. Instrument cluster ■ Setting items ● “Vehicle Settings” and “Meter Settings” setting items are not selectable during driving and cannot be operated. Also, the settings screen is temporarily canceled in the following situations. • A warning message is displayed. •...
Page 103 2. Instrument cluster WARNING ■ Caution for use while driving ● When operating the multi-information display while driving, pay extra attention to the safety of the area around the vehicle. ● Do not look continuously at the multi-information display while driving as you may fail to see pedestrians, objects on the road, etc.
Page 104: Fuel Consumption Information
2. Instrument cluster Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the trip information or past record screen Press the “APPS” button, and then select “Eco” on the screen. Fuel consumption Trip information ■...
Page 105 2. Instrument cluster ■ Past record If the “Trip Information” screen is displayed, select “Past Record”. Resetting the past record data Best recorded fuel consump- tion Average fuel consumption (if equipped) Previous fuel consumption record Update the average fuel consumption data The average fuel consumption history is divided by color into past averages and the average fuel consumption since the last updated.
Page 106 2. Instrument cluster...
Page 107: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........108 3-2. Opening, closing and locking the doors Side doors......113 Back door......118 Smart key system ..... 128 3-3. Adjusting the seats Front seats ......136 Rear seats......138 Driving position memory ......
Page 108: Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key sys- tem (128) • Operating wireless remote control function Mechanical keys Key number plate Wireless remote control Locks all the doors (P. 113) Check that the door is securely locked.
Page 109 ■ If you lose your keys New genuine key can be made by your Toyota dealer. The following are necessary when making new keys. Mechanical key: The key number for the mechanical key stamped on the number plate and the other key.
Page 110 P. 444 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization Settings (e.g. wireless remote control system) can be changed. (Customizable features: P. 544)
Page 111 3-1. Key information ■ Certification for wireless remote control For vehicles sold in the U.S.A.  FCC ID: GQ4-52T FCC ID: GQ4-49R NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 112 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 113: Opening, Closing And
3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors from the outside ◆ Smart key system Carry the electronic key to enable this function. Grip the driver’s door handle to unlock the door. Grip the passenger’s door handle to unlock all the doors.
Page 114 3-2. Opening, closing and locking the doors ■ When the door cannot be locked by the lock sensor on the surface of the door handle When the door cannot be locked even if the lock sensor on the surface of the door handle is touched by a finger, touch the lock sensor with the palm.
Page 115 3-2. Opening, closing and locking the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position. Locking the doors from the outside without a key Move the inside lock button to the lock position.
Page 116 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 544. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- mately 12 mph (20 km/h) or higher.
Page 117 3-2. Opening, closing and locking the doors Shift lever Driver’s door lock Function position switch position Shift position linked door locking function Shift position linked door unlock- ing function Speed linked door locking func- tion Driver’s door linked door unlock- ing function When the setting or canceling operation is complete, all the doors are locked and then unlocked.
Page 118: Back Door
3-2. Opening, closing and locking the doors Back door Unlocking and locking the back door from the outside ◆ Entry function Press the button to unlock the back door. The door cannot be unlocked for 3 seconds after the door is locked.
Page 119 3-2. Opening, closing and locking the doors Opening/closing the back door with the wireless remote control (vehicles with power back door) Opening/closing the back door using the wireless remote con- ■ trol Press and hold the switch to open/close the power back door.
Page 120 3-2. Opening, closing and locking the doors Opening the back door from outside the vehicle Raise the back door while pushing up the back door opener switch. Closing the back door from outside the vehicle ◆ Back door strap Lower the back door using the back door strap and make sure to push the back door down from the outside to close it.
Page 121 While the power back door is opening automatically, applying excessive force to it will stop the opening operation to prevent the power back door from rap- idly falling down. ■ Customization that can be configured at Toyota dealer Settings (e.g. power back door) can be changed. (Customizable features P. 544)
Page 122 3-2. Opening, closing and locking the doors WARNING ■ Before driving Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 123 3-2. Opening, closing and locking the doors WARNING ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 124 When installing an accessory part to the back door, using a genuine Toyota part is recommended. ■ Back door closer (vehicles with power back door) ●...
Page 125 When installing an accessory part to the back door, using a genuine Toyota part is recom- mended.
Page 126 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 127 3-2. Opening, closing and locking the doors NOTICE ■ To prevent back door closer malfunction (vehicles with a power back door) Do not apply excessive force to the back door while the back door closer is operating. ■ To prevent damage to the power back door (if equipped) ●...
Page 128: Smart Key System
3-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Locks and unlocks the doors (P. 113) ●...
Page 129 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the front outside door handles.
Page 130 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure An attempt was made to open the door and exit the vehicle when Shift the shift lever to P. the shift lever was not in P. Interior alarm sounds The engine switch was continuously turned to ACC while the...
Page 131 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
Page 132 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 133 3-2. Opening, closing and locking the doors ● The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock sensor on the lower part of the door handle. ●...
Page 134 3-2. Opening, closing and locking the doors ■ Certification for the smart key system For vehicles sold in U.S.A.  FCC ID: HYQ23ABL FCC ID: HYQ14FBA NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 135 (P. 128) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 136: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Power type  Seat position adjustment switch Vertical height adjustment switch (driver’s side only) Seatback angle adjustment switch Driver’s seat support adjustment switch Seat cushion (front) angle equipped) adjustment switch (driver’s side only) Lumbar support adjustment switch (if equipped)
Page 137 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 138: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedures Second seats ■ Separated type  Seat position adjustment lever Seatback angle adjustment lever SEQUOIA_OM_USA_OM0C021U_20MY...
Page 139 3-3. Adjusting the seats Bench type  Seat position adjustment lever Seatback angle adjustment lever : The second center seat can be moved forward further than side seats. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 140 3-3. Adjusting the seats Third seats ■ Manual type  Seatback angle adjustment lever Power type  Seatback angle adjustment switch Seatback folding/returning switch SEQUOIA_OM_USA_OM0C021U_20MY...
Page 141 3-3. Adjusting the seats Folding down the second seats Before folding down the second seats ■ Adjust the head restraints to the downmost position. Stow the rear seat belt buck- les. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 142 3-3. Adjusting the seats Folding down the second seats ■ Pull the lever to unlock the seatback and then fold the seatback down. Separated type Bench type   After folding down the second seat (if equipped) ■ Fold out the board from the seatback.
Page 143 3-3. Adjusting the seats Moving a second seat for access to the third seats Getting in the vehicle ■ Pull up the lever and fold down the seatback. The seat will slide forward. Move the seat to the front-most position. Getting out of the vehicle ■...
Page 144 3-3. Adjusting the seats Folding down the third seats Before folding down the third seats ■ Stow the third center seat belt. ( P. 32)  Adjust center head restraint to the downmost position. Stow the third seat belt buck- les.
Page 145 3-3. Adjusting the seats Folding down the third seats (manual type) ■ Pull the head restraint lock release lever to fold the head restraint. Pull the lever to unlock the seatback and then fold the seatback down. From rear door side From back door side ...
Page 146 3-3. Adjusting the seats Folding down the third seat (power type) ■ Press and hold the seatback folding switch until the seatback folds down fully and the buzzer sounds. The outside head restraints are folded automatically. From rear door side From back door side ...
Page 147 3-3. Adjusting the seats WARNING ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 148 3-3. Adjusting the seats NOTICE ■ Stowing the seat belts The seat belts and the buckles must be stowed. ■ Second seatback board weight capacity (if equipped) Do not place any object heavier than 220 lb. (100 kg) on the second seat- back board.
Page 149: Driving Position Memory
3-3. Adjusting the seats Driving position memory  This feature automatically adjusts the front seats, steering wheel and outside rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The steering wheel will automatically adjusted to allow the driver to enter and exit the vehicle easily.
Page 150 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory. Recording procedure ■...
Page 151 3-3. Adjusting the seats ■ To stop the position recall operation part-way through Perform any of the following: ● Press the “SET” button. ● Press button “1” or “2”. ● Operate any of the seat adjustment switches (only cancels seat position recall).
Page 152 3-3. Adjusting the seats Memory recall function Each key can be registered to recall your preferred driving position. Registering procedure ■ Record your driving position to button “1” or “2” before performing the following: Carry only the key you want to register, and then close the driver’s door.
Page 153 3-3. Adjusting the seats Cancelation procedure ■ Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to ON. While pressing the “SET”...
Page 154: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front and second seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Third seats Center seat ...
Page 155 3-3. Adjusting the seats ■ Removing the head restraints Pull the head restraint up while pressing the lock release button. The head restraint of second center seat (if equipped) and third outer seats cannot be removed. Lock release button ■ Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock...
Page 156: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Manual adjustment type  Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 157 3-4. Adjusting the steering wheel and mirrors Horn To sound the horn, press on or close to the mark. ■ The steering wheel can be adjusted when (power adjustment type) The engine switch is in ACC or ON. ■ Automatic adjustment of the steering position (if equipped) A desired steering position can be entered to memory and recalled automati- cally by the driving position memory system.
Page 158: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 159 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror ■ Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Type A Type B   Indicator Indicator Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indicator illumi-...
Page 160 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error (auto anti-glare type) Type A  To ensure that the sensors operate prop- erly, do not touch or cover them. Type B  To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 161: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left SEQUOIA_OM_USA_OM0C021U_20MY...
Page 162 3-4. Adjusting the steering wheel and mirrors Folding the mirrors From outside  Push the mirrors towards the back of the vehicle to fold them. From inside (if equipped)  Press the switch to fold the mir- rors. Press it again to extend them to the original position.
Page 163 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (vehicles with driving position memory) When the mirror select switch is in the “L” or “R” position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 164 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 165: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (front windows only) Opening One-touch opening (front windows only) : To stop the window partway, oper-...
Page 166 ■ Door lock linked window operation The power windows can be opened and closed using the key. (P. 108) : These settings must be customized at your Toyota dealer. ■ Customization Settings (e.g. key linked operation) can be changed. (Customizable features P. 544)
Page 167 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 168: Power Back Window
3-5. Opening, closing the windows and moon roof Power back window The power back window can be opened and closed using the switch or key. Opening and closing procedures From inside the vehicle  1, 2 One-touch closing Closing One-touch opening Opening : Pressing the switch in the opposite direction will stop window travel...
Page 169 Continue holding the switch for a further 2 seconds after the window has closed. If you release the switch while the window is moving, start again from the beginning. If the window re-opens slightly after performing the above procedure cor- rectly, have the vehicle inspected by your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 170 3-5. Opening, closing the windows and moon roof ■ Customization Settings (e.g. linked operation) can be changed. (Customizable features P. 544) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Caution while driving Keep the back door and back window closed while driving.
Page 171: Moon Roof
3-5. Opening, closing the windows and moon roof Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 172 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when The engine switch is in ON. ■ Operating the moon roof after turning the engine off The moon roof can be operated for approximately 45 seconds after the engine switch is turned to ACC or OFF.
Page 173 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open reminder function The buzzer sounds and a message is shown on the multi-information display in the instrument cluster when the engine switch is turned off and the driver’s...
Page 174 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 175: Driving
Cargo and luggage ... 187 4-5. Using the driving Vehicle load limits ..... 193 support systems Trailer towing..... 194 Toyota Safety Sense P ..247 Dinghy towing ....213 4-2. Driving procedures (Pre-Collision System) ..254 Engine (ignition) switch ..214 Automatic transmission ..
Page 176: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 214 Driving With the brake pedal depressed, shift the shift lever to D. (P. 220) Release the parking brake. (P. 226) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 177 4-1. Before driving ■ When starting off on an uphill  Hill-start assist control is activated. ( P. 322) ■ Driving in the rain ● Drive carefully when it is raining, because visibility will be reduced, the win- dows may become fogged-up, and the road will be slippery. ●...
Page 178 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 179 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
Page 180 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 181 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ●...
Page 182 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 183 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 184 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 185 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 186 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 187: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Roof luggage carrier Roof rails Cross rails Adjustment the position of cross rails Turn the knobs counterclock- wise to release the cross rails. Slide the cross rails to the appropriate position for loading luggage and turn the knobs...
Page 188 4-1. Before driving Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) — (Total weight of occupants) Steps for Determining Correct Load Limit — (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 189 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 519) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 190 4-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 191 4-1. Before driving WARNING ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 192 4-1. Before driving WARNING ■ Cross rail adjustment Make sure the cross rails are locked securely by pushing forward and rearward them. Failure to do so may cause an accident or serious injury in the event of emergency braking or a collision. NOTICE ■...
Page 193: Vehicle Load Limits
4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): (P. 519) Total load capacity means the combined weight of occupants, cargo and luggage.
Page 194: Trailer Towing
To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about addi- tional requirements such as a towing kit, etc.
Page 195 4-1. Before driving Towing related terms GCWR (Gross Combination Weight Rating) ■ The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 196 4-1. Before driving GAWR (Gross Axle Weight Rating) ■ The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR TWR (Trailer Weight Rating) ■ The maximum allowable gross (With brakes) trailer weight.
Page 197 4-1. Before driving Unbraked TWR (Unbraked Trailer Weight Rating) ■ The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. Tongue Weight ■ The load placed on the trailer hitch ball. (P. 200) SEQUOIA_OM_USA_OM0C021U_20MY...
Page 198 4-1. Before driving Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (P. 199) ● The gross combination weight must never exceed the GCWR described in the table. (P. 199) ● The gross vehicle weight must never exceed the GVWR indi- cated on the Certification Label.
Page 199 4-1. Before driving GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. GCWR and TWR ■ Driving Model code Engine GCWR system USK60L- 13600 lb.
Page 200 4-1. Before driving Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 201 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 202 4-1. Before driving Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 203 64 watts/5 amps of electrical current per side (right and left) for the trailer brake/turn light functions. Please contact your Toyota dealer with any questions or concerns. ■ Service connector for towing brake controller (with towing package) Your vehicle is equipped with a service connector for the trailer brake controller as shown.
Page 204 4-1. Before driving Connecting and disconnecting a trailer (vehicles with electroni- cally modulated air suspension) If a height control system is installed in your vehicle, you have to con- nect and disconnect your trailer more carefully. ● Connecting Set the height control of electronically modulated air suspension system to “N”...
Page 205 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 206 4-1. Before driving ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before making turns. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 207 4-1. Before driving ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 208 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 209 4-1. Before driving ■ If trailer sway occurs One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely affect handling of your vehicle and trailer, causing instability. ● If trailer swaying occurs: • Firmly grip the steering wheel. Steer straight ahead. Do not try to control trailer swaying by turning the steering wheel.
Page 210 4-1. Before driving WARNING ■ Trailer towing precautions ● To tow a trailer safely, use extreme care and drive the vehicle in accor- dance with the trailer’s characteristics and operating conditions. Failure to do so could cause an accident resulting in death or serious injury. Vehicle stability and braking performance are affected by trailer stability, brake set- ting and performance, and the hitch.
Page 211 4-1. Before driving WARNING ● Do not apply the brakes suddenly as you may skid, resulting in jackknifing and loss of vehicle control. This is especially true on wet or slippery sur- faces. ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue weight capacities.
Page 212 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 213: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 214: 4-2. Driving Procedures
4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 215 4-2. Driving procedures Stopping the engine Stop the vehicle. Set the parking brake (P. 226), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that the display on the instru- ment cluster is off. Changing engine switch modes The emergency flashers can be used.
Page 216 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACC. Perform the following procedure to turn the switch off: Check that the parking brake is set.
Page 217 If the engine does not start ● The engine immobilizer system may not have been deactivated. (P. 82) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 218 4-2. Driving procedures WARNING ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 219 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 220: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in ON, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped. Shift position purpose Shift position Objective or function...
Page 221 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever can be oper- ated as follows: Upshifting Downshifting The initial shift range in S mode is set automatically to 5 or 4 accord- ing to vehicle speed.
Page 222 4-2. Driving procedures “TOW/HAUL” switch (with towing package) Use “TOW/HAUL” mode when pulling a trailer or hauling a heavy load. Press the “TOW/HAUL” switch. The indicator will come on. Press the switch once more to can- cel the mode. ■ S mode When the shift range is 3 or lower, holding the shift lever toward “+”...
Page 223 If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 224 If the “S” indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 225: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 226: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while depress- U.S.A. Canada ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Parking the vehicle engaged warning buzzer P.
Page 227: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: For U.S.A.  The headlights, daytime running lights (P. 229) and all the lights listed below turn on and off automatically.
Page 228 4-3. Operating the lights and wipers For Canada  The headlights, daytime running lights (P. 229) and all the lights listed above turn on and off automatically. (When the engine switch is in The side marker, park- ing, tail, license plate, instrument panel lights daytime running...
Page 229 4-3. Operating the lights and wipers ■ Daytime running light system ● The daytime running lights illuminate using the same lights as the parking lights and illuminate brighter than the parking lights. ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically when all of the following conditions are met.
Page 230 4-3. Operating the lights and wipers ■ Automatic light off system ● When the headlights come on: The headlights and tail lights automatically turn off after 30 seconds when all doors are closed with the engine switch turned to ACC or OFF. (The lights turn off immediately if the button on the wireless remote control is pressed after all doors are locked.) ●...
Page 231: Automatic High Beam
4-3. Operating the lights and wipers Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead, etc., and automatically turns the high beam on or off as necessary.
Page 232 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 233 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 21 mph (34 km/h). •...
Page 234 4-3. Operating the lights and wipers ● The high beam may be turned on or off when the driver does not expect it. ● Bicycles or similar objects may not be detected. ● In the situations shown below, the system may not be able to accurately detect surrounding brightness levels.
Page 235 Automatic High Beam (headlights) may turn on even the vehicle is stopped. ■ If “Headlight System Malfunction Visit Your Dealer” is displayed on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 236: Fog Light Switch
4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. For U.S.A.  Turns the front fog lights Turns the front fog lights SEQUOIA_OM_USA_OM0C021U_20MY...
Page 237 4-3. Operating the lights and wipers For Canada  Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The parking lights are on or the headlights are on in low beam. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 238: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows. Type A  Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent windshield wiper operation Low speed windshield wiper operation...
Page 239 4-3. Operating the lights and wipers Washer/wiper dual operation Pulling the lever operates the wip- ers and washer. Wipers will automatically operate a couple of times after the washer squirts. Type B  Wiper intervals can be adjusted for intermittent operation (when is selected).
Page 240 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 241: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Before operating the rear window wiper and washer switch, make sure the back window is completely closed. (P. 168) Operating instructions Operating the switch operates the rear wiper or washer as fol- lows: Type A ...
Page 242 4-3. Operating the lights and wipers Type B  Intermittent window wiper operation Normal window wiper operation Washer/wiper dual oper- ation Washer/wiper dual oper- ation The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operates one more time after a short delay to pre- vent dripping.)
Page 243 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 244: 4-4. Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Turn the engine switch to OFF and ensure that all the doors and windows are closed. ● Confirm the type of fuel. ■...
Page 245 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 246 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 247: Using The Driving Support Systems
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 248 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 249 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor WARNING ■ To avoid malfunction of the radar sensor Observe the following precautions.
Page 250 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 251 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 252 4-5. Using the driving support systems ■ Certification For vehicles sold in the U.S.A.  SEQUOIA_OM_USA_OM0C021U_20MY...
Page 253 4-5. Using the driving support systems For vehicles sold in the Canada  SEQUOIA_OM_USA_OM0C021U_20MY...
Page 254: (Pre-Collision System)
4-5. Using the driving support systems PCS (Pre-Collision System) The pre-collision system uses a radar sensor and camera sen- sor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal col- lision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 255 4-5. Using the driving support systems ◆ Pre-collision warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 256 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 257 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 258 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on the multi-information display as following: The system is automatically enabled each time the engine switch is turned to ON.
Page 259 4-5. Using the driving support systems Changing the pre-collision warning timing ■ The pre-collision warning timing can be changed on the multi-infor- mation display as following: The operation timing setting is retained when the engine switch is turned off. Press “” or “” of meter control switches and select Press “”...
Page 260 4-5. Using the driving support systems ■ Operational conditions The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high. Each function is operational at the following speeds: ●...
Page 261 4-5. Using the driving support systems ■ Pedestrian detection function The pre-collision system detects pedestri- ans based on the size, profile, and motion of a detected object. However, a pedes- trian may not be detected depending on the surrounding brightness motion, posture, angle...
Page 262 4-5. Using the driving support systems ■ Conditions under which the system may operate even if there is no pos- sibility of a collision ● In some situations such as the following, the system may determine that there is a possibility of a frontal collision and operate. •...
Page 263 4-5. Using the driving support systems • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge • When there is a metal object (manhole cover, steel plate, etc.), steps, or a protrusion on the road surface or roadside •...
Page 264 4-5. Using the driving support systems • When there are patterns or paint on the road or a wall that may be mis- taken for a vehicle or pedestrian • When driving near an object that reflects radio waves, such as a large truck or guardrail •...
Page 265 4-5. Using the driving support systems • When driving in inclement weather such as heavy rain, fog, snow or a sandstorm • When the vehicle is hit by water, snow, dust, etc., from a vehicle ahead • When driving through steam or smoke •...
Page 266 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 267 ● If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 268: Lda
4-5. Using the driving support systems LDA (Lane Departure Alert) Summary of functions When driving on roads with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visi- ble white (yellow) lines with the camera sensor on the upper por- tion of the windshield.
Page 269 4-5. Using the driving support systems ◆ Vehicle sway warning When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 270 4-5. Using the driving support systems WARNING ■ Before using LDA system Do not rely solely upon the LDA system. The LDA system does not auto- matically drive the vehicle or reduce the amount of attention that must be paid to the area in front of the vehicle. The driver must always assume full responsibility for driving safely by always paying careful attention to the sur- rounding conditions and operating the steering wheel to correct the path of the vehicle.
Page 271 Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. Turning LDA system on Press the LDA switch to turn the LDA system on.
Page 272 4-5. Using the driving support systems Indications on multi-information display LDA indicator The illumination condition of the indicator informs the driver of the system operation status. Illuminated in green: LDA system is operating. Flashing in yellow: Lane departure alert function is operating.
Page 273 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 274 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 275 4-5. Using the driving support systems ■ Warning message Warning messages are used to indicate a system malfunction or to inform the driver of the need for caution while driving. (P. 477) ■ Customization The following settings can be changed. Function Setting details Lane departure alert function...
Page 276: Dynamic Radar Cruise Control
4-5. Using the driving support systems Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 277 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 278 4-5. Using the driving support systems WARNING ● Assisting the driver to judge proper following distance The dynamic radar cruise control determines whether the following dis- tance between the driver’s own vehicle and a designated vehicle traveling ahead is within a set range. It is not capable of making any other type of judgement.
Page 279 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 328 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 280 4-5. Using the driving support systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance switch.
Page 281 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 282 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 283 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle mark vehicle-to-vehicle distance as fol- lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to If a vehicle is running ahead of you, the preceding vehicle mark...
Page 284 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 285 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 286 The operation cannot be switched for 5 seconds or more after operating the four-wheel drive control or the center differential lock switch. (4WD models) If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 287 (4WD models) If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 288 4-5. Using the driving support systems ● Vehicles with small rear ends (trailers with no load on board, etc.) ● Motorcycles traveling in the same lane ● When water or snow thrown up by the surrounding vehicles hinders the detecting of the sensor ●...
Page 289 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 290: Intuitive Parking Assist
4-5. Using the driving support systems Intuitive parking assist  The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display and a buzzer. Always check the surrounding area when using this system.
Page 291 4-5. Using the driving support systems Display When the sensors detect an obstacle, a graphic is shown on the multi- information display depending on the position and distance to the obstacle. Front corner sensor operation Rear corner sensor operation Rear center sensor operation The distance display and buzzer When a sensor detects an obstacle, the direction of and the approxi- mate distance to the obstacle are displayed and the buzzer sounds.
Page 292 4-5. Using the driving support systems Detection range of the sensors Approximately 2.0 ft. (60 cm) Approximately 2.8 ft. (85 cm) Approximately 5.9 ft. (180 cm) The diagram shows the detection range of the sensors. Note that the sensors cannot detect obstacles that are extremely close to the vehicle.
Page 293 • When an object is directly under a bumper • When objects become too close to the sensors • When a non-genuine Toyota suspension (lowered suspension, etc.) is installed In addition to the situations above, there are instances in which, because of their shape, signs and other objects may be judged by the sensor to be closer than they are.
Page 294 ■ If a message is displayed on the multi-information display P. 477 ■ Customization that can be configured at Toyota dealer Settings (e.g. buzzer volume) can be changed. (Customizable features P. 544) ■ Certification (Canada only) This ISM device complies with Canadian ICES-001.
Page 295 When using intuitive parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction, etc. Have the vehicle checked by your Toyota dealer. ● The intuitive parking assist operation display flashes, and a beep sounds when no obstacles are detected.
Page 296: (Blind Spot Monitor)
4-5. Using the driving support systems BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The BSM (Blind Spot Monitor) function Assists the driver in making the decision when changing lanes ●...
Page 297 4-5. Using the driving support systems Outside rear view mirror indicators BSM function: When a vehicle is detected in a blind spot of the outside rear view mirrors or approaching rapidly from behind into a blind spot, the outside rear view mirror indicator on the detected side will illuminate.
Page 298 4-5. Using the driving support systems Turning the BSM function/RCTA function on/off Press “” or “” of the meter control switches, select Press “” or “” of the meter control switches, select “BSM” or “RCTA”, and then press The function switches On/Off with each press.
Page 299 4-5. Using the driving support systems ■ Certification for the BSM For vehicles sold in the U.S.A.  FCC ID: HYQDNSRR002 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 300 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 301: Bsm Function
4-5. Using the driving support systems BSM function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 302 4-5. Using the driving support systems WARNING ■ Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. The Blind Spot Monitor function is a supplementary function which alerts the driver that a vehicle is present in the blind spot.
Page 303 4-5. Using the driving support systems ■ Conditions under which the BSM function may not function correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow, etc. •...
Page 304: Rcta Function
4-5. Using the driving support systems RCTA function The RCTA functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehicle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 305 4-5. Using the driving support systems RCTA function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 306 4-5. Using the driving support systems ■ Conditions under which the RCTA function will not detect a vehicle The RCTA function is not designed to detect the following types of vehicles and/or objects: ● Small motorcycles, bicycles, pedestrians, etc. ● Vehicles approaching from directly behind ●...
Page 307 4-5. Using the driving support systems • When backing up on a slope with a sharp change in grade • When backing out of a shallow angle parking spot • Immediately after the RCTA function is set to on • Immediately after the engine is started with the RCTA function is set to on •...
Page 308 4-5. Using the driving support systems ● Instances of the RCTA function unnecessarily detecting a vehicle and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
Page 309: Electronically Modulated Air Suspension
4-5. Using the driving support systems Electronically modulated air suspension  The electronically modulated air suspension allows the driver to control the vehicle’s height in order to adjust for driving condi- tions. Select the desired height with the height control switch. Height control switch Height control switch Height control mode select...
Page 310 4-5. Using the driving support systems Height modes ■ ● “N” mode (normal mode): For ordinary driving Normal height ● “HI” mode (high mode): For driving on bumpy roads 1.2 in. (30 mm) higher than the normal height The “HI” mode is unavailable when the vehicle’s speed exceeds 18 mph (30 km/h).
Page 311 Stop the engine and start again. If the warning message turns off, the system operating correctly. If the warning message continues to be displayed, have your vehicle inspected by your Toyota dealer as soon as possible. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 312 4-5. Using the driving support systems WARNING ■ The electronically modulated air suspension must be turned off in the following circumstances: Otherwise, the automatic leveling function may cause the vehicle’s height to change, and you may catch part of your body in the vehicle, resulting in an unexpected accident: ●...
Page 313 4-5. Using the driving support systems NOTICE ■ Be careful in any place where overhead space is limited. When changing to a higher mode or after unloading, the vehicle height will rise. This may cause damage to the vehicle. ■ Do not select “LO”...
Page 314: Avs (Adaptive Variable Suspension System)
4-5. Using the driving support systems AVS (Adaptive Variable Suspension System)  AVS controls the suspension according to the road and driving condi- tions. Selecting an optimum driving mode allows good vehicle posture and steering wheel operation. AVS switch Sport mode For winding mountain road driving or high speed driving.
Page 315: Four-Wheel Drive System
4-5. Using the driving support systems Four-wheel drive system Use the front-wheel drive control lever or switch to select the fol- lowing transfer modes: “2WD” (high speed position, two-wheel drive) Use this for normal driving on dry hard-surfaced roads. This position gives greater economy, quietest ride and least wear.
Page 316 4-5. Using the driving support systems Shifting between “2WD” and “4H” Shifting from “2WD” to “4H” ■ Reduce vehicle speed to less than 62 mph (100 km/h). Turn the front-wheel drive control switch to “4H”. The “4HI” indicator will turn on. Shifting from “4H”...
Page 317 4-5. Using the driving support systems ■ Shifting between “2WD” and “4H” ● When the ambient temperature is 5.0 °F (-15 °C) or lower, shifting from “2WD” to “4H” cannot be performed with the vehicle speed above 43 mph (70 km/h). ●...
Page 318 In this case, you may not be able to shift between “2WD” and “4H”, “4H” and “4L”, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. ■ Shifting to the “4L” position The VSC off indicator will come on.
Page 319 4-5. Using the driving support systems WARNING ■ Shifting the front-wheel drive control switch from “2WD” to “4H” while driving Never operate the front-wheel drive control switch if the wheels are slipping. Stop the slipping or spinning before shifting. ■ When the vehicle is parked If the shift lever is moved before the “4LO”...
Page 320: Auto Lsd System
4-5. Using the driving support systems AUTO LSD system The AUTO LSD system aids traction by using the traction con- trol system to control engine performance and braking when one of the drive wheels begins to spin. The system should be used only when one of the drive wheels spinning occurs in a ditch or rough surface.
Page 321 4-5. Using the driving support systems ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off. ■ Reactivation of the VSC system linked to vehicle speed When the AUTO LSD system is turned on, the VSC and TRAC systems will turn on automatically if vehicle speed increase.
Page 322: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 323 4-5. Using the driving support systems When the TRAC/VSC/Trailer Sway control systems are operating The slip indicator will flash while the TRAC/VSC/Trailer Sway Con- trol systems are operating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels.
Page 324 4-5. Using the driving support systems “4H” mode on 4WD models  To turn the TRAC system off, quickly press and release The “TRAC OFF” indicator light will come on. This mode can be used when the transfer mode is “4H” mode and the center differential is unlocked.
Page 325 When the “TRAC OFF” indicator light comes on even if switch has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Operating conditions of hill-start assist control When the following four conditions are met, the hill-start assist control will operate: ●...
Page 326 4-5. Using the driving support systems ■ Automatic reactivation of TRAC, Trailer Sway Control and VSC systems After turning the TRAC, Trailer Sway Control and VSC systems off, the sys- tems will be automatically re-enabled in the following situations: ● When the engine switch is turned off ●...
Page 327 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick road. ■...
Page 328 The ABS, TRAC, Trailer Sway Control and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 329: Driving Tips
4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle feature ●...
Page 330 4-6. Driving tips WARNING ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 331 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 332 4-6. Driving tips WARNING ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 333 4-6. Driving tips NOTICE ■ To prevent water damage ● Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 334: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 335 : The shift lever will be locked if it is attempted to be shifted from P to any other position without depressing the brake pedal. If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 336 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain 0.20 in. (5 mm) in diameter Cross chain 0.25 in. (6.3 mm) in diameter Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road.
Page 337 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 338 4-6. Driving tips SEQUOIA_OM_USA_OM0C021U_20MY...
Page 339 Interior features 5-1. Using the 5-4. Other interior features air conditioning system Other interior features ..375 and defogger • Sun visors ..... 375 Front air conditioning • Vanity mirrors....376 system......340 • Power outlets ....377 Rear air conditioning •...
Page 340: Using The Air Conditioning
5-1. Using the air conditioning system and defogger Front air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Adjusting the temperature setting ■ Turn the temperature control dial. (“SYNC” mode: P. 342) Increases the temperature Decreases the temperature SEQUOIA_OM_USA_OM0C021U_20MY...
Page 341 5-1. Using the air conditioning system and defogger Fan speed setting ■ Turn the fan speed control dial. Increases the fan speed Decreases the fan speed Press to turn the fan off. Change the airflow mode ■ Turn the air outlet selection dial. The air outlets switch each time either side of air outlet selection dial is turned.
Page 342 5-1. Using the air conditioning system and defogger Using automatic mode Press The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Adjust the temperature setting. To stop the operation, press Automatic mode indicator ■...
Page 343 5-1. Using the air conditioning system and defogger Defogging the windshield ■ Defoggers are used to defog the windshield and front side win- dows. Press The dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to the outside air mode if the recirculated air mode is used.
Page 344 5-1. Using the air conditioning system and defogger Changing the rear seat settings Adjusting the temperature setting ■ Press Press to increase the temperature and to decrease The air conditioning system switches between individual and simultane- ous modes each time is pressed.
Page 345 5-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 346 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Ventilation and air conditioning odors ●...
Page 347 5-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 348: Rear Air Conditioning System
5-1. Using the air conditioning system and defogger Rear air conditioning system Airflow and outlets are automatically adjusted according to the temperature setting. Change the fan speed setting ■ To change the fan speed, press Press to turn the fan off. Adjusting the temperature setting ■...
Page 349 5-1. Using the air conditioning system and defogger Change the airflow mode ■ To change the airflow mode, press the button. The indicator comes on. Air flows to the upper body. Air flows to the upper body and feet. Air flows to the feet. Using automatic mode Press The air conditioning system begins to operate.
Page 350 5-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected airflow mode. Adjusting the position of the roof side air outlets ■ Direct air flow to the left or right, up or down.
Page 351 5-1. Using the air conditioning system and defogger ■ Button lock function During the “SYNC” mode is on, the rear air conditioning system buttons will be automatically locked. (P. 342) appears on the display when the buttons are locked. To unlock the buttons, choose the “SYNC” mode is off. NOTICE ■...
Page 352: Seat Heaters/ Seat Ventilators
5-1. Using the air conditioning system and defogger Seat heaters  /seat ventilators  The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: •...
Page 353 5-1. Using the air conditioning system and defogger Seat heaters/ventilators Front seats ■ Vehicles without ventilator  The indicator light comes on. Adjusts the seat temperature The further you move the dial upward, the warmer the seat becomes. Move the dial fully downward. The indicator light turns off.
Page 354 5-1. Using the air conditioning system and defogger Rear seat (vehicles with rear console box) ■ High heating temperature The indicator (yellow) comes Press lightly on the opposite side to turn off. Low heating temperature The indicator (green) comes Press lightly on the opposite side to turn off.
Page 355: Using The Interior Lights
5-2. Using the interior lights Interior lights list Outer foot lights (if equipped) Interior light (P. 358) Personal/interior lights (P. 357) Engine switch light Footwell lights Door courtesy lights Auxiliary lighting SEQUOIA_OM_USA_OM0C021U_20MY...
Page 356: Personal/Interior Light Main Switch
5-2. Using the interior lights Personal/interior light main switch The personal/interior lights cannot be individually turned off. Door position The personal/interior lights come on when a door is opened. They turn off when the doors are closed. The personal/interior lights and interior light can be individually turned on or off.
Page 357: Personal/Interior Lights
5-2. Using the interior lights Personal/interior lights Front ■ Turns the lights on/off Center ■ Turns the lights on/off Type A Type B   Rear ■ Turns the lights on/off SEQUOIA_OM_USA_OM0C021U_20MY...
Page 358: Interior Light
5-2. Using the interior lights Interior light Door position on The interior light comes on when a back door is opened. It turns off when the door is closed. ■ Illuminated entry system The lights automatically turn on/off according to the engine switch mode, whether the doors are locked/unlocked, and whether the doors are open/ closed.
Page 359: Using The Storage Features
5-3. Using the storage features List of storage features Overhead console (P. 365) Rear console box (if equipped) (P. 363) Card holder (P. 362) Front console box (P. 361) Glove boxes (P. 360) • Card holder Auxiliary boxes (P. 370) •...
Page 360: Glove Boxes
5-3. Using the storage features WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: • Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 361: Front Console Box
5-3. Using the storage features Front console box Lift the lid while pulling up the knob to release the lock. ● When using the front console box lid as an armrest, pull the knob up and slide the lid forward as needed. When the lid is forward, it cannot be lifted.
Page 362: Card Holder
5-3. Using the storage features ● To remove the box, lift up. ● The following items can be stowed on the backside of the console box lid. Card holder Map holder Tissue holder Pen holder Card holder SEQUOIA_OM_USA_OM0C021U_20MY...
Page 363: Map Holder (Center Console)
5-3. Using the storage features Map holder (center console) Push the tab down to release the lock and remove the lid. Stow the lid. Rear console box (if equipped) Upper box Lower box   Push the knob and lift the lid. Push the knob and lift the lid.
Page 364 5-3. Using the storage features ● The separator can be used at either of two positions, change the separator position. ● The separator can be stowed, stow the separator to the lid. ● When using the back side tray, open the upper box ●...
Page 365: Overhead Console
5-3. Using the storage features WARNING ■ When opening/closing the lower box Be careful not to get your hands or feet caught between the lower box and the upper box. Failure to do so may result in serious injury. ■ When opening the lower box Make sure that the upper box is locked.
Page 366: Cup Holders
5-3. Using the storage features Cup holders Front Front console box   Pull the lid down. Rear  Rear console box (if equipped)  On the rear console box In the rear console box Attach the separator when using either console box as a cup holder. Both cup holders cannot be used at the same time.
Page 367 5-3. Using the storage features ■ Removing the cup holder (front) Remove and stow the lid. (P. 363) Pull the cup holder up. ■ Removing the separator (rear console box) In the rear console box  Pull the separator up. On the rear console box ...
Page 368 5-3. Using the storage features ■ The position of the separator can be changed (rear console box) In the rear console box  Change the separator position. On the rear console box  Change the separator position. ■ The separator can be adjusted (rear console box) Adjust the separator.
Page 369: Bottle Holders
5-3. Using the storage features Bottle holders Front seats Rear seats   ■ When using the bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. WARNING ■...
Page 370: Auxiliary Boxes
5-3. Using the storage features Auxiliary boxes Front Rear   Press the knob then pull the lid Pull the lid up. down. Rear console box (if equipped)  Pull the lever and open the box. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 371: Luggage Compartment Features
5-3. Using the storage features Luggage compartment features Cargo hooks The cargo hooks are provided for securing loose items. Cargo net hooks The cargo net itself is not included as original equipment. To hang the cargo net, use the cargo net hooks. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 372 5-3. Using the storage features Grocery bag hooks To hang shopping bags, use the grocery bag hooks. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 373 5-3. Using the storage features Storage compartment Type A  Pull the lever upwards to lift the deck board. Type B (if equipped)  Open the cover. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 374 5-3. Using the storage features WARNING ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. ■ Caution while driving Keep the auxiliary box closed. Injuries may result in the event of an accident or sudden braking.
Page 375: Other Interior Features
5-4. Other interior features Other interior features Sun visors Main visor ■ To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 376: Vanity Mirrors
5-4. Other interior features Vanity mirrors Vehicles without vanity light  Open the cover. Vehicles with vanity light  Open the cover. The light turns on when the cover is opened. Adjust the brightness of the light. NOTICE To prevent battery discharge, do not leave the vanity lights on for extended periods while the engine is not running.
Page 377: Power Outlets
5-4. Other interior features Power outlets 12 V DC ■ Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). When using electronic goods, make sure that the power consumption of all the connected power outlets is less than 120 W.
Page 378 5-4. Other interior features Front console box (inside)  Lift the lid while pulling up the knob to release the lock. Open the lid. 120 V AC (if equipped) ■ Accessories that use less than 100 W. Open the lid. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 379 5-4. Other interior features ■ The power outlets can be used when 12 V DC  The engine switch is in ACC or ON. 120 V AC  The engine switch is in ON. ■ When turning the engine switch off Disconnect electrical devices with charging functions, such as mobile battery packs.
Page 380: Usb Charging Ports
5-4. Other interior features USB charging ports The USB charging ports are used to supply 2.1 A of electricity at 5 V to external devices. The USB charging ports are for charging only. They are not designed for data transfer or other purposes. Depending on the external device, it may not charge properly.
Page 381 5-4. Other interior features NOTICE ■ To prevent damage to the USB charging ports ● Do not insert foreign objects into the ports. ● Do not spill water or other liquids into the ports. ● When the USB charging ports are not in use, close the lids. If a foreign object or liquid enters a port may cause a short circuit.
Page 382: Armrest (Second Seats)
5-4. Other interior features Armrest (second seats) Separated type  Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise armrest desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position.
Page 383: Rear Side Sunshades
5-4. Other interior features Rear side sunshades (if equipped) Rear door window Rear quarter window   Pull the tab up. Hook the sunshade onto the anchors. To lower the sunshade, pull the tab slightly to unhook the shade, and lower it slowly.
Page 384: Assist Grips
5-4. Other interior features Assist grips An assist grip (type A) installed on the ceiling can be used to support your body while sitting on the seat. An assist grip (type B) installed on the pillar can be used when getting in or out of the vehicle and others.
Page 385: Garage Door Opener
5-4. Other interior features Garage door opener  The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 386 5-4. Other interior features ® Programming the HomeLink ■ Steps through must be performed within 60 seconds, otherwise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 387 5-4. Other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● Indicator light illuminates: Programming of a fixed code device has completed. The garage door or other device should operate ®...
Page 388 5-4. Other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor operates when the ®...
Page 389 5-4. Other interior features ® Press a programmed HomeLink button to operate a garage door. ® Within 1 minute of pressing the HomeLink button, after the garage door operation has stopped, press the “Learn” or “Smart” button on the garage door opener motor. Within 5 seconds of the establishment of 2-way communication with the garage door opener, both garage door operation indicators in the vehicle will flash rapidly green and the light on the garage door opener motor...
Page 390 5-4. Other interior features Garage door operation indicators The status of the opening and closing of a garage door is shown by the indicators. Opening Closing This function is only available if the garage door opener motor used is a compatible device. (To check device compatibility, refer...
Page 391 5-4. Other interior features ® Erasing the entire HomeLink memory (all three codes) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit orange to rapidly flashing green. If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 392 ■ When support is necessary Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. WARNING ■ When programming a garage door or other remote control device The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm.
Page 393: Compass
5-4. Other interior features Compass  The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. Operation To turn the compass on or off, press the button for more than 3 sec- onds.
Page 394 5-4. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 395 5-4. Other interior features Circling calibration ■ Stop the vehicle in a place where it is safe to drive in a circle. Press and hold the button for 9 seconds. “C” appears on the compass display. Type A Type B ...
Page 396 5-4. Other interior features WARNING ■ While driving the vehicle Do not adjust the display. Be sure to adjust the display only when the vehi- cle is stopped. ■ When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.
Page 397 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..398 Cleaning and protecting the vehicle interior... 401 6-2. Maintenance Maintenance requirements ....404 General maintenance..406 Emission inspection and maintenance (I/M) programs......409 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 398: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 399 ■ Precaution regarding the Blind Spot Monitor If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 400 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels, etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 401: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 402 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 403 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 404: Maintenance Maintenance Requirements
■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 405 Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 406: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 407 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmis- • When parked on a slope and the shift lever is in P, sion “Park” mecha- is the vehicle securely stopped? nism •...
Page 408 6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? Engine hood • Does the engine hood lock system work properly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 409: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 410: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
• Rag or paper towel (P. 420) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology For the U.S.A.:...
Page 411 6-3. Do-it-yourself maintenance Items Parts and tools Fuses (P. 446) • Fuse with same amperage rating as original • Bulb with same number and wattage rating as origi- Light bulbs (P. 449) • Phillips-head screwdriver • Flathead screwdriver • Wrench ®...
Page 412 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 413: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. WARNING ■...
Page 414: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (P. 424) Fuse box (P. 446) Engine oil level dipstick Battery (P. 422) (P. 415) Radiator (P. 419) Engine coolant reservoir Cooling fans (P. 418) Condenser (P. 419) Engine oil filler cap (P. 416) Power steering fluid reservoir (P.
Page 415 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 416 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 417 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 418 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 419 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 420 6-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the reservoir. Adding fluid ■ Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
Page 421 6-3. Do-it-yourself maintenance Power steering fluid Fluid level ■ The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
Page 422 6-3. Do-it-yourself maintenance WARNING ■ When checking the reservoir Take care as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 423 6-3. Do-it-yourself maintenance WARNING ■ Chemicals in the battery Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
Page 424 6-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid Add washer fluid in the following situations: ● A washer does not work. ●...
Page 425: Tires
6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 426 Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. Do not fail to initialize the tire pressure warning system after tire rotation.
Page 427 6-3. Do-it-yourself maintenance ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■ lowing circumstances: ● When rotating the tires. ● When the tire inflation pressure is changed such as when chang- ing tire size.
Page 428 6-3. Do-it-yourself maintenance Drive straight (with occasional left and right turns) at approxi- mately 25 mph (40 km/h) or more for approximately 10 to 30 min- utes. Initialization is complete when the position of each tire is determined and the inflation pressure of each tire is displayed on the multi-infor- mation display.
Page 429 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ When replacing the tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 430 6-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 431 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 432 After performing initialization, the tire pressure warning light blinks for 1 minute then stays on while driving about 20 minutes. If the inflation pressure of each tire is still not displayed, have the vehicle inspected by your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 433 6-3. Do-it-yourself maintenance ■ Tire pressure warning system certification For vehicles sold in the U.S.A.  For vehicles sold in Canada  SEQUOIA_OM_USA_OM0C021U_20MY...
Page 434 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 435 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 436: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 527) SEQUOIA_OM_USA_OM0C021U_20MY...
Page 437 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 438 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 439: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 440 6-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 441 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 442: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch to OFF. Open the glove box. Remove the internal tray. Remove the inside cover by sliding up while pulling toward you.
Page 443 6-3. Do-it-yourself maintenance Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one. The “UP” marks shown on the fil- ter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 444: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the module.
Page 445 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 446: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch to OFF. Open the fuse box cover. Engine compartment ...
Page 447 Type A, B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer. Type A Type B  ...
Page 448 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 449) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 449: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 528) Bulb locations Rear ■...
Page 450 6-3. Do-it-yourself maintenance Replacing light bulbs Stop/tail, rear side marker lights and rear turn signal lights ■ Open the back door and remove the cover. To protect the cover, place a rag between the flathead screwdriver or equivalent and cover as shown in the illustrations. Right side Left side...
Page 451 6-3. Do-it-yourself maintenance Turn the bulb bases counter- clockwise. Stop/tail and rear side marker light Rear turn signal light Remove the light bulb. Stop/tail and rear side marker light Rear turn signal light When installing, reverse the steps listed. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 452 6-3. Do-it-yourself maintenance Tail lights, back-up lights ■ Vehicles with power back door only: Remove the cov- ers. To protect the cover, place a rag between the flathead screw- driver or equivalent and cover as shown in the illustrations. Remove the nuts. Remove the rear combina- tion light assembly in the order shown in the illustra-...
Page 453 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Tail light Back-up light Remove the light bulb. Tail light Back-up light When installing, reverse the steps listed. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 454 6-3. Do-it-yourself maintenance License plate lights ■ Remove the screws and lens. Remove the light bulb. When installing, reverse the steps listed. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 455 ● Outer foot lights (if equipped) ■ LED light bulbs The following lights consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ● Headlight low beams ●...
Page 456 6-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 457: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..458 If your vehicle has to be stopped in an emergency ...... 459 If the vehicle is trapped in rising water....461 7-2. Steps to take in an emergency If your vehicle needs to be towed ......
Page 458: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 459: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 460 7-1. Essential information WARNING ■ If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 461: If The Vehicle Is Trapped In Rising Water
However, an emergency hammer can not shatter the windshield as it is lam- inated glass. : Contact your Toyota dealer or aftermarket accessory manufacturer for further information about an emergency hammer. ■ Escaping the vehicle from the window There are cases where escaping the vehicle from the window is not possi- ble due to seating position, passenger body type, etc.
Page 462: 7-2. Steps To Take In An Emergency
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 463 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Use a towing dolly under the rear Use a towing dolly under the wheels. front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the...
Page 464 7-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 50 miles (80 km) at under 18 mph (30 km/h).
Page 465 7-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle 2WD models: Be sure to transport the vehicle with all four wheels raised off the ground.
Page 466 7-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck ● Do not tow the vehicle from the rear when the engine switch is in OFF or the key is removed. The steering lock mechanism is not strong enough to hold the front wheels straight.
Page 467: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 468: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 469: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The emission control system; • The electronic engine control system; (U.S.A.) • The electronic throttle control system; or • The electronic automatic transmission control sys-  Have the vehicle inspected by your Toyota dealer (Canada) immediately. SRS warning light Indicates a malfunction in: •...
Page 470 ABS warning light Indicates a malfunction in: • The ABS; or (U.S.A.) • The brake assist system  Have the vehicle inspected by your Toyota dealer immediately. (Canada) Power steering warning light Indicates a malfunction in the power steering system ...
Page 471 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system (P. 473)  Have the system checked by your Toyota dealer. Master warning light A buzzer sounds and warning light comes on and flashes to indicate that the master warning system has detected a malfunction.
Page 472 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 473 1 minute If the tire pressure warning light frequently comes on after blinking for 1 minute when the engine switch is turned to ON, have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 474 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 475 7-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 476 7-2. Steps to take in an emergency NOTICE ■ Precaution when installing a different tire When differently constructed tires or tires of different makers, models or tread patterns are installed, the tire pressure warning system may not operate properly. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 477: If A Warning Message Is Displayed
Multi-information display If any of the warning message or indicator comes on again after the following actions have been performed, contact your Toyota dealer. Warning message and warning buzzer list Warning message Details/Actions Indicates that: •...
Page 478 SRS Airbag System Indicates a malfunction in the SRS airbag system Malfunction A buzzer also sounds. Visit Your Dealer  Have the vehicle inspected by your Toyota dealer immediately. Indicates a malfunction in the automatic transmis- CHECK sion system TRANSMISSION SYSTEM A buzzer also sounds.
Page 479 Indicates a malfunction in the BSM (Blind Spot Malfunction Monitor) A buzzer also sounds. Visit Your Dealer  Have the vehicle inspected by your Toyota dealer immediately. Rear Cross Traffic Alert Indicates a malfunction in the RCTA (Rear Cross Malfunction Traffic Alert) A buzzer also sounds.
Page 480 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the RCTA (Rear Cross Traffic Alert) Rear Cross Traffic Alert sensors or the surrounding area on the bumper is dirty or covered with ice Unavailable A buzzer also sounds. ...
Page 481 • The brake fluid level is low; or • The brake system is malfunctioning.  Immediately stop the vehicle in a safe place and contact your Toyota dealer. Indicates remaining fuel is approximately 4.0 gal. Fuel Low (15.0 L, 3.3 Imp.gal.) or less A buzzer also sounds.
Page 482 Pre-Collision System Indicates a malfunction in the PCS (Pre-Collision Malfunction System). Visit Your Dealer A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. Indicates a malfunction in the LDA (Lane Depar- Malfunction ture Alert). Visit Your Dealer A buzzer also sounds.
Page 483 7-2. Steps to take in an emergency Warning message Details/Actions Indicates that the dynamic radar cruise control Radar Cruise system cannot be used temporarily due to bad Control weather Unavailable A buzzer also sounds.  Use the dynamic radar cruise control sys- tem when it becomes available again.
Page 484 Pre-Collision System  Please wait until the system returns. If the Unavailable message does not disappear, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immedi- ately. Pre-Collision System Unavailable Indicates that the pre-collision system sensor is dirty, covered with ice, etc.
Page 485 7-2. Steps to take in an emergency Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning message and light go off. Interior Exterior Warning message Details/Actions buzzer buzzer The driver’s door was opened Shift into P Position when the shift lever was not in Contin-...
Page 486 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer An attempt was made to exit Turn Power OFF the vehicle with the electronic key and lock the doors without first turning the engine switch Contin- Once off when the shift lever was in uous...
Page 487 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The steering lock could not be released within 3 seconds of engine switch being Steering Lock pressed. Once  Press the engine switch  while depressing brake pedal and moving (Flashes) the steering wheel left...
Page 488 7-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer After the engine switch has been turned off with the shift Turn Power OFF lever in a position other than Once P, the shift lever has been ...
Page 489: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 425 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 490 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Spare tire Jack Tool bag SEQUOIA_OM_USA_OM0C021U_20MY...
Page 491 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 492 7-2. Steps to take in an emergency Taking out the jack and tool bag Pull the deck board up. Remove the cover and loosen the strap. Remove the tools . Take out the jack. For tightening For loosening SEQUOIA_OM_USA_OM0C021U_20MY...
Page 493 7-2. Steps to take in an emergency Taking out the spare tire Assemble jack handle extension as shown. Remove the cover. Insert the end of the jack han- dle extension into the lowering screw and turn it counterclock- wise. Lower the spare tire completely to the ground.
Page 494 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 495 7-2. Steps to take in an emergency Position the jack at the jack points as shown. Front Rear Make sure the jack is positioned on a level and solid place. Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 496 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 497 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 498 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque 154 ft·lbf (209 N·m, 21.3 kgf·m) : When used on aluminum wheel, apply 97 ft·lbf (131 N·m, 13.4 kgf·m) WARNING ■...
Page 499 7-2. Steps to take in an emergency Stowing the flat/spare tire, jack and tools Remove the center wheel ornament by pushing from the reverse side. Lay down the tire with the valve stem facing up and install the holding bracket, inserting the claw into the wheel lug nut hole.
Page 500 7-2. Steps to take in an emergency Confirm that the tire is not loose after tightening: Push and pull the tire Try rotating Visually check to ensure the tire is not hung on surrounding parts. If looseness or misassembly exists, repeat step and step Repeat step any time the tire is lowered or disturbed.
Page 501 7-2. Steps to take in an emergency WARNING ■ When using the temporary spare tire ● Remember that your temporary spare tire is specifically designed for use with your vehicle. Do not use your temporary spare tire on another vehicle. ●...
Page 502 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 503: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 214), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
Page 504 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 507) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. ● There may be a malfunction in the steering lock system Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 505: If The Electronic Key Does Not Operate Properly
Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 506 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 507: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 508 ON. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 509 7-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. ●...
Page 510 7-2. Steps to take in an emergency WARNING ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 511: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir. Reservoir “FULL” line “LOW”...
Page 512 Start the engine to check that the radiator cooling fan operate and to check for coolant leaks from the radiator or hoses. If the fan are not operating: Stop the engine immediately and contact your Toyota dealer. If the fan are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 513 7-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■...
Page 514: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the stuck tire.
Page 515 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 516 7-2. Steps to take in an emergency SEQUOIA_OM_USA_OM0C021U_20MY...
Page 517 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..518 Fuel information ....529 Tire information ....532 8-2. Customization Customizable features ..544 8-3. Items to initialize Items to initialize ....555 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 518: Specifications Maintenance Data
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 205.1 in. (5210 mm) Overall width 79.9 in. (2030 mm) 77.0 in. (1955 mm) Overall height Wheelbase 122.0 in. (3100 mm) Front 67.9 in. (1725 mm) Tread Rear 69.1 in. (1755 mm) : Unladen vehicle SEQUOIA_OM_USA_OM0C021U_20MY...
Page 519 8-1. Specifications Weight Vehicle capac- Driving ity weight Model code Engine (Trailer weight system (Occupants + cargo) +luggage) USK60L- 1320 lb. 7400 lb. GKTSKA (600 kg) (3357 kg) USK60L- 1305 lb. GKTLKA (590 kg) 7200 lb. (3266 kg) USK60L- 1320 lb. 5.7 L V8 GKTZKA (600 kg)
Page 520 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 521 8-1. Specifications Engine Model 3UR-FE Type 8-cylinder V-type, 4-cycle, gasoline Bore and stroke 3.70  4.02 in. (94.0  102.0 mm) Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research Octane Number 91) or...
Page 522 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 523 8-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 524 Capacity Vehicles with towing package  14.1 qt. (13.3 L, 11.7 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol- based non-silicate, non-amine, non- Coolant type nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 525 Oil type and viscosity LT 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of matching quality to satisfy the above specification.
Page 526 8-1. Specifications Brakes 4.1 in. (104 mm) Min. Pedal clearance Pedal free play 0.04  0.24 in. (1  6 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Parking brake pedal travel 6 ...
Page 527 8-1. Specifications Tires and wheels Type A  P275/65R18 114T, Tire size P255/70R18 112T (spare tire) Front tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 33 psi (230 kPa, 2.3 kgf/cm or bar) inflation pressure) Spare tire:...
Page 528 8-1. Specifications Light bulbs Light Bulbs Bulb No. Type Stop/tail rear side 7443 21/5 marker lights Rear turn signal lights — Tail lights Exterior Back-up lights License plate lights Outer foot light (if equipped) — Vanity lights (if equipped) 7065 Personal/interior lights Front —...
Page 529: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 530 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 531 8-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 532: Tire Information
8-1. Specifications Tire information Typical tire symbols Tire size (P. 534) DOT and Tire Identification Number (TIN) (P. 533) Location of treadwear indicators (P. 425) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 533 8-1. Specifications Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire. Summer tires or all season tires (P. 430) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire.
Page 534 8-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 535 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer SEQUOIA_OM_USA_OM0C021U_20MY...
Page 536 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 537 8-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 538 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 539 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 540 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 541 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 542 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 543 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 544: 8-2. Customization
Your vehicle includes a variety of electronic features that can be personalized to your preferences. Programming these prefer- ences requires specialized equipment and may be performed by your Toyota dealer. Customizing vehicle features Changing by using the multimedia system ■...
Page 545 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using the multi-information display. Settings that can be changed using the multimedia system.
Page 546 8-2. Customization Gauges, meters and multi-information display (P. 94, 98) ■ Customized Function Default setting setting French Language English Spanish miles (MPG Imperial) miles Units (MPG USA) km (km/L) km (L/100 km) Drive Desired status — Switch settings information 1 screen Average Fuel Economy...
Page 547 8-2. Customization LDA (Lane Departure Alert) (P. 268) ■ Customized Function Default setting setting — LDA sensitivity 1 (Standard) 2 (High) — Sway warning 1 (Low) — Sway Warning sensitivity 2 (Standard) 3 (High) PCS (Pre-Collision System) (P. 254) ■ Customized Function Default setting...
Page 548 8-2. Customization BSM (Blind Spot Monitor) (P. 296) ■ Customized Function Default setting setting — — BSM brightness Standard RCTA — (Rear Cross Traffic Alert) — RCTA volume Door lock (P. 113) ■ Customized Function Default setting setting Driver’s door unlocked in one All doors —...
Page 549 8-2. Customization Smart key system and wireless remote control (P. 113) ■ Customized Function Default setting setting Operation signal — (Emergency flashers) Operation signal — — (Buzzer) Operation buzzer volume Level 5 Off to level 7 Time elapsed before auto- matic door lock function is 30 seconds activated if door is not...
Page 550 8-2. Customization Wireless remote control (P. 113, 118) ■ Customized Function Default setting setting — — Wireless remote control Driver’s door unlocked in one All doors — Unlocking operation step, all doors unlocked in unlocked in two one step steps Time elapsed before auto- matic door lock function is —...
Page 551 8-2. Customization Power back door (P. 118) ■ Customized Function Default setting setting One short — — Switch operation Push and hold push Wireless remote control — — linked operation — — Operation signal volume Operation when door — — Possible Impossible locks...
Page 552 8-2. Customization Moon roof (P. 171) ■ Customized Function Default setting setting Open only — — Door key linked operation Open and close Close only Linked operation of com- — — ponents when door key is Slide only Tilt only used Automatic light off system (P.
Page 553 8-2. Customization Illumination (P. 355) ■ Customized Function Default setting setting Time elapsed before lights — 15 seconds 7.5 seconds turn off 30 seconds Operation after the engine — — is off Operation when the doors — — are unlocked Time elapsed before the —...
Page 554 8-2. Customization ■ In the following situations, customize mode in which the settings can be changed through the multi-information display will automatically be turned off ● A warning message appears after the customize mode screen is displayed. ● The engine switch is turned off. ●...
Page 555: Items To Initialize
8-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Power window When functioning abnormally P.
Page 556 8-3. Items to initialize SEQUOIA_OM_USA_OM0C021U_20MY...
Page 557: For Owners
For owners Reporting safety defects for U.S. owners......558 Seat belt instructions for Canadian owners (in French) ....... 559 SRS airbag instructions for Canadian owners (in French) ....... 561 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 558: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 559: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 560 AVERTISSEMENT ■ État et usure des ceintures de sécurité Inspectez les ceintures de sécurité périodiquement. Contrôlez qu’elles ne sont pas entaillées, effilochées, et que leurs ancrages ne sont pas desserrés. Ne pas utiliser une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée. Une ceinture de sécurité défectueuse n’apporte aucune garantie de protection de l’occupant contre des blessures graves, voire mortelles.
Page 561: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 562 Coussins gonflables SRS rideau ● Participent principalement à la protection de la tête des occupants assis dans les sièges des places extérieures ● Participent à empêcher les occupants d’être éjectés du véhicule en cas de retournement de celui-ci Composition du système de coussins gonflables SRS Coussins gonflables Système de classification...
Page 563 Votre véhicule équipé COUSSINS GONFLABLES INTELLIGENTS (ADVANCED AIRBAGS) conçus selon les normes de sécurité américaines applicables véhicules à moteur (FMVSS208). Le boîtier électronique de coussins gonflables (ECU) utilise les informations reçues des capteurs, etc. détaillés dans le schéma ci-dessus de composition du système pour commander le déploiement des coussins gonflables.
Page 564 Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que tous les nourrissons et enfants soient installés dans les sièges arrière du véhicule et convenablement attachés.
Page 565 AVERTISSEMENT ■ Précautions avec les coussins gonflables SRS ● Ne pas laisser un enfant rester debout devant coussin gonflable passager avant ni assis sur les genoux du passager avant. ● Ne pas laisser les occupants des sièges avant voyager avec un objet sur les genoux.
Page 566 Si les parties renfermant les coussins gonflables SRS, telles que la garniture centrale du volant de direction et les garnitures de montants avant et arrière, apparaissent abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota. ● Ne rien poser sur le siège du passager avant, comme un coussin par exemple.
Page 567 SRS Ne mettez pas à la casse votre véhicule et ne lui apportez aucune des modifications suivantes sans consulter votre concessionnaire Toyota. Les coussins gonflables SRS peuvent ne pas fonctionner correctement ou se déployer (se gonfler) accidentellement, provoquant ainsi des blessures graves, voire mortelles.
Page 568 SEQUOIA_OM_USA_OM0C021U_20MY...
Page 569: What To Do If
Index What to do if... (Troubleshooting) ....570 Alphabetical index ..... 574 For details of equipment related to the audio/navigation system, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”. SEQUOIA_OM_USA_OM0C021U_20MY...
Page 570 Toyota dealer. (P. 109) ● If you lose your keys or electronic keys, the risk of vehicle theft increases significantly. Contact your Toyota dealer immediately. (P. 112) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (P. 444) ●...
Page 571 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the brake pedal? (P. 214) ● Is the shift lever in P? (P. 216) ●...
Page 572 What to do if... (Troubleshooting) The engine switch is turned off automatically ● The auto power off function will be operated if the vehicle is left in ACC or ON (the engine is not running) for a period of time. (P. 216) A warning buzzer sounds during driving ●...
Page 573 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 489) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 574: Alphabetical Index
Alphabetical index Alphabetical index Alarm A/C ........340, 348 Alarm ........84 Air conditioning filter ..... 442 Warning buzzer ....469 Front air conditioning Anchor brackets ......62 system ........ 340 Anti-lock Brake System Rear air conditioning (ABS) ........322 system ........
Page 575 Alphabetical index Back door Care ........398, 401 Back door......118 Aluminum wheels ....399 Back window......168 Exterior ......... 398 Wireless remote control ..119 Interior ........401 Back window......168 Seat belts......402 Back-up lights Cargo capacity......193 Replacing light bulbs.....
Page 576 Alphabetical index Child safety ........ 57 Airbag precautions....42 Daytime running light Back door precautions ..122 system........229 Battery precautions..423, 510 Defogger Child restraint system ..... 58 Outside rear view mirrors ..343 How your child should Rear window......343 wear the seat belt ....
Page 577 Alphabetical index Engine EDR (Event data recorder)..11 Compartment......414 Electronically modulated Engine switch ....... 214 air suspension....... 309 Hood ........413 Emergency flashers ....458 How to start the engine..214 Emergency, in case of Identification number .... 520 If a warning buzzer If the engine will not start..
Page 578 Alphabetical index Front side marker lights ..227 Flat tire........489 Light switch......227 Floor mats ........26 Replacing light bulbs .... 455 Fluid Front turn signal lights ... 225 Automatic transmission..525 Replacing light bulbs .... 455 Brake ........526 Turn signal lever ....
Page 579 Alphabetical index Hands-free system I/M test ........409 (for cellular phone) Identification Head restraints ......154 Engine ........520 Headlights ........ 227 Vehicle........520 Automatic High Beam Ignition switch system ........ 231 (engine switch)...... 214 Light switch ......227 Illuminated entry system ..358 Replacing light bulbs.....
Page 580 Alphabetical index Jack Lane Departure Alert (LDA) ..268 Vehicle-equipped jack... 490 Language ......... 100 Jack handle ......493 LATCH anchors ......64 Jam protection function LDA (Lane Departure Alert) ..268 Moon roof......172 Lever Power back door....121 Auxiliary catch lever....
Page 581 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 410 Noise from under vehicle ... 8 General maintenance ... 406 Maintenance data ....518 Maintenance requirements ... 404 Odometer ........94 Reset the maintenance Off-road precautions....329 data ........405 Malfunction indicator lamp..469 Differential oil......
Page 582 Alphabetical index Parking brake......226 Radiator........419 Operation ......226 Radio Parking brake engaged RCTA (Rear Cross Traffic warning buzzer/ Alert)........296 message......480 Rear air conditioning Parking lights......227 system........348 Light switch ......227 Rear console box ....363 Replacing light bulbs.....
Page 583 Alphabetical index Seats......... 136, 138 Safety Connect ......76 Adjustment....136, 138 Seat belt reminder light... 471 Adjustment Seat belts........30 precautions....137, 147 Adjusting the seat belt .... 33 Child seats/child restraint Automatic Locking system installation....62 Retractor (ALR) ....34 Cleaning .......
Page 584 Alphabetical index Shift lever ......... 220 Stop lights Automatic transmission..220 Replacing light bulbs .... 450 If the shift lever Wattage ........ 528 cannot be shifted from P ..223 Storage feature ......359 Shift lock system ..... 222 Storage precautions....190 Side airbags .......
Page 585 Alphabetical index Interior light main switch ..356 Vehicle-to-vehicle distance Intuitive parking assist ..290 button ......... 276 Ignition switch ....... 214 VSC off switch ...... 323 LDA (Lane Departure Window lock switch ....165 Alert)........268 Windshield wipers Light switches ....... 227 and washer switch....
Page 586 (VSC) ........322 Emergency towing ....464 Ventilators Trailer towing ......194 (seat ventilators) ....352 Toyota Safety Sense P .... 247 Automatic High Beam ... 231 (Vehicle Stability Control) ..322 Dynamic radar cruise control......... 276 LDA (Lane Departure Alert)........
Page 587 Alphabetical index Warning messages....477 Warning buzzers Washer ......238, 241 Brake system ......469 Checking....... 424 BSM (Blind Spot Monitor) ..296 Preparing and checking Downshifting ......224 before winter ...... 334 Intuitive parking assist ..290 Switch ......238, 241 Key reminder ......
Page 588 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 413 P. 246 Tire inflation Hood lock release lever pressure P. 527 P. 413 Fuel tank capacity 26.4 gal. (100.0 L, 22.0 Imp.gal.) (Reference) Fuel type P. 521, 529 Cold tire inflation P.

Toyota SEQUOIA 2020 Manual

Quick Links

Related Manuals for Toyota SEQUOIA 2020

Summary of Contents for Toyota SEQUOIA 2020

Table of Contents
