Icom IC-M85 Instruction Manual page 29

IC-M85E (European, UK, German, Australian):
D General
• Frequency coverage:
Marine TX
RX
TX (Australian) 156.025 ~ 157.425 MHz
RX (Australian) 156.300 ~ 162.025 MHz
PMR 136.000 ~ 174.000 MHz
• Mode:
Marine 16K0G3E
PMR 16K0F3E (Wide)/8K50F3E (Narrow)
PMR (German) 14K0F3E (Wide)/8K50F3E (Narrow)
• Channel spacing:
Marine ±25 kHz
PMR ±25 kHz (Wide), ±12.5 kHz (Narrow)
PMR (German) ±20 kHz (Wide), ±12.5 kHz (Narrow)
• Current drain (at 7.2 V DC): TX High (5 W) 1.5 A typical
Maximum audio 450 mA typical
• Frequency stability:
European/UK/German ±1.5 kHz
Australian ±5.0 ppm (Marine), ±1.5 kHz (PMR)
• Operating temperature range:
Marine –15˚C ~ +55˚C
PMR –25˚C ~ +55˚C
Marine (Australian) –10˚C ~ +55˚C
PMR (Australian) –10˚C ~ +50˚C
• Dimensions (projections not included):
56 (W) × 92 (H) × 29 (D) mm
• Weight (approximately): 215 g with BP-290
• Antenna impedance: 50 ˘ nominal
D Transmitter
• Output power:
• Modulation system :
• Maximum frequency deviation:
156.000 ~ 161.450 MHz
156.000 ~ 163.425 MHz
• Audio harmonic distortion:
• Spurious emissions:
D Receiver
• Receive system:
• Sensitivity (at 20 dB SINAD): –4 dBμ EMF (Wide, Typical)
• Squelch sensitivity (Threshold): –6 dBμ EMF (typical)
• Intermodulation rejection ratio:
• Sprious response rejection ratio:
• Adjacent channel selectivity:
• Ham and Noise ratio:
• Audio output power:
SPECIFICATIONS AND OPTIONS
5 W (Hi), 3 W (Mid), and 1 W (Low)
Variable reactance frequency modulation
Marine ±5 kHz
PMR ±5 kHz (Wide), ±2.5 kHz (Narrow)
PMR (German) ±4 kHz (Wide), ±2.5 kHz (Narrow)
Less than 10% (at 60% deviation)
European/UK/German 0.25 μW (below 2 GHz)
1 μW (above 2 GHz)
Australian Less than –70 dBc typical
Double conversion superheterodyne
–2 dBμ EMF
(Narrow, Typical, PMR only)
European/UK/German 68 dB (Marine), 65 dB (PMR)
Australian 65 dB
European/UK/German 70 dB
Australian 65 dB (Marine), 70 dB (PMR)
European/UK/German 70 dB, 60 dB (Narrow, PMR only)
Australian (Marine) 65 dB
Australian (PMR) 70 dB (Wide), 60 dB (Narrow)
40 dB
34 dB (Narrow, PMR only)
0.7 W typical at 10% distortion into a
12 ˘ load (at 1 kHz)
