System Setup

1
VolumeView sensor
2
VolumeView femoral arterial catheter
3
VolumeView thermistor manifold
4
PreSep oximetry catheter
TruWave pressure transducer
5
Oximetry cable
6
VolumeView Set
EV1000 Clinical Platform
Setup Guide
6
3
5
1
4
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Edwards EV1000

  • Page 1 VolumeView Set EV1000 Clinical Platform Setup Guide System Setup VolumeView sensor VolumeView femoral arterial catheter VolumeView thermistor manifold PreSep oximetry catheter TruWave pressure transducer Oximetry cable...
  • Page 2 EV1000 Clinical Platform Startup with the VolumeView Set Before startup, please ensure monitor, cables and patient cables are all connected. 1. Turn on monitor and databox. System self-test starts. 2. Enter new patient data OR continue with existing patient. 3. Set up and prime VolumeView sensor and TruWave CVP transducer and connect to databox.
  • Page 3 6. Connect the databox thermistor cable to the VolumeView femoral arterial thermistor and confirm appropriate temperature on the EV1000 monitor. 7. Prime the VolumeView set manifold, removing all air. Connect the TruWave central venous pressure transducer to the VolumeView manifold and then...
  • Page 4 Article 3 of the Medical Device Directive 93/42/EEC bear the CE marking of conformity. Edwards, Edwards Lifesciences, the stylized E logo, EV1000, PreSep, TruWave, and VolumeView are trademarks of Edwards Lifesciences Corporation. © 2012 Edwards Lifesciences Corporation.
