III.STRUCTURE AND PERFORMANCE
3.2 Product characteristics of the electric wheelchair
Classification according to prevent electric shock type : internal power
supply
Classification according to prevent electric shock level : type B applied
part Wheelchairs are non-AP or APG-type device.
Classification according to the operation pattern classification: run
continuously.
The power of the equipment : internal power DC 24V
3.3 ELECTRICAL DIAGRAM OF MODEL 5513
CONNECTORS FOR RIGHT MOTOR
JOYSTICK
CONTROLLER
CONNECTORS FOR BATTERY
CONNECTORS FOR LEFT MOTOR
6
RIGHT MOTOR
RIGHT BRAKE
24V LITHIUM BATTERY
LEFT BRAKE
LEFT MOTOR
