Eneo IER-25R040004A User Manual

Netzwerk video rekorder, h.264, ohne hdd, hdmi, poe
Hide thumbs Also See for IER-25R040004A:
Table of Contents

Advertisement

Quick Links

Download this manual
EN

User Manual

Netzwerk Video Rekorder, H.264,
ohne HDD, HDMI, PoE
IER-25R040004A
IER-25N080004A
IER-25N160004A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IER-25R040004A and is the answer not in the manual?

Questions and answers

Related Manuals for Eneo IER-25R040004A

Summary of Contents for Eneo IER-25R040004A

  • Page 1: User Manual

    User Manual Netzwerk Video Rekorder, H.264, ohne HDD, HDMI, PoE IER-25R040004A IER-25N080004A IER-25N160004A...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EX- POSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 3 FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful inter ference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 5 Table of Contents Table of Contents ..........................1 Overview Package Contents ........................4 NVR Description ......................... 4 Installation Installing HDD ........................... 7 Starting System ......................... 7 Quick Setup ..........................8 2.3.1 Account........................8 2.3.2 System ......................... 8 2.3.3 Network ........................9 2.3.4 Time/Date ........................
  • Page 6 4.3.1 Basic .......................... 35 4.3.2 Advanced ........................38 DEVICE ........................... 39 4.4.1 Display ........................39 4.4.2 Disk > Setup ......................43 4.4.3 PTZ > PTZ ......................... 46 4.4.4 Serial Device > Serial Device ..................47 4.4.5 Text > Text ......................... 48 RECORD ..........................

  • Page 7: 1. Overview

    Overview This chapter describes NVR overview, components and their terms and features. This manual introduces a network video recorder (NVR) which monitors or record, controls images via a network camera. Multiple users may monitor video at the same time, and many cameras can be controlled simultaneously by a manager.

  • Page 8: Package Contents

    Package Contents The device package contents consist of the following: Note Please check all components involved. Table 1-1 Package contents Name 번호 Name SATA cable DC adapter & Power cord SATA power cable Mouse HDD fixing screw Quick guide Program CD NVR Description Each part is listed in the below: Figure 1-1 Name and Connection of each front section...
  • Page 9 4ch NVR 8ch NVR 16ch NVR Figure 1-2 Name and Connection of rear section of 4ch, 8ch and 16ch NVR Table 1-3 Name and Function of rear section of 4ch, 8ch and 16ch NVR Name Function IP CAM / PoE IP camera input port, IEEE802.3af PoE support Network connector Network...

  • Page 10: 2. Installation

    Installation This chapter describes the way to install NVR. When installing a device, connect rear of the device with each port on the basis of below connection map. Figure 2-1 Connection map The device starts first like below sequences: 1 Installing HDD 2 Connecting with an exterior device 3 Starting a system 4 Setting an quick setup...

  • Page 11: Installing Hdd

    Installing HDD How to install HDD in the device:  Withdraw the mains plug before installing HDD to reduce the risk of injury or electrical shock, or device malfunction. Attention  Make sure to check the compatibility of HDD with the device. 1 Always switch off and unplug the unit.

  • Page 12: Quick Setup

    Quick Setup 2.3.1 Account 1 Click the keyboard icon to set ID and Password users want.  Default ID/Password is admin/admin. Note  Change the password for security.  Max character length is 16. 2.3.2 System 1 Set each item in System setting screen. Language: Select system language.

  • Page 13: Network

    2.3.3 Network How to set the network of Easy Installation: 1 Set each item in Network setting screen. WAN Port: Select whether to use static IP or dynamic IP.  IP Address, Subnet Mask, Gateway, DNS, and Port: As for dynamic IP, enter information in each ...

  • Page 14: Easy Installation Wizard

    2.3.5 Easy Installation Wizard 1 Select to run Easy Installation every time when the system start. 2 Press Save button to save set value and end Easy Installation. IER-25Nxxx Seite 10...

  • Page 15: 3. Live Screen Configuration

    Live Screen Configuration UI screen is configured like below figure. Figure 3-1 UI Screen Configuration Table 3-1 Items and Description of UI Screen Configuration Item Description Setup menu Setting menu is located in the corner of upper screen. See “4 Setup” to display detailed information about the setting menu.

  • Page 16: Icons In Live Screen

    Icons in Live screen Each icon in the live screen displays a present setting status or a function. UI screen consists of like below. Chosen live screen is marked as a blue frame; mouse-located live screen is marked Note as yellow one. Figure 3-2 Live screen icon Table 3-2 Live screen icon and its description Icon...

  • Page 17: Live Launcher Menu

    Live Launcher menu This chapter describes Launcher menu in the bottom of the screen. Figure 3-3 Launcher menu Table 3-3 Launcher menu Item and Description Item Description Log in/out status and logged in ID. Date & Time Displaying present date and time. Displaying HDD capacity in use.

  • Page 18: Backup

    3.2.1 Backup The device provides a back-up function of live screen. Figure 3-4 Backup Table 3-4 Backup Item and Description Item Description Select CH Selecting a channel users want to back-up. Select All/ Select or clear all channels. Unselect All Start Setting back-up start time (Bookmark: bookmark list).

  • Page 19: Quick Menu

    Quick menu This chapter depicts Quick menu when users click the right button of the mouse in live screen. Figure 3-5 Quick menu Table 3-5 Quick menu Item and Description Item Description Screen Mode Selecting the partition mode of live screen (Full, 2X2, 3X3, and 4x4). Zoom in Magnifying selected live screen (Zoom out, 2 times, 4 times, and 8 times).

  • Page 20: Ptz Control

    Item Description Log in/Log out Log in/Log out. Shutdown Shuts down or restarts the device (shutdown, restart). 3.3.1 PTZ Control The location of images may be moved to monitor with PTZ ball. PTZ Control menu can be displayed if relevant channel’s protocol is set in DEVICE > Note PTZ in the upper live screen.

  • Page 21: Camera Registration

    In PTZ Control screen, clicking the right button of the mouse displays Quick menu. Figure 3-7 PTZ Control Quick menu Table 3-7 PTZ Control Item and Description in Quick menu Item Description Preset Go Run selected Preset number. Preset Save Save specific positions of the camera, at most 255 settings.
  • Page 22 Table 3-8 Quick Menu > Camera Registration Item and Description Item Description Search the connected IP cameras. Auto Assign Automatically assign the channel windows. Port Show the detected camera port (WAN, PoE). Assign Selecting the channel windows manually. Model Show detected camera model number. Show detected camera IP address.

  • Page 23: Status > System Log

    Item Description Onvif Port Enter web port. Default port is 80. RTSP Port Enter RTSP port. Default port is 554. Mode Select video stream format (RTSP/HTTP). 3.3.3 Status > System log Users can see the system log information in System log tap in Status screen. Figure 3-10 Status >...

  • Page 24: Status > Event

    3.3.4 Status > Event Users can see the real-time event information of the unit in Event tap in Status screen. Figure 3-11 Status > Event in Quick menu Table 3-11 Status > Event Item and Description in Quick menu Item Description Temporary fixing or releasing an event list (toggle).

  • Page 25: Status > Record

    3.3.5 Status > Record Users can see the recording status in Record tap in Status screen. Figure 3-12 Status > Record in Quick menu Table 3-12 Status > Record Item and Description in Quick menu Item Description Record time Marking recorded period. Record list Displaying the record setting status.

  • Page 26: Status > Disk

    3.3.6 Status > Disk Users can see the disk status in Disk tap in Status screen. Figure 3-13 Status > Disk in Quick menu Table 3-13 Status > Disk Item and Description in Quick menu Item Description Disk Info Display disk temperature and S.M.A.R.T information. Rec.

  • Page 27: 4. Setup Menu

    Setup menu This chapter describes Setup menu in the upper side of the screen. Figure 4-1 Setup menu Selecting the menu opens the setting screen. Setup screen is available to click Setup in Quick menu by clicking the right button Note of the mouse.
  • Page 28 Setup menu includes: Table 4-2 Setup menu tree 1 Depth 2 Depth 3 Depth System System F/W Upgrade Time/Date Time/Date Holiday SYSTEM Account User Export/Import Configuration Factory Default Basic(Title, Covert) Basic Audio In/Out CAMERA Advanced Advanced(Video, Stream, VA) Registration Registration Display Display Sequence...

  • Page 29: General Buttons In Setup Menu

    1 Depth 2 Depth 3 Depth Schedule WAN Port Basic PoE Port DVRNS/Dashboard DVRNS/DDNS DDNS E-Mail E-Mail NETWORK Warp Registration Notification Server Notification Server Notification Message General buttons in Setup menu This section depicts General buttons in Setup menu. Figure 4-2 General buttons in Setup menu Table 4-3 Item and Description of General buttons in Setup menu Item Description...

  • Page 30: System

    Item Description Restore Cancel the set value, and reverse it to previous value. Apply Apply the content set. SYSTEM In SYSTEM, basic system environment is set. 4.2.1 System Set and upgrade the basic items of the system. System > System Set the basic items in the System.
  • Page 31 If change video type, system will reboot and all setup go to factory default. Warning System > F/W Upgrade Set the upgraded items of the system. Figure 4-4 SYSTEM > System > F/W Upgrade Table 4-5 SYSTEM > System > F/W Upgrade Item and Description Name Function Current Version...

  • Page 32: Time/Date

    4.2.2 Time/Date Set the date, time, and holidays of the system. Time/Date > Time/Date Set the date, time, and holidays of the system. Figure 4-5 SYSTEM > Time/Date > Time/Date Table 4-6 SYSTEM > Time/Date > Time/Date Item and Description Name Function System Time...
  • Page 33 Time/Date > Holiday Set holidays of the system. Figure 4-6 SYSTEM > Time/Date > Holiday Table 4-7 SYSTEM > Time/Date > Holiday Item and Description Name Function Year Select years to set holidays. Delete selected holidays. Add Holiday Add holidays. List Display added holiday lists.
  • Page 34 Clicking Add Holiday displays holiday addition screen like below. Figure 4-7 SYSTEM > Time/Date > Holiday > Add Holiday Table 4-8 SYSTEM > Time/Date > Holiday > Add Holiday Item and Description Name Function Name Enter the holiday name. Date Display chosen date.

  • Page 35: Account > User

    4.2.3 Account > User Set the user’s account of the system. Figure 4-8 SYSTEM > Account > User Table 4-9 SYSTEM > Account > User Item and Description Name Function Add Group Add users’ group. Add User Add users. Group List Display a total group list.
  • Page 36 Press Add Group button, then Add Group screen displays. Figure 4-9 SYSTEM > Account > User > Add Group Table 4-10 SYSTEM > Account > User > Add Group Item and Description Name Function Name Enter the group name. PERMISSION Select items to permit access.

  • Page 37: Configuration (Config)

    4.2.4 Configuration (Config) Set Export/Import and Factory Default of the system. Config > Export/Import Through a save medium, users may apply information set to other devices identically. Figure 4-11 SYSTEM > Config > Export/Import Table 4-12 SYSTEM > Config > Export/Import Item and Description Name Function Device...
  • Page 38 Config > Factory Default Default the setting value of the device. Figure 4-12 SYSTEM > Config > Factory Default Table 4-13 SYSTEM > Config > Factory Default Item and Description Name Function Select All Select/deselect all items to be defaulted. /Unselect All Default Item Select/deselect related items to be defaulted.

  • Page 39: Camera

    CAMERA In CAMERA section, set the camera to be connected with the device. 4.3.1 Basic Set the fundamental functions of camera and audio. Basic > Basic Set the basic items of camera by channels. Figure 4-13 CAMERA > Basic > Basic Table 4-14 CAMERA >...
  • Page 40 Press Copy Covert Setup button, then Copy Covert Setup screen displays. Figure 4-14 CAMERA > Basic > Basic > Copy Covert Setup Table 4-15 CAMERA > Basic > Basic > Copy Covert Setup Item and Description Name Function From Select a channel converted setting. Select a channel to be copied.
  • Page 41 Basic > Audio In/out How to set audio of camera across channels Figure 4-15 CAMERA >Basic > Audio In/Out Table 4-16 CAMERA > Basic > Audio In/Out Item and Description Name Function Display channels of audio Select/deselect whether to use audio. Assign Select channels to be assigned audio.

  • Page 42: Advanced

    4.3.2 Advanced As advanced function of camera, users can set privacy. Figure 4-16 CAMERA > Advanced Table 4-17 CAMERA > Advanced Item and Description Name Function Display channels. Video Setup camera image such as Color, White Balance, WDR, AE and etc. Stream Setup camera stream such as Resolution, Framerate, Bitrate and etc.

  • Page 43: Device

    DEVICE In DEVICE, set the device to connect with the unit. 4.4.1 Display Set matters related to a display device and live screen. Display > Display Set the display device. Figure 4-17 DEVICE > Display > Display Table 4-18 DEVICE > Display > Display Item and Description Name Function HDMI/VGA...
  • Page 44 Display > OSD Set the OSD of the display device. Figure 4-18 DEVICE > Display > OSD Table 4-19 DEVICE > Display > OSD Item and Description Name Function Camera Name Select the way to display camera in live screen (Off, CH+Title, CH). Live Bar Select the way to display the live bar (Always On, Auto Hide).
  • Page 45 Display > Sequence How to set the play sequence of live screen Figure 4-19 DEVICE > Display > Sequence Table 4-20 DEVICE > Display > Sequence Item and Description Name Function Quad Sequence Set to convert automatically as 4-partition screen on the time basis. Division Select screen partition mode to be marked in the below table (All, Full, and Quad).
  • Page 46 Clicking Add Sequence displays Add Sequence screen. Figure 4-20 DEVICE > Display > Sequence > Add Sequence Table 4-21 DEVICE > Display > Sequence > Add Sequence Item and Description Name Function Dwell Time Select time to play (3 sec, 5 sec, 10 sec, 15 sec, and 30 sec). Division Select the partition screen to play (Full, Quad).

  • Page 47: Disk > Setup

    4.4.2 Disk > Setup Disk > Setup The way to set the disk Figure 4-21 DEVICE > Disk > Setup Table 4-22 DEVICE > Disk > Setup Item and Description Name Function Refresh disk information. Disk Info Display the basic disk information in disc list. ...
  • Page 48 Name Function Overwrite Select/deselect to rewrite new data on the existing disk in case of Recording insufficient saving space remained Auto Delete Select/deselect to use the function to delete saved data automatically (1- 365 days). Disk > iSCSI The way to set the iSCSI .
  • Page 49 iSCSI register screen. Name Function Target Address Input IP address and ports for iSCSI Target Port HTTP Port Discover Click to search iSCSI storage. Enable CHAP Select Enable CHAP if iSCSI use CHAP authentication. User Name Enter user name of CHAP authentication. Password Enter password of CHAP authentication.

  • Page 50: Ptz > Ptz

    4.4.3 PTZ > PTZ To use PTZ Function of the device, users need to match ID, protocol, and speed with each camera. Figure 4-23 DEVICE > PTZ > PTZ Table 4-24 DEVICE > PTZ > PTZ Item and Description Name Function Copy PTZ Setup Apply setting history to all or selected channels in the same way.

  • Page 51: Serial Device > Serial Device

    4.4.4 Serial Device > Serial Device Users need to set Serial Device to connect PTZ camera, USB device with the unit. Figure 4-24 DEVICE > Serial Device > Serial Device Table 4-25 DEVICE > Serial Device > Serial Device Item and Description Name Function USB (to Serial)

  • Page 52: Text > Text

    4.4.5 Text > Text Set the input device such as ATM or POS, etc. Figure 4-25 DEVICE > Text > Text Table 4-26 DEVICE > TEXT > TEXT Item and Description Name Function Select/deselect whether to use text function. Select camera channels to connect with the text input device. Protocol Select protocol to correspond with the text input device.
  • Page 53 Press Copy to Text Setup button, then Copy to Text Setup screen displays. Figure 4-26 DEVICE > Text > Text > Copy to Text Setup Table 4-27 DEVICE > TEXT > Text > Copy to Text Setup Item and Description Name Function From...

  • Page 54: Record

    RECORD In RECORD, users may set matters related to recording. 4.5.1 Schedule > Schedule Recording types can be set across channels and time. Figure 4-27 RECORD > Schedule > Schedule Table 4-28 RECORD > Schedule > Schedule Item and Description Name Function Select channels to set schedules.
  • Page 55 The function of each scheduling type involves: Table 4-29 Function of each scheduling type Color Scheduling type Function None Do not record. Continuous Record on consecutive mode when time set. Motion Record on event recording mode when motion sensitive event occurs. Alarm Record on event recording mode when alarm occurs.
  • Page 56 7 Copy Schedule Setup screen displays. 8 Select channels to be copied. 9 Select channels to apply copied content. 10 Copy the schedule by pressing Apply. 11 Press Save to save the schedule. IER-25Nxxx Seite 52...

  • Page 57: Stream

    4.5.2 Stream To set the image resolution when event occurs across channels or general recording is in process. Stream > Main Stream To set the image quality and resolution of Main Stream Figure 4-28 RECORD > Stream > Main Stream Table 4-30 RECORD >...
  • Page 58 Clicking Copy Stream Setup opens Copy Stream Setup. Figure 4-29 RECORD > Stream > Main Stream > Copy Stream Setup Table 4-31 RECORD > Stream > Main Stream > Copy Stream Setup Item and Description Name Function From Select the channel set. Select the device to be copied.
  • Page 59 Stream > Sub Stream To set the image quality and resolution of Sub Stream Figure 4-30 RECORD > Stream > Sub Stream Table 4-32 RECORD > Stream > Sub Stream Item and Description Name Function Display channels. Resolution Show camera second stream setup status. Framerate Bitrate Pre-Alarm...
  • Page 60 Stream > Panic How to set immediate recording Figure 4-31 RECORD > Stream > Panic Table 4-33 RECORD > Stream > Panic Item and Description Name Function Panic Record Select/deselect to use immediate recording function. Display channels. Resolution Panic recording stream follows the Event stream. Frame rate Quality Dwell Time...

  • Page 61: Event

    EVENT In EVENT, users may set each event of the device. 4.6.1 System/Disk To set the system and disk event System/Disk > System To set the system event of the device Figure 4-32 Event > System/Disk > System Table 4-34 Event > System/Disk > System Item and Description Name Function System Restart...
  • Page 62 System/Disk > Disk To set disk event Figure 4-33 Event > System/Disk > Disk Table 4-35 Event > System/Disk > Disk Item and Description Name Function Disk Unplugged Select/deselect whether to use disk unplugged event Beep Select/deselect whether to use buzzer sound in case of event. Alarm out Select to end alarm time (null, Relay1-Keep, 5 sec, 10 sec, 20 sec, 30 sec, 1 min, 10 min, 30 min, and 1 hour).

  • Page 63: Alarm In

    4.6.2 Alarm In To set sensor alarms and schedule Alarm In > Setup To set sensor alarms Figure 4-34 Event > Alarm In > Setup Table 4-36 Event > Alarm In > Setup Item and Description Name Function Sensor Display sensor numbers. Select/deselect whether to use alarm in the sensor.
  • Page 64 Placing your mouse on Alarm, Group Rec, Noti., Preset and clicking editing Icon ( ) in right corner displays Event: Alarm screen. Figure 4-35 Event > Alarm In > Setup > Event: Alarm Table 4-37 Event > Alarm In > Setup > Event: Alarm Item and Description Name Function Alarm-out...
  • Page 65 Alarm In > Schedule To schedule recording time when alarm occurs across device sensors Figure 4-36 Event > Alarm In > Schedule Table 4-38 Event > Alarm In > Schedule Item and Description Name Function Sensor Select the sensor to set the schedule. Schedule Type Select the types of schedules.

  • Page 66: Motion

    4.6.3 Motion To set and schedule motions across channels Motion > Setup To set motions across channels Figure 4-37 Event > Motion > Setup Table 4-39 Event > Motion > Setup Item and Description Name Function Display channels. Select/deselect whether to use motion function in the channel. Area Display the motion area.
  • Page 67 Motion > Schedule To schedule record time when the motion sensor detects across channels Figure 4-38 Event > Motion > Schedule Table 4-40 Event > Motion > Schedule Item and Description Name Function Select channels to set schedules. Schedule Type Select the types of schedules.

  • Page 68: Video Loss > Setup

    4.6.4 Video Loss > Setup To set Video Loss across channels Figure 4-39 Event > Video Loss > Setup Table 4-41 Event > Video Loss > Setup Item and Description Name Function Display channels. Select/deselect whether to use Video Loss in the channel. Beep Select use time of buzzer sound (null, 5 sec, 10 sec, 20 sec, 30 sec, 1 min, 10 min, 30 min, and 1 hour).

  • Page 69: Notification

    4.6.5 Notification To set and schedule periodical alarms Notification > Periodic To set periodical alarms Figure 4-40 EVENT > Notification > Periodic Table 4-42 EVENT > Notification > Periodic Item and Description Name Function Periodic Select/deselect whether to use periodical alarms Notification Summary Send the save or event information.
  • Page 70 Notification > Schedule To schedule periodical alarms Figure 4-41 EVENT > Notification > Schedule Table 4-43 EVENT > Notification > Schedule Item and Description Name Function Notification Type Select the types of notification. Selection (None, E-mail, Push(Mobile), E-mail+Push, FTP, FTP+E-mail, FTP+Push, FTP+E-mail+Push) Schedule Table Display the schedule users set.

  • Page 71: Network

    NETWORK In NETWORK, users may set the network environment. 4.7.1 Basic Basic > WAN Port To set the network WAN port Figure 4-42 NETWORK > Basic > WAN Port Table 4-44 NETWORK > Basic > WAN Port Item and Description Name Function Check if you use static IP.
  • Page 72 Basic > PoE Ports To set the network PoE Ports Figure 4-43 NETWORK > Basic > PoE Ports Table 4-45 NETWORK > Basic > PoE Ports Item and Description Name Function DHCP Server Select whether to enable DHCP server. DHCP (Dynamic) Select whether to use DHCP (Dynamic). IP Address Enter the each information properly.

  • Page 73: Dvrns/Ddns

    4.7.2 DVRNS/DDNS To set DVRNS/DDNS DVRNS/DDNS > DVRNS/Dashboard To register DVRNS/Dashboard account Figure 4-44 NETWORK > DVRNS/DDNS > DVRNS/Dashboard Table 4-46 NETWORK > DVRNS/DDNS > DVRNS/Dashboard Item and Description Name Function DVRNS Register DVRNS account  ID: Enter DVRNS ID (default: MAC address of the unit) ...
  • Page 74 DVRNS/DDNS > DDNS To set DDNS site for remote users to access in networking Figure 4-45 NETWORK > DVRNS/DDNS > DDNS Table 4-47 NETWORK > DVRNS/DDNS > DDNS Item and Description Name Function DDNS Site Select DDNS site Host Name Enter the host name.

  • Page 75: E-Mail

    4.7.3 E-Mail To set email server to send email on the occasion of event Figure 4-46 NETWORK > E-Mail > E-Mail Table 4-48 NETWORK > E-Mail > E-Mail Item and Description Name Function Server Type Select SMTP server.  gmail.com ...
  • Page 76 4.7.4 Setup FTP server to send video to FTP server. The file format is AVI file. Figure 4-47 NETWORK > FTP > FTP Table 4-49 NETWORK > FTP > FTP Name Function FTP Server Select whether to use FTP. Address(URL)/Port Enter server address and port. ID, Password Enter ID &...

  • Page 77: Warp

    4.7.5 Warp Register the recorder to monitor and control remotely. Figure 4-48 NETWORK > Warp > Registration Table 4-50 NETWORK > Warp > Registration Name Function Use Warp Select whether to enable Warp. Delete registered recorder. Add Recorder Register the recorder to monitor and control. IER-25Nxxx Seite 73...
  • Page 78 4.7.6 User can connect recorder from mobile app using QR code scan. Figure 4-49 NETWORK > P2P > P2P Table 4-51 NETWORK > P2P > P2P Name Function P2P Registration Click button to check up registration status. P2P QR Code Scan QR code using mobile app to connect recorder.

  • Page 79: Notification Server

    4.7.7 Notification Server Notification Server > Notification Server Figure 4-50 NETWORK > Notification Server > Notification Server Table 4-52 NETWORK > Notification Server > Notification Server Name Function Notification Server Check Enable to use Notification function. Type Select protocol type (TCP/UDP). IP/Port Enter server address and port.
  • Page 80 Notification Server > Notification Message Figure 4-51 NETWORK > Notification Server > Notification Message Table 4-53 NETWORK > Notification Server > Notification Message Name Function Deleted registered notification message. Notification message edit window pop-up. Camera channel. Event Display event type as Motion, Alarm, Video Loss. Message Display notification message.

  • Page 81: Search/Play

    Search/Play This chapter describes Live Launcher search and play menu in the below screen bar. Figure 5-1 Live Launcher Search, Play menu Table 5-1 Item and Description of Live Launcher Search, Play menu Item Description Search recording data (time, event, thumbnail, smart search, text and VCA).
  • Page 82 Figure 5-3 Search: Event Table 5-3 Search: Event Item and Description Item Description Select CH Select channels to search Select All Select/deselect all channels. /Unselect All Start Setting starting time to search Setting ending time to search EVENT TYPE Selecting the types of event (immediate recording, motion, Alarm-In, Video Loss, and bookmark).
  • Page 83 Figure 5-4 Search: Thumbnail Table 5-4 Search: Thumbnail Item and Description Item Description Calendar Selecting dates to search Selecting channels to search Time Selecting time to search Interval Setting time interval for searching images Time Playing or stopping videos searched Lapse/Pause Cancel Ending search screen...
  • Page 84 Item Description Start Setting starting time to search. Setting ending time to search. Figure 5-6 Search: Text Table 5-6 Search: Text Item and Description Item Description Select CH Select channels to search Select All Select/deselect all channels. /Unselect All Start Setting starting time to search Setting ending time to search Keyword...
  • Page 85 Figure 5-7 Search: VCA Table 5-7 Search: VCA Item and Description Item Description Select CH Selecting channels to search Start, End Set start time and end time. Event Type Selecting VCA event type. Search Search VCA event. Play Playback selected event. IER-25Nxxx Seite 81...

  • Page 86: Playback

    Playback To play recorded data Figure 5-8 Playback Launcher Table 5-8 Playback Launcher Item and Description Item Description Display present play status. Date and Time Display date and time of playing videos. Go to first section of the video. Play fast backward (2~64x). Decrease speed under playback mode (1/2~1/8x), Backward step under pause mode Play and pause the videos (toggle).

  • Page 87: Playback Quick Menu

    Name Function Open manual backup menu. Open calendar. Show time bar by single channel, 4channels or all channels. Show time line by 1hour or 24hours (toggle). 5.2.2 Playback Quick menu Click mouse right button to open quick menu in the playback mode. Figure 5-9 Playback Quick menu Table 5-9 Playback Quick menu Item...

  • Page 88: Webviewer

    Webviewer This chapter describes webviewer for monitoring videos through a PC in remote mode. How to monitor with webviewer Table 6-1 System Requirement for Webviewer Item Recommended Minimum MicrosoftⓇ WindowsⓇ 10 x86(64bit) MicrosoftⓇ WindowsⓇ XP Home SP3 (Home Premium, Professional, Ultimate) MicrosoftⓇ...
  • Page 89 1 Click Viewer. 2 When Java download screen opens, download and install JAVA. 3 Live images may be monitored. In case of selecting Viewer (Chrome) After click Viewer, .jnlp file can be downloaded. Click Keep button. IER-25Nxxx Seite 85...
  • Page 90 Click webviewer_chrome.jnlp. When Java download screen opens, download and install JAVA. Live images may be monitored. In case of selecting Setup Users can set the menu in similar ways with NVR connected monitor. Figure 6-1 Setup screen IER-25Nxxx Seite 86...

  • Page 91: Appendix

    Appendix Installing System Keyboard To setup the keyboard controllers, the user needs to setup the network, passwords and perform special tasks such as Uploading and Downloading programmed data from the dome cameras. To enter the Keyboard menu, press and hold CTRL and press MENU expressed as CTRL + MENU in the manual. You will see the following menu.
  • Page 92 Set USB On in the keyboard menu. Menu Status Configuration Client Keyboard : Only USB Port(The other ports and slave keyboards are not supported) General Keyboard : Dome1/Dome2/RS232(The USB port is not supported) If Keyboard Controller power is disconnected and reconnected, you must also Note disconnect and reconnect the USB either from the Keyboard Controller or DVR/NVR side...
  • Page 93 Recorder Setup Set serial port of recorder. Device > Serial Device In case of USB Connection Name Baudrate Parity Data Stop bit Type 9600 None Keyboard In case of RS-485 Connection Name Baudrate Parity Data Stop bit Type RS-485 9600 None Keyboard KBD Controller Keys in Live mode...
  • Page 94 Press again to exit zoom mode. Digital Zoom Control Digital zoom in/out control. From Live Display, click the FRE button to activate the Freeze Freeze Mode. When in the Live Mode, press the SEQ button will display another Auto Sequence Mode full live channel sequentially.
  • Page 95 CTRL + Joystick : In a programming mode (Preset, Pattern, Scan, Privacy….) the joystick operates as if in the normal control mode. While pressing and holding down Control the CTRL key, all movements of the joystick will start recording when in the pattern programming menu Cancels current inputs.

  • Page 96: Products Specification

    Products Specification Model 16Ch VIDEO Video Input 4 IP 8 IP 16 IP Video Input Up to 5MP Up to 5MPx4ch+3MPx4ch Up to 5MPx4ch+3MPx12ch Resolution Compression H.264 H.264 H.264 Display Output 1 VGA, 1 HDMI 1 VGA, 1 HDMI 1 VGA, 1 HDMI 1920x1080, 1280x720, 1920x1080, 1280x720, 1920x1080, 1280x720,...
  • Page 97 POS/ATM POS/ATM POS/ATM Text In (VSSI-Pro, ASCII, (VSSI-Pro, ASCII, (VSSI-Pro, ASCII, Network, ) Network, ) Network, ) Mouse, IR Remote Mouse, IR Remote Control, Mouse, IR Remote Control, User Interface Control, USB/RS485 USB/RS485 Keyboard USB/RS485 Keyboard Keyboard NETWORK 1 RJ45 10/100/1000 1 RJ45 10/100/1000 Base- 1 RJ45 10/100/1000 Base-T Base-T...
  • Page 98 VIDEOR E. Hartig GmbH Exclusive distribution through special- ised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
