IDW G-10 Instruction Manual

G-series upright cooler.
Hide thumbs

Advertisement

G-10f/GCG-10f
UPRIGHT COOLER
Manual is for the following models:
G-10
G-10-F31N*
GCG-10
GCG-10-F31N*
GCG-10-F231N*
GCG-10-FA31N*
*G,I,M,7,J plug
Instruction Manual

Advertisement

   Related Manuals for IDW G-10

   Summary of Contents for IDW G-10

  • Page 1 G-10f/GCG-10f UPRIGHT COOLER Manual is for the following models: G-10 G-10-F31N* GCG-10 GCG-10-F31N* GCG-10-F231N* GCG-10-FA31N* *G,I,M,7,J plug Instruction Manual...
  • Page 2 Manual is for the following models: G-10 G-10-F31N* GCG-10 GCG-10-F31N* GCG-10-F231N* GCG-10-FA31N* *G,I,M,7,J plug Instruction Manual G-10f GCG-10f...
  • Page 3 G-10f/GCG-10f FOR YOUR FUTURE REFERENCE • This easy-to-use manual will guide you in getting the best use of your cooler. • Remember to record the model number and the serial number. This information can be found on the inside of your cooler. •...
  • Page 4: Parts & Identification

    Return Pipe Switching Power Supply Door Lock Foam Cabinet Electric Box Cover Left Bottom Hinge Top Hinge Power Cord Right Bottom Hinge Evaporator Compressor Bottom Hinge Axle Connecting Tube for Return Pipe Door Limiter Innovative DisplayWorks offi ce 909.447.8254 • fax 909.305.8756 • toll free 877.307.2665 • www.idw.global Last Revised: February 22, 2016 8:34 AM...
  • Page 5: Safety Precautions

    G-10f/GCG-10f SAFETY PRECAUTIONS When using this appliance, always follow the basic safety precautions: 1. This appliance is intended for commercial only or similar use. 2. DO NOT use the appliance outside. For indoor use only 3. DO NOT use jet/pressure washers to clean this appliance. 4.
  • Page 6: Features

    Instruction Manual FEATURES • Designed with an elegant shape and quick refrigeration speed, this commercial-grade product is an ideal choice for shopping malls, supermarkets, hotels, etc. • Transparent glass doors are built with hollow, toughened glass that provides a high level of heat insulation. Clear doors allow for high product visibility.
  • Page 7 • Remove all packaging materials before using cooler. This includes: foam pedestal, adhesive tape (used to fix accessories) and protective gaskets. • Inspect cooler for concealed damage. Immediately file a claim with the freight carrier if there is damage. IDW is not responsible for damage incurred during shipping. • For proper operation, place the cooler on a dry, level surface. • Clean the interior surface with a soft cloth and lukewarm water before operation. • Keep cooler in an upright position for 30 minutes prior to use. • IDW requires that a sole use circuit be dedicated for the unit. Failure to do so voids warranty. WARNING: Do not use extension cords. WARNING: Compressor warranties are void if compressor burns out due to low voltage. WARNING: Power supply cord should not be removed or altered in any way. Leveling • Set unit in its final location, making certain there is adequate ventilation in the room. WARNING: Warranty is void if ventilation is insufficient. • Proper leveling of the G-10f/GCG-10f cooler is critical to it operating correctly. Condensation removal and door operation will be affected by leveling. < The cooler should be leveled front to back and side to side with a level.
  • Page 8: Replacing The Interior Light

    Instruction Manual REPLACING THE INTERIOR LIGHT Press two sides of plastic cover by the fingers and remove it. Disconnect the lights. Unscrew (3) screws using a Phillip’s screwdriver. Remove LED light strand. To install LED lights follow the above directions in reverse order.
  • Page 9: Replacing The Door Led Lights

    G-10f/GCG-10f REPLACING THE DOOR LED LIGHTS Unplug the cooler. Disconnect top Remove light strand. plastic cover. Disconnect Unscrew light strand. middle light strand. Remove entire light strand. To install LED lights follow the above instructions in reverse order. Notes: If there are any malfunctions with the main control panel of LED lights, please contact a professional for replacement. SETTING UP SPACER & POWER CORD HOLDERS The G-10f/GCG-10f is supplied with one set (2 pieces) of Spacers to hold the extra length of Power Cord Take out the two Spacers and screws supplied in the Accessory Pack shipped with the Cooler. Use a Phillips screwdriver to secure the two Spacers onto the rear of the cooler. Innovative DisplayWorks...
  • Page 10: Startup, Operation & Temperature Adjustment

    Instruction Manual STARTUP, OPERATION AND TEMPERATURE ADJUSTMENT Operation • Prior to stocking cooler with product, it should Lit Door “Logo” be operated empty for half an hour. Switch Operation • For GCG-10f Temperature Adjustment coolers only. The light switch • G-10f/GCG-10f performance testing position of the located at the bottom thermostat is around 4~6. left hand side on the rear of the cabinet is the ON/OFF switch for the Lit logo located on the door of cooler. REPAIR AND MAINTENANCE FOR REFRIGERATION DRAWER * A CERTIFIED TECHNICIAN IS REQUIRED TO REPAIR ALL REFRIGERATION COMPONENTS FOR WARRANTY PURPOSES.
  • Page 11: Condenser Maintenance

    G-10f/GCG-10f CONDENSER MAINTENANCE It is essential to keep the condenser coils clean and free of dust and debris at all times. It is required to periodically clean the condenser coils with a soft bristle brush or vacuum-cleaner to properly maintain the refrigeration system. Failure to clean the condenser at regular intervals may cause failure of the refrigeration system and could void the warranty. Remove the rubber cap from the front grill. Using a Phillips screwdriver, remove the three screws as shown. The front plastic grill can now be removed by pulling it up. Using plastic bristle brush, carefully clean the coil being aware that fins can bend or be damaged if too much force is used - shown left. Replace grill and utilize the Phillips screwdriver to tighten the screws into place, replace the rubber caps. MAINTENANCE - Cleaning Shutdown Questions and Answers Cleaning and Maintenance Unplug the cooler before cleaning. Use a soft cloth or sponge with water or soap (non-corrosive mild detergent), while cleaning. After cleaning, wipe the cooler using dry cloth to keep the cooler from rusting. Do not spray water on the cooler, and do not use hard or steel brushes to clean the cooler. Do not use organic solvents, boiling water, washing powder or acid while cleaning. If the cooler’s power will be off for a long period of time, unplug it, clean as instructed above, and keep door open until dry. Innovative DisplayWorks...
  • Page 12: Door Reversal

    Instruction Manual DOOR REVERSAL (For G-10f Coolers Only) Delete clause 1 in the left and adjust the rest clause Seiral No and content as below: 1 Remove the front grill, disconnect the terminals and then hide reversible   d oor   e xchange   the terminals in the door’s reserved hole. 1.Remove the front grill, disconnect the terminals and then hide the terminals in the door's reserved hole.
  • Page 13 wiring is stretching out from the bottom G-10f/GCG-10f of the door left 7. Remove the hinge axis from the right bottom hinge, inert it into the left bottom hinge. DOOR REVERSAL Cont. (For G-10f Coolers Only) 8.Remove door limit from right hinge into corresponding holes on left hinge  ...
  • Page 14: Troubleshooting

    Instruction Manual TROUBLESHOOTING The following are not Malfunctions: Issues Solutions Liquid fl owing noise within cooler This liquid is the sound of the cooling agent fl owing through the pipes. Refrigeration system is shutdown for This refrigerator has a strong level of heat preservation and can main- longer periods of time while temperature tain a relatively ambient temperature.
  • Page 15: G-10f Circuit Diagram

    G-10f/GCG-10f G-10f CIRCUIT DIAGRAM A: Evaporator Fan B: Transformer for all Lights F: Condenser Fan C1: On/Off Switch for Interior Light G: Overload D1: Interior Top LED Light H: Compressor D2: Door Side LED Light I: Compressor Start Capacitor E: Thermostat J: Relay SPECIFICATIONS MODEL VOLUME (L) RATED CLIMATE CLASS RATED LAMP INPUT REFRIGERANT VOLTAGE CURRENT POWER G-10, G- 10-F31N* GCG-10, 220-240V/50Hz 1.7A R290/100g GCG-10F31N*, GCG-10-F231N*, GCG-10-FA31N* *G,I,M,7,J plug Innovative DisplayWorks...
  • Page 16: G-10f Electrical Wiring Diagram

    Instruction Manual G-10f ELECTRICAL WIRING DIAGRAM CONDENSER UNIT SOCKET TRANSFORMER START CAPACITOR...
  • Page 17: Gcg-10f Circuit Diagram

    G-10f/GCG-10f GCG-10f CIRCUIT DIAGRAM A: Evaporator Fan E: Thermostat B: Transformer for all Lights F: Condenser Fan C1: On/Off Switch for Interior Light G: Overload C2: On/Off Switch for Lit Door Logo Light H: Compressor D1: Interior Top LED Light I: Start Capacitor D2: Door Side LED Light J: Relay D3: Logo LED Light Innovative DisplayWorks...
  • Page 18: Gcg-10f Electrical Wiring Diagram

    Instruction Manual GCG-10f ELECTRICAL WIRING DIAGRAM CONDENSER UNIT SOCKET TRANSFORMER START CAPACITOR...
  • Page 19 G-10f/GCG-10f Innovative DisplayWorks...
  • Page 20 Innovative DisplayWorks, Inc. To locate the distributor in your area go to: http://www.idw.global/contact/#distributors...
