Feature
100/1000 BASE-X
Fiber Port
USB Port
RJ-45 LAN Port
(10/100/1000
BASE-T)
Transmit LEDs
Cable Test/Wire
Mapping Input
(WMAP)
Power Button
and LED
Charging Port
Microphone
Camera and
Flash
Micro SD Card
Slot
Description
Connects to an SFP adapter and
fiber cable
Connects to any USB device
Connects to the network using
an Ethernet cable
Charges the unit if PoE is
available
Green LED lit: Linked
Yellow LED flashing: Activity
Used for patch cable testing
Glows green when the unit is
powered on
Glows red when the unit is
charging
Connects to AC adapter for
charging
Allows voice input
Captures images and acts as a
flashlight
Used for removable storage
expansion
16
Physical Features
